Page 2 This section tells you when to perform vehicle maintenance and what fluids and lubricants to use. Customer Assistance Information This section tells you how to contact Chevrolet for assistance and how to get service and owner publications. It also gives you information on “Reporting Safety Defects” on page 8 Index Here’s an alphabetical listing of almost every subject in this manual.
Page 3 For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division whenever it appears in this manual. Please keep this manual in your vehicle, so it will be there if you ever need it when you’re on the road.
Page 4: How To Use This Manual
How to Use this Manual Many people read their owner’s manual from beginning to end when they first receive their new vehicle. If you do this, it will help you learn about the features and controls for your vehicle. In this manual, you’ll find that pictures and words work together to explain things quickly.
Page 5: Vehicle Damage Warnings
Vehicle Damage Warnings Also, in this book you will find these notices: NOTICE: These mean there is something that could damage your vehicle. In the notice area, we tell you about something that can damage your vehicle. Many times, this damage would not be covered by your warranty, and it could be costly.
Page 6: Vehicle Symbols
Vehicle Symbols These are some of the symbols you may find on your vehicle. For example, These symbols these symbols are important are used on an for you and original battery: your passengers whenever your vehicle is CAUTION driven: POSSIBLE INJURY DOOR LOCK PROTECT...
Page 7 yellowblue NOTES...
Page 8: Table Of Contents
Section 1 Seats and Restraint Systems Here you’ll find information about the seats in your vehicle and how to use your safety belts properly. You can also learn about some things you should not do with air bags and safety belts. Seats and Seat Controls Safety Belts: They’re for Everyone Here Are Questions Many People Ask About...
Page 9: Seats And Seat Controls
Seats and Seat Controls This section tells you how to adjust the seats and explains reclining seatbacks and head restraints. Manual Front Seat CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving.
Page 10 6-Way Power Driver’s Seat (If Equipped) This switch is designed to control the movements of your seat cushion. It is located on the left side of the driver’s seat cushion. To move the seat forward or rearward, push the switch forward or rearward. To raise or lower the seat, push the switch up or down.
Page 11: Reclining Front Seatbacks
Heated Front Seat (If Equipped) If your vehicle is equipped with this feature, both the driver’s and passenger’s heated seat switches are on the outboard side of the seat near the front. Press LO to warm the seat to a lower temperature. Press HI to warm the seat to a higher temperature.
Page 12 yellowblue CAUTION: Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts can’t do their job when you’re reclined like this. The shoulder belt can’t do its job because it won’t be against your body.
Page 13: Head Restraints
Head Restraints Slide the head restraint up or down so that the top of the restraint is closest to the top of your ears. This position reduces the chance of a neck injury in a crash. Split Folding Rear Seat You can fold either side of the seatback down in your vehicle for more cargo space.
Page 14 To raise the rear seatback, follow these steps: 1. Raise the seatback up and make sure it latches. Push and pull on the seatback to be sure it is locked in position. 2. Reconnect the center safety belt latch plate to the buckle.
Page 15: Safety Belts: They're For Everyone
Safety Belts: They’re for Everyone This part of the manual tells you how to use safety belts properly. It also tells you some things you should not do with safety belts. And it explains the air bag system. CAUTION: Don’t let anyone ride where he or she can’t wear a safety belt properly.
Page 16: Why Safety Belts Work
You never know if you’ll be in a crash. If you do have a crash, you don’t know if it will be a bad one. A few crashes are mild, and some crashes can be so serious that even buckled up a person wouldn’t survive. But most crashes are in between.
Page 17 yellowblue Put someone on it. Get it up to speed. Then stop the vehicle. The rider doesn’t stop. 1-10...
Page 18 yellowblue The person keeps going until stopped by something. or the instrument panel ... In a real vehicle, it could be the windshield ... 1-11...
Page 19: Here Are Questions Many People Ask About Safety Belts -- And The Answers
or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense. 1-12 Here Are Questions Many People Ask About Safety Belts...
Page 20: How To Wear Safety Belts Properly
If I’m a good driver, and I never drive far from home, why should I wear safety belts? You may be an excellent driver, but if you’re in an accident even one that isn’t your fault your passengers can be hurt. Being a good driver doesn’t protect you from things beyond your control, such as bad drivers.
Page 21 3. Pick up the latch plate and pull the belt across you. Don’t let it get twisted. The shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly.
Page 22 yellowblue 5. To make the lap part tight, pull down on the buckle The lap part of the belt should be worn low and snug on end of the belt as you pull up on the shoulder belt. the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones.
Page 23 Shoulder Belt Height Adjuster Before you begin to drive, move the shoulder belt adjuster to the height that is right for you. 1-16 To move it down, squeeze the release lever and the shoulder belt guide as shown and move the height adjuster to the desired position.
Page 24 What’s wrong with this? The shoulder belt is too loose. It won’t give nearly as much protection this way. CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body.
Page 25 What’s wrong with this? The belt is buckled in the wrong place. 1-18 CAUTION: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not at the pelvic bones.
Page 26 What’s wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. CAUTION: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury.
Page 27 What’s wrong with this? The belt is twisted across the body. 1-20 CAUTION: You can be seriously injured by a twisted belt. In a crash, you wouldn’t have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to fix it.
Page 28: Safety Belt Use During Pregnancy
To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.
Page 29: Right Front Passenger Position
The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash. For pregnant women, as for anyone, the key to making safety belts effective is wearing them properly.
Page 30 CAUTION: You can be severely injured or killed in a crash if you aren’t wearing your safety belt have air bags. Wearing your safety belt during a crash helps reduce your chance of hitting things inside the vehicle or being ejected from it. Air bags are “supplemental restraints”...
Page 31 CAUTION: Both frontal and side impact air bags inflate with great force, faster than the blink of an eye. If you’re too close to an inflating air bag, as you would be if you were leaning forward, it could seriously injure you. Safety belts help keep you in position for air bag inflation before and during a crash.
Page 32 There is an air bag readiness light on the instrument panel, which shows the air bag symbol. The system checks the air bag electrical system for malfunctions. The light tells you if there is an electrical problem. See “Air Bag Readiness Light” in the Index for more information.
Page 33 The right front passenger’s frontal air bag is in the instrument panel on the passenger’s side. 1-26 The driver’s side impact air bag is in the side of the driver’s seatback closest to the door. yellowblue...
Page 34 CAUTION: If something is between an occupant and an air bag, the bag might not inflate properly or it might force the object into that person. The path of an inflating air bag must be kept clear. Don’t put anything between an occupant and an air bag, and don’t attach or put anything on the steering wheel hub or on or near any other air bag covering and don’t let seat covers block the...
Page 35 What makes an air bag inflate? In an impact of sufficient severity, the air bag sensing system detects that the vehicle is in a crash. For both frontal and side impact air bags, the sensing system triggers a release of gas from the inflator, which inflates the air bag.
Page 36 CAUTION: When an air bag inflates, there is dust in the air. This dust could cause breathing problems for people with a history of asthma or other breathing trouble. To avoid this, everyone in the vehicle should get out as soon as it is safe to do so. If you have breathing problems but can’t get out of the vehicle after an air bag inflates, then get fresh air by opening a window or a door.
Page 37: Center Front Passenger Position
Servicing Your Air Bag-Equipped Vehicle Air bags affect how your vehicle should be serviced. There are parts of the air bag systems in several places around your vehicle. Your dealer and the service manual have information about servicing your vehicle and the air bag systems.
Page 38 When you sit in the center front seating position, you have a lap safety belt, which has no retractor. To make the belt longer, tilt the latch plate and pull it along the belt. To make the belt shorter, pull its free end as shown until the belt is snug.
Page 39: Rear Seat Passengers
Rear Seat Passengers It’s very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety belts. Rear passengers who aren’t safety belted can be thrown out of the vehicle in a crash.
Page 40 yellowblue If the belt stops before it reaches the buckle, tilt the 3. To make the lap part tight, pull down on the buckle latch plate and keep pulling until you can buckle it. end of the belt as you pull up on the shoulder part. Pull up on the latch plate to make sure it is secure.
Page 41 yellowblue The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you’d be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen.
Page 42 yellowblue CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body. To unlatch the belt, just push the button on the buckle. 1-35...
Page 43: Rear Safety Belt Comfort Guides
Rear Safety Belt Comfort Guides for Children and Small Adults Rear shoulder belt comfort guides will provide added safety belt comfort for children who have outgrown child restraints and for small adults. When installed on a shoulder belt, the comfort guide pulls the belt away from the neck and head.
Page 44 2. Slide the guide under and past the belt. The elastic cord must be under the belt. Then, place the guide over the belt, and insert the two edges of the belt into the slots of the guide. 3. Be sure that the belt is not twisted and it lies flat. The elastic cord must be under the belt and the guide on top.
Page 45: Children
4. Buckle, position and release the safety belt as described in “Rear Seat Passenger Positions” earlier in this section. Make sure that the shoulder belt crosses the shoulder. To remove and store the comfort guides, squeeze the belt edges together so that you can take them out from the guides.
Page 46 CAUTION: Smaller children and babies should always be restrained in a child or infant restraint. The instructions for the restraint will say whether it is the right type and size for your child. A very young child’s hip bones are so small that a regular belt might not stay low on the hips, as it should.
Page 47 CAUTION: Never hold a baby in your arms while riding in a vehicle. A baby doesn’t weigh much crash. During a crash a baby will become so heavy you can’t hold it. For example, in a crash CAUTION: (Continued) 1-40 CAUTION: (Continued) at only 25 mph (40 km/h), a 12 will suddenly become a 240...
Page 48: Child Restraints
Child Restraints Every time infants and young children ride in vehicles, they should have protection provided by appropriate restraints. What are the different types of add child restraints? on child restraints are available in four basic types. When selecting a child restraint, take into consideration not only the child’s weight and size, but also whether or not the restraint will be compatible with the motor vehicle in which it...
Page 49 yellowblue A rear facing infant restraint (B) positions an infant to face the rear of the vehicle. Rear facing infant restraints are designed for infants of up to about 20 lbs. (9 kg) and about one year of age. This type of restraint faces the rear so that the infant’s head, neck and body can have the support they need in a frontal crash.
Page 50 yellowblue A forward facing child restraint (C E) positions a child upright to face forward in the vehicle. These forward facing restraints are designed to help protect children who are from 20 to 40 lbs. (9 to 18 kg) and about 26 to 40 inches (66 to 102 cm) in height, or up to around four years of age.
Page 51 A booster seat (F) is designed for children who are about 40 to 60 lbs., or even up to 80 lbs. (18 to 27 kg, or even up to 36 kg), and about four to eight years of age. A booster seat is designed to improve the fit of the vehicle’s safety belt system.
Page 52 Where to Put the Restraint Accident statistics show that children are safer if they are restrained in the rear rather than the front seat. We at General Motors therefore recommend that you put your child restraint in the rear seat. Never put a rear child restraint in the front passenger seat.
Page 53: Top Strap
Top Strap Canadian law requires that forward facing child restraints have a top strap, and that the strap be anchored. If your child restraint has a top strap, it should be anchored. Your vehicle has top strap anchors already installed for the rear seating positions.
Page 54 Securing a Child Restraint in a Rear Seat Position CAUTION: A child in a child restraint in the center front seat can be badly injured or killed by the right front passenger air bag if it inflates. Never secure a child restraint in the center front seat.
