Canon PD-82K Service Manual

2x500 sheet paper deck
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2x500 sheet
PAPER DECK
SERVICE
MANUAL
REVISION 0
JAN. 1999
©
COPYRIGHT
1999 CANON INC.
RY8-1392-000
CANON 2x500 sheet paper deck PD-82K REV. 0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

Advertisement

Table of Contents
loading

Related Manuals for Canon PD-82K

Summary of Contents for Canon PD-82K

  • Page 1 2x500 sheet PAPER DECK SERVICE MANUAL REVISION 0 RY8-1392-000 JAN. 1999 © COPYRIGHT 1999 CANON INC. CANON 2x500 sheet paper deck PD-82K REV. 0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
  • Page 2 COPYRIGHT © 1999 CANON INC. Printed in Japan Imprimé au Japon Use of this manual should be strictly supervised to avoid disclosure confidential information. Prepared by PERIPHERAL PRODUCTS QUALITY PLANNING DIV. PERIPHERAL PRODUCTS TECHNICAL DOCUMENTATION DEPT. CANON INC. 5-1 Hakusan 7-chome, Toride-City, Ibaraki-Pref.,302-8501 Japan...
  • Page 3 PREFACE This Service Manual contains basic information required for after-sales service of 2x500 sheet paper deck PD-82K. This information is vital to the service technician in maintaining the high print quality and performance of the paper deck. This manual consists of the following chapters:...
  • Page 4 DTP system This manual was produced on an Apple PowerMacintosh 9500/233 personal computer and output by an Apple LaserWriter 16/600 PS laser beam printer; final pages were printed on DAINIPPON SCREEN MFG CO. LTD DT-R3100. All graphics were produced with Macromedia FreeHand (J), and all documents and page layouts were created with QuarkXPress (E).

  • Page 5: Table Of Contents

    CONTENTS CHAPTER 1 PRODUCT INFORMATION SPECIFICATIONS ....1-1 III. INSTALLATION ...... 1-4 PARTS OF THE PAPER DECK . 1-2 A. Notes ........ 1-4 A. External Views ....1-2 B. Unpacking and Installation 1-4 B. Cross Sectional Views ..1-3 CHAPTER 2 OPERATION AND TIMING BASIC OPERATION ....
  • Page 6 CHAPTER 4 TROUBLESHOOTING PREFACE ......4-1 B. Electrical Adjustment ..4-18 A. Malfunction Diagnosis C. LEDs, test pins, jumpers, Flowchart ......4-1 and switches on PCB ..4-18 B. Initial Checks ....4-3 VII. MAINTENANCE AND C. Service Checkpoints ..4-4 SERVICING ......

  • Page 7: Chapter 1 Product Information

    CHAPTER 1 PRODUCT INFORMATION SPECIFICATIONS ....1-1 III. INSTALLATION ...... 1-4 PARTS OF THE PAPER DECK .. 1-2...

  • Page 9: Specifications

    CHAPTER 1 I. SPECIFICATIONS 1) Paper type Plain paper, colored paper, and thick paper 2) Paper size Upper cassette B4, A4, Legal, and Letter sized plain paper (64g/m to 105g/m recommended paper) Lower cassette A3, B4, A4, Ledger, Legal, and Letter sized plain paper (64g/m 105g/m recommended paper) 3) Cassette type...

  • Page 10: Parts Of The Paper Deck

    CHAPTER 1 II. PARTS OF THE PAPER DECK A. External Views 1: Positioning pins 2: Paper feed unit 3: Housing unit 4: Lower cassette 5: Upper cassette 6: Status LED Figure 1-2-1 7: Option interface connectors 8: Power receptacle Figure 1-2-2 1 - 2...

  • Page 11: Cross Sectional Views

    CHAPTER 1 B. Cross Sectional Views Figure 1-2-3 1: Status LED 6: Separation roller 2: Upper cassette 7: Registration paper sensor lever 3: Lower cassette 8: Registration roller 4: Pick-up roller 9: Feed roller 2 5: Feed roller 1 10: Paper jam sensor lever 1 - 3...
  • Page 12 CHAPTER 1 III. INSTALLATION A. Notes Use the following power supplies; • Line voltage (AC): -10%, +6% rated voltage • Power frequency: 50/60Hz ± 2Hz B. Unpacking and Installation Condensation will form on the metal surfaces when brought into a warm room from the cold. Therefore, when moving the unit into a warm environment, leave it packed in its box for at least an hour to acclimatize to room temperature.

