- Page 1 SkyZhone 1600, 1400, 1200 Hardware Installation Guide For software version 1.2.x January 2008 Document Part Number: 830-01810-01...
- Page 2 Further, Zhone Technologies reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Zhone Technologies to notify any person of such revision or changes.
- Page 3 A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
- Page 4 Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. ____________________________________________________________ SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 5: Table Of Contents
DIAGNOSTICS ....................... 43 Status and LED ......................43 SAFETY, REGULATIONS, AND CERTIFICATIONS ....45 Safety ..........................45 Grounding and isolation....................47 Installation safety precautions..................47 Important Safety Instructions..................47 EMI Notices ......................48 SkyZhone 1600, 1400, 1200 Hardware Installation Guide... - Page 6 Supplier’s Declaration of Conformity ..............50 Notice to Users of the Canadian Telephone Network ..........51 CE Marking....................... 51 Contacting Global Service and Support................ 52 Technical Support ..................... 52 Service Requirements ....................52 SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 7: About This Guide
Tip: A tip provides additional information that enables users to more readily complete their tasks. ______________________________________________________ WARNING! A warning alerts users to conditions or actions that could lead to injury or death. ______________________________________________________ SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 8: Typographical Conventions
Refer to the release notes for software installation information and for changes in features and functionality of the product, if any. Acronyms The following acronyms are related to Zhone products and may appear throughout this manual: Table 1: Acronyms and their descriptions... -
Page 9: Contacting Global Service And Support
Zhone Management System Contacting Global Service and Support Contact Global Service and Support (GSS) if you have any questions about this or other Zhone products. Before contacting GSS, make sure you have the following information: • Zhone product you are using •... -
Page 10: Technical Support
Service requirements If the product malfunctions, all repairs must be performed by the manufacturer or a Zhone-authorized agent. It is the responsibility of users requiring service to report the need for service to GSS. SkyZhone 1600, 1400, 1200 Hardware Install Guide... -
Page 11: The Skyzhone Access Point
VPNs optimized for citywide Wi-Fi deployments by telephone companies. SkyZhone enables telephone companies to deploy a more reliable, lower latency, higher speed and lower cost network than traditional mesh Wi-Fi solutions. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 12: Skyzhone Models
Ethernet is used for backhaul. 120VAC power is required. • SkyZhone-1200 Wi-Fi Access Point Supports wireless radio transmission of 2.4 GHz 802.11b/g. A single 10/100 Ethernet is used for backhaul. 120VAC power is required. SkyZhone 1600, 1400, 1200 Hardware Install Guide... -
Page 13: Skyzhone Features
Remote configuration and troubleshooting is supported via SSH and HTTPS to SkyZhone access points through a separate management VLAN. In addition, a console port is provided for local access to the CLI. Figure 2 shows an example of a SkyZhone network configuration. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... - Page 14 Figure 2: SkyZhone network configuration SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 15: Mounting Options
The following figure shows the SkyZhone access point with the enclosure lid removed. Figure 3: Wall-Mount Enclosure with cover removed See Wall-mounting enclosure kit on page 26 for using the wall-mounted enclosure kit. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 16: Cables
Cables The SkyZhone Port Connectors The port connectors are located on either side of the SkyZhone unit. Figure 4 shows the SkyZhone access point port locations. Figure 4: SkyZhone port connectors SkyZhone 1600, 1400, 1200 Hardware Install Guide... - Page 17 Figure 5: AC Power PLUG connector Table 3 lists the pinouts for the AC Power PLUG cable. Table 3: AC Power PLUG connector pinouts Signal Color Neutral White No connection Line Black Chassis GND Green SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
- Page 18 IP66 rating for the unit. Table 4: Power-over-Ethernet (PoE) connector pinouts Signal Color TX_P Blue TX_N White/Blue RX_P Orange RX_N White/Orange Not used Green Return_48V White/Green Not used SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 19: Grounding