Page 55 3. Tilt the latch plate to adjust the belt if needed. If the shoulder belt goes in front of the child’s face or neck, put it behind the child restraint. 1-48 4. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
Page 56: Front Seat Position
5. To tighten the belt, pull up on the shoulder belt while you push down on the child restraint. If you’re using a forward facing child restraint, you may find it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 57 Although a rear seat is a safer place, you can secure a forward facing child restraint in the right front seat. You’ll be using the lap shoulder belt. See the earlier part about the top strap if the child restraint has one. Be sure to follow the instructions that came with the child restraint.
Page 58 5. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to. 6. To tighten the belt, pull up on the shoulder belt while you push down on the child restraint. You may find it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 59: Larger Children
Larger Children Children who have outgrown child restraints should wear the vehicle’s safety belts. If you have the choice, a child should sit next to a window so the child can wear a lap get the additional restraint a shoulder belt can provide. 1-52 Accident statistics show that children are safer if they are restrained in the rear seat.
Page 60 CAUTION: Never do this. Here two children are wearing the same belt. The belt can’t properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A belt must be used by only one person at a time. What if a child is wearing a lap but the child is so small that the shoulder belt is very close to the child’s face or neck?
Page 61 1-54 CAUTION: Never do this. Here a child is sitting in a seat that has a shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt. The belt’s force would then be applied right on the child’s abdomen.
Page 62: Safety Belt Extender
Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt isn’t long enough to fasten, your dealer will order you an extender. It’s free. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you.
Page 63 yellowblue NOTES 1-56...
Page 64 Section 2 Features and Controls Here you can learn about the many standard and optional features on your vehicle, and information on starting, shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is working properly and what to do if you have a problem.
Page 65 yellowblue Keys CAUTION: Leaving children in a vehicle with the ignition key is dangerous for many reasons. A child or others could be badly injured or even killed. They could operate power windows or other controls or even make the vehicle move. Don’t leave the keys in a vehicle with children.
Page 66 One key is for the ignition, the doors and all other locks. If you ever do get locked out of your vehicle, call the Chevrolet Roadside Assistance Center at CHEV . (In Canada call 1 NOTICE: Your vehicle has a number of features that can help prevent theft.
Page 67: Door Locks
Door Locks CAUTION: Unlocked doors can be dangerous. Passengers especially children open the doors and fall out. When a door is locked, the inside handle won’t open it. Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. This may not be so obvious: You increase the chance of being thrown out of the vehicle in a crash if the doors aren’t locked.
Page 68: Power Door Locks
Power Door Locks Press the power door lock switch on the driver’s or front passenger’s door to lock or unlock all doors. The rear doors do not have power door lock switches. The lever on each rear door works only that door’s lock. It won’t lock or unlock all the doors.
Page 69: Leaving Your Vehicle
Rear-Door Security Locks Your vehicle is equipped with rear door security locks that help prevent passengers from opening the rear doors of your vehicle from the inside. To use one of these locks: 1. Open one of the rear doors. 2.
Page 70 Changes or modifications to this system by other than an authorized service facility could void authorization to use this equipment. At times you may notice a decrease in range. This is normal for any remote keyless entry system. If the transmitter does not work or if you have to stand closer to your vehicle for the transmitter to work, try this: Check to determine if battery replacement is...
Page 71: Matching Transmitter(S) To Your Vehicle
Panic Alarm Button This feature allows you to activate an alarm by pressing a button on the RKE transmitter. Your vehicle’s ignition must be off for the instant alarm to work. When you press the horn button on the RKE transmitter, your vehicle’s headlamps will flash, the horn will honk repeatedly and your interior lamps will illuminate attracting attention if you need it.
Page 72: Battery Replacement
Battery Replacement Under normal use, the battery in your remote keyless entry transmitter should last about three years. You can tell the battery is weak if the transmitter won’t work at the normal range in any location. If you have to get close to your vehicle before the transmitter works, it’s probably time to change the battery.
Page 73 Resynchronization After you have changed the battery in your transmitter, you will need to resynchronize the transmitter. To do this, press the LOCK and UNLOCK buttons on the transmitter together and hold for approximately seven seconds or until three brief horn chirps are heard. Trunk CAUTION: It can be dangerous to drive with the trunk lid...
Page 74: Remote Trunk Release
Trunk Lock To unlock the trunk from the outside, insert the key and turn it. You can also press the car symbol on your remote keyless entry transmitter. Remote Trunk Release You can also unlock the trunk from inside the vehicle. Press the button located below the headlamp control knob on the underside of the dashboard.
Page 75 Parking at Night Park in a lighted spot, close all windows and lock your vehicle. Remember to keep your valuables out of sight. Put them in a storage area, or take them with you. Parking Lots If you park in a lot where someone will be watching your vehicle, it’s best to lock it up and take your keys.
Page 76: Disarming With Your Key
Once armed, the alarm will go off if someone tries to enter the vehicle (without using the remote keyless entry transmitter or a key) or turns the ignition on with an incorrect key. The horn will sound and your vehicle’s parking lamps will flash for 110 seconds.
Page 77: Vehicle Customization Settings
Vehicle Customization Settings Some of your vehicle’s convenience features can be reset or customized to perform according to your preference. Customization cannot be changed with the AM radio. See your dealer to have the settings changed. The features you can program depend upon the options that came with your vehicle.
Page 78 The following information shows how to reset or customize features after entering the main menu: SETTINGS Display Current Settings OIL LIFE Oil Life Reset: This feature allows you to reset the GM Oil Life System after an oil change, see “Engine Oil”...
Page 79 AUTOLOCK (Automatic Door Lock and Unlock): With the ignition in ON and the vehicle’s doors closed, this feature allows the vehicle doors to automatically lock and unlock when the driver shifts the vehicle’s transaxle into and out of PARK (P). To customize the automatic door lock and unlock: 1.
Page 80 FOB HORN (Remote Audible Verification): This feature allows the horn to chirp when the remote keyless entry transmitter is used to lock or unlock the vehicle. To customize remote audible verification 1. Scroll, using the SEEK up or down arrows, until FOB HORN appears on the display.
Page 81 TRNKJAMB (Trunk Jamb): This feature allows the content theft system trunk lock sensor to be disabled or enabled. To customize the trunk lock sensor: 1. Scroll, using the SEEK up or down arrows, until TRNKJAMB appears on the display. 2. Press the PREV or NEXT button to enter the submenu.
Page 82 Your vehicle is not protected by Passlock at this time. You may also want to check the fuse (see “Fuses and Circuit Breakers” in the Index). See your dealer for service. In an emergency, call the Chevrolet Roadside Assistance USA R (1 Center at 1...
Page 83: Ignition Switch
New Vehicle “Break In” NOTICE: Your vehicle doesn’t need an elaborate “break in.” But it will perform better in the long run if you follow these guidelines: Don’t drive at any one speed slow for the first 500 miles (805 km). Don’t make full throttle starts.
Page 84: Starting Your Engine
NOTICE: If your key seems stuck in OFF and you can’t turn it, be sure you are using the correct key; if so, is it all the way in? If it is, then turn the steering wheel left and right while you turn the key hard.
Page 85: Starting Your 3400 V6 Engine
Starting Your 3400 V6 Engine 1. Without pushing the accelerator pedal, turn your ignition key to START. When the engine starts, let go of the key. The idle speed will go down as your engine gets warm. NOTICE: Holding your key in START for longer than 15 seconds at a time will cause your battery to be drained much sooner.
Page 86 Starting Your 3800 Series II V6 Engine 1. Without pushing the accelerator pedal, turn your ignition key to START. When the engine starts, let go of the key. The idle speed will go down as your engine gets warm. NOTICE: Holding your key in START for longer than 15 seconds at a time will cause your battery to be drained much sooner.
Page 87 Engine Coolant Heater (If Equipped) In very cold weather, 0 _ F ( 18 _ C) or colder, the engine coolant heater can help. You’ll get easier starting and better fuel economy during engine warm the coolant heater should be plugged in a minimum of four hours prior to starting your vehicle.
Page 88: Automatic Transaxle Operation
4. Before starting the engine, be sure to unplug and store the cord as it was before to keep it away from moving engine parts. If you don’t, it could be damaged. How long should you keep the coolant heater plugged in? The answer depends on the outside temperature, the kind of oil you have, and some other things.
Page 89 The above graphic is also displayed on your instrument panel cluster. Maximum engine speed is limited on automatic transaxle vehicles when you’re in PARK (P) or NEUTRAL (N) to protect driveline components from improper operation. There are several different positions for your shift lever. PARK (P): This locks your front wheels.
Page 90 Make sure the shift lever is fully in PARK (P) before starting the engine. Your vehicle has an automatic transaxle shift lock control system. You must fully apply your regular brakes before you can shift from PARK (P) when the ignition is in ON. If you cannot shift out of PARK (P), ease pressure on the shift lever by pushing it all the way into PARK (P) while keeping the brake pedal pushed down.
Page 91 AUTOMATIC OVERDRIVE ( ): This position is for normal driving. If you need more power for passing, and you’re: Going less than 35 mph (55 km/h), push your accelerator pedal about halfway down. Going about 35 mph (55 km/h) or more, push the accelerator pedal all the way down.
Page 92 NOTICE: Don’t drive in SECOND (2) for more than 25 miles (40 km), or at speeds over 55 mph (90 km/h), or you can damage your transaxle. Use AUTOMATIC OVERDRIVE ( THIRD (3) as much as possible. Don’t shift into SECOND (2) unless you are going slower than 65 mph (105 km/h), or you can damage your engine.
Page 93: Parking Brake
Parking Brake To set the parking brake, hold the regular brake pedal down with your right foot. Push down the parking brake pedal with your left foot. To release the parking brake, hold the regular brake pedal down with your right foot and push the parking brake pedal with your left foot.
Page 94 Shifting Into PARK (P) CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake firmly set. Your vehicle can roll. If you have left the engine running, the vehicle can move suddenly.
Page 95 Move the lever up as far as it will go. 3. Turn the ignition key to OFF. 4. Remove the key and take it with you. If you can leave your vehicle with the ignition key in your hand, your vehicle is in PARK (P). 2-32 Console Shift 1.
Page 96: Torque Lock
Leaving Your Vehicle With the Engine Running CAUTION: It can be dangerous to leave your vehicle with the engine running. Your vehicle could move suddenly if the shift lever is not fully in PARK (P) with the parking brake firmly set. And, if you leave the vehicle with the engine running, it could overheat and even catch fire.
Page 97: Parking Over Things That Burn
Shifting Out of PARK (P) Your vehicle has an automatic transaxle shift lock control system. You must fully apply your regular brakes before you can shift from PARK (P) when the ignition is in ON. See “Automatic Transaxle Operation” in the Index. If you cannot shift out of PARK (P), ease pressure on the shift lever by pushing it all the way into PARK (P) while keeping the brake pedal pushed down.
Page 98: Engine Exhaust
Engine Exhaust CAUTION: Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you can’t see or smell. It can cause unconsciousness and death. You might have exhaust coming in if: Your exhaust system sounds strange or different. Your vehicle gets rusty underneath.
Page 99: Power Windows
CAUTION: It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake firmly set. Your vehicle can roll. Don’t leave your vehicle when the engine is running unless you have to. If you’ve left the engine running, the vehicle can move suddenly.
Page 100 The driver’s window switch has an express feature. This switch is labeled AUTO. Tap the rear of the switch, and the driver’s window will open a small amount. If the rear of the switch is pressed all the way down, the window will go all the way down. To stop the window while it is lowering, press the front of the switch.
Page 101: Turn Signal And Lane Change Indicator
Turn Signal/Multifunction Lever The lever on the left side of the steering column includes your: Turn Signal and Lane Change Indicator Headlamp High/Low Beam Changer Flash Pass Windshield Wipers Windshield Washer Cruise Control ON/OFF Switch 2-38 Turn Signal and Lane Change Indicator The turn signal has two upward (for right) and two downward (for left) positions.
