Summary of Contents for Sony DVP-FX94
- Page 1 Portable CD/DVD Player Operating Instructions Manual de instrucciones DVP-FX94 © 2010 Sony Corporation 4-169-963-22(1)
-
Page 2: Warning
Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. DVP-FX94 Serial No._____________ CAUTION You are cautioned that any... -
Page 3: Important Notice
If you have any questions or problems concerning your player, please consult your nearest Sony dealer. Copyrights and trademarks • Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. -
Page 4: Table Of Contents
Table of Contents WARNING ..........2 Guide to Parts and Controls . -
Page 5: Guide To Parts And Controls
Guide to Parts and Controls For more information, see the pages indicated in parentheses. Player DISPLAY PUSH CLOSE POWER CHARGE POWER OFF ON HOLD PHONES Buttons B C D and E (but not C/X/x/ c/ENTER) can be operated with a single touch. - Page 6 D DISPLAY Displays the playback information. • When playing a DVD: Displays the playback information and changes the playback mode. See page 15. • When playing a CD: Each time you press the button, the time information switches. E MENU •...
-
Page 7: Number Buttons
T INPUT SELECT button (page 12) Each time you press the button, the LCD screen image switches as follows: • Disc mode (default): When playing an inserted disc. • USB mode: When playing DATA files on a connected USB device. Appears “USB”... -
Page 8: Rotating And Folding Down The Lcd Panel
AUDIO button Changes the audio signal. • When playing a DVD VIDEO: Each time you press the button, the language of the sound track switches. Depending on the disc, the choice of language varies. • When playing a DVD VR: Each time you press the button, the type of sound tracks recorded on a disc switches between main, sub and... -
Page 9: Preparations
Preparations Checking the Accessories Check that you have the following items: • Battery pack (NP-FX110) (1) • AC power adaptor (1) • Car battery adaptor (1) • Audio/video cord (mini plug × 2 y phono plug × 3) (1) • Remote (1) •... - Page 10 Connect the AC power adaptor. When charging begins, the CHARGE indicator lights up in orange. SELECT INPUT POWER OFF ON HOLD PHONES AUDIO VIDEO DC IN 9.5V DC IN 9.5V AC power Adaptor (supplied) When charging ends, the CHARGE indicator lights off. Disconnect the AC power adaptor.
-
Page 11: Using The Car Battery Adaptor
Using the Car Battery Adaptor The car battery adaptor (supplied) is for a 12V car battery, negative earth (do not use it with a 24V car battery, positive earth). Start the engine. Connect the car battery adaptor. SELECT INPUT POWER OFF ON HOLD PHONES... -
Page 12: Connecting To Other Equipment
Connecting to Other Equipment By connecting the player to your TV or other equipment, you can increase your viewing options. • Refer to the instructions supplied with the equipment to be connected. • Before connecting, turn off the player and the equipment to be connected, then unplug from their wall sockets. -
Page 13: Playback
Playback Playing Discs Depending on the disc, some operations may be different or restricted. Refer to the operating instructions supplied with the disc. Connect the AC power adaptor or attach the battery pack. DISPLAY MENU RETURN POWER CHARGE PUSH CLOSE OPEN Open the LCD panel. - Page 14 To resume playback from the point where you stopped the disc (Resume Play) When you press N again after you stop playback, the player starts playback from the point when you pressed x. • To play from the beginning of the disc, press x twice, and press N.
- Page 15 Using the Playback Information Display While playing a DVD, you can check the current playback information. The playback information display also allows you to set a title/chapter or change sound/ subtitle, and so on. When entering the numbers, operate the number buttons on the remote.
-
Page 16: Playing Mp3 And Jpeg Files
Playing MP3 and JPEG Files You can play MP3 and JPEG files. For details on playable files, see “Playable Media” (page 27). When you set a DATA media, a list of albums appears. DATA CDs recorded in KODAK Picture CD format automatically start playing when inserted. - Page 17 Press INPUT SELECT to deselect “USB.” Disconnect the USB device. About supported Sony USB devices The following Sony USB Memory Stick reader/writer and USB flash drive “Micro Vault” are supported: MSAC-US40, USM-J series, USM-JX series, USM-J/B series, USM-L series, and USM-LX series.
-
Page 18: Adjusting The Picture Size And Quality
Adjusting the Picture Size and Quality You can adjust the picture displayed on the LCD screen. DISPLAY MENU Press OPTIONS. The menu display appears. Press X/x to select “LCD Mode” and press ENTER. The “LCD Mode” display appears. items LCD Mode LCD Aspect : Backlight : Contrast :... -
Page 19: Settings And Adjustments
Settings and Adjustments Using the Setup Display By using the setup display, you can make various settings to items such as picture and sound. Some discs have stored playback settings, which take priority. DISPLAY MENU RETURN OPTIONS POWER CHARGE Press OPTIONS when the player is in stop mode. -
Page 20: Audio Setup
4:3 Pan Scan 4:3 Letter Box 16:9 Depending on the disc, “4:3 Letter Box” may be selected automatically instead of “4:3 Pan Scan” or vice versa. ◆ Angle Mark (DVD VIDEO only) Displays the angle mark when you can change the viewing angles during playback of DVDs recorded with multi-angles. -
Page 21: Parental Control
Parental Control You can limit playback of a DVD that has the parental control function. When you operate this setting, use the remote. ◆ Password (DVD VIDEO only) Enter or change a password. Set the password for the parental control function. Enter your 4-digit password using the number buttons on the remote. -
Page 22: Additional Information
Should any problem persist, consult your nearest Sony dealer. Power The power is not turned on. , Check that the AC power adaptor is connected securely (page 9). - Page 23 The disc does not start playing from the beginning. , Repeat Play or Random Play is selected (page 14). , Resume play has taken effect (page 14). , The Playlist of the created disc is automatically played. To play original titles, press TOP MENU to set “Original”...