Proper grounding must be complete before you connect power to the unit. See Grounding on page 36 SkyZhone ordering information To order SkyZhone Wi-Fi outdoor access points by model number contact GSS, see Contacting Global Service and Support on page 9. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 20: Preparing For Installation
SkyZhone network. Also check with local wiring codes. Serious injury can occur if the antennas come in contact with electric power lines. Carefully follow the instructions in this manual. During and after SkyZhone 1600, 1400, 1200 Hardware Install Guide... - Page 21 The 4.9 GHz band has been designed to operate with the antennae listed below, and having a maximum gain of 5.3 dBi. Antennae not included in this list (Comet Part Number SF-D49NW-SR) or having a gain greater than SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
-
Page 22: Selecting The Locations
The following table lists SkyZhone’s technical specifications: Table 6: SkyZhone technical specifications Description Specifications PHYSICAL Dimensions 14” W x 6”H x 6”D Weight 18 lbs Operating Temperature -31F to 131F (-35C to 55C) SkyZhone 1600, 1400, 1200 Hardware Install Guide... - Page 23 2.412 - 2.462 GHz (2.4 GHz Wireless) 4.900 - 4.990 GHz (4.9 GHz Wireless) Channel Width 20 MHz (2.4 GHz Wireless) 20 MHz (4.9 GHz Wireless) Output Power (EIRP) 1.15 W (2.4 GHz Wireless) SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
- Page 24 IEEE 802.1Q Traffic Prioritization IEEE 802.1p, 802.11e, IP TOS Number of Priority Queues Traffic Classification Based on priority bits, protocol type, IP address Rate Limiting Upstream and downstream rate limiting per classified flow SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 25: Installing The Skyzhone Access Point
One nut to attach shelf to the center stud on the pole bracket • Banding with screw clamps • 4 screws to securely fasten shelf to the pole bracket • 1 driver bit for the tamper-resistant screws SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 26: Wall-Mounting Enclosure Kit
Cordless screwdriver with a 2 1/2 " extension to be able to secure the tamper- resistant screws, or a screwdriver that can receive a tamper-resistant screw that is at least three inches long. SkyZhone 1600, 1400, 1200 Hardware Install Guide... -
Page 27: Mounting The Skyzhone To A Pole
Choose the one most appropriate for this installation. Figure 8: Threading screw clamp bands through mounting plate slots Secure the screw clamp bands around the pole, using a large slotted screwdriver. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... - Page 28 Secure the mounting bracket to the pole, see Figure 11 on page 30. The SkyZhone shelf is attached to the poll-mounting bracket. The shelf may need to be adjusted so that it is level. SkyZhone 1600, 1400, 1200 Hardware Install Guide...
- Page 29 Secure with 4 (four) tamper-resistant screws, provided in the mounting kit, through the holes on the front of the unit. _________________________________________________________ WARNING! Insure that the Chassis Ground is properly connected before the next steps. _________________________________________________________ Attach the Ethernet cable. SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
- Page 30 The same instructions apply to the installation on a horizontal pole or any other orientation as shown in the figure below. _________________________________________________________ Figure 11: The bracket and sunshield mounted on a horizontal pole SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 31: Mounting The Skyzhone To The Side Of A Building
Figure 12: SkyZhone with a cover The SkyZhone wall mount enclosure kit (920-07811-01) includes the following items: • • front cover • bracket and base These items are also displayed in Figure 13: SkyZhone 1600, 1400, 1200 Hardware Installation Guide... - Page 32 Fasten the mounting bracket in the desired location with the appropriate type of screw. Use the outside holes displayed in Figure 16. These should line up with the holes in the cover. SkyZhone 1600, 1400, 1200 Hardware Install Guide...
- Page 33 Attach the protective cover to the base and then attach the base to the (concrete) wall. Note that the cover should be attached so that the top contains the two cutouts for the angled antennas. SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
- Page 34 Attach the lid of the protective cover and secure it with the screws provided in the installation kit. The final assembly appears in Figure 17, and the final installation appears in Figure 18. SkyZhone 1600, 1400, 1200 Hardware Install Guide...