Page 102: Headlamp High/Low Beam Changer
Turn Signal On Chime If you leave either one of your turn signals on and drive more than 3/4 mile (1.2 km), a chime will sound to alert you. Headlamp High/Low Beam Changer To change your headlamps from low beams to high beams, or high to low, pull the multifunction lever all the way toward you.
Page 103: Windshield Washer
Windshield Wipers When the ignition key is in ACC or ON, you control the windshield wipers by turning the band marked WIPER. For a single wiping cycle, turn the band to MIST. Hold it there until the wipers start, then let go. The wipers will stop after one cycle.
Page 104: Cruise Control
Cruise Control With cruise control, you can maintain a speed of about 25 mph (40 km/h) or more without keeping your foot on the accelerator. This can really help on long trips. Cruise control does not work at speeds below about 25 mph (40 km/h).
Page 105 Resuming a Set Speed Suppose you set your cruise control at a desired speed and then you apply the brake. This, of course shuts off the cruise control. But you don’t need to reset it. Once you’re going about 25 mph (40 km/h) or more, press the RESUME button on your steering wheel.
Page 106 Passing Another Vehicle While Using Cruise Control Use the accelerator pedal to increase your speed. When you take your foot off the pedal, your vehicle will slow down to the cruise speed you set earlier. Using Cruise Control on Hills How well your cruise control will work on hills depends upon your speed, load and the steepness of the hills.
Page 107: Exterior Lamps
Exterior Lamps The lamp controls are located on the instrument panel. They control these systems: Headlamps Taillamps Parking Lamps License Lamps Instrument Panel Lights Dome Lamp Fog Lamps 2-44 If you pull the knob out halfway, it will turn on your parking lamps and your other operating lamps.
Page 108: Daytime Running Lamps
Daytime Running Lamps Daytime Running Lamps (DRL) can make it easier for others to see the front of your vehicle during the day. DRL can be helpful in many different driving conditions, but they can be especially helpful in the short periods after dawn and before sunset.
Page 109: Interior Lamps
Fog Lamps (If Equipped) To turn the fog lamps on, press the fog lamps switch located next to the exterior lamp control on the left side of the steering column. A light will glow on the switch to let you know that they are on.
Page 110: Reading Lamps
Delayed Entry Lighting Delayed entry lighting illuminates your vehicle’s interior for a period of time after all the doors have been closed. The ignition must be off for delayed entry lighting to work. Just after all the doors have been closed, the delayed entry lighting feature will continue to work until: the ignition is in ON, the doors are locked or...
Page 111: Battery Rundown Protection
Battery Rundown Protection Your vehicle has a feature to help prevent you from draining the battery in case you accidentally leave the interior courtesy lamps, reading/map lamps, visor vanity lamps, trunk lamp or glove box lamps on. If you leave any of these lamps on, they will automatically turn off after 10 minutes, if the ignition is in OFF.
Page 112: Power Outside Mirrors
Electrochromic Automatic Dimming Rearview Mirror (If Equipped) Your vehicle may have an electrochromic day/night rearview mirror. Push the button in the center of the mirror to turn this feature on. The mirror will darken gradually to reduce glare from headlamps behind you. This may take a few moments.
Page 113: Storage Compartments
Convex Outside Mirror Your passenger’s side mirror is convex. A convex mirror’s surface is curved so you can see more from the driver’s seat. CAUTION: A convex mirror can make things (like other vehicles) look farther away than they really are. If you cut too sharply into the right lane, you could hit a vehicle on your right.
Page 114: Ashtrays And Lighter
Ashtrays and Lighter The center front ashtray may be on the instrument panel or on the console. To remove the instrument panel ashtray, open it, push down on the locking tab and pull out the ashtray. To remove the console ashtray, open the ashtray door, lift up on the ashtray and pull it out.
Page 115: Auxiliary Power Connection
Accessory Power Receptacle Your vehicle has a 12 volt outlet. Vehicles without a center console, it is located in the ashtray. Vehicles with a center console, it is located at the rear of the console. NOTICE: Adding some electrical equipment to your vehicle can damage it or keep other things from working as they should.
Page 116: Garment Hooks
NOTICE: Adding some electrical equipment to your vehicle can damage it or keep other things from working as they should. This wouldn’t be covered by your warranty. Check with your dealer before adding electrical equipment, and never use anything that exceeds the fuse rating.
Page 117 Power Sunroof (Option) Your vehicle may have an express open sunroof. It includes a sliding and tilting glass panel. The control switch works only when the ignition is in ACC, ON or with the retained accessory power. The control switch is located on the overhead console.
Page 118: Programming The Transmitter
Universal Transmitter (If Equipped) This transmitter allows you to consolidate the functions of up to three individual hand held transmitters. It will operate garage doors and gates, or with the accessory package, other devices controlled by radio frequency such as home/office lighting systems and security systems. The transmitter will learn and transmit the frequencies of most current transmitters and is powered by your vehicle’s battery and charging system.
Page 119: Operating The Transmitter
2. Hold the end of the hand held transmitter against the bottom surface of the universal transmitter so that you can still see the red light. 3. Decide which one of the three channels you want to program. Using both hands, press the hand transmitter button and the desired button on the universal transmitter.
Page 120 To determine if your garage door opener has this “rolling code” feature, press the appropriate button on the universal transmitter that was programmed. If the red light flashes rapidly for one to two seconds, then turns solid, your garage door opener has this feature. To program a garage door opener with the rolling code feature, do the following: 1.
Page 121 The Instrument Panel The main components of your instrument panel are: A. Instrument Panel Fuse Block B. Multifunction Lever C. Hazard Warning Flasher Switch D. Audio System E. Climate Controls 2-58 Your Information System F. Center Console Shift Lever (If Equipped) G.
Page 122: Instrument Panel Cluster
yellowblue Instrument Panel Cluster Standard Cluster: United States Version Shown, Canadian Similar Your instrument cluster is designed to let you know at a glance how your vehicle is running. You’ll know how fast you’re going, about how much fuel is in your tank and many other things you need to drive safely and economically. 2-59...
Page 123 yellowblue Optional Cluster: United States Version Shown, Canadian Similar 2-60...
Page 124: Speedometer And Odometer
Speedometer and Odometer Your speedometer lets you see your speed in both miles per hour (mph) and kilometers per hour (km/h). Your odometer shows how far your vehicle has been driven in either miles (used in the United States) or in kilometers (used in Canada).
Page 125: Safety Belt Reminder Light
Warning Lights, Gages and Indicators This part describes the warning lights and gages that may be on your vehicle. The pictures will help you locate them. Warning lights and gages can signal that something is wrong before it becomes serious enough to cause an expensive repair or replacement.
Page 126: Air Bag Readiness Light
Air Bag Readiness Light There is an air bag readiness light on the instrument panel, which shows the air bag symbol. The system checks the air bag’s electrical system for malfunctions. The light tells you if there is an electrical problem. The system check includes the air bag sensors, the air bag modules, the wiring and the crash sensing and diagnostic module.
Page 127: Brake System Warning Light
Brake System Warning Light Your vehicle’s hydraulic brake system is divided into two parts. If one part isn’t working, the other part can still work and stop you. For good braking, though, you need both parts working well. If the warning light comes on, there is a brake problem. Have your brake system inspected right away.
Page 128 Anti-Lock Brake System Warning Light (Option) The anti lock brake system warning light should come on for a few seconds when you turn the ignition key to ON. If the anti lock brake system warning light stays on longer than normal after you’ve started your engine, turn the ignition off.
Page 129: Engine Coolant Temperature Gage
If the traction control system warning light comes on and stays on for an extended period of time when the system is turned on, your vehicle needs service. Engine Coolant Temperature Gage United States Standard States Cluster 2-66 Canada This gage shows the engine coolant temperature. It also provides an indicator of how hard your vehicle is working.
Page 130: Malfunction Indicator Lamp
Malfunction Indicator Lamp (Check Engine Light) United States Your vehicle is equipped with a computer which monitors operation of the fuel, ignition and emission control systems. This system is called OBD II (On Board Diagnostics Second Generation) and is intended to assure that emissions are at acceptable levels for the life of the vehicle, helping to produce a cleaner environment.
Page 131 This light should come on, as a check to show you it is working, when the ignition is on and the engine is not running. If the light doesn’t come on, have it repaired. This light will also come on during a malfunction in one of two ways: Light Flashing A misfire condition has been...
Page 132 Are you low on fuel? As your engine starts to run out of fuel, your engine may not run as efficiently as designed since small amounts of air are sucked into the fuel line causing a misfire. The system can detect this. Adding fuel should correct this condition.
Page 133 Low Oil Pressure Light This message is displayed when the engine oil pressure is low. A chime will sound continuously, also. If this occurs, have your vehicle serviced immediately. CAUTION: Don’t keep driving if the oil pressure is low. If you do, your engine can become so hot that it catches fire.
Page 134: Message Center
Fuel Gage United States Standard States Cluster Canada The fuel gage, when the ignition is on, tells you about how much fuel you have left in your tank. The gage will first indicate empty before you are out of fuel, and you should get more fuel as soon as possible. Here are four situations you may experience with your fuel gage.
Page 135 Modes SERVICE TRACTION SYSTEM If this message appears when you are driving, there is a problem with your traction control system and your vehicle is in need of service. When this message is displayed, the system will not limit wheel spin. The message will stay on for 60 seconds and then go out.
Page 136 HOT COOLANT TEMP This message is displayed when the cooling system temperature gets hot. A chime will sound continuously, also. Check the coolant temperature gage and the coolant level. See “Engine Coolant” and “Engine Coolant Temperature Gage” in the Index. See “Engine Overheating”...
Page 137 CHANGE ENGINE OIL This message is displayed when the engine oil needs to be changed. When you change the engine oil, be sure to reset the GM Oil Life System See “Engine Oil, When to Change” in the Index. DOOR AJAR This message will appear if the driver’s door or one of the passenger’s doors is not...
Page 138 LOW WASHER FLUID This message is displayed when the vehicle is low on windshield washer fluid. The message is only displayed for 60 seconds at the start of each ignition cycle. For more information see, “Windshield Washer Fluid” in the Index. LOW TIRE PRESSURE The low tire pressure system monitors the...
Page 139 SERVICE VEHICLE SOON This message will come on if you have a certain emissions vehicle problems. These problems may not be so obvious and may not affect vehicle performance or durability. Consult a qualified dealership for necessary repairs to maintain top vehicle performance.
Page 140 Driver Information Center (DIC) (Option) Sunroof (Optional) Version Shown The DIC will show information about the vehicle and the surroundings. RESET (Reset Button): You can reset the AVG ECON, FUEL USED or AVG SPEED trip computer modes by pressing and holding this button for three seconds while you are in the mode you wish to reset.
Page 141: Compass Variance
Compass Variance Compass variance is the difference between magnetic north and geographic north. In some areas of the country, the difference is great enough to cause the compass to give false readings. If this occurs, the compass variance must be set. Setting the Variance 2-78 Turn the ignition on and cycle the DIC to the...
Page 142: Trip Computer
Manual Compass Calibration If the compass appears erratic and the calibration symbol does not appear, you must manually put the compass into the calibration mode. Turn the ignition on and cycle the DIC to the Compass/Temperature mode. Press the RESET button for at least 10 seconds until the calibration symbol appears and all segments of the compass display are illuminated.
Page 143 yellowblue NOTES 2-80...
