- Page 1 Installation and Setup Manual Publication No II 3478 4/99 Supersedes 7/97 KODAK Network ID Camera Health Imaging...
- Page 3 Kodak reserves the right to change this information without notice, and makes no warranty, expressed or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from the use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
-
Page 5: Table Of Contents
II 3478 Installation and Set-up Manual Table of Contents Description Page 1 General 2 Installation 2.1 Unpacking............................ 1 2.2 Installation Details........................1 3 Setup 3.1 Getting into setup mode......................3 3.2 Resetting to factory default ......................3 3.3 Main configuration window ......................4 3.3.1 Picture and settings ........................ - Page 6 Installation and Set-up Manual II 3478 4 Upgrading the firmware 4.1 Download the firmware......................21 5 Error Messages 5.1 Illegal value..........................23 5.2 The adjustment may be max 32....................23 5.3 Out of storage for FTEXT ......................23 5.4 Length must be between 1 and 8 ....................23 5.5 Communication error.........................23...
-
Page 7: Installation
Installation and Set-up Manual General This manual describes how to install and setup the KODAK Network ID Camera herein called KNIC. This includes anything from installation to setting-up what the picture printed on the film should look like, which language for the display, to how it should communicate with a booking system. - Page 8 Check with customer that the keyboard has the local used keycaps. Country keycap sets can be ordered as spare parts if needed. Caution The KODAK Network ID Camera is classified as Information Technology Equipment according to EN 60950. According to European Safety Regulations for Medical Equipments, the following conditions must be fullfilled: - if the camera is operated within a distance of 1.5 m from the patient, it must...
-
Page 9: Setup
Get into configuration mode as described in chapter 3.1. Then press Ctrl-E. This will reset the memory of the KODAK Network ID Camera and restart the camera just as if you were switching the power on again. Go to chapter ”Settings” to find out how to change the language of your preference. -
Page 10: Main Configuration Window
(settings for example). The soft-keys are used as follows: Lock the set-up with a password. Will make the KODAK Network ID Camera Lock ask for password the next time set-up is entered. An alternative to LOCK is to wait for the password time-out. -
Page 11: Sensor Adjustment
II 3478 Installation and Set-up Manual 3.3.4 Sensor adjustment This selection will show a picture showing the status of the three cassette sensors. For detailed information, please refer to the Service manual. 3.3.5 Test functions Here parameters regarding the opening of the cassette window can be set. For detailed information, please refer to the Service Manual. -
Page 12: Some Frequently Used Words
To add a new item, place the cursor on the position where you like to add a field and press the NEW soft-key. This will make the KODAK Network ID Camera duplicate the field at the cursor and you can then edit one of the copies as you wish. The maximum numbers of fields are 50 for each window, C1/C1N. -
Page 13: Editing A Field
AP/PA - Anterior or Posterior. This tells, whether the X-ray picture is taken with the X-ray tube in front or behind the patient. Apart from displaying it in the film, the information is used by the KODAK Network ID Camera to mirror the picture when the picture is taken PA. - Page 14 (MMM). Time - Prints current time. Functions the same way as the DATE field. COMM - Communication. This field is used if the KODAK Network ID Camera is connected to other equipment that sends data to the KODAK Network ID Camera, for example an X-ray unit that can send information about kV and mAs.
-
Page 15: Settings Standard, C1/Min-R2, C1N
II 3478 Installation and Set-up Manual 3.4.5 Settings Standard, C1/Min-R2, C1N If Settings Standard, C1 is selected, the following will be displayed: Settings Status: Used Text: Normal Exposure: 550 ms Location: Bottom Intensity: Vert adjust: Name: Standard, C1 Previous Next Save The cursor is located at ”Status”... -
Page 16: Menues
Selecting this item will present a window where the communication channels of the KODAK Network ID Camera can be configured. This window works slightly different from the previous windows: instead of presenting a sub-menu where the item to configure is... -
Page 17: Communication Parameters Channel: Host
Channel (F1) soft-key. To configure a parameter of the selected protocol press the Shift Protocol (Shift-F1) soft-key. Note that not all protocols have a protocol set-up associated. This chapter does not cover all details of the KODAK Network ID Camera communication. For more information please refer to the Network Installation Manual. -
Page 18: Protocol Set-Up
This window is used to set-up a translation table between a field number used in the communication protocol and the field number in the C1 and C1N window of the KODAK Host C1 Network ID Camera. -
Page 19: Protocol Set-Up Siemens Mammomat 3000
Swedish ÅÄÖ for example. AUTO - Fortunately there are, in most cases, no conflicts between the codes used in the different character sets, which means that the KODAK Network ID Camera can apply the translation scheme for all character sets at the same time without any conflicts. - Page 20 3000 is sending ether 0 or 1 as the FOCUS parameter and the Kodak Network ID Camera is translating it to a text according to the protocol set-up above. In this case the texts are SF for 0 and LF for 1.
-
Page 21: Protocol Set-Up Ge Medical System Senographe
Type COMM. The The Senographe is sending 0, 1 or 2 as the MODE parameter and the Kodak Network ID Camera is translating it to a text according to the protocol set-up above. In this case the texts are AOP for 0, AEC for 1 and Manual for 2. -
Page 22: Protocol Set-Up Gxdp
Installation and Set-up Manual II 3478 These fielddefinitions will give us the text ”Mode” followed by the ”MODE”-value at the center bottom of the patient data window. 3.5.6 Protocol set-up GXDP Select GXDP-P or GXDP-NP protocol depending on whether the polling function is to be used or not, refer to the Network Installation Manual. - Page 23 II 3478 Installation and Set-up Manual field and it should start at column 132 (The COMM field starts at column 108 and has a length of 4 character, a small font character is 6 pixels wide, this gives us that the start position of the F-text field should be 108 + 4 x 6).
-
Page 24: Settings
Exit Use the up and down arrows to move the cursor between the settings, and use Previous and Next soft-keys to select option. Selects the language the KODAK Network ID Camera will speak. Factory Language default is ENGLAND. will select country-depending settings like date format, PID number format. -
Page 25: Remote Control
HOST or AUX on the camera and the other end either COM1 or COM2 on the PC. The software kit is available from Kodak with part number T240000. 3.7.1 Save a Set-up To save a set-up to a PC the following must be performed: •... -
Page 26: Load A Set-Up
To load a set-up from a PC the following must be performed: • Connect a PC to the Kodak Network ID Camera. • Enter ”Remote control” and select which communication port and speed to use. • Press F1 ”Connect”, a text ”Waiting” appear on the display. The camera is now ready for a transmission session. - Page 27 • Software for the PC is required. The software, FWDL.EXE, runs under MS-DOS or in a MS-DOS box in WINDOWS 3.1, WINDOWS 95 or WINDOWS NT. FWDL.EXE is included in the ”Software Kit” which is available from Kodak with part number T240000.
- Page 28 Installation and Set-up Manual II 3478 When downloading is finished the camera will restart as if the camera was switched off and on again. The final step is to check if the setup is erased and thus needs to be reloaded.
- Page 29 II 3478 Installation and Set-up Manual Error Messages Although all error messages are plain text and self explaining, some guidelines on how to react and handle on these will be appropriate. The error message will disappears when any key is pressed.
- Page 30 Installation and Set-up Manual II 3478 Programming voltage missing (JP8) Action: Make sure the JP8 jumper is correctly installed. The jumper should be set at 1 - 2 (to the left). Failed to erase set-up memory Action: Make sure the JP8 jumper is correctly installed. The jumper should be set at 1 - 2 (to the left).