-
Page 24: Precautions
Hookup There is no picture or sound on the connected equipment. , Re-connect the connecting cord securely (page 12). , The connecting cord is damaged. , Check the setting of a connected TV or amplifier. , When “USB” or “Line In” is displayed, press INPUT SELECT repeatedly to select the disc mode (page 7). - Page 25 On temperature increases Heat may build up inside the player during charging or if it is being used for a long time. This is not a malfunction. On placement • Do not place the player in a confined space such as a bookshelf or similar unit. •...
- Page 26 • Do not touch the metal parts, as it may cause a short and damage the adaptors, especially if touched by other metal objects. On adjusting volume Do not turn up the volume while listening to a section with very low level inputs or no audio signals.
-
Page 27: Playable Media
Playable Media Type Disc Logo DATA disc or — • Notes about recordable media Some recordable media cannot be played on the player due to the recording quality or physical condition of the media, or the characteristics of the recording device and authoring software. - Page 28 Notes on MP3 and JPEG files The player can play the following files: • MP3 files with the extension “.mp3”* • JPEG files with the extension “.jpg”* • JPEG image files that conform to the DCF (Design rule for Camera File system) image file format.
-
Page 29: Specifications
Specifications System Laser: Semiconductor laser Signal format system: NTSC Inputs/Outputs VIDEO (video input/output): Minijack AUDIO (audio input/output): Stereo minijack PHONES (headphones) A/B: Stereo minijack USB: USB jack Type A (For connecting USB memory) Liquid Crystal Display Panel size: 9 inches wide (diagonal) Driving system: TFT active matrix Resolution: 800 ×... -
Page 30: Index
Index Numerics 16:9 19 4:3 Letter Box 19 4:3 Pan Scan 19 Angle Mark 7 Audio 8 Audio DRC 20 Audio Setup 20 CD 13 Charging time and playing time 10 DATA 16 Disc Menu 20 DVD 13 General Setup 19 JPEG 16 Language Setup 20 LCD Aspect 18... - Page 32 Índice Este manual explica los preparativos y el funcionamiento básico del reproductor portátil de CD/DVD. Para obtener más información, consulte el Manual de Instrucciones en inglés. Preparativos ........3 Control de accesorios .
-
Page 33: Preparativos
Preparativos Control de accesorios Compruebe que dispone de los siguientes elementos: • Batería (NP-FX110) (1) • Adaptador de alimentación de CA (1) • Adaptador para batería de automóvil (1) • Cable de audio/video (clavija mini × 2 y clavija fono × 3) (1) •... - Page 34 Conecte el adaptador de alimentación de CA. Cuando comienza el proceso de carga, se enciende la luz naranja del indicador CHARGE. SELECT INPUT POWER OFF ON HOLD PHONES AUDIO VIDEO DC IN 9.5V DC IN 9.5V Adaptador de alimentación de CA (suministrado) Cuando termina el proceso de carga, el indicador CHARGE se apaga.
-
Page 35: Uso Del Adaptador Para Batería De Automóvil
Uso del adaptador para batería de automóvil El adaptador para batería de automóvil (suministrado) está diseñado para una batería de automóvil de 12 V, con conexión a tierra negativa (no lo utilice con baterías de automóvil de 24 V y conexión a tierra positiva). -
Page 36: Reproducción
Reproducción Reproducción de discos De acuerdo con el disco, algunas operaciones pueden ser diferentes o estar restringidas. Consulte las instrucciones de operación proporcionadas con el disco. Conecte el adaptador de alimentación de CA o la batería. PUSH CLOSE OPEN Abra el panel LCD. Deslice el interruptor POWER a “ON”. - Page 37 • Los discos creados en grabadoras de DVD deben finalizarse correctamente para reproducirlos en este reproductor. Para más información sobre la finalización, consulte las instrucciones de operación suministradas con la grabadora de DVD. • El disco todavía puede estar girando al abrir la tapa del disco.
-
Page 38: Rotación Y Plegado Del Panel Lcd
Para Operación Presione C/c Reproducir el CD en retroceso o repetidamente en el avance rápido reproductor para (Reproducción seleccionar la rápida) velocidad. * DVD VIDEO solamente Rotación y plegado del panel LCD Abra el panel LCD en la posición vertical y luego rótelo lentamente 180 grados siguiendo la dirección que indica la flecha (en sentido de las agujas del reloj). - Page 40 4-169-963-22(1) Sony Corporation Printed in China...