  • Page 13: Chapter 2 Operation And Timing

    CHAPTER 2 OPERATION AND TIMING 1. This chapter describes the paper deck functions, the relationships between mechanisms and circuits, and the timing of operations. Mechanical linkages are indicated by black and white lines ( ), the flow of control signals by solid arrows ( ), and the flow of groups of signals by outline arrows ( 2.

  • Page 15: Basic Operation

    CHAPTER 2 I. BASIC OPERATION A. Outline The paper deck feeds print paper to the printer. The sequence of paper deck operations is controlled by the paper deck driver PCB. This PCB contains an eight-bit microcomputer (IC201) to control the sequence of operations and serial communication with the option controller PCB.

  • Page 16: Input/Output Of Paper Deck Driver Pcb

    CHAPTER 2 B. Input/Output of Paper Deck Driver PCB Paper deck Driver PCB +24V J201-5/-10/-15 SERIAL IN signal SERIAL OUT signal CONTO Communication ready signal To option controller Serial clock signal STRBI Strobe signal PWRON-IN Power on signal -2/-7/-8/-9/-11/-14 +24V J202-5/-10/-15 SERIAL OUT signal SERIAL IN signal...
  • Page 17 CHAPTER 2 Paper deck driver PCB Pick-up PCB J208-18 J1201-5 J14-3 J1206-1 P5VBDOR Paper feed unit sensor /RDOORS /RDOORS "L" when the feed unit is open. PS1201 Lower cassette /LDECKC "L" when the sensor detects the sensor lower cassette. PS1202 Upper cassette "L"...
  • Page 18 CHAPTER 2 Paper deck driver PCB Status LED PCB LED1 J1-3 J229-1 J219-3 J209-1 RED LED Status LED control signal GREEN LED Status LED Cassette paper-size detection switch PCB SW1601 J1601B-1 J204-10 LSIZE1 SW1602 Lower cassette LSIZE2 Detects the lower cassette SW1603 paper-size LSIZE3...

