Wall hung, fanflue, roomsealed, high efficiency gas boiler
Service manual
Riva Plus HE ERP
Models
RIVA PLUS HE 24C ERP
RIVA PLUS HE 28C ERP
Leave this manual adjacent to the gas meter
Warning:
Service / repairs must be carried out, only by a qualified Gas Safety
Registered Engineer, who will be responsible for the current Regulations for
gas appliances.
Note:
After servicing, complete the relevant Service Interval Record section of the
Benchmark Checklist of the user and installation manual.
G.C. Appl. No.
47-583-41
COMBI BOILER
47-583-42
COMBI BOILER
