MSI MS-9892 Manual

Industrial computer board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MS-9892
(v1.x) Industrial Computer Board
i

Advertisement

Table of Contents
loading

Related Manuals for MSI MS-9892

Summary of Contents for MSI MS-9892

  • Page 1 MS-9892 (v1.x) Industrial Computer Board...

  • Page 2: Technical Support

    Preface Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.

  • Page 3: Safety Instructions

    MS-9892 Safety Instructions ￭ Always read the safety instructions carefully. ￭ Keep this User’s Manual for future reference. ￭ Keep this equipment away from humidity. ￭ Lay this equipment on a reliable flat surface before setting it up. ￭ The openings on the enclosure are for air convection hence protects the equipment from overheating.

  • Page 4: Chemical Substances Information

    Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), MSI provides the information of chemical substances in products at: https://www.msi.com/html/popup/csr/evmtprtt_pcm.html Battery Information European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste.

  • Page 5: Ce Conformity

    MS-9892 CE Conformity Hereby, Micro-Star International CO., LTD declares that this device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive. FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 6: Table Of Contents

    Preface CONTENTS Copyright and Trademarks Notice ..............ii Revision History .................... ii Technical Support ..................ii Safety Instructions ..................iii Chemical Substances Information ............... iv Battery Information ..................iv CE Conformity ....................v FCC-B Radio Frequency Interference Statement ......... v WEEE Statement ..................v 1 Overview1-1 Motherboard Specifications ................1-2 Motherboard Layout ...................1-5...
  • Page 7 Overview Thank you for choosing the MS-9892, an excellent industrial computer board. Based on the innovative Intel Apollo Lake processor for optimal ® system efficiency, the MS-9892 accommodates versatile I/O interfaces and supports up to 2 DDR3L 1867MHz SO-DIMM slots to provide the maximum of 8GB memory capacity.

  • Page 8: Motherboard Specifications

    Overview Motherboard Specifications Processor ■ Intel Atom™ X7-E3950 QC 1.6/2.0GHz (Burst) ® ■ Intel Atom™ X5-E3940 QC 1.6/1.8GHz (Burst) ® ■ Intel Atom™ X5-E3930 DC 1.3/1.8GHz (Burst) ® ■ Intel Pentium N4200 QC 1.1/2.5GHz (Burst) ® ® ■ Intel Celeron N3350 DC 1.1/2.4GHz (Burst) ®...
  • Page 9 MS-9892 Internal I/O ■ 1 x 4-pin power connector ■ 1 x SATA power box header ■ 1 x System fan header ■ 3 x USB 2.0 box headers (6 ports) ■ 2 x RS232/422/485 COM port box headers ■ 4 x RS232 COM port box headers ■...
  • Page 10 Overview Power ■ DC 12~24V ■ 1 x 4-pin power connector ■ 1 x DC-In jack Environment ■ Operating temperature: -10 ~ 60 C (for Apollo Lake) ■ Operating temperature: -40 ~ 85 C (for Apollo Lake-I) ■ Storage temperature: -20 ~ 80 C (for Apollo Lake) ■...

  • Page 11: Motherboard Layout

    MS-9892 Motherboard Layout LVDS Blacklight TXE F/W eDP Power Header Jumper Jumper & Power Jumper Rear Panel I/O Power SMBus Box System Fan LVDS Connector Header Header Connector Connector SO-DIMM Slots Holder Clear CMOS Jumper TPM Header Mini-PCIe GPIO1 Box...

  • Page 13: Hardware Setup 2-1

    Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly.
  • Page 14 Hardware Setup Components Reference Guide Memory 2-3 Power Supply 2-4 System Power Connector: JPWR1 ............2-4 SATA Power Box Header: JSATA_PWR1 ..........2-4 Rear Panel I/O 2-5 Connector 2-6 Fan Power Header: SYSFAN1 ..............2-6 Serial ATA Connector: JSATA1, JSATA2 ............2-6 Chassis Intrusion Header: JCASE1 ............2-7 3.3V GPIO Box Header: JGPIO1 ...............2-7 5V GPIO Box Header: JGPIO2 ..............2-7 Audio Amplifier Box Header: JAMP1 ............2-8...

  • Page 15: Memory

    MS-9892 Memory The SO-DIMM slot is intended for memory modules. 1. Locate the SO-DIMM slot. Align the notch on the DIMM with the key on the slot and insert the DIMM into the slot. 2. Push DIMM gently downwards until the slot levers click and lock the DIMM in place.

  • Page 16: Power Supply

    Hardware Setup Power Supply System Power Connector: JPWR1 This connector is used to provide power to the system. SATA Power Box Header: JSATA_PWR1 This connector is used to provide power to SATA devices. Important Make sure that all power connectors are connected to the power supply to ensure stable operation of the motherboard.

