Ultra Tugger
for use with Greenlee 640 and 6001
99950286 REV 4
INSTRUCTION MANUAL
11147
®
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com
© 2019 Greenlee Tools, Inc.
Adapter Package
10/19
Advertisement
Table of Contents
Related Manuals for Greenlee Ultra Tugger 11147
Summary of Contents for Greenlee Ultra Tugger 11147
- Page 1 INSTRUCTION MANUAL 11147 Ultra Tugger Adapter Package ® for use with Greenlee 640 and 6001 Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 99950286 REV 4 ©...
-
Page 2: Table Of Contents
All specifications are nominal and may change as design improvements occur. Greenlee Tools, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. Tugger, Super Tugger and Ultra Tugger are registered trademarks and VersiBoom is a trademark of Greenlee Tools, Inc. -
Page 3: Important Safety Information
• Do not allow any personnel to stand in line with the Failure to observe this warning, could result in severe pulling rope. injury or death. Failure to observe these warnings could result in severe injury or death. Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 4 Failure to observe this warning could result in severe injury or death. For use only with Greenlee Model 640 and 6001 cable pullers. Use with other pullers may result in insecure mount- ing and improper rope alignment.
-
Page 5: Identification-Boom Mount Adapter
Length......................94 cm (37 in) Width ......................18 cm (7 in) Height ......................30 cm (12 in) Use with: Greenlee 640 and 6001 Cable Pullers only Load Rating ....................... 6500 lb Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 6: Identification-Versiboom™ Components
4. Sight Hole 11. Hitch Pin Clips 5. Boom Mount Adapter 12. 3' Boom Tube (optional) 6. T-Stand (optional) 13. Long Pin 7. Wheeled Carriage 14. Tray Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 7: Setup
Slide the puller up against the stop and chain it down securely. For use only with Greenlee Model 640 and 6001 cable pullers. Use with other pullers may result in insecure mount- ing and improper rope alignment. -
Page 8: Mounting Components
Set up the elbow unit as shown. STRAIGHT EDGE Improper setup will cause the elbow unit to collapse. Failure to observe this warning could result in severe injury or death. Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 9 Sight the tube through the sight hole to be sure the tube is fully inserted. Tighten the set screw. Sight Hole Sight Hole Sight Hole Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 10 Secure the pins with hitch pin clips. Nose Unit Coupler Coupler Pin secured with Conduit must not Hitch Pin Clip protrude past here Support Structure Pull Conduit Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 11: Typical Setups
ON/OFF switch. Pulling Up Using One Boom, Nose Unit and Slip-in Coupler Pulling Up Using Two Booms, Nose Unit, Elbow Unit and Slip-in Coupler Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 12 Pulling Horizontally in Manhole Using Two Booms, Nose Unit, Elbow Unit and Slip-in Coupler Pulling Horizontally in Manhole Using Two Booms, Nose Unit, Elbow Unit and Slip-in Coupler Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 13: Illustration And Parts List-Boom Mount Adapter
Pin, roll, .187 x 1.5" ................... 1 90503023 Clip, hitch pin #8 ..................1 Screw, 3/8-16 x 1" hex head ..............1 50009206 Wheel unit ....................1 50167987 Bushing ..................... 2 Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 14: Accessories
Puller pin kit (includes one each of the items marked with an asterisk) ............2 50061925 Elbow shaft kit (includes one of item 3 and two of item 5) ................2 Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 15: Elbow Unit
Elbow pins kit (includes one each of the items marked with an asterisk) ............1 50061950 Pivot pins kit (includes one of item 4 and two of item 6) ......1 Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 16: Couplers
Screw ......................1 50007963 Handle ....................... 1 90527178 Roll pin ...................... 1 Boom Tubes Part No. Description 50008358 3' Boom tube .................... 1 50007912 4' Boom tube .................... 1 Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 17: T-Stand
Puller pin kit (includes one each of the items marked with an asterisk) ............2 52066231 Wheel service kit (set of 4) ................ 1 52066332 Wheel service kit (single wheel) ..............1 Greenlee Tools, Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 18 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 USA Tel: 800-435-0786 Canada Tel: 800-435-0786 International Tel: +1-815-397-7070 ©2019 Greenlee Tools, Inc. • An ISO 9001 Company Fax: 800-451-2632 Fax: 800-524-2853 Fax: +1-815-397-9247 www.greenlee.com...
