SERVICE MANUAL
Indoor Unit
<High Wall, Heat Pump Type>
RAS-M10PKVPG-E
RAS-M13PKVPG-E
RAS-M16PKVPG-E
R32
FILE NO. SVM-18047
MULTIPLE TYPE
"
/U
'"
�
�
�
li'@®[M]OOO&
�
'
!
---
o�
�eo
:::,.. � �
7
"'
-
i
May, 2018

Advertisement

Table of Contents
loading

Related Manuals for Toshiba RAS-M10PKVPG-E

Summary of Contents for Toshiba RAS-M10PKVPG-E

  • Page 1 FILE NO. SVM-18047 SERVICE MANUAL MULTIPLE TYPE Indoor Unit <High Wall, Heat Pump Type> RAS-M10PKVPG-E RAS-M13PKVPG-E RAS-M16PKVPG-E " '" � � � o� li'@®[M]OOO& �eo :::,.. � � "' � May, 2018...

  • Page 2: Table Of Contents

    FILE NO. SVM-18047 CONTENTS 1. SAFETY PRECAUTIONS ................3 2. SPECIFICATIONS ..................6 3. REFRIGERANT R32 .................. 7 4. CONSTRUCTION VIEWS ................ 15 5. WIRING DIAGRAM .................. 16 6. SPECIFICATIONS OF ELECTRICAL PARTS ......... 17 7. REFRIGERANT CYCLE DIAGRAM ............18 8.

  • Page 3: Safety Precautions

    FILE NO. SVM-18047 1. SAFETY PRECAUTIONS Read the precautions in this manual This appliance is fi lled with R32. carefully before operating the unit. (Flammable Material) Information included in the Operation Service personnel should be handing this equipment Manual and/or Installation Manual. with reference to the Installation Manual.
  • Page 4 FILE NO. SVM-18047 DANGER • ASK AN AUTHORIZED DEALER OR QUALIFIED INSTALLATION PROFESSIONAL TO IN- STALL/MAINTAIN THE AIR CONDITIONER. INAPPROPRIATE SERVICING MAY RESULT IN WATER LEAKAGE, ELECTRIC SHOCK OR FIRE. • TURN OFF MAIN POWER SUPPLY BEFORE ATTEMPTING ANY ELECTRICAL WORK. MAKE SURE ALL POWER SWITCHES ARE OFF.
  • Page 5 FILE NO. SVM-18047 Do not pierce or burn as the appliance is pressurized. Do not expose the appliance to heat, fl ame, sparks, or • other sources or ignition. Else, it may explode and cause injury or death. • For R32 model, use pipes, fl are nut and tools which is specifi ed for R32 refrigerant. Using of existing (R22) piping, fl...

  • Page 6: Specifications

    FILE NO. SVM-18047 2. SPECIFICATIONS RAS‐M13PKVPG‐E  Indoor unit RAS‐M10PKVPG‐E R R AS-M16PKVPG-E  Models  Outdoor unit Single phase, 220‐240V~50Hz. (supplied by Outdoor unit)  Indoor unit   Power supply  Outdoor unit   Operation mode Cooling Heating Cooling Heating Cooling Heating  Capacity (Rated) (kW)   Capacity (range, Min ‐ Max) (kW)   Electrical   Indoor unit  Running current (A)  0.24‐0.22 0.28‐0.26 0.24‐0.22 0.28‐0.26 0.24‐0.22 0.28‐0.26  characteristics  Power consumption (kW) ...

