Devolo dsl+1100 Technical Specifications

+
dsl 1100 WLAN
ADSL2+ Modem & WLAN-Router
+ WLAN-USB-Stick

Technical specifications

LAN standards
DSL standards
Transmission rate
WLAN frequency interval
Firewall
WLAN encryption
Ports
WAN connection
LAN connection
WLAN connection
LEDs
Power supply
Weight
Dimensions
devolo AG
Sonnenweg 11 • 52070 Aachen • Tel: +49 (0)241-182 79 0 • Fax: +49 (0)241-182 79 99 • www.devolo.de • info@devolo.de
Stand: 20.05.08
Ethernet specification IEEE 802.3
Fast Ethernet specification IEE 802.3u
Fullduplex specification IEEE 802.3x
Auto MDI/MDIX
WLAN IEEE 802.11b/g(g++)
ADSL over ISDN (Annex B)
T-Com specification 1TR112 (U-R2)
ITU G.992.1 (G.dmt)
ITU G.992.3 (ADSL2)
ITU G.992.5 (ADSL2+)
ITU G.994.1 (G.hs)
oder: ADSL over POTS (Annex A)
ANSI T1.413 Issue2
ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
ITU G.992.3 (ADSL2)
ITU G.992.3 Annex L (RE-ADSL2)
ITU G.992.5 (ADSL2+)
ITU G.994.1 (G.hs)
ITU G.997.1 (G.ploam)
ADSL: up to 25 Mbps
Wireless: up to 54 Mbps (IEEE 802.11g standard),
up to 125 Mbps (Turbo Mode g++, no standard)
2412 MHz – 2472 MHz
Stateful Packet Inspection
Stealth Mode
DoS-Blocking
NAT
IP-Masquerading
WEP
WPA
WPA2
4 Ethernet LAN with Auto MDI/MDI-X
1 WLAN AccessPoint
1 ADSL WAN
1 Connector type: RJ11 (DSL)
4 Connector type: RJ45 (Ethernet)
Coaxial Connector for detachable, rotatable 2,4 Ghz antenna
Internet status
Power
LEDs:
DSLstatus
WLAN status
Power adapter 9 V DC / 1000 mA, EU
440 g WLAN Router
10 g WLAN USB stick
WLAN-Router: 202 x 152 x 38 mm (width x depth x height)
WLAN-USB-Stick: 72 x 19 x 9 mm (width x depth x height)