  • Page 19: Pick-Up/Feed System

    CHAPTER 2 II. PICK-UP/FEED SYSTEM A. Outline On receiving the pick-up command from the option controller, the paper deck driver starts paper-pick up operation. The paper is picked up by the pick-up roller and fed into the feed unit by the feed roller 1 and the separation roller. The paper stops after its skew is corrected by the registration roller.
  • Page 20 CHAPTER 2 Option controller PCB Serial line Paper deck driver PCB Pick-up PCB Feed roller 2 PS1208 Pick-up roller Feed roller 1 Registration roller Separation roller SW1601 SW1602 PS1202 SW1603 PS1205 SW1604 Feed roller 1 PS1206 PS1207 Separation SW1601 roller Pick-up roller SW1602 PS1201...
  • Page 21 CHAPTER 2 Option controller PCB Serial line Paper deck driver PCB Feed roller 2 Pick-up PCB Registration roller SPM2 Pick-up roller Feed roller 1 SPM1 Paper feed unit Separation roller Rotation SPM3 Reverse rotation Upper cassette Feed roller 1 Lifter Pick-up roller Separation roller Lower cassette...
  • Page 22 CHAPTER 2 B. Paper pick-up 1. Pick-up operation This paper deck conducts paper pick-up operation by lifting the paper to the paper pick-up position with the lifter and lowering the rotating cassette pick-up roller to the paper level. Paper pick-up operation is conducted only when the paper deck driver receives the pick-up command from the option controller.
  • Page 23 CHAPTER 2 (Unit: Seconds) PRINT Pick-up command about 1.0 Drive motor (SPM1) Pick-up solenoid (SL1) Pick-up motor (SPM3) Paper feed motor (SPM2) about 0.4 Registration sensor (PS1) about 0.1 Registration clutch (CL1) about 0.8 Paper jam sensor (PS2) T=Upper cassette pick-up : 0.8 T=Lower cassette pick-up : 1.1 Figure 2-2-4 2 - 9...
  • Page 24 CHAPTER 2 a. Cassette detection/cassette paper size detection/cassette paper level detection The upper and lower cassettes detection is executed by the upper cassette sensor (PS1202) and the lower cassette sensor (PS1201). The paper detection in the upper and lower cassettes is executed by the upper cassette paper out sensor (PS1208) and the lower cassette paper out sensor (PS1207).
  • Page 25 CHAPTER 2 Pick-up unit Pick-up PCB Paper level Paper amount (Note) Full About 430 sheets or more High About 210 - 490 Middle About 60 -270 Low empty About 120 or less Note: In case of plain paper (75g/m recommended paper) PS1204/PS1206 PS1203/PS1205 Light blocking...
  • Page 26 CHAPTER 2 b. Lift-up operation The lift-up operation is executed by the paper deck drive motor when a cassette is installed or the pick-up roller shaft is set lower than certain level due to the paper reduce. The two cases for the lift-up operation are as follows. Cassette pick-up cam Pick-up roller Feed roller 1...
  • Page 27 CHAPTER 2 1) Cassette is installed When a cassette is installed, the paper deck drive motor rotates, and the cassette paper pick-up solenoid (SL3) is turned ON. Then, the shaft drive arm is driven by the cassette paper pick-up cam rotation through the gear. Cassette pick-up cam Shaft drive arm Paper deck drive motor drive...
  • Page 28 CHAPTER 2 As the shaft drive arm goes down, the pick-up roller shaft goes down. Then, the lift-up release arm is pushed, and the lift-up cam is unfixed. At the same time, the shaft drive arm is fixed to the pick-up roller shaft fixing arm, and the pick-up roller shaft is stopped in the designated position.
  • Page 29 CHAPTER 2 The pick-up roller shaft is lifted up when the paper on the paper lifting plate touches the pick-up roller. Then, the fixing arm is released, and the lift-up release arm lifts up the pick-up roller shaft to the waiting position by force of the spring. At the same time, the lift- up cam is fixed by driving the pick-up roller shaft fixing arm and the lift-up release arm.
  • Page 30 CHAPTER 2 2) Paper level is lower than certain level As the paper level lowers, the moving distance of the pick-up roller increases. When the moving distance reaches the specified value, the pick-up roller shaft pushes the lift up release arm, and the lift up cam is unfixed. •...
  • Page 31 CHAPTER 2 When the lift-up cam is unfixed, the lift-up arm lifts up the lifter gear one tooth by the rotation of the lift-up cam. The paper lifting plate is lifted up by repeating the operation. (See Figure 2-2-9) When the paper on the paper lifting plate touches the pick-up roller, the pick-up roller shaft is lifted up.
  • Page 32 CHAPTER 2 c. Multi-feed prevention mechanism The paper deck utilizes the separation roller to prevent feeding multiple sheets of paper. Normally the separation roller is imparted with the rotational force in the same direction as that of the feed roller. However, since the separation roller has a torque limitter, it is rotated in the opposite direction by the rotational force transmitted from the feed roller 1 via the picked up paper.
  • Page 33 CHAPTER 2 C. Paper Jam Detection The following paper sensors are installed to detect the presence of paper and ensure that the paper is fed correctly. • Registration paper sensor (PS1) • Paper jam sensor (PS2) The CPU on the paper deck driver PCB determines whether or not a paper jam has occurred by monitoring the paper at each sensor according to the pre-set 'check timing' in the memory.
  • Page 34 CHAPTER 2 III. POWER SUPPLIES A. Outline The power supply unit of this paper deck employs the remote switch method. When the printer is turned ON, it outputs a command to the option controller via the video controller. Based on this command, the option controller outputs the POWER-ON signal (PWRON-IN) to the power supply unit via the paper deck driver.
  • Page 35 CHAPTER 3 THE MECHANICAL SYSTEM PREFACE ......3-1 SENSORS ......3-10 EXTERNALS ......3-2 VI. SOLENOID/CLUTCH ....3-13 III. MAIN UNITS ......3-5 VII. MOTORS ....... 3-16 IV. MAIN PARTS ......3-8 VIII. PCBs ........3-19...

  • Page 37: Preface

    CHAPTER 3 I. PREFACE A. Outline This chapter describes disassembly and reassembly procedures of the paper deck. The service technician is to find the cause of the failure according to the "Chapter 4 Troubleshooting" and to follow the disassembly procedures in this chapter to replace the defec- tive part(s).

