Summary of Contents for Haier HIH-T60HM-V
- Page 1 HIH-T60HM-V HIH-T90HM-V...
-
Page 2: Table Of Contents
CONTENTS ......................1 Safety Precaution ....................4 Important Information ......................5 Product Overview .........................5 Packing List ........................6 Installation ......................9 Use Instruction ..................10 Maintenance and Services ......................11 Prats Removal ......................13 Circuit Diagram ..................... 3 General Troubleshooting... -
Page 3: Safety Precaution
Range Hood Dear users: Thank for your buying our range hood Please accept our best regards Please read this user manual carefully before installation and operation. *The pictures in this manual only for your reference. If the picture isn’t accord with object, subject to object. We keep to right to update appearance, structure or products without notice. - Page 4 Range Hood Danger Please turn off range hood immediately if pan got fire range hood shall aggravate fire if it’s working) and extinguish fire by effective action. Strict For example, cover flame by metal cover, turn off gas valve immediately Execution and remove inflammable things.
- Page 5 Range Hood Warning There shall be adequate ventilation of the room when the range hood is Strict used at the same time as appliances burning gas or other fuels. Execution This appliance just for household use only.And it’s not allowed to exhaust dangerous or explosive matter or air.
-
Page 6: Important Information
Range Hood Notice Because the installation is difficult and hood is heavy, the installation shall be executed by professional person based on manul. Strict Execution Don t break electric wire or other invisible equipment when cutting Strict something or drilling holes on ceiling. Execution When range hood is using in well sealed building, it should have air inlet Strict... -
Page 7: Product Overview
Range Hood Product Overview Product Parameter HIH-T60HM-V ≤59dB Model Noise HIH-T90HM-V Power Supply Rated Power Input 220-240V~ 50Hz 282W ≥23% Total Pressure Efficiency Rated Main Motor Power Input 280W ≤2W Nominal Wind Pressure 350Pa Lamp Power(max) Heating Power Turbo Airflow 1200m /h ≥91%... -
Page 8: Installation
Range Hood Installation Warning 1.The air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels, the discharge of air must fulfill the requirements of local regulations. 2. ote that when installing the metal expansion pipe, the pipe shall match with the hole in size Overlarge hole is prohibited, as it will result in loose pipe and accidental drops. - Page 9 Range Hood Installation The hood shall be installed right above the hob The minimum distance between the bearing surface of cooking appliance and the lowest part of hood is mm larger space specified in the installation instruction of gas hob shall be considered if any the distance for electric cooker may be reduced appropriately depending on the actual situations Note All data units of the following diagram are expressed in mm Figure 1...
-
Page 10: Use Instruction
Range Hood Use Instruction Switch Control Panel Quick Medium on/off Setting speed speed delay S l o w Stir-fry lighting Heating speed Note: tir-fry: Under the standby mode, then press this button to start the Stir-fry function, and it will turn to the quick speed automatically after 1 minute. Quick speed:Under the standby mode, then press this button to start the quick speed function. -
Page 11: Maintenance And Services
Range Hood Maintenance and Services Warning 1 There is a fire risk if cleaning is not carried out in accordance with the instructions. 2 Cleaning and maintenance shall be conducted under outage. Electrical components such as motor, switch, and connector shall not be spoiled by water so as to prevent from accidents. It s prohibited to wash with water so as to prevent accidents. - Page 12 Range Hood Parts Removal Warning 1.The machine body needs not to be disassembled in ordinary conditions. Disassembly shall be operated by professional serviceman. 2. Before cleaning, installation or maintenance for the range hood, cut off the power supply to avoid electric shock. Note The assembly steps are opposite with the disassembly steps Please wear protective glove during operation avoiding from hurting hands.
- Page 13 Range Hood Switch Removal This is under power disconnected situation to handle: 1. push the glass from right to left, then take out the glass panel, replace the control board. Then assemble the glass with the opposite way, comparing with disassemble the glass. And make sure the re-assembled glass is on the same level with the range hood body.
-
Page 14: Circuit Diagram
Range Hood Circuit Diagram CONTROL BOARD POWER BOARD MOTOR Heating CAPACITOR 6 F 450V μ AC220-240V/50Hz General Troubleshooting Fault Phenomenon Fault Cause Elimination Methods No response by pressing any switch Power plug is not well connected ( . . e g impeller does not rotate Well connect the power plug or power outage lighting lamp is not on... - Page 15 HAIER WARRANTY HAIER APPLIANCES (INDIA) PVT. LTD. (here-in-after referred to as “the Company”) hereby offers the following warranty to the original domestic purchaser commencing from the Date of the Purchase (DOP). The Company at its sole discretion, will free of charge repair or replace any defective part or parts which prove to be defective in workmanship and/or materials and...
