- Page 1 INSTRUCTION MANUAL Installation and Operating Garage Fan Heater Model: PFH30E This product is supplied and operated with a Bluetooth Remote Control handset 08/53942/0 ISSUE: 1...
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance IMPORTANT SAFETY ADVICE DO NOT use the heater in the immediate surroundings of a bath, a shower or a swimming pool.
- Page 3 Always ensure combustible materials such as drapes or other furnishings are kept clear of the air inlet and air outlet. This product should be mounted vertically and securely fixed to a solid wall location at a minimum height of 1.8m. WARNING: The supply circuit to the heater must incorporate a double pole isolating switch having a contact separation of at least 3mm in all poles.
-
Page 4: Technical Details
This product complies with Lot20 of the Energy Efficiency Directive (2015/1188). Type of heat output/ room temperature control Electronic room temperature control plus week timer With open window detection With adaptive start control Technical Details Model Identifier(s): PFH30E Nominal heat output Pnom 3.0 kW Height (mm) Width (mm) Depth (mm) - Page 5 Supply ~230-240 V, 50Hz Class II Colour / Finish Grey Approvals CE, BEAB Warranty 2 years Country of Origin British Isles Manufacturer Glen Dimplex Heating & Ventilation (GDC Group Ltd.)
- Page 6 Fig. 1 Fig. 2 250 Min. 1.8m Min...
- Page 7 Fig. 3 ‘x’...
- Page 8 ‘y’ ‘z’ Fig. 4...
-
Page 9: Wall Mounting
The heater works by gradually raising the air temperature in a garage or workshop and should be positioned above head height approximately 1.8m - 2.3m - (see Fig. 2). The PFH30E heater has an output of 3kW. The angle the appliance is mounted at may be adjusted horizontally and vertically - see Fig. -
Page 10: Remote Control
Remote Control The product is supplied with a Bluetooth remote control which should be contained in the carrier bag along with these instructions. This remote control is required to operate the appliance. When paired with the remote control various operational modes and features can be accessed. - Page 11 Fitting the Batteries: The remote requires two AA batteries. These are supplied with the product con- tained in the bag along with the instructions and remote. To fit the batteries: 1. On the rear of the remote, remove the battery cover by pushing the catch downwards and pulling outwards in one motion.
- Page 12 Remote Pairing Instructions To pair the product to the Bluetooth remote: 1. Press the Bluetooth button which is located on the back of the product. The product will emit a beep and begin to broadcast a signal to be paired via Bluetooth. NOTE: If no remote pairs within 2 minutes, the product will stop broadcasting.
-
Page 14: Setting Time And Date
Setting Time & Date After initial remote control start up and after replacing the batteries it is required to set the time and date. It is not possible to navigate to the home screen and product settings until the time and date have been set. It is possible to modify these settings at any stage from within the menu structure, see page 19. -
Page 16: Operation
Operation The product is controlled using the remote control. The remote consists of a display screen and six touch sensitive buttons. The function of each button and the meaning of each screen icon is explained in the graphic below. The remote offers fully programmable time and temperature control with a host of additional useful control features. -
Page 17: Operating Modes
Waking from Standby Mode When in standby mode, holding ENTER for two seconds will wake the remote and attempt to reconnect to the product, this will be signified by the connectivity icon and loading graphic appearing on the screen. Operating Modes The remote control provides the option of a number of standard control modes, •... -
Page 18: Home Screen
Home Screen Typically the Home Screen will display the active operational mode, the desired room temperature set-point and the heating status. Any of the Advance function which are active will also be displayed on the home screen. Pressing ENTER while on the Home screen will display the current time.. -
Page 19: Thermostat Control
Navigation and Selecting Modes The remote control and menus are navigated using the six button keypad. In order to select/ change operational mode, press the MENU button. The remote will then enter the basic menu structure, this menu provides the option to quickly select the following options, each option is represented by an icon. - Page 20 Heat Output Selection The remote control offers the facility to select the heat output from the appliance between HI, LO heat and FAN settings. HI heat is set by default. This is a global heat setting and once set all other operational modes will operate with this setting. In order to set/change the heat setting: •...
-
Page 21: Timer Mode
Timer Mode The Timer offers the most efficient mode of operation for a predictable heat demand. The user has the flexibility program up to four distinct time and temperature profiles per day, per week. The user has the ability to adjust the temperature during any heating period and additional functions such as ‘Advance’... - Page 22 Setting/Modifying the Time Profiles • Press the MENU key from the home screen. • Use the arrow keys to highlight the Schedule Icon, • Press ENTER to enter Timer Settings. • Use the arrow keys to highlight ‘ Edit’ and Press ENTER again to confirm selection. •...
