DPS-300AB-5/-6
Series
150 (W) x 86 (H) x 140 (L) mm
ELECTRICAL SPECIFICATIONS
FEATURES
ENVIRONMENTAL
• Application: Desktop PC
• Operating ambient temperature: 0~50 ºC
INPUT
• 120mm fan
• Operating relative humidity: 5~85%
• Input Range
90~135Vac/ 180~265Vac
• Comply with Intel ATX12V 2.0
• Storage ambient temperature: -40~70ºC
• Frequency
47~63Hz
• Remote On/Off
• Input Current
<8A @ 115Vac, <4A @ 230Vac
• Storage relative humidity: 5~95%
• Low acoustics noise
• Efficiency
>70% @ 115Vac/230Vac
• Altitude: 10,000~50,000 feet
• High reliability
• EMI/RFI
CISPR 22 Class B, FCC
• MTBF: > 100K hours @ max. load & 25ºC
• Fan speed control
ambient conditions.
• Short circuit protection
OUTPUT
• Over voltage protection
• Maximum Power
300 Watts
• Over current protection
• Holdup Time
>17mS @ 115Vac or 230Vac
• Passive PFC @ 230Vac to meet
• Rise Time
0.1~20mS
EN61000-3-2 (optional)
• Leakage Current
<0.75mA @ 250Vac
• Overvoltage Protection: +3.3V, +5V, +12V
• Overcurrent Protection: <240VA
• Short-Circuit Protection: Latch off
Ripple & Noise
• Power Good Signal: TTL compatible on delay 100mS
Minimum
Maximum
Output
Voltage
Regulation
Peak Load
to 500mS, off delay 1mS.
Load
Load
Vp-p
V1
+3.3V
0.5A
20.0A
-
50mV
±5%
V2
+5V
±5%
0.3A
20.0A
-
50mV
V3
+12V1
±5%
1.0A
8.0A
10.0A
120mV
V4
+12V2
±5%
1.0A
14.0A
120mV
V5
-12V
±10%
0.0A
0.5A
-
120mV
V6
+5Vsb
±5%
0.0A
2.0A
2.5A
50mV
1. Total continue power output: 300W
2. The combined power on +3.3V & +5V: 120W max
3. The combined power on +3.3V, +5V, +12V1 & +12V2: 290W max
All specifications are subject to change without prior notice.
DELTA ELECTRONICS, INC.
DELTA PRODUCTS CORPORATION
DELTA ELECTRONICS(JAPAN) INC.
DELTA ELECTRONICS, EUROPE LTD.
3, TUNG YUAN ROAD, CHUNGLI
4405 CUSHING PARKWAY
DELTA SHIBADAIMON BLDG.
2 YOUNG PLACE
INDUSTRIAL ZONE
FREMONT, CA 94538, U.S.A.
2-1-14 SHIBADAIMON, MINATO-KU,
KELVIN INDUSTRIAL ESTATE
TAOYUAN SHIEH, TAIWAN, R.O.C.
TEL: 1-510-668-5100
TOKYO, 105-0012, JAPAN
EAST KILBROIDE, GLASGOW G75 OTD,
U.K.
TEL: 886-3-4526107
FAX: 1-510-668-0680
TEL: 81-3-5733-1111
TEL: 44-1355-588888
FAX: 886-3-4527314
FAX: 81-3-5733-1211
FAX: 44-1355-588889
mail: powersales@delta.com.tw