  • Page 17: Rear Panel I/O

    MS-9892 Rear Panel I/O DC-In USB 32 Gen 1 HDMI Port DisplayPort GbE RJ45 Ports Line-Out Jack Ports Jack DC-In Jack This jack is used to provide power to the motherboard. USB 3.2 Gen 1 Port The USB 3.2 Gen 1 port is backward-compatible with USB 2.0 devices and supports data transfer rate up to 5 Gbit/s (SuperSpeed).

  • Page 18: Connector

    Hardware Setup Connector Fan Power Header: SYSFAN1 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND.

  • Page 19: Chassis Intrusion Header: Jcase1

    MS-9892 Chassis Intrusion Header: JCASE1 This connector connects to the chassis intrusion switch cable. If the computer case is opened, the chassis intrusion mechanism will be activated. The system will record this intrusion and a warning message will flash on screen. To clear the warning, you must enter the BIOS utility and clear the record.

  • Page 20: Audio Amplifier Box Header: Jamp1

    Hardware Setup Audio Amplifier Box Header: JAMP1 The connector is used to connect audio amplifiers to enhance audio performance. S/PDIF Header: JSPDI1 This header is used to connect S/PDIF (Sony & Philips Digital Interconnect Format) interface for digital audio transmission. Front Audio Header: JAUD1 This connector allows you to connect the front panel audio.

  • Page 21: Front Panel Header: Jfp1

    MS-9892 Front Panel Header: JFP1 This front panel connector is provided for electrical connection to the front panel switches & LEDs and is compliant with Intel Front Panel I/O Connectivity Design Guide. Keyboard/Mouse Box Header: JKBMS1 This connector is provided to connect a keyboard and a mouse.

  • Page 22: Smbus Box Header: Jsmb1

    Hardware Setup SMBus Box Header: JSMB1 This connector, known as I2C, is for users to connect System Management Bus (SMBus) interface. LVDS Connector: JLVDS1 The LVDS (Low Voltage Differential Signal) connector provides a digital interface typically used with flat panels. After connecting an LVDS interface flat panel to the JLVDS1, be sure to check the panel datasheet and set the LVDS jumper to proper power voltage.

  • Page 23: Com Port Box Headers: Jcom1 ~ Jcom6

    MS-9892 COM Port Box Headers: JCOM1 ~ JCOM6 This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs. You can attach a serial device to it. JCOM1~JCOM2 RS232 SIGNAL DESCRIPTION Data Carrier Detect Receive Data Transmit Data...

  • Page 24: Edp Connector: Fpc1_Edp

    Hardware Setup JCOM3~JCOM6 RS232 SIGNAL DESCRIPTION Data Carrier Detect Receive Data Transmit Data Data Terminal Ready Ground Data Set Ready Request To Send Clear To Send Ring Indicator eDP Connector: FPC1_EDP This connector is for connecting the flat eDP cable. 2-12...

  • Page 25: Lpc Debug Port Header: Jtpm1 (With Tpm Support)

    MS-9892 LPC Debug Port Header: JTPM1 (With TPM Support) This connector works as LPC debug port and supports TPM modules. 2-13...

  • Page 26: Jumper

    Hardware Setup Jumper Important Avoid adjusting jumpers when the system is on; it will damage the motherboard. Clear CMOS Jumper: JCMOS1 There is a CMOS RAM onboard that has a power supply from an external battery to keep the data of system configuration. With the CMOS RAM, the system can automatically boot OS every time it is turned on.

  • Page 27: Txe F/W Jumper: Jtxe1

    MS-9892 TXE F/W Jumper: JTXE1 This jumper is used to enable/disable the Intel TXE F/W. Normal Disable TXE F/W eDP Power Jumper: JEDP_VDD1 Use this jumper to specify the operation voltage of the eDP interface flat panel. 3V (Default) LVDS Blacklight Header & Power Jumper: JVDD1 The connector is provided for LCD backlight options and allows users to select the operation voltage of the LVDS flat panel.

  • Page 28: Slot

    Hardware Setup Slot PCIe (Peripheral Component Interconnect Express) Slot The PCI Express slot supports PCIe interface expansion cards. PCIe x1 slot Mini PCIe (Peripheral Component Interconnect Express) Slot The Mini PCIe slot is provided for WiFi modules, Bluetooth modules, TV tuner cards and other Mini-PCIe cards.

  • Page 29: Bios Setup 3-1

    BIOS Setup This chapter provides information on the BIOS Setup program and allows users to configure the system for optimal use. Users may need to run the Setup program when: ■ An error message appears on the screen at system startup and requests users to run SETUP.