  • Page 38: Externals

    CHAPTER 3 II. EXTERNALS A. Locations Front sub cover Feed cover Right cover Housing unit Left cover Rear cover Figure 3-2-1 Follow the procedures below to remove the cover(s) when cleaning, inspecting, or repairing inside the paper deck. The procedures for the covers, which can be removed simply by removing screws without tak- ing out other parts, are omitted.
  • Page 39 CHAPTER 3 1. Left cover 3. Rear cover 1) Remove the 2 screws. 1) Remove the 4 screws and the rear cover. 2) Remove the claw and the left cover. Screws Rear cover Screws Claw Left cover Figure 3-2-4 Figure 3-2-2 4.
  • Page 40 CHAPTER 3 5. Front sub cover 6. Housing unit 1) Remove the rear cover, left cover and 1) Remove the rear cover, left cover and right cover. right cover. 2) Unhook the 4 hooks and slide the front 2) Remove the 4 hooks, then slide the sub cover with the status LED PCB housing unit in the direction of the toward you.

  • Page 41: Main Units

    CHAPTER 3 III. MAIN UNITS B. Pick-up unit 1) Remove the rear cover and the right cover. A. Feed unit 2) Remove the feed unit according to the 1) Open the feed unit. feed unit removal procedures on page 3- 2) Disconnect the 3 connectors 3) Slide the 2 feed spacers in the direction 3) Disconnect the connector and then...
  • Page 42 CHAPTER 3 Notes: 1. While replacing parts in the pick-up unit, to prevent grease from getting on the pick-up, feed and separation rollers, be sure to remove them before working on the unit. Take care not to get grease on the paper feed guide. 2.
  • Page 43 CHAPTER 3 Roller holder Shaft Upper lift-up cam Pick-up cam 100T gear 20T/41T gear Lower lift-up cam 31T/47T gear Lifter Figure 3-3-4 3 - 7...

  • Page 44: Main Parts

    CHAPTER 3 IV. MAIN PARTS A. Locations Registration rollers Pick-up rollers Feed rollers 1 / Separation rollers Figure 3-4-1 3 - 8...

  • Page 45: Separation Roller

    CHAPTER 3 B. Registration roller C. Pick-up roller / Feed roller 1 / 1) Remove the registration clutch accord- Separation roller ing to the registration clutch removal 1) Grasp the knobs of each roller and pull procedures on page 3-14. the rollers out of the printer.
  • Page 46 CHAPTER 3 V. SENSORS A. Locations 1: Registration paper sensor 2: Paper feed unit sensor 3: Upper cassette paper-level sensor 2 4: Upper cassette paper-level sensor 1 5: Lower cassette paper-level sensor 2 6: Lower cassette paper-level sensor 1 7: Lower cassette sensor 8: Paper jam sensor 9: Lower cassette paper-out sensor 10: Upper cassette paper-out sensor...

  • Page 47: Upper Cassette Sensor

    CHAPTER 3 B. Paper feed unit sensor C. Upper cassette sensor / Lower cas- 1) Remove the pick-up motor according to sette sensor / Upper cassette paper- the pick-up motor removal procedures level sensor 1, 2 / Lower cassette on page 3-18. paper-level sensor 1, 2 / Upper cas- 2) Remove the pick-up PCB according to sette paper-out sensor / Lower cas-...

  • Page 48: Paper Jam Sensor

    CHAPTER 3 D. Registration paper sensor E. Paper jam sensor 1) Remove the feed cover. 1) Remove the feed cover. 2) Remove the connector. 2) Remove the connector. 3) Remove the screw from the bottom, and 3) Remove the paper jam sensor. take out the sensor holder and then the registration paper sensor.

  • Page 49: Solenoid/Clutch

    CHAPTER 3 VI. SOLENOID / CLUTCH A. Locations Pick-up solenoid Registration clutch Figure 3-6-1 3 - 13...

  • Page 50: Pick-Up Solenoid

    CHAPTER 3 B. Pick-up solenoid C. Registration clutch 1) Remove the pick-up unit according to 1) Remove the feed unit according to the the pick-up unit removal procedures on feed unit removal procedures on page 3- page 3-5. 2) Remove the screw, connector, and then 2) Remove the feed cover.
  • Page 51 CHAPTER 3 4) Remove the 3 screws and the feed motor mount plate. Screws Feed motor mount plate Figure 3-6-4 5) Remove the E-ring and the registration clutch. E-ring Registration clutch Figure 3-6-5 3 - 15...