  • Page 7: Refrigerant R32

    FILE NO. SVM-18047 3. REFRIGERANT R32 3. If a refrigeration gas leakage occurs during This air conditioner adopts the new refrigerant HFC installation/servicing, be sure to ventilate fully. (R32) which does not damage the ozone layer. If the refrigerant gas comes into contact with fire, a The next section describes the precautions for air poisonous gas may occur.
  • Page 8 FILE NO. SVM-18047 Table 3-2-1 Thicknesses of annealed copper pipes Thickness (mm) Nominal diameter Outer diameter (mm) 6.35 0.80 0.80 9.52 0.80 0.80 12.70 0.80 0.80 15.88 1.00 1.00 2. Joints For copper pipes, flare joints or socket joints are used. Prior to use, be sure to remove all contaminants. a) Flare Joints Flare joints used to connect the copper pipes cannot be used for pipings whose outer diameter exceeds 20 mm.
  • Page 9 FILE NO. SVM-18047 d) Flare Processing Make certain that a clamp bar and copper pipe have been cleaned. ØD By means of the clamp bar, perform the flare processing correctly. Use either a flare tool for R32 or conven- tional flare tool. Flare processing dimensions differ according to the type of flare tool.
  • Page 10 FILE NO. SVM-18047 Table 3-2-6 Flare and flare nut dimensions for R22 Dimension (mm) Nominal Outer diameter Thickness Flare nut width diameter (mm) (mm) (mm) 6.35 9.52 13.0 13.5 12.70 16.2 16.0 12.9 15.88 19.7 19.0 16.0 19.05 23.3 24.0 19.2 Fig.
  • Page 11 FILE NO. SVM-18047 3-3. Tools 3-3-1. Required Tools The service port diameter of packed valve of the outdoor unit in the air-water heat pump using R32 is changed to prevent mixing of other refrigerant. To reinforce the pressure-resisting strength, flare processing dimensions and opposite side dimension of flare nut (For Ø12.7 copper pipe) of the refrigerant piping are lengthened.
  • Page 12 FILE NO. SVM-18047 3-4. Recharging of Refrigerant When it is necessary to recharge refrigerant, charge the specified amount of new refrigerant according to the following steps. Recover the refrigerant, and check no refrigerant remains in the equipment. When the compound gauge’s pointer has indicated –0.1 Mpa (–76 cmHg), place the handle Low in the fully closed position, and turn off the vacuum pump’s power switch.
  • Page 13 FILE NO. SVM-18047 1. Be sure to make setting so that liquid can be charged. 2. When using a cylinder equipped with a siphon, liquid can be charged without turning it upside down. It is necessary for charging refrigerant under condition of liquid because R32 is mixed type of refrigerant. Accordingly, when charging refrigerant from the refrigerant cylinder to the equipment, charge it turning the cylinder upside down if cylinder is not equipped with siphon.
  • Page 14 FILE NO. SVM-18047 2. Characteristics required for flux 3-5-3. Brazing • Activated temperature of flux coincides with the As brazing work requires sophisticated techniques, brazing temperature. experiences based upon a theoretical knowledge, it must be performed by a person qualified. •...

  • Page 15: Construction Views

    FILE NO. SVM-18047 4. CONSTRUCTION VIEWS 4-1. Indoor Unit Heat exchanger Plasma ion charger (Air puri er) Air lter Front panel " " " " " -" � ,-,iii' " llr--1 � � � � _.., o� � © 0 TI'@@[MJ O [ID&...

  • Page 16: Wiring Diagram

    FILE NO. SVM-18047 5. WIRING DIAGRAM - 16 -...

  • Page 17: Specifications Of Electrical Parts

    FILE NO. SVM-18047 6. SPECIFICATIONS OF ELECTRICAL PARTS 6-1. Indoor Unit Parts name Type Specif icat io ns Fan motor (for indoor) ICF-340U30-2 DC340, 30W Room temp. sensor (TA-sensor) ( - ) at 25°C Ω Heat exchanger temp. sensor (TC-sensor) 10kΩ...

  • Page 18: Refrigerant Cycle Diagram

    FILE NO. SVM-18047 7. REFRIGERANT CYCLE DIAGRAM 7-1. Refrigerant Cycle Diagram RAS-M10PKVPG-E RAS-M13PKVPG-E Temp. measurement INDOOR UNIT Indoor heat exchanger Cross flow fan Max. Min. Pressure measurement Deoxidized copper pipe Chargeless : * Gauge attaching port Outer dia. : 6.35mm Vacuum pump connecting port Thickness : 0.8mm...
  • Page 19 FILE NO. SVM-18047 RAS-M16PKVPG-E Temp. measurement INDOOR UNIT Indoor heat exchanger Cross flow fan Max. Pressure measurement Min. Deoxidized copper pipe Chargeless : * Gauge attaching port Outer dia. : 6.35mm Vacuum pump connecting port Thickness : 0.8mm Charge : * Sectional shape Deoxidized copper pipe of heat insulator...
  • Page 20 FILE NO. SVM-18047 7-2. Operation Data <Cooling> Tempeature Heat exchanger pipe Indoor fan Outdoor fan Standard Compressor Model name condition(°C) temp. mode mode pressure revolution RAS- P (MPa) (rps) Indoor Outdoor T1 (°C) T2 (°C) M10PKVPG-E 27/19 35/- M13PKVPG-E M16PKVPG-E <Heating>...

  • Page 21: Control Block Diagram

    FILE NO. SVM-18047 8. CONTROL BLOCK DIAGRAM 8-1. Indoor Unit M.C.U. Indoor Unit Control Unit Functions Heat Exchanger Sensor (TCJ) Louver Motor · Cold draft preventing Function Heat Exchanger Sensor (TC) · 3-minute Delay at Restart for Compressor Room Temperature Sensor (TA) Louver Motor ·...

