BEFORE YOU BEGIN
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information-please leave instructions for the
consumer.
ORDERING INFORMATION
VIA Wall-hung Toilet............................................K-18609T-W
Includes VIA Wall-hung Toilet Bowl ...............K-19720T-W
Includes Quiet-close Toilet Seat.....................K-17660T-M
3/4.5L VIA Wall-hung Toilet W/4141T...............K-18609T-BW
Includes VIA Wall-hung Bowl.........................K-19720T-W
Includes Quiet-Close Toilet Seat ....................K-4141T-2P
NOTES
·
Observe all local plumbing and building codes.
·
Shut off the water supply.
·
Seat post holes are on 140mm centers.
·
Passageways is longer than 60mm.
·
Ensure have the correct roughing-in dimensions.
Fig.#1
.
·
Be very careful while working with vitreous china products.
Vitreous china can break or chip if the bolts or nuts are
overtightened, or if carelessly handled.
·
Carefully inspect the new bowl for any sign of damage.
·
Fixture dimensions are nominal and conform to tolerances
established by ASME Standards (A112.19.2-2013).
·
The product complies with GB 6952-2015.
No.2 KOHLER ROAD, SANSHUI CENTRAL INDUSTRIAL PARK, LEPING TOWN, SANSHUI DIST., FOSHAN, GUANGDONG, PRC POST CODE 528137
8# MENGSHAN RD, ECONOMIC DEVELOPMENT ZONE OF HUANTAI, ZIBO, SHANDONG, CHINA POST CODE: 256410
1132463-T01-C
VITREOUS CHINA WALL-HUNG P-TRAP TOILET
·
·
·
3/4.5
·
·
·
·
·
See
·
·
·
2013)
·
2
8
©
Copyright Kohler China Investment Co., Ltd. 2017
-1-
©
INSTALLATION INSTRUCTIONS
K-18609T-W/K-18609T-BW
................................................K-18609T-W
...............................K-19720T-W
..........................................K-17660T-M
..................................K-18609T-BW
...............................K-19720T-W
........................K-4141T-2P
140mm
60mm
1
ASME
GB 6952-2015
528137
256410
VIA
-
(A112.19.2-
2017