Page 144 Section 3 Comfort Controls and Audio Systems In this section, you’ll find out how to operate the comfort control and audio systems offered with your vehicle. Be sure to read about the particular systems supplied with your vehicle. Comfort Controls Manual Single Zone Climate Control Dual ComforTemp Climate Control (If Equipped)
Page 145: Comfort Controls
Comfort Controls Manual Single Zone Climate Control With this system, you can control the heating, cooling and ventilation in your vehicle. The system works best if you keep your windows closed while using it. Fan Knob The knob on the left side of the climate control panel controls the fan speed.
Page 146 DEFOG: This setting sends half of the air to the floor ducts and half to the defroster and side window outlets. The air conditioning compressor will run automatically in this setting unless the outside temperature is below 40 _ F (4 _ C). Air inlet will also be automatically set to outside air.
Page 147 Dual ComforTemp Climate Control (If Equipped) With this system, you can control the heating, cooling and ventilation in your vehicle. The system works best if you keep your windows closed while using it. Fan Knob The knob on the left side of the climate control panel controls the fan speed.
Page 148 Mode Knob The knob on the right side of the control panel has several settings to control the direction of airflow: UPPER: This setting directs air through the instrument panel outlets. LEV: This setting directs air two ways. Half of the air is directed through the instrument panel outlets.
Page 149: Air Conditioning
Air Conditioning On very hot days, open the windows long enough to let hot, inside air escape. This reduces the time for the vehicle to cool down. Then keep your windows closed for the air conditioner to work its best. For quick cool down on very hot days, turn the mode knob on the control panel to UPPER, push the A/C...
Page 150: Rear Window Defogger
Rear Window Defogger The rear window defogger uses a warming grid to remove fog from the rear window. Press the button marked turn the defogger on. An indicator on the button will light. The rear window defogger will turn itself off after about 15 minutes.
Page 151: Ventilation System
Ventilation System Adjust the direction of airflow by moving the vents. Your vehicle’s flow through ventilation system supplies outside air into the vehicle when it is moving. Outside air will also enter the vehicle when the air conditioning fan is running and the OUTSIDE AIR button is pushed. If the airflow seems very low when the fan is adjusted to the highest setting, regardless of the mode setting, your passenger compartment air filter (if equipped) may need to...
Page 152: Audio Systems
Audio Systems Your audio system has been designed to operate easily and give years of listening pleasure. You will get the most enjoyment out of it if you acquaint yourself with it first. Find out what your audio system can do and how to operate all its controls, to be sure you’re getting the most out of the advanced engineering that went into it.
Page 153 AM FM Stereo Playing the Radio PWR VOL: Press this knob to turn the system on and off. To increase volume, turn the knob clockwise. Turn it counterclockwise to decrease volume. RCL TUNE: Press this knob to recall the station being played or to display the clock.
Page 154 Setting the Tone BASS: Press and release AUDIO repeatedly until BAS appears on the display. Then press and hold the up arrow to increase bass. “B” and a positive number will appear on the display. Press and hold the down arrow to decrease bass.
Page 155 FADE: Press and release AUDIO until FAD appears on the display. Then press and hold the up arrow to move the sound to the front speakers or the down arrow to move the sound to the rear speakers. “F” and a number will appear on the display when the sound is balanced toward the front speakers.“R”...
Page 156 AUTO VOL: Your system has a feature called Speed Compensated Volume (SCV). With SCV, your audio system adjusts automatically to make up for road and wind noise as you drive. Set the volume at the desired level. Press AUTO VOL to adjust the SCV. AVOL will appear on the display.
Page 157 P SCAN: Press and hold one of the arrows for more than two seconds. The radio will produce one beep. Use P SCAN to listen to each of your favorite stations stored on your pushbuttons for a few seconds. The radio will scan through each of the stations stored on your pushbuttons, except those stations with weak reception.
Page 158 Adjusting the Speakers BAL: Press and release the AUDIO knob until BAL appears on the display. Turn the knob clockwise to move the sound to the right speakers and counterclockwise to move the sound to the left speakers. The middle position balances the sound between the speakers.
Page 159 Accessing RDS Mode: 1. Push the SEEK TYPE button or rotate the P LIST/AUDIO knob to display the program type list. 2. Turn knob either clockwise or counterclockwise to select a program type. List is alphabetical. 3. Push SEEK TYPE button to activate search. VOL: Turn this knob clockwise to increase volume when RDS interrupts regular play.
Page 160 ALERT!: This type of announcement warns of national or local emergencies. You will not be able to turn off alert announcements. ALERT! appears on the display when an alert announcement plays. When an alert announcement comes on the tuned radio station, you will hear it, even if the volume is muted or a cassette tape or compact disc is playing.
Page 161 FWD (4): Press this button to advance quickly to another part of the tape. Press the button again to return to playing speed. The radio will play the last selected station while the tape advances. You may select stations during FWD operation by using TUNE, SEEK and P SCAN controls.
Page 162 Tight/Loose Tape Sensor Defeat With the radio off and the ignition on, press and hold the TAPE AUX button to disable the tight/loose tape sensing feature to enable play of some tape head cleaners and portable CD adapters. The radio will display READY and flash the cassette icon.
Page 163 NEXT (2): Press this button to go to the next track. TRACK and the track number will appear on the display. If you hold the button or press it more than once, the player will continue moving forward through the disc. The sound will mute while seeking. REV (3): Press and hold this button to reverse quickly within a track.
Page 164 TAPE AUX: With a cassette tape in the player and the radio playing, press this button to play a cassette tape. Press AM FM to return to the radio when a cassette tape is playing. Press TAPE AUX to switch between the tape and compact disc if both are loaded.
Page 165 AUTO VOL: Your system has a feature called Speed Compensated Volume (SCV). With SCV, your audio system adjusts automatically to make up for road and wind noise as you drive. Set the volume at the desired level. Press AUTO VOL to adjust the SCV. AVOL will appear on the display.
Page 166 Setting the Tone BASS: Press and release the AUDIO knob until BASS appears on the display. Then turn the knob clockwise to increase bass and counterclockwise to decrease bass. The display will show the bass level. When you use this control, the radio’s AUTO TONE setting will switch to manual and the AUTO TONE display will go blank.
Page 167 RDS features are only available for use on FM stations which broadcast RDS information. The RDS features of your radio rely upon receiving specific RDS information from these stations. These features will only work when the RDS information is available. In rare cases, a radio station may broadcast incorrect information that will cause the radio features to work improperly.
Page 168 TYPE: Turn this knob clockwise or counterclockwise to select the Program Type (PTY) you want to listen to. TYPE and a PTY will appear on the display. See “Radio Data System (RDS) Program Type (PTY) Selections” in the Index. SEEK TYPE: Press this button to go to a station with the last selected PTY TYPE and the last selected PTY will appear on the display, if it is not already showing.
Page 169 Playing a Compact Disc Insert a disc partway into the slot, label side up. The player will pull it in. The disc should begin playing. The display will show the CD symbol. If you want to insert a compact disc with the ignition off, first press DISP or EJT. If you’re driving on a very rough road or if it’s very hot, the disc may not play and Err (error) may appear on the display.
Page 170 RDM (6): Press this button to hear the tracks in random, rather than sequential, order. RDM ONE will show on the display. RDM T and the track number will appear on the display when each track starts to play. Press RDM again to turn off random play.
Page 171 AUTO VOL: Your system has a feature called Speed Compensated Volume (SCV). With SCV, your audio system adjusts automatically to make up for road and wind noise as you drive. Set the volume at the desired level. Press AUTO VOL to adjust the SCV. AVOL will appear on the display.
Page 172 The channel number (P1 P6) will appear with the frequency. In FM mode, this function will scan through the current band such as FM1 and FM2. Setting the Tone BASS: Press and release the P TYPE LIST/AUDIO knob until BASS appears on the display. Then turn the knob clockwise to increase bass and counterclockwise to decrease bass.
Page 173 Using RDS Mode Your audio system is equipped with a Radio Data System (RDS). RDS mode gives you many useful new features. With RDS, the radio can: seek only to stations with the types of programs you want to listen to, seek to stations with traffic announcements, receive announcements concerning local and national emergencies and...
Page 174 INFO: If the current station has a message, the INFO icon will appear on the display. Press this button to see the message. If the whole message does not appear on the display, each time you press this button, the next part of the message will appear on the display until the message is completed.
Page 175 Playing a Cassette Tape Your tape player is built to work best with tapes that are up to 30 to 45 minutes long on each side. Tapes longer than that are so thin they may not work well in this player.
Page 176 SEEK (6): Seek is the same as NEXT, and "" SEEK is the same as PREV. If the button is held or pressed more than once, the player will continue moving forward or backward through the tape. SEEK and a positive or negative number will appear on the display.
Page 177 NEXT (2): Press this button to go to the next track. TRACK and the track number will appear on the display. If you hold the button or press it more than once, the player will continue moving forward through the disc. The sound will mute while seeking. REV (3): Press and hold this button to reverse quickly within a track.
Page 178: Audio Steering Wheel Controls
Theft-Deterrent Feature THEFTLOCK is designed to discourage theft of your radio. The feature works automatically by learning a portion of the Vehicle Identification Number (VIN). If the radio is moved to a different vehicle, it will not operate and LOC will be displayed. With THEFTLOCK activated, your radio will not operate if stolen.
Page 179: Understanding Radio Reception
SEEK TYPE: Press this button to go to a station with the last selected PTY TYPE and the last selected PTY will appear on the display, if it is not already showing. If a station with the selected PTY is not found, the radio will return to the original station.
Page 180 Tips About Your Audio System Hearing damage from loud noise is almost undetectable until it is too late. Your hearing can adapt to higher volumes of sound. Sound that seems normal can be loud and harmful to your hearing. Take precautions by adjusting the volume control on your radio to a safe sound level before your hearing adapts to it.
Page 181: Care Of Your Cassette Tape Player
Care of Your Cassette Tape Player A tape player that is not cleaned regularly can cause reduced sound quality, ruined cassettes or a damaged mechanism. Cassette tapes should be stored in their cases away from contaminants, direct sunlight and extreme heat. If they aren’t, they may not operate properly or may cause failure of the tape player.
Page 182 If your vehicle is equipped with the AM Cassette Tape Player with Radio Data System and Automatic Tone Control or the AM Cassette Tape and Compact Disc Player with Radio Data System and Automatic Tone Control: Turn the ignition to ON or ACC. Turn the radio off.
Page 183: Backglass Antenna
Backglass Antenna Your AM FM antenna is integrated with your rear window defogger, located in the rear window. Be sure that the inside surface of the rear window is not scratched and that the lines on the glass are not damaged.
Page 184 Section 4 Your Driving and the Road Here you’ll find information about driving on different kinds of roads and in varying weather conditions. We’ve also included many other useful tips on driving. Defensive Driving Drunken Driving Control of a Vehicle Braking Steering Road Recovery...
Page 185: Defensive Driving
Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your vehicle: Buckle up. (See “Safety Belts” in the Index.) Defensive driving really means “be ready for anything.” On city streets, rural roads or freeways, it means “always expect the unexpected.”...
Page 186: Drunken Driving
Drunken Driving Death and injury associated with drinking and driving is a national tragedy. It’s the number one contributor to the highway death toll, claiming thousands of victims every year. Alcohol affects four things that anyone needs to drive a vehicle: Judgment Muscular Coordination Vision...
Page 187 It’s the amount of alcohol that counts. For example, if the same person drank three double martinis (3 ounces or 90 ml of liquor each) within an hour, the person’s BAC would be close to 0.12 percent. A person who consumes food just before or during drinking will have a somewhat lower BAC level.
