34oz(1Liter)Heavy Duty Multi-Purpose
HIGH PRESSURE
SPRAY GUN
MODEL: 4001J
NOTICE
CLEAN IMMEDIATELY
Clean the spray gun IMMEDIATELY after EVERY
use, in between costs, and when it will be idle for
more than 5 minutes. Delay or inadequate cleaning
will permanently clog the spray gun.
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAIN-
TENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND UNDERSTAND
ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO COULD
RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
IF YOU SHOULD HAVE ANY QUESTIONS OR EXPERIENCE A PROBLEM WITH YOUR RED THUNDER
PRODUCT, DO NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER SER-
VICE DEPARTMENT AT 1-866-355-0018. BEFORE YOU CALL, HAVE THE FOLLOWING INFORMATION
AVAILABLE: MODEL No., DATE PURCHASED AND STORE LOCATION. AN RED THUNDER REPRE-
SENTATIVE CAN RESOLVE YOUR PROBLEM OVER THE PHONE. IF YOU WOULD LIKE TO MAKE A
SUGGESTION OR COMMENT, GIVE US A CALL OR EMAIL US AT: INFO@REDTHUNDERSTORE.COM.
YOUR FEEDBACK IS VITAL TO US.
1
Advertisement
Table of Contents
Related Manuals for Thunder 4001J
Summary of Contents for Thunder 4001J
- Page 1 ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE. IF YOU SHOULD HAVE ANY QUESTIONS OR EXPERIENCE A PROBLEM WITH YOUR RED THUNDER PRODUCT, DO NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER SER- VICE DEPARTMENT AT 1-866-355-0018.
-
Page 3: Recognize Safety Symbols, Words And Labels
CONGRATULATIONS! Thanks for choosing this product. At Red Thunder, our goal is to provide you with quality products at an affordable price, and we want you to be totally satisfied with your product and our Customer Service. If any help and advice is needed, please contact us at 1-866-355-0018. -
Page 4: Important Safeguards
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage. -
Page 5: General Safety Warnings
SAFETY WARNINGS READ ALL SAFETY WARNINGS BEFORE USING SPRAY GUN GENERAL SAFETY WARNINGS Keep work area clean. Messy areas and cluttered workbenches invite personal injury and/or property damage. Keep children and visitors away. All children should be kept away from the work area. - Page 6 Use the right tool. Use tools properly and for their intended task. Do not force a small tool to do the job of a heavy-duty tool. Using the right tool to do the right job will make doing the job safer. Check damaged parts before use of any air tools or attachments.
-
Page 7: Safety Rules For Spray Guns
SAFETY RULES FOR SPRAY GUNS RISK TO BREATHING • Spray materials may be harmful if inhaled, or if there is contact with the skin. Adequate exhaust must be provided to keep the air free of accumulations of toxic materials. For toxic vapors produced by spraying certain materials can create intoxica- tion and serious damage to health. -
Page 8: Risk Of Burns
• Maintain tools with care. Keep tools clean and oiled for best and safest performance. Follow instructions for lubricating and changing accessories. Wiping or cleaning rags and other flammable waste materials must be placed in a tightly closed metal container and disposed of later in the proper fashion. Do not direct paint stream at body. -
Page 9: Installation And Location
INSTALLATION AND LOCATION DO NOT place Spray Gun in an area: • Where there is evidence of oil or gas leaks. • Where flammable gas vapors or materials may be present. • Where air temperatures fall below 32ºF or exceed 104ºF. INSTALLATION AND LOCATION External Needle Pack Adjustment (Packing Nut) -
Page 10: Before Setup
BEFORE SETUP TO PREVENT SERIOUS INJURY FROM EXPLOSION: Use only clean, dry, regulated, compressed air to power this tool. Do not use oxygen, carbon dioxide, combustible gases, or any other bottled gas as a power source for this tool. 1. Incorporate a filter, regulator with pressure gauge, in-line shutoff valve, and quick coupler for best service, An in-line shutoff ball valve is an important safety device becauseit controls the air supply even if the air hose is ruptured. -
Page 11: Preparation And Assembly
PREPARATION AND ASSEMBLY 1. After unpacking the product, inspect carefully for any damage that may have occurred during transit. Make sure to tighten fittings, bolts, etc., before put- ting unit into service. Tighten the gun to the cup securely using the connector with filter inside. -
Page 12: Operation
ADJUSTMENTS The desired pattern, volume of fluid output and fine atomization can easily be obtained by regulating the Pattern Adjusting Knob, Fluid (PAINT) Adjusting Knob and Air Adjusting Knob. • PATTERN ADJUSTMENT: Turning Pattern Adjusting Knob to the right Pattern until tight will make spray pattern Fluid round, or turning left make spray... -
Page 13: Maintenance
Two thin coats of paint will yield better results and have less NOTE chance of runs than one heavy layer. Coating should be even Coating will be Coating will be too 6-12 inches and wet when spraying light at this point heavy at this point WRONG RIGHT... - Page 14 Always exercise extreme care when using any solvent or thinner. Never clean gun near fire, flame, or any source of heat or sparks. Properly dispose of used cleaning materials. DO NOT soak entire spray gun in solvent or thinner for a long period of time as this will destroy lubricants and possibly make motion uneven.
- Page 15 Parts List and Diagram PART DESCRIPTION PART DESCRIPTION PART DESCRIPTION Gun body Hanger Split Washer Sealing screw Hook-up Trigger Sealing gasket Uper Lid Trigger Stud Air Spacng ring Sealing Gasket Gasket Fluid Nozzle Lock Nut Needle Sleeve Air Cap Sealing Gasket Needle Seate Gasket Lower Lid...
-
Page 16: Specifications
SPECIFICATIONS SPECIFICATIONS Max Pressure 120psi (8.3bar) Air Consumption 4.6-7.1CFM Fluid Nozzle Size 1.8mm (0.071in.) Air Inlet 1/4 In.-18 NPS Cup Size 33.8 fl.oz (1000ML) Type of feed Suction Optional Dia of Nozzle 2.0mm Recommended air pressure 40-60psi Weight 1.87lbs(0.85kgs) Pattern Width 7.9”-9.8”... - Page 17 Troubleshooting - Spray Pattern Diagnosis Note: The drawings on the left below resemble symptoms of spray pattern problems.Refer to the accompanying possible causes and likely solutions to the right. Problem Possible Causes Likely Solutions Heavy center 1. Pattern Knob partially 1.
-
Page 18: General Troubleshooting Chart
General Troubleshooting Chart Possible Causes Likely Solutions Sputtering Spray 1. Low paint level. 1. Refill. 2. Cup tipped. 2. Hold upright. 3. Clogged Air Vent on Cup. 3. Clean Air Vent hole. 4. Loose Fluid Inlet connection. 4. Tighten Fluid Inlet connection. 5. -
Page 19: Limited Warranty
1. The sales receipt or other evidence of the date and place of purchase. 2. A description of the problem. 3. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to: Red Thunder, Inc 7683 SE 27th St, Suite 186 Mercer Island, WA 98040 OUT OF WARRANTY Conditions, malfunctions or damage not resulting from defects in material or workmanship. - Page 20 Red Thunder, Inc. Address: 7683 SE 27TH Street, Suite 186 Mercer Island, WA 98040, USA Phone: +1 (866) 355-0018 Email: info@redthunderstore.com www.redthunderstore.com...