  • Page 22: Operation Description

    FILE NO. SVM-18047 9. OPERATION DESCRIPTION 9-1. Outline of Air Conditioner Control • Detection of inverter input current and current release operation This air conditioner is a capacity-variable type air • Over-current detection and prevention operation to conditioner. Its system can control the speed of compressor motor according to load.
  • Page 23 FILE NO. SVM-18047 9-2. Operation Description 1. Basic operation ......................24 1. Operation control ....................24 2. Cooling/Heating operation ..................25 3. AUTO operation ..................... 25 4. DRY operation ......................25 2. Indoor fan motor control ..................... 26 Capacity control ......................29 Current release control ....................

  • Page 24: Basic Operation

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 1. Basic 1. Operation control operation Receiving the user’s operation condition setup, the operation statuses of indoor/outdoor units are controlled. 1) The operation conditions are selected by the remote controller as shown in the below. 2) A signal is sent by ON button of the remote controller.

  • Page 25: Cooling/Heating Operation

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 1. Basic 2. Cooling/Heating operation operation The operations are performed in the following parts by controls according to cooling/heating conditions. 1) Receiving the operation ON signal of the remote controller, the cooling or heating operation signal starts being transferred form the indoor controller to the outdoor unit.

  • Page 26: Indoor Fan Motor Control

    +1.5 *5 : Fan speed = (M + –L) x 1/4 + L +1.0 +0.5 (Linear approximation L(W7) from M+ and L) (Table 1) Indoor fan air flow rate RAS-M10PKVPG-E Mode Cooling Heating Fan speed level Cool Heat Fan speed...
  • Page 27 FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 2. Indoor fan motor control (Table 2) Indoor fan air flow rate RAS-M13PKVPG-E Mode Cooling Heating Fan speed level Cool Heat Fan speed Air flow rate Fan speed Air flow rate (rpm) (rpm) UH/H...
  • Page 28 FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 2. Indoor fan <In heating operation> 1) When setting the fan speed to L, motor control L+, M, M+, H or Quiet on the remote controller, the operation is per- formed with the constant speed HEAT ON shown in Fig.

  • Page 29: Capacity Control

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 3. Capacity The cooling or heating capacity depending on the load is 1) The difference between set control adjusted. temperature on remote controller (Ts) and room temperature (Ta) According to difference between the setup value of tempera- is calculated.

  • Page 30: Release Protective Control By Temperature Of Indoor Heat Exchanger

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 6. Release protective <In cooling/dry operation> 1) When temperature of the indoor control by tempera- heat exchanger drops below 5°C, (Prevent-freezing control for indoor heat exchanger) ture of indoor heat the compressor speed is In cooling/dry operation, the sensor of indoor heat exchanger...

  • Page 31: Louver Control

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 7. Louver control This function controls the air direction of the indoor unit. 1) Louver • The position is automatically controlled according to the operation position mode (COOL/HEAT). • The set louver position is stored in memory by the microcomputer, and the louver returns to the stored position when the next operation is performed.
  • Page 32 FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 7. Louver control 2) Louver position in heating operation Manual and automatic operation HI-POWER operation Initial setting is directs downward (73mm) Default setting is directs downward (45mm) Wide air direction Wide position is directs downward (73mm) Wide-angle Right wide...

  • Page 33: Wind Direction Adjustment

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 7. Louver control 2) Wind direction adjustment Horizotal blowing Inclined blowing • The Up-Down louver position can be arbitrarily set up by pressing [FIX ] button. • The Left-Right louver position can be arbitrarily set up by pressing [FIX...

  • Page 34: Eco Operation

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 8. ECO When pressing [ECO] button on the remote controller, a <Cooling operation> operation Economic operation is performed. 1) The control target temperature <Cooling operation> increase 0.5ºC per hour up to 2ºC This function operates the air conditioner with the difference starting from the set temperature between the set and the room temperature as shown in the...

  • Page 35: Temporary Operation

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 9. Temporary Pressing [RESET] button starts the temporary 1) When pressing [RESET] button, the operation operation of [AUTO] operation. When keeping temporary [AUTO] operation starts. [RESET] button pressed for 10 seconds or more, 2) When keeping [RESET] button pressed the temporary [COOL] operation is performed.

  • Page 36: Plasma Ionizer Purifier Control [Detection Of Abnormality]

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 1. Purpose 10. Plasma ionizer purifier control [Detection of abnormality] The air purifying control function is to alert the user to trouble in the plasma purifier Plasma purifier operation operation.

