ATTACH YOUR RECEIPT HERE
Serial Number ________________________________ Purchase Date _________________________________
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST,
Monday – Friday or e-mail us at customerservice@ghpgroupinc.com.
70-10-636
40" 2-Door Vertical
Electric Digital Smoker
MODEL #DGU951SDE / DGU951SDE-D
1
Français p. 28
Español p. 55
FOR OUTDOOR
USE ONLY
Use only with Class A GFI
(Ground Fault Interrupter)
Rev. 02/03/20
Advertisement
Related Manuals for Dyna-Glo DGU951SDE
Summary of Contents for Dyna-Glo DGU951SDE
- Page 1 40" 2-Door Vertical Electric Digital Smoker MODEL #DGU951SDE / DGU951SDE-D Français p. 28 Español p. 55 FOR OUTDOOR USE ONLY Use only with Class A GFI (Ground Fault Interrupter) ATTACH YOUR RECEIPT HERE Serial Number ________________________________ Purchase Date _________________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-447-4768, 8:00 a.m.
- Page 2 ® DYNA-GLO 40" 2-DOOR VERTICAL ELECTRIC DIGITAL SMOKER STOP! NO NEED TO RETURN TO THE STORE Questions with The Assembly? Require Parts Information? Product Under Manufacturers Warranty? Call Toll Free : 1-877-447-4768 8:00 a.m. – 4:30 pm CST, Monday – Friday...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Information ........................Package Contents ........................Hardware Contents ........................9 Preparation Before Assembly ....................... 9 Assembly Instructions ........................ 10 Operating Instructions ......................... 14 Tips On Smoking ......................... 20 Care and Maintenance ........................ 22 Troubleshooting ........................... 23 Replacement Parts List ......................25 Warranty ............................ -
Page 4: Safety Information
SAFETY INFORMATION IMPORTANT SAFEGUARDS READ ALL INSTRUCTIONS, PRIOR TO USING THIS SMOKER • DO NOT use this product for anything other than its intended purpose. It is NOT intended for commercial use. It is NOT intended to be installed or used in or on a recreational vehicle and/or boat. •... - Page 5 SAFETY INFORMATION • DO NOT wear loose clothing while operating the smoker. Tie back long hair while operating the smoker. • ALWAYS wear shoes that fully cover your feet while operating the smoker. • DO NOT touch hot surfaces. Use handles or knobs. •...
- Page 6 SAFETY INFORMATION Ground Fault Interrupter • Since 1971, the National Electric Code (NEC) has required Ground Fault Interrupter devices on all outdoor circuits. • If your residence was built before 1971, check with a qualified electrician to determine if a Ground Fault Interrupter protector exists. • Do not use this appliance if the circuit does not have Class A GFI protection. •...
- Page 7 SAFETY INFORMATION WARNING To avoid serious injury: • While cooking, the smoker must be on a level, stable, noncombustible surface in an area clear of combustible material, including long or dry grass. • The use of alcohol, prescription or nonprescription drugs may impair the user’s ability to properly assemble and safely operate this appliance.
-
Page 8: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Smoker cabinet assembly Rear casters Front legs (left/right) Rear handle Door handle (upper door/ lower door) Rib & Sausage rack Cooking grates Water bowl Wood chip box Drawer assembly Grease tray... -
Page 9: Hardware Contents
HARDWARE CONTENTS (PRE-ASSEMBLED) M4 x 35 mm M6 x 12 mm M5 x 12 mm Screw Screw Screw Qty. 8 Qty. 6 Qty. 12 8 M4 x 35 mm screws 6 M6 x 12 mm screws 12 M5 x 12 mm (AA) are pre-assem- (BB) are pre-assem- screws (CC) are... -
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS Remove the pre-installed screws on the bottom of the cabinet assembly (A). Attach each of the rear casters (B) to the bottom of the cabinet assembly (A) using 4 M5 x 12 (CC) screws per caster. At- tach the bottom of the front legs (C) to the bottom of the cabinet assembly (A) using 3 M6 x 12 (BB) screws per leg. - Page 11 ASSEMBLY INSTRUCTIONS Remove the pre-installed screws on the door handle (E) and attach the handle to the upper door on the cabinet assembly (A) using the pre- installed screws. Hardware Used M4 x 35 mm Screw Remove the lower drawer assembly (J) from the cabinet assembly (A).
- Page 12 ASSEMBLY INSTRUCTIONS Place the grease tray (K) onto the lower frame of the drawer assembly (J). Place the water bowl (H) and wood chip box (I) onto the upper wire sup- ports of the drawer assembly (J). Slide the drawer assembly (J) onto the cabinet support rails as shown.
- Page 13 ASSEMBLY INSTRUCTIONS Slide the 4 cooking grates (G) onto the support rails of the cabinet (A) as shown Installing the Rib Rack (Optional). Place the rib and sausage rack (F) directly onto the desired grate (G) before sliding the grate onto the supports.
-
Page 14: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. - 4:30 p.m. CST, Monday - Friday or e-mail us at customerservice@ghpgroupinc.com. PART DESCRIPTION PART # PART DESCRIPTION PART # Smoker Cabinet 70-01-610 Rear Casters (L/R) 70-01-624 Assembly Front Leg Assembly... - Page 15 REPLACEMENT PARTS LIST 70-10-636 Printed in China...
