Directed Electronics Intelliguard 850 Owner's Manual

Dei clifford intelliguard 850 car alarms: owners guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Intelliguard 850
O O w w n n e e r r ' ' s s G G u u i i d d e e

Advertisement

Table of Contents
loading

Related Manuals for Directed Electronics Intelliguard 850

Summary of Contents for Directed Electronics Intelliguard 850

  • Page 1 Intelliguard 850 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 2: Limited Lifetime Consumer Warranty

    limited lifetime consumer warranty Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the life- time of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized Directed dealer;...

  • Page 3: Trademarks And Copyrights

    LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON- TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights that vary from State to State.

  • Page 4: Table Of Contents

    contents limited lifetime consumer warranty .....i trademarks and copyrights ..ii what is included ... . .2 important information .

  • Page 5: What Is Included

    what is included Intelliguard control module and harness Two five-button transmitters Presentation envelope and quick reference card Two window decals XHF antenna/receiver with harness Pre-wired blue status LED PlainView 2 Valet switch 518C neo-siren Digital dual-zone proximity sensor Digital dual-zone omnisensor important information Congratulations on the purchase of your state-of-the-art vehicle security system.

  • Page 6: System Maintenance

    system maintenance The system requires no specific maintenance. Your transmitter is pow- ered by a miniature 3V lithium battery that will last approximately one year under normal use. When the battery weakens, operating range will be reduced and the system will provide a low battery warning chirp indi- cation when disarming.

  • Page 7: Transmitter Configurations

    transmitter configurations Remote Start or Accessory Output Button Silent Arm/Disarm or Accessory Output Button Shift Button n n o o t t e e : : This manual describes the features and accessories that are included with your system along with information about compatible Clifford accessories that are not included.

  • Page 8: Standard Configuration

    standard configuration Button The arming, disarming, and panic function are controlled by this button. Button The trunk release or accessory output A is controlled by this button. Button Silent arm and disarm is controlled by this button. Button Remote start is controlled by this button. Button, then Accessory B output is controlled by these buttons.

  • Page 9: Using Your System

    Button twice, then These buttons enter safe start mode for manual transmission vehicles and activate Autostart mode. Button three times, then These buttons adjust the dual-zone omnisensor. Button three times, then These buttons adjust the dual-zone radar sensor. using your system The buttons used in the instructions in this manual correspond to the standard transmitter configuration.
  • Page 10 While the system is armed, the LED status indicator will flash approxi- mately once per second showing that the system is actively protecting your vehicle. If you hear more than two chirps when arming, refer to the Diagnostics section of this guide. These extra chirps confirm a mal- function autobypass.

  • Page 11: Disarming

    Digital dual zone radar sensor will protect the interior of the vehicle and it’s contents with an invisible perimeter of protec- tion. disarming To disarm the system, press ing lights will flash once. If the power locks are connected to the sys- tem, the doors will unlock.

  • Page 12: Transmitter Chirp Muting

    the siren has been sounding, press trigger and return the unit to the armed state. The system will not dis- arm, but rather reset. This prevents you from disabling the system should you wish to silence it without visually checking the vehicle. After resetting the system, press transmitter chirp muting To temporarily turn off the arm or disarm chirps, use transmitter chirp...

  • Page 13: Intellistart And Smartwindows Sensor Bypass

    The lights will flash four more times; the sensor warn away and full trigger zones are now bypassed. The sensor zones will reset when disarmed. intellistart and smartwindows sensor bypass When the system sees a command to start the vehicle via the Intellistart, it bypasses sensor zones and will continue to bypass these zones until the remote start shuts down.

  • Page 14: Disarm/Valet Mode

    disarm/valet mode Entering your pin code using the PlainView 2 Valet switch allows you to disarm the system or enter valet mode without using the transmit- ter. In valet mode, the security system will not arm, even with the trans- mitter, but all convenience functions (door locks, trunk release, etc.) will continue to work normally.

  • Page 15: Transmitter Valet Mode

    transmitter valet mode The operations described in this section refer to transmitter buttons. Remember, the buttons used in all the instructions in this guide corre- spond to a Standard Configuration transmitter. This may not be how your transmitter is set up. To enter Valet Mode, press LED status indicator will light solid if you are entering Valet Mode, or will turn off if you are exiting Valet Mode.

  • Page 16: Multiple Event Total Recall

    multiple event total recall This will report the last eight system triggers. Press and hold While still holding release the button. The LED will start to blink to indicate the most recent trigger and proceed down to the eighth trigger. If fewer than eight triggers are stored in memory, the LED will blink continuous- ly until the system is armed/disarmed using the transmitter or the ignition is turned on.

