Summary of Contents for Lenovo ThinkVision S28u-10
- Page 1 ThinkVision S28u-10 User Guide Machine Types: 61E6...
- Page 2 Product numbers 61E6-G*R2-WW First Edition (August 2019) © Copyright Lenovo 2019. LENOVO products data computer software and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use reproduction and disclosure.
-
Page 3: Table Of Contents
Contents Safety information ............. iii General Safety guidelines. -
Page 4: Safety Information
Safety information General Safety guidelines For tips to help you use your computer safely, go to: http://www.lenovo.com/safety Before installing this product, read the Safety Information. í í í... -
Page 5: Chapter 1. Getting Started
Chapter 1. Getting started This User’s Guide provides detailed operation instructions for the user. For quick instruction overview, please see the Setup Poster for brief information. Shipping contents The product package should include the following items: • Information Flyer • Flat Panel Monitor •... -
Page 6: Notice For Use
Notice for use To set up your monitor, please see the illustrations below. Note: Do not touch the monitor within the screen area. The screen area is glass and can be damaged by rough handling or excessive pressure. 1. Place your monitor with the screen face down on a soft flat surface. 2. -
Page 7: Product Overview
Product overview This section will provide information on adjusting monitor positions, setting user controls, and using the cable lock slot. Types of adjustments Tilt Please see the illustration below for an example of the tilt range. Chapter 1. -
Page 8: Monitor Controls
Monitor controls The keypad controls on the panel frame are accesses to various functions. For information on how to utilize these keypad controls, please see “Adjusting your monitor image”on page 2-3. Cable lock slot Your monitor is equipped with a cable lock slot located on the rear of your monitor. Chapter 1. -
Page 9: Setting Up Your Monitor
Setting up your monitor This section provides information on how to set up your monitor. Connecting and turning on your monitor Note: Be sure to read the Safety information on page iii before carrying out this procedure. Power off your computer and all attached devices, then unplug the computer power cord. Connect the cables according to below icon indication. - Page 10 For computer in DisplayPort connecting. Connect the speaker’s audio cable and audio jack of monitor to transfer audio source from HDMI or DP. Note: The audio output in HDMI or DP modes. Warning note: Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the equalizer to maximum increases the earphones and headphones output voltage and therefore the sound pressure level.
- Page 11 Insert the power cord into the monitor, then plug the monitor power cord and the computer cord into grounded electrical outlets. Note: A certified power supply cord has to be used with this equipment. The relevant national installation and or equipment regulations shall be considered. A certified power supply cord not lighter than ordinary polyvinyl chloride flexible cord according to IEC 60227 (designation H05VV-F 3G 0.75mm or H05VVH2-F2 3G 0.75mm...
-
Page 12: Registering Your Option
Thank you for purchasing this Lenovo™ product. Please take a few moments to register your Product and provide us with information that will help Lenovo to better serve you in the future. Your feedback is valuable to us in developing product and services that are important to you, as well as in developing better ways to communicate with you. -
Page 13: Chapter 2. Adjusting And Using Your Monitor
For more detailed information on any of these topics, visit the Healthy Computing Web site at: http://www.lenovo.com/healthycomputing/. Arranging your work area Use a work surface of appropriate height and available working area to allow you to work in comfort. -
Page 14: Quick Tips For Healthy Work Habits
Accessibility information Lenovo is committed to providing greater access to information and technology to people with disabilities. With assistive technologies, users can access information in the way most appropriate to their disability. Some of these technologies are already provided in your operating system;... -
Page 15: Adjusting Your Monitor Image
Adjusting your monitor image This section describes the control features to adjust your monitor image. Using the direct access controls The direct access controls can be used when the On-Screen Display (OSD) is not displayed. Icon Control Description Press and hold for 10 seconds to enable or disable the DDC-CI DDC-CI function Exit... -
Page 16: Using The On-Screen Display (Osd) Controls
Using the On-Screen Display (OSD) controls To adjust the settings, the user controls can be viewed through the OSD. Adjusts overall screen Brightness/Contrast/DCR Exit To use the controls: Press to open the main OSD menu. to move among the icons. Select an icon and press to access the selected function. - Page 17 Table 2-1. OSD functions OSD Icon on Main Controls and Submenu Description Menu Adjustments Brightness Adjusts overall screen All input ports brightness. Contrast Adjusts difference between light Brightness/ and dark areas. Contrast/DCR Enable dynamic contrast ratio. Color Adjusts intensity of red, green, and blue.
- Page 18 Table 2-1. OSD functions OSD Icon on Main Controls and Submenu Description Menu Adjustments Shows resolution, refresh rate, Information All input ports and product details. Note: This screen offers Options information only, and (does) not allow for setting changes. Language Changes languages of menu.
