Dell™ Vostro™ 430
Setup and Features Information Tech Sheet
Front and Back View
11
10
9
8
7
6
1
drive bay front panel (open)
3
USB 2.0 connectors (4)
5
power button
7
microphone connector
9
drive access light
11
optical drive
January 2010
A WARNING indicates a potential for property damage, personal injury, or death.
1
17
2
16
3
15
4
5
14
2
optical drive eject buttons (2)
4
front panel door (open)
6
headphone connector
8
media card reader (optional)
10
optical drive (optional)
12
padlock ring
Regulatory Model: D02M series
Regulatory Type: D02M001
12
13