  • Page 37: Discharge Temperature Control

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 11. Discharge Refer to the service manual of outdoor unit temperature which combined. control 12. High pressure Please refer "Current release control" of outdoor unit control service manual. 13. Pulse Please refer "Current release control"...

  • Page 38: Self-Cleaning Function

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 14. Self-Cleaning 1. Purpose function The Self-Cleaning operation is to minimize the growth of mold, bacteria etc. by running the fan and drying so as to keep the inside of the air conditioner clean. Unit now performing cooling or dry operation Self-Cleaning operation When the cooling or dry operation shuts...
  • Page 39 FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 14. Self-Cleaning function 14-1-1. Self-Cleaning diagram Operation display FCU fan rpm is depend on presetting. (500RPM) FCU louver OPEN OPEN (12.7º) CLOSE ON or OFF ON or OFF Timer display depend on presetting of timer function.

  • Page 40: Remote-A Or B Selection

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 15. Remote-A or B Setting the remote controller 1. Purpose selection To separate using of remote control for each indoor This operation is to operate only one indoor unit using one remote controller. unit in case of 2 air conditioner are installed nearly.

  • Page 41: Short Timer

    FILE NO. SVM-18047 Item Operation flow and applicable data, etc. Description 18. Short Timer In the normal condition, after switching one circuit Purpose breaker, 3-minute delay time for compressor and To start the unit immediately for the purpose of 1 hour for plasma air purifier are set for the testing, trial...etc, short timer can be used.

  • Page 42: P Ower Selection Mode

    FILE NO. SVM-18047 Item Operation flow and applicable data,etc Description ([POWER-SEL] button on the remote controller 1. Purpose 20. POWER is pressed) Selection The function is used when its circuit Mode − Power Selection 75% is 75% of maximum breaker is shared with other electrical current.

  • Page 43: Outdoor Quiet Control

    As the maximum number of revolution of the compressor is restricted, the rise- up performance at the start time is weakened. <Maximum number of revolution of compressor at normal time and Quiet control time> RAS-M10PKVPG-E RAS-M13PKVPG-E RAS-M16PKVPG-E Outside temp. Normal time...

  • Page 44: Degree Heating / Frost Protective Operation

    FILE NO. SVM-18047 Item Operation flow and applicable data,etc Description 25. 8C heating Intended for cold latitudes and 8C Button on remote controller is pressed. / Frost performs objective heating operation. Set temperature is performed for 5C to 13C protective and no cold draft prevention control.

  • Page 45: Auto Restart Function

    FILE NO. SVM-18047 9-3. Auto Restart Function (Default setting from factory is ON) This indoor unit is equipped with an automatic restarting function which allows the unit to restart operating with the set operating conditions in the event of a power supply being accidentally shut down. The operation will resume without warning three minutes after power is restored.

  • Page 46: How To Cancel The Au To Restar T Function

    FILE NO. SVM-18047 9-3-2. How to Set the Auto Restart Function To set Auto Restart Function, proceed as follows: 1. The power supply to the unit must be ON ; The function will not set or reset if the power supply is OFF. 2.

  • Page 47: Parts Name Of Remote Contr Oller

    FILE NO. SVM-18047 9-4. Remote control 4-1. Remote control and its functions I nfrared signal emitter Memory and preset button (PRESET) Start/Stop button Temperature up/down button (TEMP.) Mode select button (MODE) Swing louver button (SWING) Fan speed button (FAN) Wide air flow, spot air flow (AIR FLOW) Set louver button for vertical direction (FIX ) Set louver button for Horizontal divection (FIX ) 8 degree celcius operation and fireplace function button (...
  • Page 48 FILE NO. SVM-18047 How to set WEEKLY TIMER Press to enter WEEKLY TIMER setting. Blink Press to select desired day in sequence. The sequence of day symbol appears on the LCD WEEKLY SUMO TUWETHFRSA (All day) Press to select the program number. •...
  • Page 49 FILE NO. SVM-18047 Press to select desired operation. Press to select desired temperature. • The temperature can be set between 17°C and 30°C. Press to select the desired fan speed. Add operations, if required. • Press to use 8°C operation. •...
  • Page 50 FILE NO. SVM-18047 Edit Weekly timer program To edit the program after confi rming the weekly timer setting on Page 23 , follow steps below. Press • The day of the week and the program number of the current day will be displayed. Press to select the day of the week and press to select program number to be confi...
  • Page 51 FILE NO. SVM-18047 To delete programs The individual program Press • The day of the week and the program number is displayed. • Select the day to delete the program. Press to select the program number to be deleted. Press •...
  • Page 52 FILE NO. SVM-18047 2. AUTOMATIC OPERATION To automatically select cooling, heating, or fan only operation. Press Press : Select Press Press : Select the desired temperature 3. Press Press : Select AUTO, LOW , LOW+ , MED , MED+ , HIGH or Quiet 3.
  • Page 53 FILE NO. SVM-18047 8. ECO OPERATION To automatically control room to save energy (except in DRY and FAN ONLY mode) Press : Start and stop the operation. Note: Cooling operation; the set temperature will increase automatically 1 degree/ hour for 2 hours (maximum 2 degrees increase). For heating operation the set temperature will decrease.
  • Page 54 FILE NO. SVM-18047 10. COMFORT AIR FLOW • Wide air flow : Air flows around the room. • Spot air flow : Air flow is concentrated at one point. While operating (Auto, Cool, Heat, Dry and these modes with PURE), Select •...
  • Page 55 FILE NO. SVM-18047 13. QUIET OPERATION To operate at ultra low fan speed for quiet operation (except in DRY mode) Press [Fan] Button : Start and stop the operation. Note: Under certain conditions, QUIET operation may not provide adequate cooling or heating due to low sound features. 14.

