TP-Link Archer AX6000 Quick Installation Manual page 2

LED Explanation
Solid Blue
The router is working normally.
Circulating Blue
The system is starting up or the
router is being reset.
Circulating Blue in Parallel
The firmware is being upgraded or
WPS connection is being established.
Solid Orange
The router is connected to the
internet, but the wireless function is off.
Solid Red
No internet connection.
Button Explanation
WPS Button
Press the WPS button for 1 second, and immediately press the
WPS button on your client to start the WPS process.
Wi-Fi Button
Press and hold the Wi-Fi button for about 2 seconds to turn on
or off the wireless function of your router.
LED Button
Press the LED button for about 2 seconds to turn on or off the
LED of your router.
Safety Information
Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need
service, please contact us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Do not use the device where wireless devices are not allowed.
Adapter shall be installed near the equipment and shall be easily accessible.
Need Help?
Q1. What should I do if I can't access the web
management page?
• Reboot your router and try again.
• If the computer is set to a static IP, change its settings to
obtain an IP address automatically.
• Verify that http://tplinkwifi.net is correctly entered in the web
browser. Alternatively, enter http://192.168.0.1 or
http://192.168.1.1 in the web browser.
• Use another web browser and try again.
• Disable and enable the network adapter in use.
Q2. What should I do if I can't access the internet?
• Power off your modem for about 5 minutes, then power it on
and check the internet.
• Check if the internet is working normally by connecting a
computer directly to the modem via an Ethernet cable. If it is
not, contact your internet service provider.
• Log in to the web management page of the router, and go to
the Network Map page to check whether the internet IP
address is valid or not. If it's valid, go to Advanced > Network >
Internet, click Advanced Settings, select Use the Following
DNS Addresses, set the primary DNS to 8.8.8.8, and set the
secondary DNS to 8.8.4.4. If it is not, check the hardware
connection or contact your internet service provider.
• For cable modem users, log in to the web management page
of the router. Go to Advanced > Network > Internet > MAC
Clone, select Clone Current Device MAC and click SAVE.
Then reboot both the modem and the router.
Q3. What should I do if the router can't be found via
Bluetooth in Tether (how to reset the router)?
The router's Bluetooth will be enabled for 30 minutes following
a reset to factory defaults. There are two ways to reset the
router:
• With the router powered on, use a pin to press and hold the
Reset button on the back of the router for at least 2 seconds
until the LED begins circulating blue.
• Log in to the web management page of the router. Go to
Advanced > System > Backup & Restore, and click FACTORY
RESTORE. The router will reset and restart automatically.
For technical support, replacement services, user guides, and other
information, please visit https://www.tp-link.com/support.
To communicate with TP-Link users or engineers, please join the
TP-Link Community at https://community.tp-link.com.
Email techwriter@tp-link.com.cn to give suggestions.
©2020 TP-Link 7106509101 REV2.0.0
Quick Installation Guide
AX6000
AX6000 8-Stream Wi-Fi 6 Router
