WASH/RINSE TEMPERATURE
WARM
COLD
COLD
COLD
WARM
HOT
WARM
COLD
Versión en español
Si desea obtener una copia en español de estas
Instrucciones de Funcionamiento, sírvase escribir a la
dirección que se incluye a continuación. Solicite la
P/N 131933800.
Spanish Owner's Guides
Frigidaire Home Products
P. O. Box 212378
Augusta, GA 30917
Before Operating Your Washer
Read your washer Owner's Guide. It has important
safety and warranty information. It also has many
suggestions for best washing results.
To reduce the risk of fire, electric shock,
or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS in your washer Owner's Guide before
operating this appliance.
Printed in U. S. A.
OPERATING INSTRUCTIONS
EXTRA RINSE
REGULAR/PERM PRESS
YES
NO
DOOR
LOCK
Operating Steps
Read and follow Washing Procedures in your
Owner's Guide. It provides detailed information for
preparing the wash load and choosing control
settings to ensure best washing results.
1. Sort laundry into loads that can be washed
together.
2. Prepare items for washing.
3. Pretreat stains and heavy soil.
4. Add laundry load to the wash drum.
5. Open the dispenser drawer and add the
measured amount of detergent to the
detergent compartment. If desired, add liquid
bleach and fabric softener to the appropriate
compartments. Slowly close dispenser drawer.
The washer will not operate with the drawer
open.
6. Set Wash/Rinse Temperature according to
fabric type and soil level of each load.
7. If desired, select Extra Rinse in the Regular
or Perm Press cycle.
8. Select Final Spin Speed, as desired, when
using the Perm Press or Hand Washables
cycles.
DELICATES &
FINAL SPIN SPEED
HAND WASHABLES
ON
CYCLE SIGNAL
PREWASH
FINAL
SPIN
WASH
FINAL
SPIN
OFF
PERM PRESS
WASH
COLORS
9. Push in the cycle selector knob and turn it
clockwise to the desired wash cycle.
10. Start the washer by closing the door and
pulling out the cycle selector knob. The
washer will not operate with the door open.
As a safety measure, the door will
automatically lock during the entire wash
cycle.
•
To stop the washer, push in the cycle
selector knob.
•
To change a cycle, push in the cycle
selector knob and turn it clockwise to the
desired setting.
•
Pull out the knob to restart the washer.
11. Remove items when cycle ends. A signal
will sound at the end of the cycle. On some
models, the Cycle Signal can be turned off.
Note: From time to time you may see water in
the bleach and fabric softener compartments.
This is a result of the siphoning action and is
part of the normal operation of the washer.
(continued, reverse side)
•
•
REGULAR
WHITES
HEAVY WASH
WASH
•
LIGHT WASH
FINAL
SPIN
P/N 131932500A (0401)
