D-Link DGS-1024T User Manual

24-port 10/100/100mbps with 2 combo sfp ports gigabit ethernet switch
Hide thumbs Also See for DGS-1024T:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual
D-Link DGS-1024T
24-Port 10/100/100Mbps with 2 Combo SFP Ports
Gigabit Ethernet Switch
Manual
First Edition
Building Networks for People
RECYCLABLE

Advertisement

Table of Contents
loading

Related Manuals for D-Link DGS-1024T

Summary of Contents for D-Link DGS-1024T

  • Page 1 D-Link DGS-1024T 24-Port 10/100/100Mbps with 2 Combo SFP Ports Gigabit Ethernet Switch Manual First Edition Building Networks for People RECYCLABLE...

  • Page 2: Table Of Contents

    D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch PREFACE... III NTENDED EADERS NOTES, NOTICES, AND CAUTIONS... III SAFETY INSTRUCTIONS... IV Safety Cautions...iv General Precautions for Rack-Mountable Products ...v Protecting Against Electrostatic Discharge...vi INTRODUCTION...7 ...7 THERNET ECHNOLOGY Fast Ethernet Technology ...7 Gigabit Ethernet Technology ...7 ...7...

  • Page 3: Preface

    D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch Preface The DGS-1024T Manual is divided into sections that describe the system installation and operating instructions with examples. Section 1, Introduction - A description of the physical features of the switch, including LED indicators, ports and panel descriptions.

  • Page 4: Safety Instructions

    • To help avoid damaging your system, be sure the voltage selection switch (if provided) on the power supply is set to match the power available at your location: – 115 volts (V)/60 hertz (Hz) in most of North and South America and some Far Eastern countries such as South Korea and Taiwan –...

  • Page 5: General Precautions For Rack-Mountable Products

    D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch Safety Instructions (continued) • Use only approved power cable(s). If you have not been provided with a power cable for your system or for any AC-powered option intended for your system, purchase a power cable that is approved for use in your country.

  • Page 6: Protecting Against Electrostatic Discharge

    D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch Safety Instructions (continued) Always load the rack from the bottom up, and load the heaviest item in the rack first. Make sure that the rack is level and stable before extending a component from the rack.

  • Page 7: Introduction

    Switching is a cost-effective way of increasing the total network capacity available to users on a local area network. A switch increases capacity and decreases network loading by making it possible for a local area network to be divided into different segments that do not compete with each other for network transmission capacity, giving a decreasing the load on each segment.

  • Page 8: Switch Description

    Switch Description The DGS-1024T Switch unit is equipped with twenty-four ports providing dedicated 10, 100 or 1000 Mbps bandwidth. These ports can be used for connecting PCs, servers, hubs and other Ethernet devices. The twenty- four tri-speed ports use standard twisted pair cabling and are ideal for segmenting networks into small, connected subnets.

  • Page 9: Ports

    Two Gigabit Ethernet Combo ports for making 1000BASE-T and Mini GBIC connections Front-Panel Components The front panel of the Switch consists of LED indicators, 24 (10/100/1000 Mbps) Ethernet ports and 2 Mini GBIC Combo ports. Figure 1 - 1. Front Panel View of the switch as shipped Comprehensive LED indicators display the status of the switch and the network.

  • Page 10: Rear Panel Description

    The system fans are used to dissipate heat. The sides of the system also provide heat vents to serve the same purpose. Do not block these openings, and leave at least 4 inches of space at the rear and sides of the switch for proper ventilation.

  • Page 11: Gigabit Combo Ports

    D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch Gigabit Combo Ports In addition to the 24 10/100/1000 Mbps ports, the Switch features two Mini-GBIC Combo ports. These two ports are 10/100/1000BASE-T copper ports (built-in) and Mini-GBIC ports (optional). See the diagram below to view the two Mini-GBIC port modules being plugged into the Switch.

