Stanley 78-411 Instruction Manual

Stanley 78-411 Instruction Manual

Cut off tool

Advertisement

Available languages

Available languages

Quick Links

3 YEAR LIMITED WARRANTY
Stanley warrants this product to the original purchaser for a period of THREE (3) YEARS against
deficiencies in material and workmanship. This LIMITED WARRANTY does not cover products that are
improperly used, abused, altered or repaired. Deficient products will be replaced or repaired at Stanley's
option. Please call 800-262-2161 for more information or return instructions.
THIS LIMITED WARRANTY IS GIVEN IN LIEU OF ALL OTHERS INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND EXCLUDES ALL INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states do not allow limitations on how long an implied warranty
lasts or the exclusion or limitation of incidental or consequential damages, so these limitations may not
apply to you. This LIMITED WARRANTY gives you specific legal rights that may vary from state to state.
GARANTÍA LIMITADA DE 3 AÑOS
Stanley garantiza este producto al comprador original durante un período de TRES (3) AÑOS contra
deficiencias en material y mano de obra. Esta GARANTÍA LIMITADA no cubre productos que sean usados
impropiamente, abusados, alterados o reparados. Los productos deficientes serán reemplazados o
reparados a la opción de Stanley. Por favor llame al teléfono 800-262-2161 para obtener mayor
información o instrucciones de retorno.
ESTA GARANTÍA LIMITADA ES OTORGADA EN LUGAR DE TODAS LAS DEMÁS, INCLUYENDO
GARANTÍA IMPLÍCITA DE COMERCIABILIDAD O APTITUD PARA UN PROPÓSITO EN PARTICULAR Y
EXCLUYE TODOS LOS DAÑOS INCIDENTALES O CONSECUENTES. Algunos estados no permiten
limitaciones con relación a cuanto dura una garantía implícita, o la exclusión o la limitación de daños
incidentales o consecuentes, de modo que estas limitaciones pueda que no le apliquen a usted. Esta
GARANTÍA LIMITADA le otorga derechos legales específicos los cuales pueden variar de estado a estado.
GARANTIE LIMITÉE DE 3 ANS
Stanley garantit ce produit à l'acheteur d'origine pendant une période de TROIS (3) ANS contre les
défauts de matériaux et de main d'œuvre. Cette GARANTIE LIMITÉE ne couvre pas les produits qui ont
été mal utilisés, abusés, modifiés ou réparés. Les produits défectueux seront remplacés ou réparés au
choix de Stanley. Veuillez appeler le 800-262-2161 pour plus de renseignements ou au sujet des
instructions de renvoi.
CETTE GARANTIE LIMITÉE EST DONNÉE EN LIEU DE TOUTES AUTRES, Y COMPRIS LES GARANTIES
TACITES D'APTITUDE À ÊTRE VENDU ET UTILISÉ À UN BUT PARTICULIER, ET EXCLUT TOUS LES
DÉGÂTS SECONDAIRES OU CONSÉQUENTS. Quelques états ne permettent pas de limites sur la durée de
garanties tacites ou sur l'exclusion ou la limitation des dégâts secondaires ou conséquents, donc il se
peut que ces limitations ne s'appliquent pas à vous. Cette GARANTIE LIMITÉE vous procure des droits
spécifiques qui peuvent varier d'un état à l'autre.
CUT OFF TOOL
• Molded grip reduces fatigue,
vibration and cold
• Free Speed of 20,000 RPM
• 360˚ directional rear exhaust
keeps air away from your face
and work area
©2005 The Stanley Works, New Britain, CT 06053
• Adjustable air inlet controls
• Teasing throttle lets you control
• Suggested applications:
WARNING
Read and understand this instruction manual and tool labels before
installing, operating or servicing this tool. Keep these instructions in a
safe accessible place.
Operators and others in work area must wear ANSI Z87.1 approved
safety glasses with side shields.
Operators and others in work area must wear ear protection.
Always disconnect from air source when oiling or servicing the tool,
or when changing attachments.
Use only accessories rated at or above tool rated RPM.
Avoid prolonged use: repetitive motion or exposure to vibration may be
harmful to your hands or arms.
Do Not Use oxygen or reactive gases; explosion may occur.
Do Not Exceed air pressure of 90 PSI.
Oil daily for optimal performance.
THE STANLEY WORKS: New Britain, CT 06053
Tel 800-262-2161 www.stanleyworks.com
US
F
E
78-411
power of tool
Cut Off Tool speed
For cutting fasteners, muffler
pipe and other metals

Advertisement

loading

Summary of Contents for Stanley 78-411

  • Page 1 3 YEAR LIMITED WARRANTY CUT OFF TOOL Stanley warrants this product to the original purchaser for a period of THREE (3) YEARS against 78-411 deficiencies in material and workmanship. This LIMITED WARRANTY does not cover products that are improperly used, abused, altered or repaired. Deficient products will be replaced or repaired at Stanley's option.
  • Page 2: Specifications

    Specifications Especificaciones Fiche technique Proper Use Of Tool Always disconnect air supply before changing any accessories. To remove and replace wheels, use the wrenches included in this kit or a 17mm open end Your new Cut Off Tool is designed for use with 3" wrench to hold arbor and then loosen arbor screw cut-off wheels to cut through bolts, steel rods, Average Air...
  • Page 3: Air Regulator

    16) Do not install the tool unless an easily The inside diameter of the hose should be Air Regulator accessible and easily operable on/off valve increased to compensate for unusually long air is incorporated in the air supply. hoses (over 25 feet). Minimum hose diameter should be 3/8"...
  • Page 4 15) Se espera que los usuarios adopten prácticas agarre la herramienta y oprima la traba de de trabajo seguras y observen todos los seguridad mientras acelera. requisitos legales relevantes al instalar, usar o THE STANLEY WORKS: New Britain, CT 06053 Tel: 800-262-2161 www.stanleyworks.com...
  • Page 5 darle mantenimiento a la herramienta. La conexión recomendada se muestra en la figura Regulador de aire A. Las herramientas neumáticas operan sobre un 16) No instale la herramienta a manos que tenga amplio margen de presiones de aire. Para obtener una válvula de encendido/apagado fácilmente máxima eficiencia y larga vida de la herramienta, la accesible y operable en la fuente de aire.
  • Page 6 Pour commencer à l’utiliser, saisissez règlements légaux appropriés lors de l’outil et enfoncez le levier de sûreté tout en l’installation, utilisation ou entretien de l’outil. appuyant sur l’accélération. THE STANLEY WORKS: New Britain, CT 06053 USA Tél. : 800-262-2161 www.stanleyworks.com...
  • Page 7 16) N’installez l’outil que s’il existe une vanne de Le raccordement recommandé est illustré dans la Régulateur d’air marche/arrêt facilement accessible et opérable figure A. Les outils pneumatiques fonctionnent incorporée dans l’arrivée d’air. dans une grande plage de pressions d’air. Pour obtenir l’efficacité...
