TP-Link AX1500 Quick Installation Manual

Connect the Hardware
1
Unplug the power to turn off your modem, if any, and remove
the backup battery if it has one.
Place the router horizontally and orient the antennas vertically.
If your internet connection is through an Ethernet cable directly from the wall instead of through a DSL /
Cable / Satellite modem, connect the Ethernet cable to the router's WAN port, and then follow steps 3
and 4 to complete the hardware connection.
*Image may differ from actual product.
Connect the powered-off
1
modem to the router's WAN
port with an Ethernet cable.
Internet
Power on the modem, and then wait
2
about 2 minutes for it to restart.
4
Verify that the hardware connection is correct by checking the following LEDs.
Power 2.4GHz 5GHz Internet
On On On On
Note: If the 2.4GHz LED and 5GHz LED are off, press and hold the WPS/Wi-Fi button on the back for more
than 2 seconds, then release the button. Both the LEDs should turn solid on.
Unplug the power
Modem
Connect the power adapter to
3
the router and turn on the router.
Set Up the Network
2
Method 1: Via a Web Browser
1. Connect your device to the router wirelessly
or with an Ethernet cable.
The default wireless network names (SSIDs) and password
are printed on the label at the bottom of the router.
SSID:XXX@CelcomFiber
SSID:XXX@CelcomFiber_5G
2. Launch a web browser, and enter
http://tplinkwifi.net or http://192.168.1.1 in
the address bar. Enter the username
customer and password celcom123 to log in.
Note: If the login window does not appear, please refer to
Q1 of Need Help? in this guide.
http://tplinkwifi.net
Username:
customer
Local Password:
celcom123
Enter the code shown above
LOG IN
3. Follow the step-by-step instructions to
set up the internet connection.
Method 2: Via TP-Link Tether App
1. Download the Tether app.
or
Scan for Tether
Tether
2. Open the Tether app and log in with your
TP-Link ID.
Note: If you don't have an account, create one first.
3. Tap the button in the Tether app and
select Router > Wireless Router. Follow
the steps to complete the setup and
connect to the internet.
Choose your device type
Router
Range Extender
Archer AX11000
Archer C5400X
Archer AX6000
