Model No. PFSB63131
Serial No.
The serial number is on a sign
behind the access panel. Write the
serial number in the space above.
Access
Panel
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The technicians on our customer
hot line will provide immediate
assistance, free of charge.
CUSTOMER HOT LINE:
1-888-884-6555
Mon.–Fri., 8 a.m.–5 p.m. CST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Pro-Form STORM
Summary of Contents for Pro-Form STORM
- Page 1 Model No. PFSB63131 Serial No. USER’S MANUAL The serial number is on a sign behind the access panel. Write the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
Table of Contents Posting the Warning Sign ..............2 Important Safety Instructions . -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 10. - Page 4 20. DANGER—Risk of electric shock. Keep all physician before using the hydrotherapy spa. electrical appliances such as radios, tele- Pregnant women should not use the spa if phones, televisions, and lights at least five the water temperature is above 100°F; the feet away from the water.
- Page 5 35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.
-
Page 6: Before You Begin
Congratulations for selecting the new PROFORM ® For your benefit, read this manual carefully before STORM hydrotherapy spa. The innovative STORM using the hydrotherapy spa. If you have questions spa allows you to enjoy all the benefits of hydrothera- after reading the manual, please call our Customer py in the comfort and privacy of your home. -
Page 7: Choosing A Location For The Hydrotherapy Spa
Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa. -
Page 8: Assembly
Assembly Before beginning assembly, carefully read the ASSEMBLY REQUIRES THE FOLLOWING following information and instructions: TOOLS (not included): • Place all parts in a cleared area and remove the • One phillips screwdriver packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is A wire connector is provided on the electronics completed and the spa is operating. - Page 9 3. Insert the Pillow (38) into the lounge seat recepta- cle. Note: Rotate the Pillow 180º to change between the high and low positions. 4. The spa should be located near a power source capable of supplying 240 volts AC power. It must be wired directly into a grounded circuit with a 45 amp circuit breaker and a Ground Fault Circuit Interrupter (GFCI) capable of carrying 45 amps.
-
Page 10: Using The Hydrotherapy Spa
Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat seven 4. Turn the power on. The spa will begin an auto- adults. The spa holds approximately 375 gallons of matic priming sequence. water and offers a heating system (80°F to 104°F), a filtration system, and adjustable hydrotherapy jets. - Page 11 8. After one minute, the current temperature of the Once you have tested the GFCI, verify that water is water will be displayed. Push the temperature up flowing from the jets. Set the air controls to the lowest or down button to set the temperature of the setting (see USING THE CONTROLS on page 13).
-
Page 12: Spa Shell Diagram
Jet Layout Diagram A. The underwater light can be used for night opera- G. The four neck jets can be adjusted to spray sooth- tion. The spa includes both red and blue covers for ing water on your neck. the light. H. -
Page 13: Using The Controls
Using the Controls Waterfall Valve Air Controls 1, 2, and 3 Waterfall Waterfall Waterfall Valve Blower Mode Button Button Display Pump Pump Light Temperature Button 1 Button 2 Button Buttons current only when pump 1 has been operating for two minutes. “Std” displays momentarily when the Standard mode is selected. - Page 14 Your spa features an LED light with ten different The Temperature Buttons control the temperature set- programmed lighting effects: ting of the water. The temperature setting can be from 1. White 80°F to 104°F. The startup temperature is set at 2.
-
Page 15: Maintenance
Maintenance The hydrotherapy spa is designed to provide years of MAINTAINING THE SPA COVER enjoyment. Please follow the guidelines below to properly maintain your spa. The spa cover should be cleaned monthly. To clean the spa cover, use water and a non-abrasive cleaner MAINTENANCE SCHEDULE on the entire cover. - Page 16 WATER CHEMISTRY To maintain the proper pH level, test the pH of the water regularly. To test the water, purchase a pH test Maintaining the pH level of the water is very important kit at a pool and spa supply store. The pH reading to the operation of the spa.
- Page 17 ATTACHING AND REMOVING THE ACCESS To drain the hydrotherapy spa, follow the steps below: PANELS 1. Using the console, adjust the temperature to the Turn off the spa power. To remove the indicated lowest setting. Access Panels (25), remove the eight #10 x 2” 2.
- Page 18 DRAINING THE PUMPS REPLACING THE LED LIGHT After the hydrotherapy spa is drained, the jet pumps Remove the access panels (see ATTACHING AND should also be drained if the spa will be stored for REMOVING THE ACCESS PANELS on page 17). more than thirty days or if it may be exposed to freez- Make sure the spa power is turned off.
-
Page 19: Troubleshooting
Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-888-884-6555, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1. - Page 20 9. SYMPTOM: THE WATER LEVEL DROPS 11. SYMPTOM: THE CONSOLE DISPLAYS “--,” “OHH,” “ICE,” “SnA,” “SnB,” “SnS,” “HFL,” a. A clamp or seal inside the pump compartment “LF,” “dr,” “OHS,” or “drY” may be loose. Check inside the pump compart- ment for excess water and watch the pump unit a.
- Page 21 NOTES...
-
Page 22: Part List
Part List—Model No. PFSB63131 R0404A Key No. Qty. Description Key No. Qty. Description Console Overlay 3-wire Power Cord Blower Filter Cover 1/4” Washer Rubber Washer Face Plate Filter Panel Rubber Isolator Heater Collar Small Adjustable Pulsating Jet Drain Plug O-ring Volcano Jet Filter Housing #8 x 1”... - Page 23 Model No. PFSB63131 R0404A...
-
Page 24: Ordering Replacement Parts
• The MODEL NUMBER of the product (PFSB63131) • The NAME of the product (PROFORM STORM hydrotherapy spa) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and the EXPLODED DRAWING on...
