- Page 1 DVP1013 PORTABLE LCD DVD PLAYER USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN...
- Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Warranty Service Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
- Page 3 In-Home service call fee. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment other than as stated in this warranty and outlined above.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Safety Information Safety Precautions Some Do‟s and Don‟ts On The Safe Use Of Equipment USB Usage Precautions Introduction Features Accessory List Supported Disc Formats Disc Care Panel and Remote Operation Panel Controls Side Panel Overview Remote Control Battery Installation Basic Operation Using the AC Adaptor... -
Page 5: Safety Information
SAFETY INFORMATION Safety Precautions To enjoy the best performance and become familiar with the product features, please read this manual carefully before operation. Please read through the manual carefully before using and retain for future use. ATTENTION: TO AVOID RISK OF FIRE AND ELECTRIC SHOCK, DO NOT OPEN THE COVER OF THE UNIT. - Page 6 SAFETY INFORMATION 4. Ventilation – The product should be used in a well-ventilated area to avoid overheating. The product should not be placed on the bed or sofa. 5. Servicing – Do not attempt to service this product yourself as opening or removing the cover may expose you to dangerous voltage or other hazards.
- Page 7 SAFETY INFORMATION Some Do’s and Don’ts on the Safe Use of Equipment This equipment has been designed and manufactured to meet international safety standards. However, care must be taken to ensure personal safety and optimum product performance. DO read the operating instructions before you attempt to use the equipment. DO ensure that all electrical connections (including the mains plug, extension leads and inter- connections between the pieces of equipment) are properly made and in accordance with the manufacturer’s instructions.
-
Page 8: Usb Usage Precautions
SAFETY INFORMATION USB Usage Precautions Never turn the unit off or disconnect a USB Storage Device (Flash Drive) when it is being accessed. Doing so could damage the unit and the connected USB storage device. Do not use a device that has a maximum current consumption of 100 mA or more. ... -
Page 9: Introduction
INTRODUCTION Thank you for choosing TEAC. Please retain this user manual for future reference. If any assistance is needed, please contact our Customer Support Hotline at 1300 553 315. Features High resolution colour TFT LCD full screen display Super electronic shock resistance (3 seconds for DVD, 10 seconds for CD/VCD... -
Page 10: Supported Disc Formats
INTRODUCTION Supported Disc Formats Disc Type Content Size Audio + Video 12cm/8cm Video DVD Audio + Video 12cm/8cm DVDR/RW Audio + Video 12cm/8cm Video CD/ Super VCD Audio 12cm/8cm Audio CD Video (Photo) 12cm/8cm JPEG Video (Photo) 12cm/8cm Picture CD Audio + Video 12cm/8cm CDR/RW... -
Page 11: Panel And Remote Operation
PANEL AND REMOTE OPERATION Panel Controls STANDBY Button Function Press to turns unit on or back to Standby STANDBY Press to switch between AV IN Mode MODE Press to cycle through the following modes: DVD>USB>SD DVD/USB/SD Play/pause playback Press to stop playback ... -
Page 12: Side Panel Overview
PANEL AND REMOTE OPERATION Press to switch the audio track AUDIO LEFT navigation button / During play back, fast rewind (scan backwards) on the current track UP navigation button / During playback, go to a previous track/chapter In Menu Setup, return to the previous page RIGHT navigation button /... -
Page 13: Remote Control
ANGL E MODE GOTO ZOOM PROGAM DVP1013 MODE: Switch between TV Mode and DVD Mode ANGLE/PROGRAM: While playback is stopped, press to enter the PROGRAM function. During DVD playback, press to select from available camera angles. (Depends on availability on disc) GOTO: Press to input a specific title/chapter on the DVD to jump to. -
Page 14: Battery Installation