  • Page 56: Name And Functions Of Indications On Remote Controller

    FILE NO. SVM-18047 9-4-3. Name and Functions of Indications on Remote Controller [Display] All indications, except for the clock time indicator, are displayed by pressing the button. Transmission mark TIMER and weekly timer indicator This transmission mark indicates when the The time setting for timer operation and weekly remote controller transmits signals to the indoor timer function is indicated.

  • Page 57: Installation Procedure

    FILE NO. SVM-18047 10. INSTALLATION PROCEDURE 10-1. Installation Diagram of Indoor and Outdoor Units For the rear left and left piping Wall Hook Installation plate Insert the cushion between the indoor unit and wall, and tilt the indoor unit for better operation.
  • Page 58 FILE NO. SVM-18047 10-2. Installation 10-2-1. Optional installation parts Part Parts name Q'ty Code Refrigerant piping Liquid side : Æ6.35 mm Gas side : Æ9.52 mm (10k, 13k) each : Æ12.7 mm (16k) Pipe insulating material (polyethylene foam, 6 mm thick) Putty, PVC tapes each - 58 -...
  • Page 59 FILE NO. SVM-18047 10-2-2. Accessory and installation parts Part Part Part Part name (Q’ty) Part name (Q’ty) Part name (Q’ty) Installation plate* x 1 Owner's Manual Mounting screw** ∅4 x 25 s x 6 Flat head wood screw Wireless remote control* x 1 ∅3.1 x 16 s x 2 Installation Manual Drain nipple*** x 1...
  • Page 60 FILE NO. SVM-18047 10-2-3. Installation/Servicing Tools Changes in the product and components In the case of an air conditioner using R32, in order to prevent any other refrigerant from being charged accidentally, the service port diameter of the outdoor unit control valve (3 way valve) has been changed. (1/2 UNF 20 threads per inch) •...
  • Page 61 FILE NO. SVM-18047 10-3. Indoor Unit 10-3-2. Cutting a Hole and Mounting Installation Plate 10-3-1. Installation Place • A place which provides the spaces around the Cutting a hole indoor unit as shown in the diagram. When installing the refrigerant pipes from the rear. •...
  • Page 62 FILE NO. SVM-18047 When the installation plate is directly 10-3-3. Piping and Drain Hose Installation mounted on the wall Piping and drain hose forming 1. Securely fit the installation plate onto the wall by screwing it in the upper and lower parts to hook •...
  • Page 63 FILE NO. SVM-18047 How to remove the drain cap In case of right or left piping • Take off the cap by hand and cut of the slit. Clip the drain cap by needle-nose After scribing slits of the bush body with a knife or •...
  • Page 64 FILE NO. SVM-18047 Bend the connecting pipe within a radius of 30 mm. 10-3-4. Indoor Unit Fixing To connect the pipe after installation of the unit 1. Pass the pipe through the hole in the wall and hook (figure) the indoor unit on the installation plate at the upper Reference position of Liquid side and Gas side's hook.
  • Page 65 FILE NO. SVM-18047 10-3-6. Drainage CAUTION 1. Run the drain hose sloped downwards. Arrange the drain pipe for proper drainage from NOTE : the unit. Improper drainage can result in dew-dropping. • The hole should be made a slight downward slant on the outdoor side.
  • Page 66 FILE NO. SVM-18047 10-4. Electrical works RAS-M10PKVPG-E RAS-M13PKVPG-E RAS-M16PKVPG-E Model Power source 50Hz, 220 – 240 V Single phase Maximum running current Circuit breaker rating Power supply cable H07RN-F or 60245 IEC66 (1.5 mm or more) Connecting cable * Refer to service manual of the outdoor unit which combined.
  • Page 67 FILE NO. SVM-18047 10-4-2. Connecting Cable Connection Stripping length of the connecting cable Connecting cable Earth line Connecting cable 50 mm Connecting cable connect to 10 mm terminal block (1, 2, 3, ˙) 10 mm 45 mm CAUTION Power supply must input at Outdoor Unit Terminal Block. POWER INPUT WIRING DIAGRAM Power input to Outdoor Unit 1 2 3...
  • Page 68 FILE NO. SVM-18047 10-5. Others 10-6-3. Test operation To switch the TEST RUN (COOL) mode, press 10-5-1. Remote Control A-B Selection Temporary switch for 10 sec. (The unit will make a short Pi sound.) • When two indoor units are installed in the same room or adjacent two rooms, if operating a unit, two units may receive the remote control signal simultaneously and operate.