  • Page 30: Entering Setup

    BIOS Setup Entering Setup Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press <DEL> or <F2> key to enter Setup. Press <DEL> or <F2> to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button.
  • Page 31 MS-9892 Control Keys ← → Select Screen ↑ ↓ Select Item Enter Select Change Option General Help Previous Values Optimized Defaults Save & Reset Exit Getting Help After entering the Setup menu, the first menu you will see is the Main Menu.

  • Page 32: The Menu Bar

    BIOS Setup The Menu Bar ▶ Main Use this menu for basic system configurations, such as time, date, etc. ▶ Advanced Use this menu to set up the items of special enhanced features. ▶ Boot Use this menu to specify the priority of boot devices. ▶...

  • Page 33: Main

    MS-9892 Main ▶ System Date This setting allows you to set the system date. The date format is <Day>, <Month> <Date> <Year>. ▶ System Time This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>.

  • Page 34: Advanced

    BIOS Setup Advanced ▶ Full Screen Logo Display This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or system manufacturer’s full-screen logo. When it is enabled, the BIOS will display the full-screen logo during the boot-up sequence, hiding normal POST messages.
  • Page 35 MS-9892 ▶ Super IO Configuration ▶ Serial Port 1/ 2/ 3/ 4/ 5/ 6 This setting enables/disables the specified serial port. ▶ Change Settings This setting is used to change the address & IRQ settings of the specified serial port.
  • Page 36 BIOS Setup ▶ H/W Monitor These items display the current status of all monitored hardware devices/ components such as voltages, temperatures and all fans’ speeds. ▶ Smart Fan Configuration ▶ Smart SYSFAN Target This setting enables/disables the Smart Fan function. Smart Fan is an excellent feature which will adjust the CPU/system fan speed automatically depending on the current CPU/system temperature, avoiding the overheating to damage your system.
  • Page 37 MS-9892 ▶ CPU Configuration ▶ Intel Virtualization Technology Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple “Virtual” systems. ▶ EIST...
  • Page 38 BIOS Setup ▶ Network Stack Configuration This menu provides Network Stack settings for users to enable network boot (PXE) from BIOS. ▶ Network Stack When this setting is set to [Enabled], the system will boot via the network instead of a disk drive. ▶...
  • Page 39 MS-9892 ▶ Audio Controller This setting enables/disables the onboard audio controller. ▶ Launch OnBoard LAN OpROM These settings enable/disable the initialization of the onboard/onchip LAN Boot ROM during bootup. Selecting [Disabled] will speed up the boot process. ▶ GPIO Group Configuration ▶...

  • Page 40: Boot

    BIOS Setup Boot ▶ CSM Support This setting enables/disables the support for Compatibility Support Module, a part of the Intel Platform Innovation Framework for EFI providing the capability to support legacy BIOS interfaces. ▶ OS Selection This setting allows users to select the Operating System. ▶...

  • Page 41: Security

    MS-9892 Security ▶ Administrator Password Administrator Password controls access to the BIOS Setup utility. ▶ User Password User Password controls access to the system at boot and to the BIOS Setup utility. ▶ Chassis Intrusion The field enables or disables the feature of recording the chassis intrusion status and issuing a warning message if the chassis is once opened.
  • Page 42 BIOS Setup ▶ Trusted Computing ▶ Security Device Support This setting enables/disables BIOS support for security device. When set to [Disable], the OS will not show security device. TCG EFI protocol and INT1A interface will not be available. ▶ SHA-1 PCR Bank, SHA256 PCR Bank These settings enable/disable the SHA-1 PCR Bank and SHA256 PCR Bank.
  • Page 43 MS-9892 ▶ Serial Port Console Redirection ▶ Console Redirection Console Redirection operates in host systems that do not have a monitor and keyboard attached. This setting enables/disables the operation of console redirection. When set to [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen.
  • Page 44 BIOS Setup ▶ Console Redirection Settings ▶ Terminal Type To operate the system’s console redirection, you need a terminal supporting ANSI terminal protocol and a RS-232 null modem cable connected between the host system and terminal(s). This setting specifies the type of terminal device for console redirection.
  • Page 45 MS-9892 ▶ Security Configuration ▶ TXE FW Version The setting shows the firmware information of the Intel Trusted Execution Engine (TXE). ▶ TXE HMRFPO The setting enables/disables TXE HMRFPO (Host ME Region Flash Protection Override). ▶ TXE EOP Message This setting determines whether or not to send EOP (Exchange Online Protection) message before entering OS.

  • Page 46: Chipset

    BIOS Setup Chipset ▶ DVMT Pre-Allocated This setting defines the DVMT pre-allocated memory. Pre-allocated memory is the small amount of system memory made available at boot time by the system BIOS for video. Pre-allocated memory is also known as locked memory. This is because it is "locked"...

