Dell Latitude 2120
Setup and Features Information
Front View
Regulatory Model: P02T
About Warnings
WARNING:
for property damage, personal injury, or death.
Regulatory Type: P02T002
A WARNING indicates a potential
1 microphone
2 camera status light (optional)
3 camera (optional)
4 right speaker
5 keyboard status lights (3)
6 power button
7 security cable slot
8 power connector
9 network connector
10 USB 2.0 connectors (2)
11 cooling vents
12 Secure Digital (SD) memory-card reader
13 touchpad buttons (2)
14 touchpad
15 cooling vents
16 device status lights (4)
17 keyboard
18 volume control buttons (3)
19 display (multi touch-screen feature is optional)
20 left speaker
September 2010

Advertisement

loading

Related Manuals for Dell Latitude 2120

Summary of Contents for Dell Latitude 2120

  • Page 1 Dell Latitude 2120 Setup and Features Information Front View Regulatory Model: P02T Regulatory Type: P02T002 About Warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. 1 microphone 2 camera status light (optional) 3 camera (optional)

  • Page 2: Back View

    WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot.

  • Page 3: Quick Setup

    Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/regulatory_compliance. WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries.

  • Page 4: Specifications

    NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start Help and Support and select the option to view information about your computer. System Information Processor type Intel Atom N455 Intel Atom N550 Chipset Intel NM10 Express Chipset Video...
  • Page 5 AC Adapter Input voltage 100 VAC to 240 VAC Input current (maximum) 1.5A/1.6 A/1.7 A Input frequency 50 Hz to 60 Hz Output power 65 W/90W Output current: 65 W 4.34 A (maximum at 4-second pulse) 3.34 A (continuous) 90 W 5.62 A (maximum at 4-second pulse) 4.62 A (continuous) Rated output voltage...

  • Page 6: Finding More Information And Resources

    Intel Corporation in the U.S. and other countries. Other trademarks and trade names may be used in this publication to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than...