  • Page 69: How To Diagnose The Trouble

    FILE NO. SVM-18047 11. HOW TO DIAGNOSE THE TROUBLE The pulse motor circuits are mounted to both indoor and outdoor units. Therefore, diagnose troubles according to the trouble diagnosis procedure as described below. (Refer to the check points in servicing written on the wiring diagrams attached to the indoor/outdoor units.) Table 11-1 Troubleshooting Procedure First Confirmation...
  • Page 70 FILE NO. SVM-18047 11-1. First Confirmation 11-1-1. Confirmation of Power Supply Confirm that the power breaker operates (ON) normally. 11-1-2. Confirmation of Power Voltage Confirm that power voltage is AC 220–230–240 ± 10%. If power voltage is not in this range, the unit may not operate normally. 11-1-3.
  • Page 71 FILE NO. SVM-18047 11-2. Primary Judgment To diagnose the troubles, use the following methods. 1) Judgment by flashing LED of indoor unit 2) Self-diagnosis by service check remote controller 3) Judgment of trouble by every symptom Firstly use the method 1) for diagnosis. Then, use the method 2) or 3) to diagnose the details of troubles. 11-3.
  • Page 72 FILE NO. SVM-18047 11-4. S elf-Diagnos is by R emote C ontroller (C hec k C ode) 1. If the lamps are indicated as shown B to E in Table 11-4-1, execute the self-diagnosis by the remote controller. 2. When the remote controller is set to the service mode, the indoor controller diagnoses the operation condition and indicates the in formation of the self-diagnosis on the display of the remote controller with the check codes.
  • Page 73 FILE NO. SVM-18047 11-4-2 Caution at Servicing 1. After using the service mode of remote controller finished, press the [ ] button to reset the remote controller to normal function. 2. After finished the diagnosis by the remote controller, turn OFF power supply and turn its ON again to reset the air conditioner to normal operation.
  • Page 74 FILE NO. SVM-18047 Block distinction Operation of diagnosis function Action and Judgment Check Check Display flashing Block Cause of operation conditioner code code error status Serial signal 1) Defective wiring of the Indoor unit Flashes when 1) to 3) The outdoor unit never and connecting connecting cable or operates...
  • Page 75 FILE NO. SVM-18047 Block distinction Operation of diagnosis function Action and Judgment Check Check Display flashing Block Cause of operation conditioner code code error status Outdoor P.C. Current on inverter circuit All OFF Flashes after 1. Remove connecting lead wire of the board is over limit in short time.
  • Page 76 FILE NO. SVM-18047 Block distinction Operation of diagnosis function Action and Judgment Check Check Display flashing Block Cause of operation conditioner code code error status 1. Check installation conditions such as Outdoor P.C. Compressor drive output error. All OFF Flashes after (Relation of voltage, current error is detected packed valve opening, refrigerant...
  • Page 77 FILE NO. SVM-18047 Block distinction Operation of diagnosis function Action and Judgment Check Check Display Block Cause of operation conditioner code code flashing error status The others Compressor does not rotate. All OFF Flashes after 1. Remove connecting lead wire of the (including Because of missed wiring, error is detected...
  • Page 78 FILE NO. SVM-18047 Block distinction Operation of diagnosis function Action and Judgment Check Check Display Block Cause of operation conditioner code code flashing error status Return signal of the outdoor Indoor unit Flashes when 1. . Check power supply (Rate +10%) The others operates error is detected...
  • Page 79 FILE NO. SVM-18047 11-5. Judgement of Trouble by Every Symptom 11-5-1. Indoor unit (Including remote controller) Operation (1) Indoor unit is not operated. Check Item Considerable principle cause Turn off power supply once, and Measures 5 second later, turn it on again. Item by symptoms Is OPERATION indicator flashing? Is it possible to turn on...