  • Page 47: Power

    MS-9892 Power ▶ Restore AC Power Loss This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: [Power Off] Leaves the computer in the power off state. [Power On] Leaves the computer in the power on state.
  • Page 48 BIOS Setup ▶ USB from S3/S4 The item allows the activity of the USB device to wake up the system from S3/ S4 sleep state. ▶ RTC When [Enabled], your can set the date and time at which the RTC (real-time clock) alarm awakens the system from suspend mode.

  • Page 49: Save & Exit

    MS-9892 Save & Exit ▶ Save Changes and Reset Save changes to CMOS and reset the system. ▶ Discard Changes and Exit Abandon all changes and exit the Setup Utility. ▶ Discard Changes Abandon all changes. ▶ Load Optimized Defaults Use this menu to load the default values set by the motherboard manufacturer specifically for optimal performance of the motherboard.
  • Page 51 Appendix GPIO WDT BKL Programming This appendix provides WDT (Watch Dog Timer), GPIO (General Purpose Input/ Output) and LVDS Backlight programming guide. 2-A-1...

  • Page 52: Abstract

    GPIO WDT BKL Programming Abstract Abstract  In  this  document,  code  examples  based  on  C  programming  language  are  provided  for  customer  interest.  Inportb,  Outportb,  Inportl  and  Outportl  are  basic  functions  used  for  access IO ports and defined as following.    Inportb: Read a single 8‐bit I/O port.  Outportb: Write a single byte to an 8‐bit port.    Inportl: Reads a single 32‐bit I/O port.  Outportl: Write a single long to a 32‐bit port.       ...

  • Page 53: General Purposed Io

    MS-9892 General Purposed IO 1. General Purposed IO – GPIO/DIO  The GPIO port configuration addresses are listed in the following table:  Name  IO Port  IO address  Name  IO Port  IO address  N_GPI0  0xA02  Bit 0  N_GPO0  0xA02  Bit 4  N_GPI1  0xA02  Bit 1  N_GPO1  0xA02  Bit 5  N_GPI2  N_GPO2  0xA02  Bit 2  0xA02  Bit 6  N_GPI3  N_GPO3  0xA02  Bit 3  0xA02  Bit 7  N_GPI4*  0x12  Bit 6 ...
  • Page 54 GPIO WDT BKL Programming Read input value from GPI:  1. Read the value from GPI port.  2. Get the value of GPI address.    Example: Get N_GPI2 input value.  val = Inportb (0xA02);      // Read value from N_GPI2 port.  val = val & (1<<2);        // Read N_GPI2 address (bit 2).  if (val)      printf (“Input of    N_GPI2    is High”);  else      printf (“Input of    N_GPI2    is Low”);    Example: Get N_GPI6 input value.  val = SMBus_ReadByte (0x6E, 0x12);  // Read value from N_GPI6 port through SMBus.  val = val & (1<<1); ...

  • Page 55: Watchdog Timer

    MS-9892 Watchdog Timer 2. Watchdog Timer – WDT  The base address (WDT_BASE) of WDT configuration registers is 0xA10.    Set WDT Time Unit  val = Inportb (WDT_BASE + 0x05);      // Read current WDT setting  val = val | 0x08;              // minute mode. val = val & 0xF7 if second mode  Outportb (WDT_BASE + 0x05, val);    // Write back WDT setting    Set WDT Time  Outportb (WDT_BASE + 0x06, Time);  // Write WDT time, value 1 to 255.    Enable WDT  val = Inportb (WDT_BASE + 0x0A);      // Read current WDT_PME setting  val = val | 0x01;            // Enable WDT OUT: WDOUT_EN (bit 0) set to 1. ...

  • Page 56: Lvds Backlight Brightness Control

    GPIO WDT BKL Programming LVDS Backlight Brightness Control 3. LVDS Backlight Brightness Control  The  LVDS  controller  support  17  level  of  backlight  brightness  value  from  0  (30%)  to  16  (100%)  and  it  is  accessible  through  SMBus.  The  associated  access  method  (SMBus_ReadByte, SMBus_WriteByte) are provided in part 4.    Set the Level of LVDS Backlight  1. Write 0xED into address 0x7F on SMBus device 0x42.  2.

  • Page 57: 4. Smbus Access

    MS-9892 SMBus Access 4. SMBus Access  The base address of SMBus must be known before access. The relevant bus and device  information are as following.    #define IO_SC              0xCF8  #define IO_DA              0xCFC  #define PCIBASEADDRESS    0x80000000  #define PCI_BUS_NUM         0  #define PCI_DEV_NUM         31  #define PCI_FUN_NUM         ...
