How to Install and Operate
the XA4100 Amplifier
P O
W
E R
H IG
H
IN
P U
T
H IG
H
IN
P U
Welcome!
What you're holding in your hands is no ordinary
owner's manual. We've tried to make the instructions
in this book clear and easy to follow.
For your Jensen amplifier to work right, it must be
installed correctly. This manual will show you how to
install your new amplifier like a pro. It's a good idea to
read all of these instructions before you begin the
installation. Most installations are straightforward and
can be handled by a do-it-yourselfer with the right
tools, patience, and the ability to follow instructions.
But, do-it-yourself installation isn't for everyone. If you
still don't feel confident after reading this book,
consider turning the installation job over to someone
better suited to it.
Warranty Service
If your Jensen amplifier should ever require service,
you will need to have the original dated receipt. If you
ever need to return the unit for any reason, always
include the receipt with the product.
Technical Assistance
For technical assistance with the operation or installation
of the XA4100, call 1-800-323-0221.
5313Eamp.p65
T
P R
O T
E C
T
1
®
Contents
Features ........................................ 2
Installation ................................... 2
Installation ..................................... 2
Amplifier Location .......................... 2
Disconnect Battery ........................ 2
Needed .......................................... 3
Routing Wires ................................ 3
• Bigger is Better .......................... 3
Wiring ............................................. 4
Power and Outputs ........................ 4
Ground Terminal (GND) ................. 4
Fuses ............................................. 4
Inputs and Controls ....................... 5
Input Wiring.................................... 5
Pass Output ................................... 5
Power Light .................................... 5
Protect Light .................................. 5
Input Level Control ........................ 6
Bass Boost..................................... 6
Crossover ...................................... 6
Speaker Wiring .............................. 7
Testing .......................................... 9
Reconnect Battery ......................... 9
Test Power Wiring .......................... 9
Noise .......................................... 9
• Installing in Trunk ..................... 10
• Crimp Connections .................. 10
• Securing Wires ........................ 10
Power Wires ............................ 10
Troubleshooting ....................... 11
and Warranty ............................. 12
4/10/99, 7:05 PM

Advertisement

Table of Contents
loading

Related Manuals for Jensen XA4100

Summary of Contents for Jensen XA4100

  • Page 1: Table Of Contents

    Pass Output ........5 in this book clear and easy to follow. Power Light ........5 For your Jensen amplifier to work right, it must be Protect Light ........5 installed correctly. This manual will show you how to Input Level Control ......6 install your new amplifier like a pro.

  • Page 2: Features

    ® XA4100 Features The Jensen XA4100 power amplifier is a two- • Bridgeable design to direct full power to two channel 400-watt total system power automotive speakers amplifier. The XA4100 includes: Audio Amplifiers • RCA inputs Amplification offers two advantages: •...

  • Page 3: Supplies And Tools Needed

    ® XA4100 Supplies and Tools Needed Routing Wires Supplies: • Speaker wire (12 gauge for subwoofers, 16-18 Battery gauge for other speakers) • Sheet metal type screws for mounting amplifier Battery Connector • Electrical tape • Solderless crimp connectors Fuse or •...

  • Page 4: Wiring

    ® XA4100 Wiring Power and Outputs FUSE + 12V A-CH B-CH C-CH D-CH – – – – POWER SPEAKER Power Terminal (BATT +12V) Remote Terminal (RMT +12V) Connect the radio power antenna lead from Connect directly to the vehicle battery+ the receiver to the amplifier remote (RMT) terminal with 8 gauge wire (minimum).

  • Page 5: Inputs And Controls

    ® XA4100 Inputs and Controls HIGH INPUT HIGH INPUT POWER protect INPUT PASS INPUT PASS Pass Output Input Wiring Inputs may be high level (from the receiver's Use pass through (PASS OUTPUT) speaker) or low level (from special low level connectors for adding other amplifiers.

  • Page 6: Input Level Control

    6" or smaller speakers. FULL CH 3/4 Use LPF and HPF to BASS-BOOST adjust from 50 to 250Hz. When using your Jensen amplifier to run a subwoofer and two full- Input Level Control range speakers (known as Tri-mode or three...

  • Page 7: Speaker Wiring

    ® XA4100 Speaker Wiring The XA4100 amplifier has inputs and outputs for four channels 4 Speakers 2 Subwoofers/Bridged Mono 2/4Ω 2/4Ω RCA Cables RCA Cables 2/4Ω 2/4Ω 4Ω 4Ω A-CH B-CH C-CH D-CH – – – – A-CH B-CH C-CH D-CH –...
  • Page 8 ® XA4100 2 Speakers + Bridged Subwoofer 4 Speakers + 2 Subwoofers 4Ω 4Ω RCA Cables RCA Cables 4Ω 4Ω 2/4Ω 2/4Ω 4Ω 4Ω 4Ω A-CH B-CH C-CH D-CH – – – – A-CH B-CH C-CH D-CH – – –...

  • Page 9: Testing

    ® XA4100 Testing Before you finish the installation, you should do the following tests to make sure the wiring is correct and everything is operating properly. Reconnect Battery Professional Tip Dealing with Alternator Noise When wiring is complete, reconnect the battery The vehicle alternator can cause a “siren”...

  • Page 10: Installing In Trunk

    ® XA4100 Professional Tip Professional Tip Securing Wires Installing in Trunk When installing the amplifier in the trunk, run Be proud of your installation! Use wire ties to the power wires along the same path as the bundle wires together when possible. (But other vehicle wiring.

  • Page 11: Troubleshooting

    2 ohms bridged No output on channels Speaker wires not connected to Refer to pages 5, 6 and 7 for proper installation speakers properly Input hooked up incorrectly Can’t find cause of problem Contact Jensen Technical Assistance (1-800-323-0221) 5313Eamp.p65 4/10/99, 7:05 PM...

  • Page 12: Specifications