  • Page 17: Select Siren Sounds

    ger ceases. FACT is programmable. See the Programming Options section of this guide. n n o o t t e e : : Arming and disarming the system does not reset this function! The only way to reset a bypassed zone is for 60 minutes or to turn on the igni- tion.

  • Page 18: Arming Diagnostics

    abling the entire system. The microprocessor will also record and report any triggers that occurred during your absence. arming diagnostics If the system is armed while an input is active (door open, sensor trig- gering, etc.) 10-seconds later the unit will chirp twice when arming and then four more times 5 seconds later.

  • Page 19: Arm/Disarm Diagnostic Chart

    arm/disarm diagnostic chart Action Chirps 2 (5 sec.) 4 2 (10 sec.) 4 Disarm Disarm table of zones The zone number is the number of LED flashes used by the system to identify a specific input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed.

  • Page 20: Anti-Code Grabbing (Acg)

    Zone - Number of LED Flashes Description Proximity sensor Omnisensor Mux 1 trigger - for optional sensors Door switch trigger Instant trigger - trunk Instant trigger - hood Ignition trigger Mux 2 trigger - for optional sensors BlackJax activation Power interrupt anti-code grabbing (ACG) This unit features Anti-Code Grabbing (ACG) with Random Code Encryption.

  • Page 21: High Frequency

    high frequency Your system transmits and receives at 433 MHz. This provides a cleaner spectrum with less interference and a more stable signal. smart power up II This security system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory.

  • Page 22: Programming Options

    Power Saver when the system is armed: After the system has been armed for 48 hours, the LED will flash at half its nor- mal rate, decreasing the system's current draw. Power Saver in Valet Mode: When the system enters Valet Mode the LED illuminates steadily.
  • Page 23 Passive door locking (with passive arming) or active door locking (only when arming with the transmitter). Passive locking allows the vehicle's doors to lock when the security system passively arms (after the 30 second countdown). This feature only works if passive arming has been programmed. Panic mode enabled/disabled: Some states have laws against siren capability while driving.

  • Page 24: Cliffnet Wizard Installation Software Programming

    cliffnet wizard installation software programming Cliffnet Wizard provides access to all available system features and some that are not available when manually programming with the Valet switch. Cliffnet Wizard is compatible with Microsoft Windows 95/98/2000/ME/XP/NT so most programming operations can be accomplished by pointing and clicking with a mouse.
  • Page 25 Feature select - Press desired feature. The siren will chirp with each press. The fea- ture can now be changed using the remote control. Feature change - Press tem chirps once, the feature has just turned off; if the sys- tem chips twice, the feature has just turned on.

  • Page 26: User Selectable Features

    user selectable features * This feature is only available with optional IntelliStart connected. ** This feature is only available with optional SmartWindows connected. © 2 0 0 4 d i re c t e d e l e c t ro n i c s , i n c .

  • Page 27: User Selectable Features Descriptions - Column One

    user selectable features descriptions - column one add new remote (auto learn) Auto-learn new five-button Radar2 remote controls to the system in the standard button configuration. Once you have entered the feature, press on the transmitter until you hear a confirmation chirp. Press again until you hear two chirps indicating the new remote is learned.
  • Page 28 auto unlock - off/ignition Off: The doors will not automatically unlock when the igni- tion is turned off. Ignition: The doors will automatically unlock as soon as the ignition is turned off. auto (passive) arm and lock - off/on Off: The doors will not lock when the system passively arms. On: The doors will lock when the system passively arms.

  • Page 29: User Selectable Features Descriptions - Column Two

    user selectable features descriptions - column two set pin code This feature allows the setting of the user's personal PIN code. For more information, please refer to the PIN Programming section of this guide. select siren sounds The individual sounds the siren produces during an full trigger alarm can be customized for owner recognition of an alarm trigger.
  • Page 30 reset to default settings All system settings (except PIN and remote programming) in the User Programming grid will be reset to their default fac- tory setting as indicated in bold lettering. Press the arm/disarm button of the TX; the siren will chirp twice as confirmation.

  • Page 31: User Selectable Features Descriptions - Column Three

    user selectable features descriptions - column three The features in this column pertain to programming individual trans- mitter channels in custom configurations. Following is an explanation of the features. arm/disarm only The remote control channel programmed into this feature will arm/dis- arm the system only.
  • Page 32 remote start This feature is only available with IntelliStart connected The transmitter channel programmed into this feature will activate or shut down the Intellistart remote start system. window control This feature is only available with SmartWindows connected The transmitter channel programmed into this feature will acti- vate the vent or roll down feature of the SmartWindows system.