  • Page 52: Motors

    CHAPTER 3 VII. MOTORS A. Locations SPM1 SPM2 SPM3 Paper deck drive motor Paper feed motor Pick-up motor Figure 3-7-1 3 - 16...

  • Page 53: Paper Feed Motor

    CHAPTER 3 B. Paper feed motor C. Paper deck drive motor 1) Remove the feed motor mount plate 1) Remove the pick-up unit according to according to step 1) to 4) in the regis- the pick-up unit removal procedures on tration clutch removal procedures on page 3-5.

  • Page 54: Pick-Up Motor

    CHAPTER 3 3) Remove the 2 screws and the connector, D. Pick-up motor and then slide the paper deck drive 1) Remove the pick-up unit according to motor in the direction of the arrow to it. the pick-up unit removal procedures on page 3-5.

  • Page 55: Pcbs

    CHAPTER 3 VIII. PCBs A. Locations Paper deck drive PCB Pick-up PCB Power supply unit Status LED PCB Upper cassette paper-size detection switch PCB Lower cassette paper-size detection switch PCB Figure 3-8-1 3 - 19...

  • Page 56: Paper Deck Driver Pcb

    CHAPTER 3 B. Paper deck driver PCB C. Pick-up PCB 1) Remove the rear cover and left cover. 1) Remove the pick-up unit according to 2) Remove the 4 nuts. the pick-up unit removal procedures on 3) Remove the 6 connectors, and 2 screws, page 3-5.

  • Page 57: Upper Cassette Paper-Size Detection Switch Pcb

    CHAPTER 3 D. Upper cassette paper-size detection E. Lower cassette paper-size detection switch PCB switch PCB 1) Remove the paper deck driver PCB 1) Remove the paper deck driver PCB and according to the paper deck driver PCB the mount plate according to step 1) to removal procedures on page 3-20.
  • Page 58 CHAPTER 3 F. Status LED PCB G. Power supply unit 1) Remove the front sub cover. 1) Remove the rear cover and the left 2) Remove the connector and status LED cover. PCB. 2) Remove the 2 screws, connector, and then the power supply unit.
  • Page 59 CHAPTER 4 TROUBLESHOOTING PREFACE ......4-1 VI. MEASURMENT AND PAPER JAMS ......4-9 ADJUSTMENT ....... 4-16 III. PAPER FEEDING VII. MAINTENANCE AND TROUBLESHOOTING ..... 4-12 SERVICING ......4-18 IV. MALFUNCTION VIII. LOCATION OF CONNECTORS . 4-22 TROUBLESHOOTING ..... 4-13 MALFUNCTION STATUS TROUBLESHOOTING .....

  • Page 61: Malfunction Diagnosis Flowchart

    CHAPTER 4 I. PREFACE A. Malfunction Diagnosis Flowchart The malfunctions that occur in the paper deck are classified into four types; "paper jams", "paper transport malfunction", "operation malfunction", and "malfunction status". If a malfunction occurred in the paper deck, the service technician is to find which type the malfunction falls into using the malfunction diagnosis flowchart and to clear the problem according to the troubleshooting procedures for each malfunction type.
  • Page 62 CHAPTER 4 Initial check execution Power ON (Note 1) Refer the item, "malfunction Displays "operator call" Displays "READY"? troubleshooting" or "service call" Do you make Refer to the item, "malfunction paper pick-up test ? status troubleshooting" Execute a paper pick-up test (Note 2) Refer the item, "paper jams"...

  • Page 63: Initial Checks

    CHAPTER 4 B. Initial Checks 1. Installation environment The same as that of the printer. 2. Paper checks a. The paper recommended for the paper deck is used. b. The paper is not damp. 3. Condensation During winter, particularly when moving the paper deck into a warm room from a cold location such as warehouse, condensation can appear in the paper deck.

  • Page 64: Service Checkpoints

    CHAPTER 4 C. Service Checkpoints 1. Pick-up roller, separation roller, and feed roller Clean the rollers with a lint-free paper or a cloth moistened with ethyl or isopropyl alcohol. Figure 4-1-2 1: Pick-up roller 2: Feed roller 1 3: Separation roller 4 - 4...