- Page 35 Figure 17: Wall Mount Kit - Final Assembly Figure 18: Example of a wall-mounted SkyZhone SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
-
Page 36: Grounding
See Figure 19. • Connect the other end of the grounding wire strap that is attached to a grounded surface or another earth ground such as a metal rod. Figure 19: Grounding lug SkyZhone 1600, 1400, 1200 Hardware Install Guide... -
Page 37: Initial Configuration
VLANs and configure the VLANs that are appropriate for your network. In the example below, VLAN 2 is used for management instead of the default VLAN 7. Also, VLAN 122 is the data VLAN instead of VLAN 1. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 38: Using The Ethernet Interface
(for example, 192.168.1.100), then use HTTPS to configure the remaining parameters. Note that the SkyZhone access point uses HTTPS and not HTTP. The default login is admin and the default password is zhone. Note that if the IP address of the management VLAN is changed, you lose your connection to the SkyZhone unit. -
Page 39: Default Settings
0 dB Attenuation WLAN 0 Antenna Select auto auto WLAN 1 SSID 1 SkyZhone SkyZhone WLAN 1 SSID 2 WLAN 1 SSID 3 WLAN 1 SSID 4 WLAN 1 SSID security None None SkyZhone 1600, 1400, 1200 Hardware Installation Guide... - Page 40 Interface Name brvlan1 brvlan1 brvlan1 Interface Alias Bridge / VLAN 1 Bridge / VLAN 1 Bridge / VLAN 1 LAN IP 0.0.0.0 0.0.0.0 0.0.0.0 Netmask 0.0.0.0 0.0.0.0 0.0.0.0 Broadcast Address 0.0.0.0 0.0.0.0 0.0.0.0 SkyZhone 1600, 1400, 1200 Hardware Install Guide...
- Page 41 Interface Name brvlan7 brvlan7 brvlan7 Interface Alias Bridge / VLAN 7 Bridge / VLAN 7 Bridge / VLAN 7 LAN IP 192.168.2.1 192.168.2.1 192.168.2.1 Netmask 255.255.255.0 255.255.255.0 255.255.255.0 Broadcast Address 192.168.2.255 192.168.2.255 192.168.2.255 SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
- Page 42 SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 43: Diagnostics
If the LED stays in this state for more than one minute, the unit should be replaced. One blink every Power is on and the unit is operational. 5 seconds There is no power SkyZhone 1600, 1400, 1200 Hardware Installation Guide... - Page 44 SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 45: Safety, Regulations, And Certifications
Serious injury can occur if the antennas come in contact with electric power lines. Carefully follow the instructions in this manual. During and after installation, the antennas must be a minimum of 24 inches from any power lines. Use caution when installing this outdoor equipment. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... - Page 46 5.3 dBi. Antennae not included in this list (Comet Part Number SF-D49NW-SR) or having a gain greater than 5.3 dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms SkyZhone 1600, 1400, 1200 Hardware Install Guide...
-
Page 47: Grounding And Isolation
NEC, CEC and all applicable local codes. Do not attempt to service this product yourself, as opening or removing covers may expose you to hazardous voltage or to other risks. Refer all servicing to qualified service personnel. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 48: Emi Notices
The following are EMI notices. United States - EMI Notice • Changes or modifications not expressly approved by Zhone Technologies, Inc. could void the user's authority to operate the equipment. • The supplied cables and antennae must be used to ensure compliance with Part 15 and Part 90, FCC Rules. - Page 49 (2) this device must accept any interference, including interference that may cause undesired operation of the device. Canada - EMI Notice This Class A and C digital apparatus complies with Industry Canada RSS-210. SkyZhone 1600, 1400, 1200 Hardware Installation Guide...
-
Page 50: Supplier's Declaration Of Conformity
Largo, FL 33773-1502 Date of Issue: January 20, 2008 Zhone Technologies, located at the above address, hereby certifies that the SKYZHONE-1200/1400/1600 bearing the FCC identification numbers PJZSZ1224, PJZSZ1424, PJZSZ1624 complies with the Federal Communications Commission's ("FCC") Rules and Regulations pursuant to part 15, subpart C (14.247), part 15 Class A and part 90, as appropriate. -
Page 51: Notice To Users Of The Canadian Telephone Network
NOTICE: This equipment has been certified to ITU-T G991.2 CE Marking When the product is marked with the CE mark on the equipment label, a supporting Declaration of Conformity may be downloaded from the Zhone World Wide Web site at www.zhone.com. SkyZhone 1600, 1400, 1200 Hardware Installation Guide... -
Page 52: Contacting Global Service And Support
Service Requirements If the product malfunctions, all repairs must be performed by the manufacturer or a Zhone-authorized agent. It is the responsibility of users requiring service to report the need for service to GSS. SkyZhone 1600, 1400, 1200 Hardware Install Guide...