Page 188 The body takes about an hour to rid itself of the alcohol in one drink. No amount of coffee or number of cold showers will speed that up. “I’ll be careful” isn’t the right answer. What if there’s an emergency, a need to take sudden action, as when a child darts into the street? A person with even a moderate BAC might not be able to react quickly enough to avoid the collision.
Page 189: Control Of A Vehicle
Control of a Vehicle You have three systems that make your vehicle go where you want it to go. They are the brakes, the steering and the accelerator. All three systems have to do their work at the places where the tires meet the road. Sometimes, as when you’re driving on snow or ice, it’s easy to ask more of those control systems than the tires and road can provide.
Page 190 Avoid needless heavy braking. Some people drive in spurts heavy acceleration followed by heavy braking rather than keeping pace with traffic. This is a mistake. Your brakes may not have time to cool between hard stops. Your brakes will wear out much faster if you do a lot of heavy braking.
Page 191 Here’s how anti lock works. Let’s say the road is wet. You’re driving safely. Suddenly an animal jumps out in front of you. You slam on the brakes. Here’s what happens with ABS. A computer senses that wheels are slowing down. If one of the wheels is about to stop rolling, the computer will separately work the brakes at each front wheel and at both rear wheels.
Page 192 Remember: Anti lock doesn’t change the time you need to get your foot up to the brake pedal or always decrease stopping distance. If you get too close to the vehicle in front of you, you won’t have time to apply your brakes if that vehicle suddenly slows or stops.
Page 193 When the system is on, this warning light will come on to let you know if there’s a problem. See “Traction Control System Warning Light” in the Index. When this warning light is on, the system will not limit wheel spin. Adjust your driving accordingly. To limit wheel spin, especially in slippery road conditions, you should always leave the Traction Control System on.
Page 194: Steering
Braking in Emergencies At some time, nearly every driver gets into a situation that requires hard braking. If you have anti lock, you can steer and brake at the same time. However, if you don’t have anti first reaction to hit the brake pedal hard and hold it down may be the wrong thing to do.
Page 195: Steering In Emergencies
Suppose you’re steering through a sharp curve. Then you suddenly apply the brakes. Both control systems steering and braking have to do their work where the tires meet the road. Unless you have four wheel anti lock brakes, adding the hard braking can demand too much of those places.
Page 196: Off - Road Recovery
An emergency like this requires close attention and a quick decision. If you are holding the steering wheel at the recommended 9 and 3 o’clock positions, you can turn it a full 180 degrees very quickly without removing either hand. But you have to act fast, steer quickly, and just as quickly straighten the wheel once you have avoided the object.
Page 197: Passing
Passing The driver of a vehicle about to pass another on a lane highway waits for just the right moment, accelerates, moves around the vehicle ahead, then goes back into the right lane again. A simple maneuver? Not necessarily! Passing another vehicle on a two highway is a potentially dangerous move, since the passing vehicle occupies the same lane as oncoming traffic for several seconds.
Page 198: Loss Of Control
Check your mirrors, glance over your shoulder, and start your left lane change signal before moving out of the right lane to pass. When you are far enough ahead of the passed vehicle to see its front in your inside mirror, activate your right lane change signal and move back into the right lane.
Page 199: Driving At Night
While driving on a surface with reduced traction, try your best to avoid sudden steering, acceleration or braking (including engine braking by shifting to a lower gear). Any sudden changes could cause the tires to slide. You may not realize the surface is slippery until your vehicle is skidding.
Page 200: Night Vision
Here are some tips on night driving. Drive defensively. Don’t drink and drive. Adjust your inside rearview mirror to reduce the glare from headlamps behind you. Since you can’t see as well, you may need to slow down and keep more space between you and other vehicles.
Page 201: Driving In Rain And On Wet Roads
yellowblue Driving in Rain and on Wet Roads Rain and wet roads can mean driving trouble. On a wet road, you can’t stop, accelerate or turn as well because your tire road traction isn’t as good as on dry roads. And, if your tires don’t have much tread left, you’ll get even less traction.
Page 202 Driving too fast through large water puddles or even going through some car washes can cause problems, too. The water may affect your brakes. Try to avoid puddles. But if you can’t, try to slow down before you hit them. CAUTION: Wet brakes can cause accidents.
Page 203: Driving Through Deep Standing Water
Driving Through Deep Standing Water NOTICE: If you drive too quickly through deep puddles or standing water, water can come in through your engine’s air intake and badly damage your engine. Never drive through water that is slightly lower than the underbody of your vehicle. If you can’t avoid deep puddles or standing water, drive through them very slowly.
Page 204: City Driving
City Driving One of the biggest problems with city streets is the amount of traffic on them. You’ll want to watch out for what the other drivers are doing and pay attention to traffic signals. Here are ways to increase your safety in city driving: Know the best way to get to where you are going.
Page 205: Freeway Driving
Freeway Driving Mile for mile, freeways (also called thruways, parkways, expressways, turnpikes or superhighways) are the safest of all roads. But they have their own special rules. 4-22 The most important advice on freeway driving is: Keep up with traffic and keep to the right. Drive at the same speed most of the other drivers are driving.
Page 206: Before Leaving On A Long Trip
Of course, you’ll find experienced and able service experts in Chevrolet dealerships all across North America. They’ll be ready and willing to help if you need it. Here are some things you can check before a trip:...
Page 207: Highway Hypnosis
Highway Hypnosis Is there actually such a condition as “highway hypnosis”? Or is it just plain falling asleep at the wheel? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the hum of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy.
Page 208 If you drive regularly in steep country, or if you’re planning to visit there, here are some tips that can make your trips safer and more enjoyable. Keep your vehicle in good shape. Check all fluid levels and also the brakes, tires, cooling system and transaxle. These parts can work hard on mountain roads.
Page 209: Winter Driving
Winter Driving Here are some tips for winter driving: Have your vehicle in good shape for winter. You may want to put winter emergency supplies in your trunk. 4-26 Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red cloth and a couple of reflective warning triangles.
Page 210: Driving On Snow Or Ice
Driving on Snow or Ice Most of the time, those places where your tires meet the road probably have good traction. However, if there is snow or ice between your tires and the road, you can have a very slippery situation. You’ll have a lot less traction or “grip”...
Page 211 Remember, unless you have anti lock, if you brake so hard that your wheels stop rolling, you’ll just slide. Brake so your wheels always keep rolling and you can still steer. Whatever your braking system, allow greater following distance on any slippery road. Watch for slippery spots.
Page 212 Tie a red cloth to your vehicle to alert police that you’ve been stopped by the snow. Put on extra clothing or wrap a blanket around you. If you have no blankets or extra clothing, make body insulators from newspapers, burlap bags, rags, floor mats anything you can wrap around yourself or tuck under your clothing to keep warm.
Page 213: Recreational Vehicle Towing
Run your engine only as long as you must. This saves fuel. When you run the engine, make it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery charged.
Page 214 The other label is the Certification label, found on the rear edge of the driver’s door. It tells you the gross weight capacity of your vehicle, called the Gross Vehicle Weight Rating (GVWR). The GVWR includes the weight of the vehicle, all occupants, fuel and cargo.
Page 215: Towing A Trailer
If you put things inside your vehicle tools, packages or anything else they will go as fast as the vehicle goes. If you have to stop or turn quickly, or if there is a crash, they’ll keep going. CAUTION: Things you put inside your vehicle can strike and injure people in a sudden stop or turn, or in a crash.
Page 216: If You Do Decide To Pull A Trailer
That’s the reason for this part. In it are many time tested, important trailering tips and safety rules. Many of these are important for your safety and that of your passengers. So please read this section carefully before you pull a trailer. Load pulling components such as the engine, transaxle, wheel assemblies and tires are forced to work harder...
Page 217: Weight Of The Trailer Tongue
You can ask your dealer for our trailering information or advice, or you can write us at: Chevrolet Customer Assistance Center P.O. Box 7047 Troy, MI 48007 7047 In Canada, write to: General Motors of Canada Limited Customer Communication Centre...
Page 218: Safety Chains
Total Weight on Your Vehicle’s Tires Be sure your vehicle’s tires are inflated to the upper limit for cold tires. You’ll find these numbers on the Certification label at the rear edge of the driver’s door or see “Loading Your Vehicle” in the Index. Then be sure you don’t go over the GVW limit for your vehicle, including the weight of the trailer tongue.
Page 219: Driving With A Trailer
Will the trailer brake parts take 3,000 psi (20 650 kPa) of pressure? If not, the trailer brake system must not be used with your vehicle. If everything checks out this far, then make the brake fluid tap at the upper rear master cylinder port. But don’t use copper tubing for this.
Page 220: Making Turns
Making Turns NOTICE: Making very sharp turns while trailering could cause the trailer to come in contact with the vehicle. Your vehicle could be damaged. Avoid making very sharp turns while trailering. When you’re turning with a trailer, make wider turns than normal.
Page 221: Parking On Hills
Parking on Hills CAUTION: You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged. But if you ever have to park your rig on a hill, here’s how to do it: 1.
Page 222 Section 5 Problems on the Road Here you’ll find what to do about some problems that can occur on the road. Hazard Warning Flashers Other Warning Devices Jump Starting Towing Your Vehicle Engine Overheating Cooling System If A Tire Goes Flat Changing a Flat Tire Compact Spare Tire If You’re Stuck: In Sand, Mud, Ice or Snow...
Page 223: Hazard Warning Flashers
Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lamps will flash on and off. Press the switch to the right of the instrument cluster to make your front and rear turn signal lamps flash on and off.
Page 224: Other Warning Devices
Other Warning Devices If you carry reflective triangles, you can set one up at the side of the road about 300 feet (100 m) behind your vehicle. Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your vehicle.
Page 225 2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles aren’t touching each other. If they are, it could cause a ground connection you don’t want. You wouldn’t be able to start your vehicle, and the bad grounding could damage the electrical systems.
Page 226 To uncover the remote positive (+) terminal, lift the plastic cap. CAUTION: Using a match near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Be sure the battery has enough water.
Page 227 5. Check that the jumper cables don’t have loose or missing insulation. If they do, you could get a shock. The vehicles could be damaged, too. Before you connect the cables, here are some basic things you should know. Positive (+) will go to positive (+) and negative ( ) will go to an unpainted metal engine part.
Page 228 7. Don’t let the other end touch metal. Connect it to the positive (+) terminal of the good battery. Use a remote positive (+) terminal if the vehicle has one. Now connect the black negative ( ) cable to the good battery’s negative ( ) terminal.
Page 229 8. Attach the cable at least 18 inches (45 cm) away from the dead battery, but not near engine parts that move. The electrical connection is just as good there, but the chance of sparks getting back to the battery is much less. 9.
Page 230: Towing Your Vehicle
Towing Your Vehicle CAUTION: To help avoid serious personal injury to you or others: Never let passengers ride in a vehicle that is being towed. Never tow faster than safe or posted speeds. Never tow with damaged parts not fully secured. Never get under your vehicle after it has been lifted by the tow truck.
Page 231: Engine Overheating
Engine Overheating You will find a coolant temperature gage and a warning light about a hot engine on your instrument panel. See “Engine Coolant Temperature Gage” and “Hot Coolant Temperature” in the Index. You also have a low coolant light on your instrument panel. See “Low Coolant Level”...
Page 232 yellowblue If Steam Is Coming From Your Engine CAUTION: Steam from an overheated engine can burn you badly, even if you just open the hood. Stay away from the engine if you see or hear steam coming from it. Just turn it off and get everyone away from the vehicle until it cools down.
Page 233: If No Steam Is Coming From Your Engine
If No Steam Is Coming From Your Engine If you get an engine overheat warning but see or hear no steam, the problem may not be too serious. Sometimes the engine can get a little too hot when you: Climb a long hill on a hot day. Stop after high speed driving.