  • Page 12: Installation

    The site where you install the Switch may greatly affect its performance. Please follow these guidelines for setting up the Switch. • Install the Switch on a sturdy, level surface that can support at least 6.6 pounds (3 kg) of weight. Do not place heavy objects on the Switch. •...

  • Page 13: Installing The Switch Without The Rack

    Installing the Switch Without the Rack When installing the Switch on a desktop or shelf, the rubber feet included with the Switch should first be attached. Attach these cushioning feet on the bottom at each corner of the device. Allow enough ventilation space between the Switch and any other objects in the vicinity.

  • Page 14: Mounting The Switch In A Standard 19" Rack

    Figure 2- 3. Installing Switch in a rack Power On Plug one end of the AC power cord into the power connector of the Switch and the other end into the local power source outlet. After the Switch is powered on, the LED indicators will momentarily blink. This blinking of the LED indicators means the system is resetting.

  • Page 15: Connecting The Switch

    End nodes include PCs, routers and other network devices outfitted with a 10, 100 or 1000 Mbps RJ-45 Ethernet/Fast Ethernet/Gigabit Ethernet ports. An end node can be connected to the Switch via a twisted-pair Category 3, 4, or 5 (or better) UTP/STP cable. The end node can be connected to any of the ports of the Switch.

  • Page 16: Connecting To Network Backbone Or Server

    D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch Figure 2- 5. Switch connected to a port on a hub or switch using either a straight or crossover cable– any standard Ethernet cable is fine Connecting To Network Backbone or Server The Mini-GBIC ports are ideal for uplinking to a network backbone or network server. These ports operate at 1000 Mbps in full-duplex mode.

  • Page 17: Technical Specifications

    D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch Technical Specifications IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet Standard IEEE 802.3x Full-duplex Flow Control IEEE 802.3 Nway auto-negotiation IEEE 802.3z Gigabit Ethernet over Fiber Protocols CSMA/CD...
  • Page 18 D-Link DGS-1024T Unmanaged Gigabit Ethernet Switch Transmission Method: Store-and-forward RAM Buffer: 400 Kbytes per device Filtering Address Table: 8K MAC address per device Full-wire speed for all connections. 14,880 pps for 10M Packet Filtering/ Forwarding Rate: 148,809 pps for 100M...

  • Page 19: Glossary

    A port that does not learn device addresses, and receives all frames with an unknown address. Backbone ports are normally used to connect the Switch to the backbone of your network. Note that backbone ports were formerly known as designated downlink ports.
  • Page 20 Switch: A device which filters, forwards and floods packets based on the packet’s destination address. The switch learns the addresses associated with each switch port and builds tables based on this information to be used for the switching decision.
  • Page 21 VLAN: Virtual LAN. A group of location- and topology-independent devices that communicate as if they are on a common physical LAN. VLT: Virtual LAN Trunk. A Switch-to-Switch link that carries traffic for all the VLANs on each Switch. VT100: A type of terminal that uses ASCII characters. VT100 screens have a text-based appearance.
  • Page 22 D-Link’s sole obligation shall be to repair or replace the defective Hardware during the Warranty Period at no charge to the original owner or to refund at D-Link’s sole discretion. Such repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office.
  • Page 23 D-Link may reject or return any product that is not packaged and shipped in strict compliance with the foregoing requirements, or for which an RMA number is not visible from the outside of the package. The product owner agrees to pay D-Link’s reasonable handling and return shipping charges for any product that is not packaged and shipped in...

  • Page 24: Wichtige Sicherheitshinweise

    HAZARD. LIMITATION OF LIABILITY IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.

  • Page 25: Limited Warranty

    Replacement product shall be of equivalent or better specifications, relative to the defective product, but need not be identical. Any product or part repaired by D-Link pursuant to this warranty shall have a warranty period of not less than 90 days, from date of such repair, irrespective of any earlier expiration of original warranty period. When D-Link provides replacement, then the defective product becomes the property of D-Link.
  • Page 26 Registration Register your product on-line at: http://support.dlink.com/register Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights.
