Aspire X3990 FRU List

Category
MB Kit
Chassis
Bezel
CPU
88
Description
MB Kit AX1930 Intel H61 Intel 82579V GbE
Proprietary W/O 1394 LF DDRIII 2 DIMM W/ EUP
Hon Hai Chassis xSFF HX097G w/ front
USB4+1port for Aspire AX360 Bezel supports I/O
shielding
Hon Hai Chassis xSFF HX097H w/o CR, w/ front
USB4+1port for Aspire AX361 Bezel supports I/O
shielding
Hon Hai Aspire Bezel AX361 w/o CR, w/ USB
4+1port bezel w/HX097H chassis
Hon Hai Aspire Bezel AX362 w/ USB 2+1port
bezel w/HX097G chassis
"CPU Intel Core i7 2600 3.4G 8M 1333 95W K-0
LGA-1155, Sandy Bridge"
"CPU Intel Core i5 2500 3.3G 6M 1333 95W K-0 ,
LGA1155, Sandy Bridge"
"CPU Intel Core i5 2400 3.1G 6M 1333 95W K-0
LGA1155, Sandy Bridge "
"CPU Intel Core i5 2300 2.8G 6M 1333 95W D-2
LGA1155, Sandy Bridge, Quad Core"
Exploded
Part Number
Diagram Item
MB.SGA07.002 3
HS.13100.214 N/A
HS.13100.215
PZ.11900.247 N/A
PZ.11900.281
KC.26001.CI7 N/A
KC.25001.CI5
KC.24001.CI5
KC.23001.CI5
Chapter 6