  • Page 33: Pin Programming

    pin programming A PIN code can have one to four digits; each digit can be from 0-9. n n o o t t e e : : A PIN code cannot begin with a zero. Programming Procedure Enter the feature location in the installer programming grid. Immediately press and release switch.

  • Page 34: Auto-Immobilization Feature

    PIN Code Confirmation Procedure Begin this procedure within 15 seconds of finishing the programming sequence or the new code will not be set. Turn on the ignition. Enter the new PIN code. Press and hold LED turns on: New PIN code is learned and program- ming is complete.

  • Page 35: One-Time Valet Feature

    Disarming auto-immobilization To disarm auto-immobilization when active, follow any of the sequences listed below. Turn ignition on and press the arm/disarm button. Arm the alarm and then disarm the alarm. Turn the ignition on and enter the system valet/PIN code. one-time valet feature This feature allows the system to be put in valet mode only until the next time the ignition is turned on.

  • Page 36: Blackjax Activation Sequence

    the engine, stranding the thief and vehicle. At this time your transmit- ter will not operate the system, only you can turn off the BlackJax by entering your secret PIN through the PlainView 2 valet switch. blackjax activation sequence When BlackJax is programmed ON, BlackJax sequence will begin every time the ignition is turned on and must be turned off by entering your PIN code.

  • Page 37: Blackjax Deactivation Sequence

    If PIN code is NOT entered within 20 seconds: System sounds siren and begins flashing parking lights. Brake lights continue to flash. The system will now immobilize as described in steps 6-7. If system sees the engine speed return to 1 ½ times idle or lower, the system will immobilize the vehicle as described in step 7.

  • Page 38: Blackjax Off Warning Indicator

    Siren chirps 1 time as confirmation of BlackJax bypassed. Turn Ignition Off, siren chirps 3 times as confirmation of exiting programming. n n o o t t e e : : If ignition remains on after entering PIN code and no action for 10 seconds, unit will automatically exit programming mode without chirps.
  • Page 39 seconds after the last adjustment signal from the transmitter and revert to its previous settings. n n o o t t e e : : You MUST exit using the ARM/DISARM button after program- ming to lock in the new settings! The proximity sensor field takes one to two minutes to settle after entering adjustment mode, so begin adjusting the sensor within 45 seconds and adjust it slowly so it has time to settle.

  • Page 40: Adjusting The Omnisensor

    Siren chirps 1 time. Warn-away Zone adjustment has now been entered. Warn-away Zone can now be adjusted. Adjust Warn-away Zone Press to increase sensitivity. Press to decrease sensitivity. The sensor Warn-away zone can be tested at any time during adjustment and will generate 1 siren chirp each time the zone is activated.
  • Page 41 n n o o t t e e : : DO NOT strike window glass or flat sheet metal panels that can dent easily. It is recommended that you only strike the metal pillars between the windows, they are structurally sound enough not to dent. ONLY strike the pillars using the heel of your hand, it is more than suf- ficient for the sensor distinguish as a theft attempt.
  • Page 42 Press Siren will chirp 2 times. Hit vehicle. Siren chirps 1 time if hit hard enough to activate sensor. Adjust Warn-away zone Press Siren chirps 2 times. Sensor adjustment mode is entered. Hit vehicle at the desired level of impact. Sensor adjusts itself to the force of Hit.

  • Page 43: Glossary Of Terms

    glossary of terms Control Unit: The "brain" of your system. Usually hidden underneath the dash area of the vehicle. It houses the microprocessor which mon- itors your vehicle and controls all of the system's functions. Input : A physical connection to the system. An input can be provided by a sensor, pinswitch or through an existing system in the vehicle, such as ignition or courtesy lights.
  • Page 44 PlainView 2 Valet Switch : A small two-button switch mounted some- where inside the vehicle. It is used to override the alarm when a trans- mitter is lost or damaged, or to enter or exit Valet mode. Proximity Sensor : This is a sensor mounted in the vehicle that is designed to protect the interior and its contents.

  • Page 45: Expansions

    security & convenience expansions Here we have listed only some of the many expansion options avail- able. Please contact your dealer for a complete list of all the options available to you. Backup Battery: The 520T keeps the system armed, triggers the alarm and keeps the immobilization circuits active if main battery power is disconnected.

  • Page 46: Health Check

    health check Directed Electronics recommends you return to your installing Clifford deal- er to have your system checked for correct operation. The first check is due one year after the installation date and at yearly intervals thereafter. n n o o t t e e : : There may be a small charge incurred for this service. ©...
  • Page 47 The company behind this system is Directed Electronics, Inc. Since its inception, Directed has had one purpose, to provide consumers with the finest vehi- ® cle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed ®...