PANEL AND REMOTE OPERATION TITLE: Press to return to disc title menu in DVD mode RETURN: Return to previous menu. CD RIPPING/SUBTITLE: In DVD Mode, press to select from available subtitles. During audio CD playback, press to enter CD Ripping Mode. REPEAT: Press repeatedly to cycle through available repeat modes A-B: Use to loop a specific section of the track. -
Page 15: Basic Operation
BASIC OPERATION Using the AC Adaptor Connect the unit to a wall power outlet using the provided AC adaptor. CAUTION: Turn off the unit before unplugging the AC adaptor to avoid damaging the unit. Make sure the power supply is turned off before making or changing any cable connections. Insert the AC adaptor into the DC IN jack on the unit. -
Page 16: External System Connection
BASIC OPERATION External System Connection Connect to external output devices like TVs, amplifiers or headphones. Ensure that the settings Connecting to TV and Stereo Amplifier Mini-plug: Connect to the AUDIO/VIDEO OUT jack of the portable DVD player. Yellow plug: Connect to the VIDEO IN jack of the TV. ... -
Page 17: Usb/Card Multimedia Playback
BASIC OPERATION If there is no disc loaded in the unit, it will auto-detect the memory card and start to read and playback compatible media files. Otherwise, press the DVD/USB/SD button to switch to CARD input. NOTE: If another USB stick/memory card is already inserted, the unit will not auto-detect the second USB/CARD memory device. -
Page 18: Cd Ripping
BASIC OPERATION Stop: Press the button to stop playback. Previous/Next track: Tap the / buttons for previous/next file. direction buttons: Rotate the current picture. Note: Some picture CDs may have design limitations that make this feature unavailable. ZOOM: Press the ZOOM button on the remote control. 100% will display on the screen. Press /... - Page 19 BASIC OPERATION RIP CD - UNKNOWN ALBUM Ripping Music CDs ENCODER OPTIONS SPEED Start in DVD Mode. BITRATE 128KBPS TRACKS START FILE OPTIONS CRATE ID3 TAG QUIT Load an Audio CD. CRATE PLAYLIST STRAGE OPTIONS STRAGE Connect a compatible USB flash drive. Press the CD RIPPING button to access RIP CD - UNKNOWN ALBUM the conversion function.
-
Page 20: Dvd Mode Setup
BASIC OPERATION DVD Mode Setup Press the SETUP button to show this menu. Adjust system and playback settings for this unit using the Setup Menu. The Setup Menu is divided into tabs showing submenus with options for different features. General Setup SYSTEM SETUP SYSTEM SETUP power resume... - Page 21 BASIC OPERATION K EY Setup LANGUAGE SETUP L ANGUAGE SETUP Option Description/Settings Set the KEY level. K EY VIDEO Setup VIDEOSETUP Brightness Contrast Saturion Sharpness Option Option Description/Settings Description/Settings Set the brightness level. Set the brightness level. Brightness Brightness Set the contrast level. Set the contrast level.
- Page 22 BASIC OPERATION Digital Setup DIGITAL SETUP Dual Mono Option Description/Settings STEREO: The player outputs the left-channel audio and right-channel audio via the FL and and FR speaker respectively. MONO L: The player outputs the left-channel audio only via both the FL and FR speaker MONO R: The player outputs the right-channel audio only via both the FL and FR speaker.
-
Page 23: Reference
REFERENCE Troubleshooting If you encounter problems using the DVD player, please refer to the table below for problem- solving measures. If problems persist, please contact the Customer Support Hotline . Turn off the DVD player immediately if you suspect a malfunction. Unplug the power plug and check whether the DVD player is unusually warm and if it is emitting smoke. -
Page 24: Specifications
REFERENCE Specifications Item Specification AC100~240V Input DC12V/1.5A Output Power supply 10W Power Consumption DVD player (supported formats: DVDR/RW, CDR/RW, VCD, Input Audio CD, JPEG) AV 3.5mm input jack USB 2.0 (supports USB drive max 32 SD/MMC Car d (supports up to 32 GB) USB 2.0 (supports USB drive max 32 Output SD/MMC Card (supports up... - Page 25 In the event of a product failure within the warranty period, please call the TEAC Warranty Service Hotline 1300 553 315 Between Monday to Friday - 8.30AM to 5PM AEST *Please have your purchase receipt and the product’s serial number ready For other enquiries and support please visit www.teac.com.au...