  • Page 80 FILE NO. SVM-18047 (3) Only the indoor motor fan does not operate <Primary check> 1. Is it possible to detect the power supply voltage (AC220–240V) between on the terminal block? 2. Does the indoor fan motor operate in cooling operation? (In heating operation, the indoor fan motor does not operate for approximately 10 minutes after it is turned on, to prevent a cold air from blowing in.) Turn off power...
  • Page 81 FILE NO. SVM-18047 Is it possible to Does check display Replace change airflow level remote on remote show high? to “HIGH”? Change the new PC Replace board. Does fan speed motor change? Fan motor operates normally. Is it possible to Does check cross-flow Replace bearing rotate cross-flow fan by...
  • Page 82 FILE NO. SVM-18047 (4) Indoor fan motor automatically starts to rotate by turning on power supply <Cause> The IC is built in the indoor fan motor. Therefore the P.C. board is also mounted to inside of the motor. If the P .C. board is soldered imperfectly or the IC is defective, the fan motor may automatically rotate by turning on power supply.
  • Page 83 FILE NO. SVM-18047 (5) Troubleshooting for remote controller <Primary check> Check that A or B selected on the main unit is matched with A or B selected on the remote controller. There is no beep from the indoor unit Push the [ ] button.
  • Page 84 FILE NO. SVM-18047 11-5-2. Wiring Failure (Interconnecting and Serial Signal Wire) (1) Outdoor unit does not operate 1) Is the voltage between of the indoor terminal block varied? Confirm that transmission from indoor unit to outdoor unit is correctly performed based upon the follow- ing diagram.
  • Page 85 FILE NO. SVM-18047 11-6. Check Code 1C (Miswiring in indoor/outdoor units) and 1E <Check procedure> Gas leakage, Discharge temp. error, disconnection of TS/TC gas leakage sensors (Check code 02, 1C) (Check code 03, 1E) Does this model have P.M.V. or not? Valve drive check Is coil of the pulse motor valve Set it correctly.
  • Page 86 FILE NO. SVM-18047 11-7. How to Diagnose Trouble in Outdoor Unit • Connect discharge Check Power Supply resistance (approx. 100Ωı , (Voltage Rate ±10%) 40W) or soldering iron (plug) between +, –terminals of the electrolytic capacitor (760µF) Turn OFF power of C08 (with printed CAUTION supply.
  • Page 87 FILE NO. SVM-18047 Does outdoor fan operate normally? Turn OFF power supply. Does compresser operate normally? Remove connector CN31 of outdoor fan motor. Check winding resistance by ohmmeter are correct? Compressor Check rotor locking by rotate is normal with hand. Can it rotate? Turn OFF power supply.
  • Page 88 FILE NO. SVM-18047 Turn off the power breaker once, and turn on again after 10 seconds. Does the OPERATION indicator flash? To item “Power supply is not turned on” Turn off the power breaker and remove CN401 (Micro switch connector). Short-circuit between of CN401 at PC side, and turn on the power breaker after 10 seconds.
  • Page 89 FILE NO. SVM-18047 11-9. How to Check Simply the Main Parts (2) Inspection procedures 1) When a P.C. board is judged to be defective, 11-9-1. How to check the P.C. board (Indoor unit) check for disconnection, burning, or discolora- tion of the copper foil pattern or this P.C. board. (1) Operating precautions 2) The P.C.
  • Page 90 FILE NO. SVM-18047 11-9-2. P .C . Board Layout +15V +12V [1] Sensor characteristic table : Discharge temp. sensor : Room temp. sensor TC and TCJ : Heat exchanger temp. sensor TA,TC,TCJ Temperature (°C) - 90 -...
  • Page 91 FILE NO. SVM-18047 11-9-3. Indoor Unit (Other Parts) Part name Checking procedure Room temp. (TA) sensor Disconnect the connector and measure the resistance value with tester. Heat exchanger (TC,TCJ) (Normal temp.) sensor Temperature 10°C 20°C 25°C 30°C 40°C Sensor TA, TC, TCJ (kΩ) 20.7 12.6 10.0...

