FEATURES
.. Twin cone design for extended frequency response
.. Multi-tap transformer for 70 V / 100 V operation
.. Steel back can with cable glands
.. Integrated hardware and mounting system included
DESCRIPTION
The CIS50 is designed for flush-mounted ceiling installation. The
driver features an auxilliary HF cone coupled to the LF cone. This
provides a smoother, more extended frequency response than
typical 5 in drivers. The result is acoustic performance not generally
associated with a commercial ceiling speaker in this price range.
The CIS50 is supplied with an integral multi-tap 70 V / 100 V line
transformer adjustable by a connector on the transformer. The
steel backcan is fitted with unique clamps that can significantly
reduce its installation time. The grille assembly is firmly attached
from behind the baffle. The driver/baffle assembly then easily
installs in the pre-mounted backcan with spring-loaded hardware.
This results in a solid attachment method that also provides a
cosmetically clean appearance. Five year warranty.
CONFIGURATION
Subsystem
Transducer
Full-range
1x5.25 in cone and whizzer Sealed
Operating Mode
Single amp
Full-range
PERFORMANCE
Operating Range
100 Hz to 20 kHz
Transformer Taps (watts)
70 V
3 / 1.5 / 0.75 / 0.38
100 V
6 / 3 / 1.5 / 0.75
Accelerated Life Test
100 V
6 W @ 1667 ohms
EAW Commercial | One Main Street | Whitinsville, MA 01588 USA | TEL toll free within US/Canada 888.337.7404
PHYSICAL
Enclosure
Painted steel, steel baffle, steel grille
Loading
Dimensions (inches / mm)
Weight (approximate net lb / kg)
TEL outside US 425.892.6503 | FAX 425.485.1152 | Page 1 of 1
5.25 in Coaxial Ceiling Loudspeaker
APPLICATIONS
.. Meeting Rooms
.. Schools
.. Hotels
.. Offices
.. Transportation Terminals
.. Boardrooms
.. Healthcare
.. Multizone Paging/Music Systems
H x Dia
5.0 x 7.1
Opening
6.3
2.9
CIS50
127 x 180
160
1.3
Part No. SW0144 Rev. A 07/04
