EXPAND AND CUSTOMIZE YOUR SYSTEM
DÉVELOPPEZ ET PERSONNALISEZ VOTRE SYSTÈME
AMPLÍE Y PERSONALICE EL SISTEMA
BB311AC1
• Fixed camera.
• Built-in night light.
• Wall mountable.
• Caméra fixe.
• Lumière de nuit intégrée.
• Montage mural.
• Cámara Fija.
• Luz de noche integrada.
• Montaje en la pared.
ACCWIFI1
• Remote viewing accessory.
• View your system on iPhone®, iPad® or Android™ devices.
• Easy QR code setup.
• Connects to your router using Wi-Fi or Ethernet.
• Doubles as a charging station for the monitor.
• Accessoire de visionnement à distance.
• Visionnez votre système sur des appareils iPhone®, iPad® ou Android™.
• Configuration facile avec code QR.
• Se raccorde à votre routeur par Wi-Fi ou Ethernet.
• Peut être également utilisé comme poste de recharge pour le moniteur.
• Accesorio para visualización remota.
• Visualice el sistema en dispositivos iPhone®, iPad® o Android™.
• Fácil configuración de código QR.
• Se conecta al enrutador mediante Wi-Fi o Ethernet.
• Funciona también como una estación de carga para el monitor.
www.lorextechnology.com
BB351AC1
• Pan / tilt camera.
• Auto motion tracking.
• Wall / ceiling mountable.
• Caméra panoramique/
inclinable.
• Détection automatique de
mouvement.
• Montage mural/au plafond.
• Cámara de vista
panorámica/inclinación.
• Seguimiento automático del
movimiento.
• Se puede montar en el techo
o en la pared.
Learn more at
Pour en savoir davantage, visitez
Más información en
www.lorextechnology.com
ADD-ON CAMERA
BB311AC1
QUICK START GUIDE
What's Included
x1 x3 x1
Getting Started
Connect the power adapter to the
2 Slide the power switch to ON.
1
camera and then to a power outlet.
Make sure all power cables are at least
3ft / 1m away from children.
Pairing the Camera with Your Monitor
Place the camera and monitor next to each other. Make sure
1
the monitor and the camera are plugged in and turned on.
2 Press , then move the joystick left or right to navigate to
SETUP. Press the joystick to select SETUP.
Select
Setup
Select Pairing.
3
Select
Pairing
www.lorextechnology.com
x2 x2
NOTE: BB331AC1 can be mounted on a
wall. Please see the User's Guide provided
with your monitor for details.
Use the included cable clips to help keep
TIP
power cables away from your child:
1. Pass the cable through the two plastic brackets on the
cable clip. Position the clip against a surface.
2. Remove the adhesive guard when you are prepared
to install the clip.
3. Wrap excess cable around the brackets as indicated
below by the arrows.
Use the joystick to select the channel you would like to pair
4
the camera to. Press the joystick to make a selection.
NOTE: If a camera is already connected to this channel,
the new camera will replace the existing camera.
Press the PAIR button on the back of the camera within 30
5
seconds of selecting the pairing channel.*
NOTE: Immediately move the camera away from the monitor
to avoid speaker feedback.
*If pairing was unsuccessful, repeat the pairing process described above starting with step 2.
