Summary of Contents for Akai HT014A-5086F
-
Page 2: Important Safety Instructions
WARNING: To prevent fire or shock hard, do not expose the unit to rain or moisture. *Note:This product is for indoor use only. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. -
Page 3: Packing List
PACKING LIST 1. Subwoofer : 1 unit 2. Satellite Speakers : 5 unit 3. Audio Cable : 3 unit 4. User Manual : 1 unit 5. Remote Control : 1 unit 6. Warranty Card : 1 unit DESCRIPTION OF THE SUBWOOFER CONTROL PANEL 1. INPUT... -
Page 4: Battery Installation
AC POWER IMPORTANT NOTES .Make sure the power supply is proper and never handle the power cord or its plug with wet hands when plugging into, or unplugging from an outlet. .Ensure that the main power switch is in the “OFF” position before connecting the AC power cord to the power supply to avoid damage to the unit. .A damaged power cord can easily cause an electric shock or fire hazard; Never use a power cord after it has been damaged. BATTERY INSTALLATION 1) Open the battery case. 2) Insert two batteries without the polarity reversed. 3) Close the battery case. 4) Keep within 5 meter range, 30 degree angle while aiming at the unit. Precautionary note: Remove the battery when the unit is not being used for a long period of time. -
Page 5: Description Of The Remote Control
DESCRIPTION OF THE REMOTE CONTROL 1.STANDBY: To enter/exit standby mode 2.USB: To enter into USB playback. 3.SD/MMC: To enter into SD/MMC playback. 4.EQ MODE/EQ OFF : To choose audio output sound field effect(POP, ROCK, JAZZ, CLASS, COUN) 5. MUTE:To mute the sound 6. BT: This button only functions when your speaker system has BT function 7. CENTER+, - : To increase or reduce the Center Volume. 8. FRONT+, - : To increase or reduce the Front Volume. 9. REAR+, - : To increase or reduce the Rear Volume. 10. BASS+, - : To increase or reduce the Bass Volume. 11. PREV : To select the previous song in USB/SD/BT. 12. PLAY/ PAUSE : To play/pause. 13. NEXT : To select next song in USB/SD/BT 14. REPEAT: To repeat an audio play 15. M: Mode switchover (USB,SD, AC-3,AUX,BT) 16. PRO : Logic channel switch 17. VOL+,- : To increase volume 18. BASS+,- : To increase the Bass volume 19. RESET : Long press to recover to default mode 20. AUX IN : To enter into Aux playback. 21. 5.1 : To enter into 5.1ch input 22. FRONT+,- : To increase or reduce the Front Volume. 23. REAR+,- : To increase or reduce the Rear Volume. -
Page 6: Stereo Input
A. STEREO INPUT RCA Connectors to take input from external audio source B. AC 3 /5.1 OUTPUT Front left, front right, rear left, rear right & center C. POWER ON/OFF switch D. POWER INPUT AC220V 50Hz UNIT OPERATION 1) First plug the cable of satellite into the output jack on rear panel of woofer, one end of audio cable connected into the input jack on rear panel of woofer, the other end connected into the output jack of the computer or any external audio source. 2) Connect the AC power cord with power socket to the main, press ON/OFF switch on the rear panel of subwoofer, LED indicator light up in red color, the units enters into AUX mode. 3) Press “Volume + / Volume - ” button on woofer front panel or remote to adjust the volume in playback mode. Press “BASS+/BASS-” button on remote to adjust the bass. 4) Press ”Prev / Next” button on woofer front panel or remote choose previous/next song in playback mode. 5) Press ”Play/Pause” button on woofer front panel or remote to pause the music in playback mode.Press again to resume the music. -
Page 7: Specifications
BT Operating: 1. Press “BT” on remote controller or “Input” button on subwoofer front panel, the units enters into BT playback, LED indicator of subwoofer front panel will flash in red color. Search for “HT014A-5086F” on BT device and pair the devices with the speaker system, the LED indicator of subwoofer front panel will keep lighting up in red color after connected successfully. 2. When playing the files in BT devices, Short press “vol+/vol-” button on remote or subwoofer front panel to increase/decrease the volume; Short press “prev/next” button on remote or subwoofer front panel to select previous/next song in BT devices. Note:BT working range is about 8 meter in open area. FEATURES →Analog audio input.