  • Page 65: Service Mode

    CHAPTER 4 D. Service Mode 1. Outline If malfunction or paper jam occurs in this paper deck, the condition of the paper deck can be checked by Status LED on the status LED PCB (LED1: LED with two-color display of Green and Orange) and Service LED on the paper deck driver PCB.
  • Page 66 CHAPTER 4 3. Condition check by service technician Service technician can check the paper deck condition by combination of the DIP switches and the display of the service LED (LED201). a. Normal condition Normal condition of the DIP switches are as follows. SW201-1: OFF, SW201-2: OFF, SW201-3: OFF, SW201-4: OFF The service LED flashes by repeating light-ON for 0.5 seconds and light-OFF for 0.3 seconds while the paper deck is executing normal operation.
  • Page 67 CHAPTER 4 Table 4-1-1 Header Sense contents The factor of the error Registration paper sensor delay jam Registration paper sensor initial jam Paper jam sensor delay jam Paper jam sensor stationary jam Paper jam sensor initial jam Door open No cassette, or the cassette is being lifted up No paper b.
  • Page 68 CHAPTER 4 Lower cassette paper out sensor (PS1207) Upper cassette paper level sensor (PS1205, PS1206) Upper cassette sensor (PS1202) Upper cassette paper out sensor (PS1208) Upper/lower cassette paper size detection switch (SW1601, SW1602, SW1603, SW1604) 5) Check if the LED flashes by moving the sensor levers or the switches. Do not move more than one sensor lever at the same time.

  • Page 69: Paper Jams

    CHAPTER 4 II. PAPER JAMS Execute the following procedure if the paper jam occurs in the paper deck. The feed path is mainly classified into two units: Pick-up unit and Feed unit. Refer to the unit in which the paper jam occurred and find out the defect parts. Figure 4-2-1 II-1: Pick-up unit II-2: Paper feed unit...
  • Page 70 CHAPTER 4 II-1 Pick-up unit < possible causes > 1. Cassette pick-up roller or feed roller 1 is worn or deformed. Action: Replace any worn or deformed roller. The feed roller and the separation roller are to be replaced together. 2.
  • Page 71 CHAPTER 4 Action: Reconnect the registration clutch connector J306, intermediate connector J210, and connector J207 on the paper deck driver PCB. 9. Registration clutch failure Action: Disconnect the registration clutch connector J306. Measure the resistance between the connector J306-1 (/REGCLD) and J306-2 (+24V) of the cable. Replace the reg- istration clutch if the resistance is not about xx Ohm.

  • Page 72: Paper Feeding Troubleshooting

    CHAPTER 4 III. PAPER FEEDING TROUBLESHOOTING III-1 Multiple feed < possible causes > 1. Separation roller is worn or deformed Action: Replace it. 2. Separation roller spring failure Action: Re-set it correctly, or replace it if deformed. III-2 Wrinkles < possible causes > 1.

  • Page 73: Malfunction Troubleshooting

    CHAPTER 4 IV. MALFUNCTION TROUBLESHOOTING IV-1 No AC power < possible causes > 1. The POWER ON signal is not input because of the poor contact in the interface connector. Action: Reconnect the interface connector correctly. 2. Power switch failure Action: Remove the power supply unit, and put the tester between the power switch termi- nals.
  • Page 74 CHAPTER 4 deck driver PCB correctly. 2. Feed motor failure Action: Replace it. 3. Paper deck driver PCB failure Action: Replace it. IV-4 Pick-up motor failure < possible causes > 1. Poor contact in the PICK-UP MOTOR DRIVE signal line connector. Action: Reconnect the connector J208 on the paper deck driver PCB and the connector J1201 and J1202 on the pick-up PCB.

  • Page 75: Malfunction Status Troubleshooting

    CHAPTER 4 V. MALFUNCTION STATUS TROUBLESHOOTING V-1 Printer cannot become READY because "Paper out status" is output when the speci- fied cassette is loaded with paper. < possible causes > 1. Pull out the upper and lower cassettes. Then, set the specified cassette in the printer. If the lifter does not go up at this point, perform step 5 onward.

  • Page 76: Measurement And Adjustment

    CHAPTER 4 VI. MEASUREMENT AND ADJUSTMENT A. Mechanical Adjustment 1. Side registration adjustment of the cassette When the side registration of the cassette is not aligned, this adjustment needs to be made. The side registration adjustment levers (see Figure 4-6-1) in the upper and lower cassettes are adjusted in the factory.
  • Page 77 CHAPTER 4 The value of "a" drops by 0.5mm for each notch moved. Leading edge of paper The value of "a" rises by 0.5mm for each notch moved. Figure 4-6-1 4 - 17...