-
Page 19: Selecting A Supported Display Mode
Selecting a supported display mode The display mode of the monitor uses is controlled by the computer. Therefore, refer to your computer documentation on how to change display modes. The image size, position and shape might be changed when the display mode changes. This is normal and the image can be re-adjusted using automatic image setup and the image controls. -
Page 20: Understanding Power Management
Understanding power management Power management is invoked when the computer recognizes that you have not used your mouse or keyboard for a user-definable period. There are several states as described in the table below. For optimal performance, switch off your monitor at the end of each working day, or whenever you expect to leave it unused for long periods during the day. -
Page 21: Caring For Your Monitor
Caring for your monitor Be sure to turn off the power before you perform any maintenance on the monitor. Do not: • Apply water or liquid directly to your monitor. • Use solvents or abrasives. • Use flammable cleaning materials to clean your monitor or any other electrical equipment. •... - Page 22 Step 3: Remove the base and stand from the monitor, refer to "Detaching the monitor base and stand"on page 2-9". Step 4: Attach the mounting bracket from the VESA compatible wall mounting kit (100mm x100mm distance), the type of VESA mounting screw is M4 x 10 mm. VESA hole Step 5: Attach the LCD display to the wall, and follow the instructions in the wall-mounting kit.
-
Page 23: Chapter 3. Reference Information
Chapter 3. Reference information This section contains monitor specifications, instructions to manually install the monitor driver, troubleshooting information, and service information. Monitor specifications Table 3-1. Monitor specifications for type-model 61E6-G*R2-WW Dimensions Depth 229.99 mm (9.05 in.) Height 450.82 mm (17.75 in) Width 636.94 mm (25.08 in) Stand... - Page 24 Table 3-1. Monitor specifications for type-model 61E6-G*R2-WW Video input HDMI (Digital) Interface HDMI Input signal VESA TMDS (Panel Link™)/HDMI 3840 pixels (max) Horizontal addressability 2160 lines (max) Vertical addressability 600 MHz Clock frequency Communications VESA DDC/CI 30 KHz - 160 KHz Supported display modes Horizontal frequency 23 Hz - 76 Hz...
-
Page 25: Troubleshooting
Troubleshooting If you have a problem setting up or using your monitor, you might be able to solve it yourself. Before calling your dealer or Lenovo, try the suggested actions that are appropriate to your problem. Table 3-2. Troubleshooting Problem... - Page 26 Table 3-2. Troubleshooting Problem Possible cause Suggested action Reference The power The video signal cable Be sure the video cable is "Connecting and indicator is amber, is loose or disconnected connected with the system turning on your but there is no from the system or properly.
-
Page 27: Manually Installing The Monitor Driver
Note: On LCD monitors, unlike CRTs, a faster refresh rate does not improve display quality. Lenovo recommends using either 3840 x 2160 at a refresh rate of 60 Hz, or 640 x 480 at a refresh rate of 60 Hz. -
Page 28: Installing The Monitor Driver In Windows 10
Note: On LCD monitors, unlike CRTs, a faster refresh rate does not improve display quality. Lenovo recommends using either 3840 x 2160 at a refresh rate of 60 Hz, or 640 x 480 at a refresh rate of 60 Hz. -
Page 29: Service Information
Scratches or punctures on monitor screens. Service parts The following parts are for use by Lenovo service, or Lenovo aurthorized dealers, to support the customer warranty. Parts are for service use only. The table below shows information for model 61E6-G*R2-WW. -
Page 30: Appendix A. Service And Support
Product replacement assistance or exchange of defective components also is available during the warranty period. In addition, if your option is installed in a Lenovo computer, you might be entitled to service at your location. A Lenovo technical support representative can help you determine the best alternative. - Page 31 Warranty service and support: +358-800-1-4260 (Finnish) France Warranty service and support: 0810-631-213 (hardware) (French) Germany Warranty service and support: 0800-500-4618 (toll-free) (German) Greece Lenovo Business Partner (Greek) Guatemala Dial 999-9190, wait for operator, and request to reach 877-404-9661 (Spanish) Appendix A.
- Page 32 (French) Malaysia 1-800-88-0013 03-7724-8023 (Standard Charges Apply) (English) Malta 356-21-445-566 (English, Italian, Maltese Arabic) Mexico 001-866-434-2080 (Spanish) Netherlands 020-513-3939 (Dutch) New Zealand 0508-770-506 (English) Nicaragua 001-800-220-2282 (Spanish) Norway 8152-1550 (Norwegian) Panama Lenovo Customer Support Center: 001-866-434 (toll-free) (Spanish) Appendix A.
- Page 33 Country or Region Telephone Number Peru 0-800-50-866 OPCION 2 (Spanish) Philippines 1-800-8908-6454 (GLOBE subscribers) 1-800-1441-0719 (PLDT subscribers) (Tagalog, English) Poland Laptops and tablets branded with logo Think: 48-22-273-9777 ThinkStation and ThinkServer: 48-22-878-6999 (Polish, English ) Portugal 808-225-115 (Standard Charges Apply) (Portuguese) Romania 4-021-224-4015...
-
Page 34: Appendix B. Notices
Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk. -
Page 35: Recycling Information
Collecting and recycling a disused Lenovo computer or monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources.
