VEHICULAR SLIDE GATE OPERATOR
LiftMaster
300 Windsor Drive
Oak Brook, IL 60523
COMMERCIAL DC
INSTALLATION MANUAL
Access installation and technical support guides or register this product
HDSL24ULTECH
• THIS PRODUCT MUST BE INSTALLED AND
SERVICED IN ACCORDANCE WITH THIS
MANUAL BY A TRAINED GATE SYSTEMS
TECHNICIAN ONLY.
• This operator is for use on vehicular passage
gates ONLY and not intended for use on
pedestrian passage gates.
• HDSL24UL is intended for use in Class I, II,
III, and IV vehicular slide gate applications.
• HDFSL24UL is intended for use in Class III
and IV vehicular slide gate applications
ONLY.
• Visit LiftMaster.com to locate a professional
installing dealer in your area.
• This gate operator is compatible with MyQ
and Security+ 2.0
accessories.
®
HDFSL24ULTECH
®
Take a photo of the
1.
camera icon including
the points ( ).
Send it in by texting
2.
the photo to 71403.
