DPS-200PB-127
100 (W) x 40.5 (H) x 190 (L) mm
FEATURES
Complies with ATX 12V V1.1
Remote
On/Off
High Reliability
Low Acoustic Noise
Built-in EMI Filter
Meets IEC 60950: 1999/UL 60950 3 Edition
TTL Compatible Power Good Signal
All Outputs SELV (Safety Extra Low Voltage)
Fan Speed Control Function Inside
With Active PFC Circuit
Output
Voltage
Regulation
V1
+3.3V
+/-5%
V2
+5V
+/-5%
V3
+12V
+/-5%
V4
-12V
+/-10%
V5
-5V
+/-5%
V6
+5Vsb
+/-5%
1. Peak-to-peak with 20MHz bandwidth and 10 F in parallel with a 0.1 F capacitor.
2. Total combined power on +3.3V & +5V rails are 140W maximum.
3. Total combined power on +3.3V, +5V & +12V are 190W maximum.
All specifications are subject to change without prior notice.
DELTA ELECTRONICS, INC.
3, TUNG YUAN ROAD,
CHUNGLI INDUSTRIAL ZONE
TAOYUAN SHIEN, TAIWAN, R.O.C.
TEL : 886-3-4526107
FAX : 886-3-4527314
mail: powersales@delta.com.tw
Series
ENVIRONMENTAL
MTBF:
>100,000 hours at Max. Load, 115Vac and 25
ambient conditions
Dielectric Withstand:
Input to Output: 3000Vdc for 1 sec
rd
Input to Frame Ground: 3000Vdc for 1 sec
ESD: IEC 61000-4-2
Surge: IEC 61000-4-5
Harmonic: IEC 61000-3-2 Class D
Minimum
Maximum
Load
Load
0A
14.0A
1.5A
25.0A
0.2A
8.0A
0A
0.8A
0A
0.3A
0A
2.0A
DELTA PRODUCTS CORPORATION
4405 CUSHING PARKWAY
FREMONT, CA 94538, U.S.A.
TEL : 1-510-668-5100
FAX : 1-510-668-0680
ELECTRICAL SPECIFICATIONS
Input
Output
Peak
Ripple & Noise
Vp-p
Load
-
50mV
-
50mV
10.0A
120mV
-
150mV
-
100mV
-
100mV
DELTA ELECTRONICS (JAPAN) INC.
DELTA SHIBADAIMON BLDG.
2-1-14 SHIBADAIMON, MINATO-KU,
TOKYO, 105-0012, JAPAN
TEL : 81-3-5733-1111
FAX : 81-3-5733-1211
Input Range
90-135/180-265Vac, Auto-Range
Frequency
47-63Hz
Input Current
6A @ 115Vac; 3A @ 230Vac
Efficiency
>68% @ Max. Load, Nominal Line
EMI/RFI
FCC Part 15 Class B
CISPR 22 Class B
Maximum Power
200 Watts
Holdup Time
>17mS @ Max. Load,
Rise Time
0.1mS ~ 20mS
Leakage Current
<1mA @ 240Vac
Overvoltage Protection: +3.3V, +5V, +12V
Overcurrent Protection: <240VA
Short-Circuit Protection:
Latch off all main outputs reset by cycling On/Off control
or AC power.
Power Good Signal:
TTL/CMOS compatible on delay 100mS to 500mS, off
delay 1mS minimum.
DELTA ELECTRONICS EUROPE LTD.
2 YOUNG PLACE
KELVIN INDUSTRIAL ESTATE
EAST KILBRIDE, GLASGOW G75 OTD, U.K.
TEL : 44-1355-588888
FAX : 44-1355-588889
Nominal Line
, -5V, -12V