Page 234: Cooling System
Cooling System When you decide it’s safe to lift the hood, here’s what you’ll see: 3400 V6 Engine A. Coolant Recovery Tank B. Electric Engine Cooling Fans 3800 V6 Engine A. Coolant Recovery Tank B. Electric Engine Cooling Fans CAUTION: An electric engine cooling fan under the hood can start up even when the engine is not running and can injure you.
Page 235 If the coolant inside the coolant recovery tank is boiling, don’t do anything else until it cools down. When the engine is cold, the coolant level should be at or above the COLD mark on the coolant recovery tank. To check the coolant level, look for the COLD mark on the side of the coolant recovery tank that faces the engine.
Page 236: Recovery Tank
NOTICE: When adding coolant, it is important that you use only DEX COOL (silicate If coolant other than DEX COOL is added to the system, premature engine, heater core or radiator corrosion may result. In addition, the engine coolant will require change sooner 30,000 miles (50 000 km) or 24 months, whichever occurs first.
Page 237 NOTICE: In cold weather, water can freeze and crack the engine, radiator, heater core and other parts. Use the recommended coolant and the proper coolant mixture. 5-16 CAUTION: You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough.
Page 238 yellowblue CAUTION: Steam and scalding liquids from a hot cooling system can blow out and burn you badly. They are under pressure, and if you turn the pressure even a little they can come out at high speed. Never turn the cap when the cooling system, including the radiator pressure cap, is hot.
Page 239: How To Add Coolant To The Radiator
How to Add Coolant to the Radiator NOTICE: Your engine has a specific radiator fill procedure. Failure to follow this procedure could cause your engine to overheat and be severely damaged. 5-18 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot.
Page 240 CAUTION: You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough. Don’t spill coolant on a hot engine. 3. If you have the 3800 V6 engine, remove the 3800 Series II V6 engine cover shield to access the bleed valve.
Page 241 3400 V6 Bleed Valve #1 3400 V6 Bleed Valve #2 5-20 3800 Series II V6 bleed valve 4. After the engine cools, open the coolant air bleed valve or valves. 3400 V6 engine: There are two bleed valves. One is located on the thermostat housing. The other is located on the thermostat bypass tube.
Page 242 5. Fill the radiator with the proper DEX coolant mixture, up to the base of the filler neck. (See “Engine Coolant” in the Index for more information about the proper coolant mixture.) If you see a stream of coolant coming from an air bleed valve, close the valve.
Page 243 8. Then fill the coolant recovery tank to the COLD mark. 9. Put the cap back on the coolant recovery tank, but leave the radiator pressure cap off. 5-22 10. Start the engine and let it run until you can feel the upper radiator hose getting hot.
Page 244: If A Tire Goes Flat
12. Then replace the pressure cap. At any time during this procedure if coolant begins to flow out of the filler neck, reinstall the pressure cap. Be sure the arrows on the pressure cap line up like this. 13. Check the coolant in the recovery tank. The level in the coolant recovery tank should be at the HOT mark when the engine is hot or at the COLD mark when the engine is cold.
Page 245: Changing A Flat Tire
Changing a Flat Tire If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on your hazard warning flashers. CAUTION: Changing a tire can cause an injury. The vehicle can slip off the jack and roll over you or other people.
Page 246 Removing the Spare Tire and Tools The equipment you’ll need is in the trunk. Turn the center nut on the compact spare cover counterclockwise to remove it. Remove the compact spare tire. See “Compact Spare Tire” later in this section for more information about the compact spare.
Page 247 Turn the nut holding the jack counterclockwise and remove it. Then remove the jack and wrench. 5-26 The tools you’ll be using include the jack (A) extension and protector/guide (B) and wheel wrench (C). If there is a wheel cover, loosen the plastic nut caps with the wheel wrench.
Page 248 Removing the Flat Tire and Installing the Spare Tire 1. Using the wheel wrench, loosen all the wheel nuts. Don’t remove them yet. The diagram shows you where you should place your jack. Use the bolts (A) as a guide when positioning the the jack lift head (C) near the rear edge of the front wheel opening (B).
Page 249 The diagram shows you where to place your jack. Use the notch (B) as a guide when positioning the jack lift head (A) near the front edge of the rear wheel opening (C). For jacking at the vehicle’s rear location, put the jack lift head about 4 inches (10 cm) from the front edge of the rear wheel opening in the cutout of the rocker panel molding.
Page 250 2. Raise the vehicle by turning the jack handle clockwise. Raise the vehicle far enough off the ground for the spare tire to fit under the vehicle. Remove all wheel nuts and take off the flat tire. 3. Remove any rust or dirt from the wheel bolts, mounting surfaces and spare wheel.
Page 251 4. Install the spare tire. 5. Replace the wheel nuts with the rounded end of the nuts toward the wheel. Tighten each nut by hand until the wheel is held against the hub. 5-30 6. Lower the vehicle by turning the jack handle counterclockwise.
Page 252 7. Tighten the wheel nuts firmly in a crisscross sequence as shown. CAUTION: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose and even come off. This could lead to an accident. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new GM original equipment wheel nuts.
Page 253: Storing The Flat Tire And Tools
Storing the Flat Tire and Tools CAUTION: Storing a jack, a tire or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place. After you’ve put the compact spare tire on your vehicle, you’ll need to store the flat tire in your trunk.
Page 254 Storing the Spare Tire and Tools CAUTION: Storing a jack, a tire or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place. The compact spare is for temporary use only.
Page 255: Compact Spare Tire
Compact Spare Tire Although the compact spare tire was fully inflated w hen your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 kPa). After installing the compact spare on your vehicle, you should stop as soon as possible and make sure your spare tire is correctly inflated.
Page 256: If You're Stuck: In Sand, Mud, Ice Or Snow
If You’re Stuck: In Sand, Mud, Ice or Snow In order to free your vehicle when it is stuck, you will need to spin the wheels, but you don’t want to spin your wheels too fast. The method known as “rocking” can help you get out when you’re stuck, but you must use caution.
Page 257 yellowblue NOTES 5-36...
Page 258 Section 6 Service and Appearance Care Here you will find information about the care of your vehicle. This section begins with service and fuel information, and then it shows how to check important fluid and lubricant levels. There is also technical information about your vehicle, and a part devoted to its appearance care.
Page 259: Doing Your Own Service Work
Service Your dealer knows your vehicle best and wants you to be happy with it. We hope you’ll go to your dealer for all your service needs. You’ll get genuine GM parts and trained and supported service people. We hope you’ll want to keep your GM vehicle all GM. Genuine GM parts have one of these marks: Doing Your Own Service Work If you want to do some of your own service work, you’ll...
Page 260 CAUTION: You can be injured and your vehicle could be damaged if you try to do service work on a vehicle without knowing enough about it. Be sure you have sufficient knowledge, experience, the proper replacement parts and tools before you attempt any vehicle maintenance task.
Page 261 (See “Malfunction Indicator Lamp” in the Index.) If this occurs, return to your authorized Chevrolet dealer for diagnosis to determine the cause of failure. In the event it is determined that the cause of the condition is the type of fuels used, repairs may not be covered by your warranty.
Page 262: Fuels In Foreign Countries
To provide cleaner air, all gasolines in the United States are now required to contain additives that will help prevent deposits from forming in your engine and fuel system, allowing your emission control system to function properly. Therefore, you should not have to add anything to the fuel.
Page 263: Filling Your Tank
Filling Your Tank CAUTION: Gasoline vapor is highly flammable. It burns violently, and that can cause very bad injuries. Don’t smoke if you’re near gasoline or refueling your vehicle. Keep sparks, flames and smoking materials away from gasoline. The tethered cap is behind a hinged door on the driver’s side of your vehicle.
Page 264 CAUTION: If you get gasoline on yourself and then something ignites it, you could be badly burned. Gasoline can spray out on you if you open the fuel filler cap too quickly. This spray can happen if your tank is nearly full, and is more likely in hot weather.
Page 265: Checking Things Under The Hood
Filling a Portable Fuel Container CAUTION: Never fill a portable fuel container while it is in your vehicle. Static electricity discharge from the container can ignite the gasoline vapor. You can be badly burned and your vehicle damaged if this occurs.
Page 266: Hood Release
Hood Release To open the hood, first pull the handle located inside the vehicle near the parking brake pedal. Then go to the front of the vehicle and release the secondary hood release. Lift the hood. yellowblue...
Page 267 When you open the hood on the 3400 V6 (Code E) engine, you’ll see: A. Windshield Washer Fluid Reservoir B. Underhood Fuse Block C. Engine Coolant Reservoir D. Power Steering Fluid Reservoir E. Transmission Fluid Dipstick 6-10 F. Brake Fluid Reservoir G.
Page 268 When you open the hood on the 3800 (Code K) V6 engine, you’ll see: A. Windshield Washer Fluid Reservoir B. Underhood Fuse Block C. Engine Coolant Reservoir D. Power Steering Fluid Reservoir (low in engine compartment) E. Transmission Fluid Dipstick F.
Page 269: Engine Oil
Before closing the hood, be sure all the filler caps are on properly. Then just pull the hood down and close it firmly. Engine Oil If the LOW OIL appears on the instrument panel, it means you need to check your engine oil level right away.
Page 270: When To Add Engine Oil
Pull out the dipstick and clean it with a paper towel or cloth, then push it back in all the way. Remove it again, keeping the tip down, and check the level. 3400 (Code E) V6 Engine When to Add Engine Oil If the oil is at or below the lower mark, then you’ll need to add at least one quart of oil.
Page 271: What Kind Of Engine Oil To Use
The engine oil fill cap is located toward the front of the engine near the yellow looped engine oil dipstick. Be sure to fill it enough to put the level somewhere in the proper operating range. Push the dipstick all the way back in when you’re through.
Page 272 yellowblue As shown in the chart, if you have the 3400 V6 engine, SAE 5W 30 is best for your vehicle. However, you can 30 if it’s going to be 0 _ F ( 18 _ C) or use SAE 10W above.
Page 273 6-16 As shown in the chart, if you have the 3800 V6 engine, SAE 10W 30 is best for your vehicle. However, you can 30 if it’s going to be colder than 60 _ F use SAE 5W (16 _ C) before your next oil change. When it’s very cold, you should use SAE 5W 30.
Page 274: Engine Oil Additives
Engine Oil Additives Don’t add anything to your oil. The recommended oils with the starburst symbol are all you will need for good performance and engine protection. When to Change Engine Oil Your vehicle has a computer that lets you know when to change your engine oil.
Page 275: What To Do With Used Oil
What to Do with Used Oil Did you know that used engine oil contains certain elements that may be unhealthy for your skin and could even cause cancer? Don’t let used oil stay on your skin for very long. Clean your skin and nails with soap and water, or a good hand cleaner.
Page 276 3. Pull out the filter. 4. Install the air filter and make sure the filter cover tabs position through the slots in the housing. See “Normal Maintenance Replacement Parts” in the Index. 5. A notch on the sides of the filter cover will indicate the correct engagement.
Page 277: Passenger Compartment Air Filter
Passenger Compartment Air Filter (If Equipped) The passenger compartment air filter is located underneath the hood just below the windshield wiper arm on the passenger’s side of the vehicle (underneath the air inlet grille). The filter traps most of the pollen from air entering the module.
Page 278: How To Check
How to Check Because this operation can be a little difficult, you may choose to have this done at the dealership service department. If you do it yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick. NOTICE: Too much or too little fluid can damage your transaxle.