- Page 23 Copy and Paste Time profiles It is possible to copy the complete time profile from one day and paste it to another day. This will copy all four program periods and associated time and temperatures. To copy and paste a day profile: •...
- Page 24 Continuous Heat Modes A Continuous Heat mode is effectively a constant heat control period. The heater will maintain a pre determined room temperature indefinitely irrespective of time until the mode is changed by the User. Available Continuous Heat Modes Each continuous heat profile is preloaded with a default Target Temperature value but is fully adjustable.
- Page 25 Frost Protect This mode maintains a constant room temperature of 7°C. This mode is not intended for human comfort and should be used to provide protection against frost. This mode is indicated by the Frost icon. To activate Frost Protect mode: •...
- Page 26 Advanced Mode Functions These functions modify the normal behaviour of the appliances operational modes. The advanced functions available will depend on the active operation mode. For example, an advance function is only available when timer mode is operational, and similarly a runback function is only available for continuous heating modes.
- Page 27 Runback The Runback mode will assign a timed period to a continuous heating mode. Once this time period has elapsed the appliance will revert to Comfort Off mode. When runback has been activated and the ADV key is pressed from a continuous heating mode then it is possible to select between four available time durations.
-
Page 28: Advanced Menu
Advanced Menu The advanced menu contains several additional settings required for non standard applications and installation. It is from within this menu the runback function can be activated and the details can be setup. Setback, PIN lock and advanced start options are also controlled from this menu. - Page 29 • You will be required to select a Maximum Runback Duration, this value can be selected from the pre programmed list. Each Max Duration will provide four selectable runback periods. See the table below for a break down of the options available: Maximum Selectable Runback options...
- Page 30 Setback Settings Setback is a function that only modifies Timer Mode operation. When Setback is enabled it overrides any Heating Off period to maintain a constant temperature during Heating Off periods. This can be used to prevent the room temperature from falling below a minimum value while there is no demand for heat (Heating On).
- Page 31 the Target Temperature is achieved when the User defined the Heating On start time. To activate Adaptive Start: • Hold ADV and MENU buttons for 2 seconds • Use the arrow keys to highlight the adaptive start icon and confirm using the ENTER key •...
- Page 32 PIN Lock This locking method utilises a PIN code that is set by the User. When activated, the appliance is locked in the previously active mode and user will be restricted to basic functions. In order to change the mode or settings the PIN code must be re entered. It is important that all required parameters such as time profiles and/or temperatures are set and the desired mode is activated before applying the PIN lock.
- Page 33 NOTE: Once the PIN has been set you will be required to re-enter the PIN if any button is pressed. The only exception is when the criteria has been met to allow runback mode using the ADV key. Exiting PIN Lock mode •...
-
Page 34: Service Settings
Service Settings Temperature Settings To choose whether the remote displays degrees Celsius or degrees Fahrenheit: • Hold down the MENU button for 2 seconds • Use the arrow keys to toggle C or The highlighted option will be flashing. • Press ENTER to confirm your selection and return to the home screen Appliance ID &... - Page 35 Factory Reset If you wish to either reset the heater to default values, or disconnect and restore default values of the Bluetooth remote: • Hold down Up and Down buttons at the same time for 5 seconds to enter “Fr” (Factory Reset) options.
-
Page 36: Error Codes
Error Codes If an error code (Er 20) appears flashing on the remote screen, this indicates that there has been an issue with the room temperature sensor. Please contact customer service. . Maintenance Battery Replacement IMPORTANT Battery should be disposed of in an appropriate manner See page 11 for battery fitting instructions. - Page 37 Important For electrical products sold within the European Community. At the end of the electrical products useful life it should not be disposed of with household waste. Please recycle where facilities exist. Check with a Local Authority or retailer for recycling advice in your country.
-
Page 38: Warranty
Once we receive your information and proof of purchase we will contact you to make the necessary arrangements. If your Dimplex product is not covered by this Dimplex Warranty there may be a charge to repair your product. However, we will contact you for agreement to any charges before any chargeable service is carried out. - Page 39 • You must provide to Dimplex or its authorised agents on request the original receipt as proof of purchase and - if required by Dimplex - proof of delivery. If you are unable to provide this documentation, you will be required to pay for any repair work required.
