- Page 1 OWNER’S MANUAL WASHING MACHINE Please read this manual carefully before operating your set and retain it for future reference. F1258FD F1258FD9 www.lg.com P/No.: MFL31245199...
-
Page 2: Table Of Contents
roduct Feature ■ Ultra Capacity The Larger drum enables not just higher head drop and stronger 추가선택, 예약, centrifugal force, but also less tangling and wrinkling of the laundry. Heavier loads, such as king size comforters, blankets, and curtains, can be washed. -
Page 3: Warnings
arnings READ ALL INSTRUCTIONS BEFORE USE For your safety, the information in this manual must be followed to minimize WARNING! the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions, including the following:... -
Page 4: Specification
pecification Shipping Bolts Power Plug • If the supply cord is damaged, it must be replaced by the manufacturer or its authorized service technician in order to avoid a hazard. Control Panel Drain Hose Drum Dispenser Door Back of Washer Cold Water Inlet Air Vent for Safety Hot Water Inlet... -
Page 5: Installation
nstallation Install or store where it will not be exposed to temperatures below freezing or exposed to the weather. Properly ground washer to conform with all governing codes and ordinances. The base opening must not be obstructed by carpeting when the washing machine is installed on a carpeted floor. - Page 6 nstallation Installation place requirement Level floor : Drain Hose Allowable slope under entire washer is 1˚ Washer Power outlet : Must be within 1.5 meters of either side of location of washer. Do not overload the outlet with more than one appliance.
- Page 7 nstallation Electrical connection 1. Do not use an extension cord or double adapter. 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or similarly qualified person in order to avoid a hazard. 3.
- Page 8 nstallation Normal Tap without thread & screw type inlet hose Unscrew the fixing screw to Push the connector up till the Push the water supply hose attach the tap. rubber packing is in tight contact vertically upwards so that the with the tap.
- Page 9 nstallation This equipment is not designed for maritime use or for use mobile installations such as caravans, aircraft etc. Turn off the stopcock if the machine is to be left for any length of time (e.g. holiday), especially if there is no floor drain(gully) in the immediate vicinity. When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside.
- Page 10 • If possible install the washer in one of the corners of the room, where the floor is more stable. ※ ※ Insert the rubber cups to reduce vibration. ※ ※ Rubber cups ( p/no. 4620ER4002B ) can be purchased from the LG spare parts department. Important! •...
-
Page 11: Care Before Washing
are before washing Before the first washing Select a cycle (COTTON 60°C, add a half load of detergent) allow the unit to wash without clothing. This will remove residues from the drum that may have been left during manufacturing. Caring before washing 1. -
Page 12: Adding Detergent
dding detergent Adding detergent and fabric softener 1. The Dispenser Drawer • Main wash only ➔ • Pre Wash + Main Wash ➔ • Detergent for Detergent Fabric main wash for pre wash softener 2. Adding Fabric Softener • Do not exceed the maximum fill line. Close the dispenser drawer slowly. - Page 13 dding detergent ❋ Tips 3. Detergent dosage Full load : according to • The detergent should be used according to the manufacturer’s recommendation. instruction of the detergent manufacture. Part load : 3/4 of the normal amount. • If too much detergent is used, too many suds Minimum load : 1/2 of full load.
-
Page 14: Function
unction Recommended courses according to the laundry type WASH Cycle Fabric type RINSE SPIN TEMP. MAIN SMALL TIME SOAK WASH WASH QUANTITY SAVE Sterilize the inside of the CLEAN washing machine MEDIUM SANITARY Heavily soiled underwear, work clothes, diapers, etc. HIGH EXTRA HIGH GENTLE... -
Page 15: How To Use Washer
ow to use washer 1. POWER ON/OFF BUTTON 5. CYCLE SETTING BUTTONS Use these buttons to select the desired cycle Press to turn the washer ON. Press again to turn the washer OFF. options for the selected cycle. Press the button for that setting until the indicator light for the NOTE: Pressing the ON/OFF button during a cycle will cancel that cycle and any load settings... - Page 16 ow to use washer THE LED DISPLAY The LED display shows the settings, estimated time remaining, options, and status messages for your washer. When the washer is turned on, the display will illuminate. 1. CYCLE COMPLETION INDICATOR 3. DOOR LOCK INDICATOR This portion of the display shows which stage of Indicates that the door is locked.
- Page 17 ow to use washer OPERATING THE WASHER Once you have loaded the washer and added laundry products (detergent, bleach, and/or fabric softener): ❶ Press the ON/OFF button to turn on the ❺ Press the START/PAUSE button to begin the washer. The lights around the cycle.
- Page 18 ow to use washer CYCLE SETTING BUTTONS TEMP. Each cycle has preset settings that are selected automatically. You may also customize the Selects the wash temperature settings using the cycle setting buttons. Press the combination for the selected cycle. button for that setting until the indicator light Press the TEMP.
- Page 19 ow to use washer CYCLE OPTION BUTTONS BIO-WASH Your WASHER features several additional cycle options to customize cycles to meet your Select this option to rinse and individual needs. Certain option buttons also spin a load separately from a feature a special function (see the following page regular cycle.
- Page 20 ow to use washer SPECIAL FUNCTIONS CHILD LOCK WOOL • Only woolen items that are designated as Use this option to prevent “Machine-Washable” should be washed in unwanted use of the washer this washing machine or to keep cycle settings •...
-
Page 21: Maintenance
aintenance ❋ Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock to avoid electrical shock hazards. ❋ When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside. The water inlet filter - "... - Page 22 aintenance The drain pump filter ❋ The drain filter collects threads and small objects left in the laundry. Check regularly that the filter is clean to ensure smooth running of your machine. CAUTION First drain using the drain hose and then open the pump filter to remove whatever any threads or objects.
- Page 23 aintenance I Dispenser drawer ❋ After a while detergents and fabric softeners leave a deposit in the drawer. • It should be cleaned from time to time with a jet of running water. • If necessary it can be removed completely from the machine by pressing the catch downwards and by pulling it out.
- Page 24 aintenance The water circulation nozzle • Clean the water circulation nozzle, if clogged. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent.
-
Page 25: Troubleshooting Guide
roubleshooting guide ❋ This washing machine is equipped with automatic safety functions which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not function at all, check the following points before you contact your service provider. Symptom Possible Cause Solution... - Page 26 roubleshooting guide Symptom Possible Cause Solution Washer does not start • Electrical power cord may not Make sure plug fits tightly in wall be plugged in or connection outlet. may be loose. • House fuse blown, circuit Reset circuit breaker or replace fuse. breaker tripped,or a power Do not increase fuse capacity.
- Page 27 roubleshooting guide Symptom Possible Cause Solution Check another tap in the house. • Water supply is not adequate in area Fully open tap. • Water supply taps are not completely open. Straighten hose(s). • Water inlet hose(s) are kinked. Check the filter of the inlet hose(s). •...
-
Page 28: Terms Of Warranty
erms of Warranty What Is Not Covered: • Service trips to your home to teach you how to use the product. • If the product is connected to any voltage other than that shown on the rating plate. • If the fault is caused by accident, neglect, misuse or Act of God. •...