  • Page 92: How To Replace The Main Parts

    FILE NO. SVM-18047 12. HOW TO REPLACE THE MAIN PARTS WARNING • Since high voltages pass through the electrical parts, turn off the power without fail before proceeding with the repairs. Electric shocks may occur if the power plug is not disconnected. •...
  • Page 93 FILE NO. SVM-18047 Part name Work procedure Remarks BUSH-BODY(R) 1) Push the bottom of part and slide to the BUSH-BODY(R) BUSH-BODY(L) right side. BUSH-BODY(L) 1) Push the bottom of part and slide to the left side. The claw of Front panel must <Point to note during re-assemble be lower ASM-FRAME Front panel>...
  • Page 94 FILE NO. SVM-18047 Part name Work procedure Remarks Electric parts 7) Disconnect the connector of box assembly. fan-motor, louver-motor and high voltage generator and cord Wi-Fi connector. High voltage generator connector Wi-Fi cord connector Louver motor Wi-Fi cord connector connector Fan motor 8) Pull out TCJ sensor from sensor holder of the evaporator.
  • Page 95 FILE NO. SVM-18047 Part name Work procedure Remarks Frame 1) Follow to the procedure 2) Remove the fixing screws at COVER-WIFI 1 Pcs. than take off wifi-cord out from hook lock. Screw 3) Remove the Fixing screws at ASM-FRAME (5 Pcs). 2 Screws Screws 4) Remove screw of earth lead on plate earth.
  • Page 96 FILE NO. SVM-18047 Part name Work procedure Remarks Plasma-ion 1) Follow to the procedure in the item charger, High 3 Screws 2) Remove 3 screws and remove the ion- volt generator charger assembly from the frame. 3) Remove the Plasma-ion charger from the High volt generator assembly.
  • Page 97 FILE NO. SVM-18047 Part name Work procedure Remarks Evaporator 1) Follow the procedure in item (Heat exchanger) 2) Remove 2 fixing screws at the left side of the end plate of the heat exchanger. Fixing screw 3) Remove 2 fixing screws on the right side of heat exchanger.
  • Page 98 FILE NO. SVM-18047 Part name Work procedure Remarks Fan motor 1) Follow the procedure 2) Remove 3 fixing screws, then remove Cover motor assembly. Fixing screw 3) Loosen the set screws of the transverse fan from the vent. Set screw 4) Remove 2 screws from the Motor- band (right) 5) Pull the motor band(right) and the Fan-...
  • Page 99 FILE NO. SVM-18047 Part name Work procedure Remarks 1) Follow to the procedure in the item Bearing Base bearing assembly 2) Remove 2 fixing screws from the Base bearing assembly, then remove Base bearing assembly from the main unit. <Caution at assembling> - If the bearing is out from the housing, Fixing screw push it into the specified position and then...
  • Page 100 FILE NO. SVM-18047 Part name Work procedure Remarks Cross flow fan <Caution at reassemblying> 1) To incorporate the Fan-motor incorporate Fan motor D Double point set shaft screw the Motor into the position in the following figure, and then install the Fan-motor - Install the cross flow fan so that the right end of the 1st joint from the right of the Cross flow fan is set keeping 5.0mm...

  • Page 101: Exploded Views And Parts List

    FILE NO. SVM-18047 13. EXPLODED VIEWS AND PARTS LIST 13-1. Indoor Unit Location Part Location Part Description Description 43T00731 ASM-PANEL(R)-S 43T11331 PIPE-SHIELD 43T00732 ASM-PANEL(L)-S HOLDER-PIPE 43049799 43005871 ASM-PANEL(AOLT) ASM-COVER-CONN 43T62352 43T09545 ASM-AINL-S 43T83305 HOLDER, REMOTE CONTROL 43T02306 ASM-BUSH-BODY(R) 43T66376 WIRELESS REMOCO 43T02307 ASM-BUSH-BODY(L) 4306A194...
  • Page 102 FILE NO. SVM-18047 13-2. Indoor Unit (E-Parts Assy) Location Part Location Part Description Description 43T6W349 43T50324 SENSOR; HEAT EXCHANGER PC BOARD (10k) 43T50320 SENSOR; HEAT EXCHANGER 43T6W350 PC BOARD (13k) 43T50355 PC BOARD (16k) TEMPERATURE SENSOR 43T6W351 43T62340 CORD-CLAMP TERMINAL 43T60378 43T6V469 PC BOARD ASSY:WRS-LED...
  • Page 103 144/9 MOO 5, BANGKADI INDUSTRIAL PARK, TIVANON ROAD, TAMBOL BANGKADI, AMPHUR MUANG, PATHUMTHANI 12000, THAILAND.

This manual is also suitable for:

Ras-m13pkvpg-eRas-m16pkvpg-e
