Storage
The product can be stored in the off-season, we recommend using the original
(or appropriately sized) packaging. It is important to keep it in a safe, dry location.
Transportation
It is recommended to transport the product in the original packaging that is
appropriately secured. Avoid excessive vibrations.

Plug replacement

This appliance is supplied with a BS1363 pin plug fitted with a 10 Amp fuse. Should
the fuse require replacement, it must be replaced with a fuse rated at 10 Amp and
approved to BS1362. In the event the mains plug has to be removed/replaced for
any reason, please note: IMPORTANT: The wires in the mains lead are coloured in
accordance with the following code:
Blue or Black – N - (Neutral)
Brown or Red – L (Live)
Green / Yellow – E / (Earth)
Connect Green /
Yellow to E (earth)
Connect Blue to
Outer sleeve
firmly clamped
As the colours of the wires in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed as follows.
The blue wire must be connected to the terminal marked with an N or coloured black.
The brown wire must be connected to the terminal marked with an L or coloured red.
WARNING! Never connect live or neutral wires to the earth terminal of the plug.
Only fit an approved 13 Amp BS 1363 or BS 1363/A plug and the correctly rated fuse.
If in doubt, consult a qualified electrician.
NOTE: If a moulded plug is fitted and has to be removed take great care
in disposing of the plug and severed cable, it must be destroyed to prevent
engaging into a socket.