Page 279 Then, without shutting off the engine, follow these steps: 3400 (Code E) V6 Engine 6. The transaxle fluid dipstick handle is the red loop near the back of the engine. Pull out the dipstick and wipe it with a clean rag or paper towel. 7.
Page 280: Engine Coolant
How to Add Fluid Refer to the Maintenance Schedule to determine what kind of transaxle fluid to use. See “Recommended Fluids and Lubricants” in the Index. If the fluid level is low, add only enough of the proper fluid to bring the level into the cross on the dipstick.
Page 281 NOTICE: When adding coolant, it is important that you use only DEX COOL (silicate If coolant other than DEX COOL is added to the system, premature engine, heater core or radiator corrosion may result. In addition, the engine coolant will require change sooner 30,000 miles (50 000 km) or 24 months, whichever occurs first.
Page 282: Checking Coolant
NOTICE: If you use an improper coolant mixture, your engine could overheat and be badly damaged. The repair cost wouldn’t be covered by your warranty. Too much water in the mixture can freeze and crack the engine, radiator, heater core and other parts.
Page 283 If this LOW COOLANT LEVEL light comes on and stays on, it means you’re low on engine coolant. Adding Coolant If you need more coolant, add the proper DEX coolant mixture at the coolant recovery tank, but be careful not to spill it. If the coolant recovery tank is completely empty, add coolant to the radiator.
Page 284: Power Steering Fluid
Radiator Pressure Cap NOTICE: Your radiator cap is a 15 psi (105 kPa) pressure type cap and must be tightly installed to prevent coolant loss and possible engine damage from overheating. Be sure the arrows on the cap line up with the overflow tube on the radiator filler neck.
Page 285: Windshield Washer Fluid
How to Check Power Steering Fluid When the engine compartment is cool, wipe the cap and the top of the reservoir clean, then unscrew the cap and wipe the dipstick with a clean rag. Replace the cap and completely tighten it. Then remove the cap again and look at the fluid level on the dipstick.
Page 286 Open the cap labeled WASHER FLUID ONLY. Add washer fluid until the tank is full. NOTICE: When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready fluid. Water can cause the solution to freeze and damage your washer fluid tank and other parts of the washer system.
Page 287: Brake Fluid
Brakes Brake Fluid Your brake master cylinder reservoir is on the driver’s side of the engine compartment. It is filled with DOT brake fluid. There are only two reasons why the brake fluid level in the reservoir might go down. The first is that the brake fluid goes down to an acceptable level during normal brake lining wear.
Page 288 What to Add When you do need brake fluid, use only DOT fluid. Use new brake fluid from a sealed container only. Refer to “Recommended Fluids and Lubricants” in the Maintenance Schedule. Always clean the brake fluid reservoir cap and the area around the cap before removing it.
Page 289: Brake Wear
Brake Wear Your vehicle has four wheel disc brakes. Disc brake pads have built in wear indicators that make a high pitched warning sound when the brake pads are worn and new pads are needed. The sound may come and go or be heard all the time your vehicle is moving (except when you are pushing on the brake pedal firmly).
Page 290: Brake Adjustment
Brake Adjustment Every time you apply the brakes, with or without the vehicle moving, your brakes adjust for wear. Replacing Brake System Parts The braking system on a vehicle is complex. Its many parts have to be of top quality and work well together if the vehicle is to have really good braking.
Page 291: Bulb Replacement
Bulb Replacement For the proper type of replacement bulb, see “Replacement Bulbs” in the Index. For any bulb changing procedure not listed in this section, contact the service department of your dealer. Halogen Bulbs CAUTION: Halogen bulbs have pressurized gas inside and can burst if you drop or scratch the bulb.
Page 292 3. Remove the two headlamp fasteners by pulling up on them. 4. Gently pull the headlamp assembly away from the vehicle and remove the electrical connector. 5. Remove the round dust caps to gain access to the bulbs. 6. Turn the bulb counterclockwise and remove it from the retaining ring by gently pulling it away from the headlamp.
Page 293 9. Install the new bulb by inserting the smallest tab on the bulb base into the matching notch in the retaining ring. Turn the bulb a quarter clockwise until it stops. 10. Reverse all steps to reinstall the headlamp assembly. Then, check the lamps. Headlamp Aiming If your vehicle is damaged in an accident, the headlamp aim may be affected.
Page 294 3. Remove the two headlamp fasteners by pulling up on them. 4. Gently pull the headlamp assembly away from the vehicle and remove the electrical connector. 5. Remove the round dust caps to gain access to the bulbs. 6. Turn the bulb counterclockwise and remove it from the retaining ring by gently pulling it away from the headlamp.
Page 295 9. Install the new bulb by inserting the smallest tab on the bulb base into the matching notch in the retaining ring. Turn the bulb a quarter clockwise until it stops. 10. Reinstall the dust caps and reconnect the electrical connector. 11.
Page 296 2. Remove the upper (convenience net) wing nut, if equipped. 3. Pull the carpet away from the rear of the vehicle. 4. Unscrew the two remaining wing nuts. 5. Pull the assembly from the body carefully. 6. To remove a socket, press the tab, turn the socket counterclockwise and pull it out.
Page 297 Rear Sidemarker Lamp A. Rear Sidemarker Lamp B. Tail/Stop/Turn Signal Lamp To remove the rear lamp assembly: 1. Open the trunk. Remove the convenience net if you have one. Unhook the net from the upper wing nut. 6-40 2. Remove the upper (convenience net) wing nut, if equipped.
Page 298 10. Install the assembly and the two lower wing nuts. 11. Reinstall the carpeting. 12. Reinstall the upper (convenience net) wing nut and convenience net, if equipped. Back-Up Lamp 1. Open the trunk. The back up lamp bulbs are in the rear of the trunk lid.
Page 299: Windshield Wiper Blade Replacement
Windshield Wiper Blade Replacement Windshield wiper blades should be inspected at least twice a year for wear or cracking. See “Wiper Blade Check” in Section 7 of this manual under Part B “Owner Checks and Services” for more information. Replacement blades come in different types and are removed in different ways.
Page 300 Your new vehicle comes with high a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your Chevrolet Warranty booklet for details. CAUTION: quality tires made by Poorly maintained and improperly used tires are dangerous.
Page 301 Inflation -- Tire Pressure The Tire Loading Information label, which is on the inside of the trunk lid, shows the correct inflation pressures for your tires when they’re cold. “Cold” means your vehicle has been sitting for at least three hours or driven no more than 1 mile (1.6 km). NOTICE: Don’t let anyone tell you that underinflation or overinflation is all right.
Page 302 Tire Inflation Monitor System (If Equipped) The tire inflation monitor system can alert you to a large change in the pressure of one tire. The system “learns” the pressure at each tire throughout the operating speed range of your vehicle. The system normally takes between 45 and 90 minutes of driving to learn the tire pressures.
Page 303: Tire Inspection And Rotation
To reset (calibrate) the system: The tire inflation monitor system can be reset by turning the exterior lamp control from OFF to parking lamps three times while the ignition is in ON. It can also be reset through “Vehicle Customization Settings.” To reset the monitor using the vehicle customization settings: 1.
Page 304 When rotating your tires, always use the correct rotation pattern shown here. Don’t include the compact spare tire in your tire rotation. After the tires have been rotated, adjust the front and rear inflation pressures as shown on the Tire Information label.
Page 305: Buying New Tires
When It’s Time for New Tires One way to tell when it’s time for new tires is to check the treadwear indicators, which will appear when your tires have only 1/16 inch (1.6 mm) or less of tread remaining. You need a new tire if any of the following statements are true: You can see the indicators at three or more places around the tire.
Page 306: Uniform Tire Quality Grading
CAUTION: Mixing tires could cause you to lose control while driving. If you mix tires of different sizes or types (radial and bias belted tires), the vehicle may not handle properly, and you could have a crash. Using tires of different sizes may also cause damage to your vehicle.
Page 307: Wheel Replacement
Traction AA, A, B, C The traction grades, from highest to lowest, are AA, A, B, and C. Those grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.
Page 308 Each new wheel should have the same load capacity, diameter, width, offset and be mounted the same way as the one it replaces. If you need to replace any of your wheels, wheel bolts or wheel nuts, replace them only with new GM original equipment parts.
Page 309: Tire Chains
Tire Chains NOTICE: Use tire chains only where legal and only when you must. Use only SAE Class “S” type chains that are the proper size for your tires. Install them on the front tires and tighten them as tightly as possible with the ends securely fastened.
Page 310: Cleaning The Inside Of Your Vehicle
Don’t use any of these unless this manual says you can. In many uses, these will damage your vehicle: Alcohol Laundry Soap Bleach Reducing Agents Cleaning the Inside of Your Vehicle Use a vacuum cleaner often to get rid of dust and loose dirt.
Page 311: Special Fabric Cleaning Problems
Special Fabric Cleaning Problems Stains caused by such things as catsup, coffee (black), egg, fruit, fruit juice, milk, soft drinks, vomit, urine and blood can be removed as follows: 1. Carefully scrape off excess stain, then sponge the soiled area with cool water. 2.
Page 312: Cleaning Leather
Cleaning Leather Use a soft cloth with lukewarm water and a mild soap or saddle soap and wipe dry with a soft cloth. Then, let the leather dry naturally. Do not use heat to dry. For stubborn stains, use a leather cleaner. See your dealer for this product.
Page 313: Cleaning The Outside Of Your Vehicle
Cleaning the Outside of the Windshield and Wiper Blades If the windshield is not clear after using the windshield washer, or if the wiper blade chatters when running, wax, sap or other material may be on the blade or windshield. Clean the outside of the windshield with GM Windshield Cleaner, Bon Ami Powder (non...
Page 314: Cleaning Aluminum Wheels
Cleaning Exterior Lamps/Lenses Use lukewarm or cold water, a soft cloth and a vehicle washing soap to clean exterior lamps and lenses. Follow instructions under “Washing Your Vehicle.” Finish Care Occasional waxing or mild polishing of your vehicle by hand may be necessary to remove residue from the paint finish.
Page 315: Underbody Maintenance
Although no defect in the paint job causes this, Chevrolet will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000 km) of purchase, whichever occurs first.
Page 316 GM Vehicle Care/Appearance Materials PART NUMBER SIZE 994954 23 in. x 25 in. 1050172 16 oz. (0.473 L) 1050173 16 oz. (0.473 L) 1050174 16 oz. (0.473 L) 1050214 32 oz. (0.946 L) 1050427 23 oz. (0.680 L) 1052918** 8 oz. (0.237 L) 1052925 16 oz.
Page 317: Electrical System
Vehicle Identification Number (VIN) This is the legal identifier for your vehicle. It appears on a plate in the front corner of the instrument panel, on the driver’s side. You can see it if you look through the windshield from outside your vehicle. The VIN also appears on the Vehicle Certification and Service Parts labels and the certificates of title and registration.
Page 318: Headlamp Wiring
Headlamp Wiring The headlamp circuit is protected by individual fuses in the underhood electrical center. An electrical overload will cause the fuse to blow. If this happens, have your headlamp system checked right away. Windshield Wipers The windshield wiper motor is protected by a circuit breaker and a fuse.
Page 319 Driver’s Side Instrument Panel Fuse Block Some fuses are in a fuse block on the driver’s side of the instrument panel. Pull off the cover labeled FUSES to expose the fuses. 6-62 Circuit Relay Description RETAINED Retained Accessory Power Relay ACCESSORY PWR RELAY HEADLAMP...
