AudioCodes RXV100Hub – Microsoft® Teams Rooms (MTR)
1. Before Getting Started
Congratulations on purchasing the AudioCodes RXV100Hub! This guide describes how to install the
RXV100Hub and pair it with your RX50.
2. Installing RXV100Hub
Use the diagram below as a reference to installing your RXV100Hub.
Note that the maximum UCB length is 3 meters
Note that the active USB extension cable can extend USB 3.0 connections up to ~30 meters
Installation & Getting Started Guide
P a g e
| 1
Advertisement
Related Manuals for AudioCodes RXV100Hub
Summary of Contents for AudioCodes RXV100Hub
- Page 1 AudioCodes RXV100Hub – Microsoft® Teams Rooms (MTR) Installation & Getting Started Guide 1. Before Getting Started Congratulations on purchasing the AudioCodes RXV100Hub! This guide describes how to install the RXV100Hub and pair it with your RX50. 2. Installing RXV100Hub Use the diagram below as a reference to installing your RXV100Hub.
- Page 2 Make sure the RXV100Hub | RX50 are in the same network. 4. Providing MTR Credentials When the RXV100Hub is switched on for the first time, Microsoft Teams Rooms (MTR) credentials must be provided to sign in. To provide MTR credentials: In the RXV100Hub Setup Wizard, select Keyboard (English - US) and Region.
- Page 3 On the RX50 screen, view Pairing activated. View also the pairing icon in the top right corner and MTR Audio (instead of Offline) in the top left corner. After they’re paired, log in to the RXV100Hub as Administrator and set RX50 to be its default audio device.
- Page 4 To perform a recovery process, use the Microsoft Teams Recovery Tool available at (https://docs.microsoft.com/en-us/MicrosoftTeams/rooms/recovery-tool) The RXV100Hub supports Windows Push Button Reset (PBR) functionality. This feature restores the device to its factory state. To reset the RXV100Hub to its factory state using PBR: Connect an external keyboard to the RXV100Hub via one of the USB ports.