  • Page 78: Electrical Adjustment

    CHAPTER 4 B. Electrical Adjustment This paper deck has no item for electrical adjustment. C. LEDs, test pins, jumpers, and switches on PCB The following LEDs, test pins, jumpers, and switches on PCB only are for after-sales service use. The test pins or the other components excluded from the list are exclusively for factory use. Do not touch these components in the field since the adjustment of those components requires special tools, adjuster, and high precision.

  • Page 79: Status Led Pcb

    CHAPTER 4 Table 4-6-1 Function Switches for the service mode SW 201 (Refer to page 4-5) Check LED for service technician LED201 2. Paper-level detection switch PCB J1601 SW1604 SW1603 SW1602 SW1601 Figure 4-6-3 Table 4-6-2 SW No. Function SW1601 Cassette paper-size detection SW1602 switches...

  • Page 80: Maintenance And Servicing

    CHAPTER 4 VII. MAINTENANCE AND SERVICING A. Periodic Replacement Parts This paper deck has no periodic replacement parts. Note: Periodic replacement parts are the parts that must be replaced at regular intervals, even if they are functioning properly and show no signs of wear. (Failure of these parts can seriously affect printer performance.) These parts should be replaced during a regular service visit closest to the end of the parts expected life.

  • Page 81: List Of Lubricants And Cleaners

    CHAPTER 4 F. List of Lubricants and Cleaners Table 4-7-2 Material name Components Remarks Alcohol: ethyl Cleaning: plastic, • Purchase locally (pure or rubber CHOH • Flammable: keep away denatured) or from flame isopropyl (pure or denatured) Lubricating oil Apply between gear Petroleum mineral oil •...

  • Page 82: Location Of Connectors

    CHAPTER 4 VIII. LOCATION OF CONNECTORS J229 J209 J219A J207 J219 J208 J206 J201 J202 J205 J1601A J203 J204 J1601B J901 J1206 J210 J308 J1203 J210A J1202 J306 J302A J307 J302 J209 J305A J305 Figure 4-8-1 4 - 22...

  • Page 83: Appendix

    APPENDIX GENERAL CIRCUIT DIAGRAM. A-1 LIST OF SIGNALS ....A-3...

  • Page 85: Paper Deck Driver Pcb

    GENERAL CIRCUIT DIAGRAM Paper feed unit sensor Pick-up PCB Lower cassette Lower cassette Pick-up motor Cassette pick-up Registration Paper jam Lower cassette Upper cassette paper-level paper-level solenoid SPM3 paper sensor sensor sensor 1 sensor 2 sensor sensor PS1201 PS1202 PS1203 PS1204 Registration clutch Upper cassette...
  • Page 87 APPENDIX II. LIST OF SIGNALS A. Input/output signals to/from Paper deck tray driver PCB Connector Abbreviation I/O Logic Signal name J201 SERIAL IN signal SERIAL OUT signal CONTO Communication ready signal +24V Serial clock signal +24V STRBI Strobe signal PWRON-IN Power on signal +24V J202...
  • Page 88 APPENDIX Connector Abbreviation I/O Logic Signal name LSIZE3 LOWER CASSETTE PAPER SIZE SENSE signal LSIZE2 LOWER CASSETTE PAPER SIZE SENSE signal LSIZE1 LOWER CASSETTE PAPER SIZE SENSE signal J205 DRVAD PAPER DECK DRIVE MOTOR DRIVE signal DRVAND PAPER DECK DRIVE MOTOR DRIVE signal DRVBD PAPER DECK DRIVE MOTOR DRIVE signal DRVBND...
  • Page 89 Prepared by PERIPHERAL PRODUCTS QUALITY PLANNING DIV. PERIPHERAL PRODUCTS TECHNICAL DOCUMENTATION DEPT. CANON INC Printed in Japan REVISION 0 ( JAN. 1999 ) 5–1, Hakusan 7-chome, Toride-City, Ibaraki-Pref., 302-8501, Japan...
  • Page 90 The printing paper contains 70% waste paper. PRINTED IN JAPAN (IMPRIME AU JAPON) 0199AT0.70 CANON INC.