Page 320 Circuit Description Breaker RETAINED Power Window, Sunroof Breaker ACCESSORY PWR BRKR Mini Fuses Description PCM/BCM/ Powertrain Control Module, CLSTR Body Control Module, Cluster (Ignition 0) Windshield Wipers, Windshield Washer Powertrain Control (CRANK) Module (Crank) CIG/AUX Accommodated Device (Accessory) Body Control Module (Accessory) Supplemental Restraint System ABS/PCM Anti...
Page 321 Passenger’s Side Instrument Panel Fuse Block Some fuses are in a fuse block on the passenger’s side of the instrument panel. Pull off the cover labeled FUSES to expose the fuses. Additional fuses are in the underhood electrical center on the passenger’s side of the engine compartment. 6-64 Circuit Relay Description...
Page 322 Circuit Relay Description BATT RUN Battery Run Down DOWN Protection Relay PROTECTION RELAY REAR Rear Defog Relay, DEFOG RELAY Heated Mirror Relay Circuit Breaker Description POWER Power Seat Circuit Breaker SEATS BRKR REAR Rear Defog Breaker DEFOG BRKR Mini Fuses Description RH HTD ST Passenger Heated Seat...
Page 323 Circuit Relay Description FUEL PUMP Fuel Pump DRL RELAY Daytime Running Lamps A.I.R. RELAY Air Induction Reaction Relay CRANK RLY Starter (Crank) Relay HORNS Horn FOG LTS Fog Lamps 6-66 Maxi Fuses Description LEFT I/P Left Bussed Electrical Center (Battery) RT I/P #1 Right Bussed Electrical Center (Battery)
Page 324 Circuit Relay Description FAN CONT #3 Secondary Cooling Fan (Passenger’s Side) FAN CONT #2 Cooling Fan Control Relay FAN CONT #1 Primary Cooling Fan (Driver’s Side) IGN RELAY Ignition Relay A/C CMPR HVAC Compressor Maxi Fuses Description IGN SW Ignition Switch BLANK Blank U/HOOD #2...
Page 325: Capacities And Specifications
Replacement Bulbs Exterior Lamps Back ....... . Front Park/Turn Signal .
Page 326: Engine Specifications
Engine Specifications 3400 (Code E) V6 Engine Type ........Displacement .
Page 327 yellowblue NOTES 6-70...
Page 328 Section 7 Maintenance Schedule This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety, dependability and emission control performance. Introduction Part A: Scheduled Maintenance Services Scheduled Maintenance Part B: Owner Checks and Services Part C: Periodic Maintenance Inspections Part D: Recommended Fluids and Lubricants Part E: Maintenance Record...
Page 329: Your Vehicle And The Environment
Have you purchased the GM Protection Plan? The Plan supplements your new vehicle warranties. See your Warranty and Owner Assistance booklet, or your dealer for details. Introduction Your Vehicle and the Environment Proper vehicle maintenance not only helps to keep your vehicle in good working condition, but also helps the environment.
Page 330: How This Section Is Organized
How This Section is Organized This maintenance schedule is divided into five parts: “Part A: Scheduled Maintenance Services” shows what to have done and how often. Some of these services can be complex, so unless you are technically qualified and have the necessary equipment, you should let your dealer’s service department or another qualified service center do these jobs.
Page 331: Using Your Maintenance Schedule
Part A: Scheduled Maintenance Services Using Your Maintenance Schedule We at General Motors want to help you keep your vehicle in good working condition. But we don’t know exactly how you’ll drive it. You may drive very short distances only a few times a week. Or you may drive long distances all the time in very hot, dusty weather.
Page 332 Scheduled Maintenance Footnotes The U.S. Environmental Protection Agency or the California Air Resources Board has determined that the failure to perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful life. We, however, urge that all recommended maintenance services be performed at the indicated intervals and the maintenance be recorded.
Page 333 Scheduled Maintenance Engine Oil Scheduled Maintenance Change engine oil and filter as indicated by the GM Oil Life System (or every 12 months, whichever occurs first). Reset the system. The system will show you when to change the oil usually between 3,000 miles (5 000 km) and 7,500 miles (12 500 km) since your last oil change.
Page 334 yellowblue Scheduled Maintenance...
Page 335 yellowblue Scheduled Maintenance...
Page 336 Scheduled Maintenance 7,500 Miles (12 500 km) Rotate tires. See “Tire Inspection and Rotation” in the Index for proper rotation pattern and additional information. (See footnote +.) 15,000 Miles (25 000 km) Inspect engine air cleaner filter if you are driving in dusty conditions. Replace filter if necessary.
Page 337 Scheduled Maintenance 30,000 Miles (50 000 km) If Equipped: Replace passenger compartment air filter. If you drive regularly under dusty conditions, the filter may require replacement more often. Rotate tires. See “Tire Inspection and Rotation” in the Index for proper rotation pattern and additional information.
Page 338 Scheduled Maintenance 50,000 Miles (83 000 km) j Change automatic transaxle fluid and filter if the vehicle is mainly driven under one or more of these conditions: – In heavy city traffic where the outside temperature regularly reaches 90 _ F (32 _ C) or higher. –...
Page 339 Scheduled Maintenance 60,000 Miles (100 000 km) (Continued) Inspect engine accessory drive belt. An Emission Control Service. Replace engine air cleaner filter. An Emission Control Service. 67,500 Miles (112 500 km) Rotate tires. See “Tire Inspection and Rotation” in the Index for proper rotation pattern and additional information.
Page 340 Scheduled Maintenance 82,500 Miles (137 500 km) Rotate tires. See “Tire Inspection and Rotation” in the Index for proper rotation pattern and additional information. (See footnote +.) 90,000 Miles (150 000 km) If Equipped: Replace passenger compartment air filter. If you drive regularly under dusty conditions, the filter may require replacement more often.
Page 341 Scheduled Maintenance 100,000 Miles (166 000 km) Inspect spark plug wires. An Emission Control Service. Replace spark plugs. An Emission Control Service. Change automatic transaxle fluid and filter if the vehicle is mainly driven under one or more of these conditions: –...
Page 342: At Least Once A Month
Part B: Owner Checks and Services Listed in this part are owner checks and services which should be performed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Whenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones, as shown in Part D.
Page 343: At Least Twice A Year
At Least Twice a Year Restraint System Check Make sure the safety belt reminder light and all your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired.
Page 344 Starter Switch Check CAUTION: When you are doing this check, the vehicle could move suddenly. If it does, you or others could be injured. Follow the steps below. 1. Before you start, be sure you have enough room around the vehicle. 2.
Page 345 Ignition Transaxle Lock Check While parked, and with the parking brake set, try to turn the ignition key to LOCK in each shift lever position. The key should turn to LOCK only when the shift lever is in PARK (P). The key should come out only in LOCK.
Page 346: Exhaust System Inspection
Part C: Periodic Maintenance Inspections Listed in this part are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You should let your dealer’s service department or other qualified service center do these jobs.
Page 347: Throttle System Inspection
Throttle System Inspection Inspect the throttle system for interference or binding, and for damaged or missing parts. Replace parts as needed. Replace any components that have high effort or excessive wear. Do not lubricate accelerator and cruise control cables. 7-20 Brake System Inspection Inspect the complete system.
Page 348 Part D: Recommended Fluids and Lubricants NOTE: Fluids and lubricants identified below by name, part number or specification may be obtained from your dealer. USAGE FLUID/LUBRICANT Engine Oil Engine Oil with the American Petroleum Institute Certified For Gasoline Engines starburst symbol of the proper viscosity.
Page 349: Maintenance Record
Part E: Maintenance Record After the scheduled services are performed, record the date, odometer reading and who performed the service in the boxes provided after the maintenance interval. Any additional information from “Owner Checks and ODOMETER DATE SERVICED BY READING 7-22 Services”...
Page 350 yellowblue Maintenance Record ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING 7-23...
Page 351 yellowblue Maintenance Record ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING 7-24...
Page 352 Section 8 Customer Assistance Information Here you will find out how to contact Chevrolet if you need assistance. This section also tells you how to obtain service publications and how to report any safety defects. Customer Satisfaction Procedure Customer Assistance for Text Telephone...
Page 353: Customer Satisfaction Procedure
Customer Satisfaction Procedure Your satisfaction and goodwill are important to your dealer and to Chevrolet. Normally, any concerns with the sales transaction or the operation of your vehicle will be resolved by your dealer’s sales or service departments. Sometimes, however, despite the best intentions of all concerned, misunderstandings can occur.
Page 354 Dealership name and location Vehicle delivery date and present mileage When contacting Chevrolet, please remember that your concern will likely be resolved at a dealer’s facility. That is why we suggest you follow Step One first if you have a concern.
Page 355: Customer Assistance For Text Telephone
Customer Assistance Offices free telephone Chevrolet encourages customers to call the toll-free number for assistance. If a U.S. customer wishes to write to Chevrolet, the letter should be addressed to Chevrolet’s Customer Assistance Center. United States Chevrolet Motor Division Chevrolet Customer Assistance Center P.O.
Page 356: Gm Mobility Program For Persons With Disabilities
Canada General Motors of Canada Limited Customer Communication Centre, 163-005 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7 1-800-263-3777 (English) 1-800-263-7854 (French) 1-800-263-3830 (For Text Telephone devices (TTYs)) Roadside Assistance: 1-800-268-6800 All Overseas Locations GMODC Customer Communication Centre 169-007 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7 Telephone: 905-644-4112 Fax:...
Page 357: Chevrolet Roadside Assistance Program
To enhance Chevrolet’s strong commitment to customer satisfaction, Chevrolet is excited to announce the establishment of the Chevrolet Roadside Assistance Center. As the owner of a 2000 Chevrolet, membership in Roadside Assistance is free. Roadside Assistance is available 24 hours a day,...
Page 358: Canadian Roadside Assistance
Courtesy Transportation will be offered in conjunction with the coverage provided by the Bumper to Bumper New Vehicle Limited Warranty to eligible purchasers of 2000 Chevrolet passenger cars and light duty trucks. (Please see your selling dealer for details.)
Page 359: Courtesy Transportation
Transportation Options Warranty service can generally be completed while you wait. However, if you are unable to wait Chevrolet helps minimize your inconvenience by providing several transportation options. Depending on the circumstances,...
Page 360: Warranty Information
Courtesy Rental Vehicle When your vehicle is unavailable due to overnight warranty repairs, your dealer may arrange to provide you with a courtesy rental vehicle or reimburse you for a rental vehicle you obtained, at actual cost, up to a maximum of $30.00 per day supported by receipts.
Page 361: Reporting Safety Defects To The United
REPORTING SAFETY DEFECTS TO THE UNITED STATES GOVERNMENT If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying General Motors.
Page 362: Reporting Safety Defects To General Motors
Please call us at 1 1020, or write: Chevrolet Motor Division Chevrolet Customer Assistance Center P.O. Box 7047 Troy, MI 48007 7047 In Canada, please call us at 1 or 1 7854 (French).
Page 363 2000 CHEVROLET SERVICE PUBLICATIONS ORDERING INFORMATION The following publications covering the operation and servicing of your vehicle can be purchased by filling out the Service Publication Order Form in this book and mailing it in with your check, money order, or credit card information to Helm, Incorporated (address below.)
Page 364 ORDER TOLL FREE (NOTE: For Credit Card Holders Only) 1-800-551-4123 (Monday-Friday 8:00 AM – 6:00 PM EST) FAX Orders Only 1-313-865-5927 PUBLICATION FORM PUBLICATION FORM NUMBER NUMBER Service Manual Car & Light Truck Transmission Unit Repair Owner’s Manual In Portfolio Owner’s Manual Without Portfolio NOTE: Dealers and Companies please provide dealer or company name, and also the name of the person to whose attention the shipment should be sent.
Page 365 yellowblue NOTES 8-14...
