Delphi Roady XT SA10175 Quick Install Manual

Mounting roadyXT in your vehicle
3
We've included two types of mounts to help you install your roadyXT in
your vehicle's interior.
Swivel Mount
Find a suitable location; the mount uses a strong adhesive and you'll have
difficulty repositioning it after installation. Do not install this mount on a
leather surface. Make sure the air temperature is at least 60°F.
Clean the mounting surface with the surface preparation
cleaning kit, following the directions on the package.
Peel away the adhesive liner and firmly press
the swivel mount to the surface for 30 seconds.
For best results, do not touch or apply any
pressure to the vehicle mount for 24 hours.
To remove the mount, lift the adhesive pad
with your fingers or a spoon. You may warm it with a hair dryer for 2 to 3
minutes to help soften the adhesive. Remove any leftover adhesive from
the dash surface by rubbing with your finger, or use a mild cleaner as
recommended by your vehicle's manufacturer.
Caution: Never use a commercial heat gun or paint-stripping gun. This could result in damage to the unit
or to your vehicle.
You can adjust the tension of the swivel mount
by using a screwdriver.
Base of mount can be rotated to accommodate
vertical or horizontal surfaces. Choose the best
for your installation.
Vent Mount
Find a horizontal air vent that is strong
enough to hold your roadyXT and its
cradle. Clip the vent mount into the vent.
To remove the mount, push it into the
vent and lift upwards slightly to release
the mount's hooks from the vent vanes.
Carefully extract the mount.
Insert your roadyXT receiver
into the vehicle cradle.
Attach the power, antenna,
and audio cable (if needed).
Tuck the cables under the
plastic tab.
Warning: roadyXT should be placed in your vehicle where it will not interfere with the function of safety features
(e.g., deployment of airbags). Failure to correctly place roadyXT may result in death and/or injury to yourself or to
others if the unit becomes detached during an accident and/or obstructs the deployment of an airbag.
Using roadyXT at home*
Turn off your roadyXT and your home
stereo. Connect your roadyXT to your
stereo as illustrated.
Place the antenna on a
window or an exterior wall
so that it points south.
*With roadyXT Home Kit, (model SA10176, sold separately)
Turn on your roadyXT.
To help aim the antenna, use roadyXT's "Antenna Aiming" feature.
Press the "menu" button. Use the arrow and "select" buttons to choose
"Antenna Aiming." This feature is most helpful when using the roadyXT in
a stationary home or office environment.
Slowly turn and tilt the antenna. The signal bars on the display will change.
Find the position that gives at least two bars on either "satellite" or
"terrestrial."
The antenna aiming screen remains as long as it's needed to help you posi-
tion the antenna. When you've found the best position, press the "menu"
button twice to return to normal operation.
Activating your roadyXT
4
Press the arrow
buttons to find
channel 0. Push
the "select" button
to choose it.
You'll see an 8-
character XM Radio
ID in the display.
(The XM Radio ID
does not use the
letters I, O, S, and F.)
Activate your XM Satellite Radio service by contacting XM at
http://activate.xmradio.com or by calling 1.800.XM.RADIO (1.800.967.2346).
You will need the XM Radio ID and a major credit card.
XM will send a signal from the satellites to activate the full channel lineup.
Activation normally takes 10 to 15 minutes, but may take up to an hour
during peak busy periods.
When you can access the full channel lineup on your roadyXT, you're done!
Do more
• Save favorite channels as presets, which you can instantly recall by
pushing just one button.
• Save and recall the artist names and titles of your favorite songs.
• Use TuneSelect ™ to find your favorite songs when they play on any
XM channel.
• Create a personal stock ticker.
• View sports scores, news, and more.
Check out your roadyXT User Guide for more information.
