Patent Pending
Model No. NTTL24990
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through di-
rect assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading

Related Manuals for NordicTrack APEX 6100

Summary of Contents for NordicTrack APEX 6100

  • Page 1 CUSTOMER HOT LINE: 1-888-825-2588 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.nordictrack.com this equipment. Save this manual for future reference. new products, prizes, fitness tips, and much more!

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    120 volts AC and informed of all warnings and precautions. 15 amps. To purchase a surge suppressor, see your local NordicTrack dealer or call 1-888- 2. Use the treadmill only as described in this 825-2588 and order part number 146148.
  • Page 4 20. Do not change the incline of the treadmill by your CD player or VCR when you are not placing objects under the treadmill. using them. 21. When folding or moving the treadmill, make 25. Inspect and tighten all parts of the treadmill sure that the storage latch is fully closed.

  • Page 5: Before You Begin

    And when you’re the product model number and serial number before not exercising, the unique APEX 6100 can be folded calling. The model number of the treadmill is up, requiring less than half the floor space of other NTTL24990.

  • Page 6: Assembly

    ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own Phillips screwdriver Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
  • Page 7 4. Insert two Handrail Bushings (94) into the right Upright (83). Turn the Handrail Bushings so they fit against the Upright as shown in the inset drawing. Insert two Handrail Bolts (96) with Handrail Washers (95) into the Handrail Bushings (94), the right Upright (83), and the right Handrail Spacer (92).

  • Page 8: Operation And Adjustment

    To purchase a surge suppressor, see your local The temporary adapter should be used only until a NordicTrack dealer or call 1-888-825-2588 and order properly grounded outlet (drawing 1) can be installed part number 146148. Use only a single-outlet surge by a qualified electrician.
  • Page 9 Program Display Main Display Pulse Pulse Sensor Sensor Note: If there is a thin sheet of clear plastic on the face Clip of the console, remove it. FEATURES OF THE CONSOLE trainer right in your home. Using the included audio cable, you can connect the treadmill to your home The advanced console offers an impressive array of stereo, portable stereo, or computer and play special...
  • Page 10 Plug in the power cord. CAUTION: Before operating the See HOW TO PLUG IN THE POWER CORD on console, read the following precautions. page 8. • Do not stand on the walking belt when turn- ing on the power. Move the on/off switch to the on position. •...
  • Page 11 Follow your progress with the LED track, the HOW TO USE THE MANUAL MODE Training Zone display, and the main display. The LED track—When Insert the key fully into the console. the manual mode or an iFit.com program is se- See GETTING STARTED on page 10.
  • Page 12 Heart Rate/Calories— When you are finished exercising, stop the When you are not walking belt and remove the key. using the handgrip pulse sensor, the main Step onto the foot rails, press the Stop button, and display will show the adjust the incline of the treadmill to the lowest level.
  • Page 13 When you select a preset program, the left side of Note: Each time a segment ends and the speed the main display will flash the maximum incline settings move to the left, if all of the indicators in setting of the program and the right side of the the Current Segment column are lit, the speed set- display will flash the maximum speed setting of tings may move downward so that only the highest...
  • Page 14 Refer to the program display. Each custom pro- HOW TO CREATE CUSTOM PROGRAMS gram is divided into one-minute segments. One speed setting and one incline setting can be pro- grammed for each segment. The speed setting for Insert the key fully into the console. the first segment will be shown in the See GETTING STARTED on page 10.
  • Page 15 When only three seconds remain in the first seg- HOW TO USE CUSTOM PROGRAMS ment of the program, both the Current Segment column and the column to the right will flash, a se- ries of tones will sound, and all speed settings will Insert the key fully into the console.
  • Page 16 If you have already entered your age, go to step 5. HOW TO USE THE FITNESS TEST PROGRAM If you have not entered your age, press the Enter Age buttons to enter your age. The buttons can be The fitness test program is designed to measure your held down to enter your age quickly.
  • Page 17 At the beginning of each four-minute level, the HOW TO USE THE PULSE-DRIVEN PROGRAM speed and/or incline of the treadmill will automati- cally increase. The fitness test program will con- tinue in this way until your heart rate reaches 70% The pulse-driven program automatically adjusts the of your estimated maximum heart rate, and the speed and incline of the treadmill to keep your heart...
  • Page 18 get heart rate setting for the second segment will Enter your age. then be shown in the flashing Current Segment column. As you exercise, the speed and/or incline Three seconds after the pulse-driven program is of the treadmill will automatically change as selected, the words “ENTER AGE”...
  • Page 19 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5mm LINE OUT jack, see instruction B. If your To use iFit.com CD’s, the treadmill must be con- stereo has only a PHONES jack, see instruction C.
  • Page 20 HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, Note: If your computer has a 3.5mm LINE OUT jack, see instruction A below. If the LINE OUT jack is see instruction A.
  • Page 21 HOW TO CONNECT YOUR VCR HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV To use iFit.com CD’s or videocassettes, the treadmill with a built-in VCR, see instruction B.
  • Page 22 If the speed or incline settings are too high or too • adjust the volume of your CD player or VCR. If low, you can manually override the settings at any the volume is too high or too low, the console time by pressing the Speed or Incline buttons on may not detect the program signals.
  • Page 23 Return to the treadmill and stand on the foot HOW TO USE PROGRAMS DIRECTLY FROM rails. Find the clip attached to the key and slide OUR INTERNET SITE the key onto the waistband of your clothing. When the on-screen countdown ends, the program Our new internet site at www.iFit.com allows you to will begin and the walking belt will begin to move.
  • Page 24 THE INFORMATION MODE/DEMO MODE THE OPTIONAL CHEST PULSE SENSOR The console features an information mode that keeps An optional chest pulse sensor adds even more track of the total number of hours that the treadmill has features to the console. The chest pulse sensor provides been operated and the total number of miles that the hands-free operation and continuously monitors your walking belt has moved.

  • Page 25: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Remove the key and unplug the power cord.

  • Page 26: Trouble-Shooting

    TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-888-825-2588, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a.
  • Page 27 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a UL-listed surge protector, rated at 15 amps, with a 14-gauge cord of five feet or less in length. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.

  • Page 28: Conditioning Guidelines

    CONDITIONING GUIDELINES uses easily accessible carbohydrate calories for en- WARNING: ergy. Only after the first few minutes does your body Before beginning this begin to use stored fat calories for energy. If your goal or any exercise program, consult your physi- is to burn fat, adjust the speed and incline of the tread- cian.
  • Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 30: Part List

    PART LIST—Model No. NTTL24990 R0400A To locate the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Key No. Qty. Description Foot Rail Insert Power Cord Left Foot Rail Power Cord Grommet Pulse Wire Harness Circuit Breaker Left Foot Rail Endcap...

  • Page 31: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCT (NTTL24990) • The NAME OF THE PRODUCT (NordicTrack ® APEX 6100 treadmill) •...
