MODEL 463370108 • PRODUCT GUIDE
THIS GRILL IS FOR OUTDOOR USE ONLY.
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
1-800-241-7548
.
463370108 • 80015850• 11-13-07
Advertisement
Table of Contents
Related Manuals for Char-Broil 463370108
Summary of Contents for Char-Broil 463370108
- Page 1 MODEL 463370108 • PRODUCT GUIDE THIS GRILL IS FOR OUTDOOR USE ONLY. CAUTION: WARNING: Read and follow all safety statements, assembly Failure to follow all manufacturer’s instructions could instructions, and use and care directions before result in serious personal injury and/or property attempting to assemble and cook.
-
Page 2: For Your Safety
WARNING: Indicates an potentially hazardous situation cooking. which, if not avoided, could result in death or serious injury. CAUTION CAUTION: Indicates a potentially hazardous situation or unsafe practice which, if not avoided, may result in minor or moderate injury. 2 • 463370108... -
Page 3: Table Of Contents
Registration Card ........27 authorized replacement parts supplied by manufacturer. 463370108 • 3... -
Page 4: Use And Care
Check the telephone inside a vehicle which may become overheated directory under “Gas Companies” for nearest certified LP Retainer Strap by the sun. dealers. • Do not store an LP tank in an area where children play. 4 • 463370108... - Page 5 LP tank valve so as not to cross- thread the connection. Nipple has to be centered into the LP tank valve. WARNING If “growing” bubbles appear do not use or move the LP tank. Contact an LP gas supplier or your fire department! 463370108 • 5...
- Page 6 • Do not use grill until leak-tested. • If a leak is detected at any time, STOP and call the fire department. • If you cannot stop a gas leak, immediately close LPtank valve and call LP gas supplier or your fire department! 6 • 463370108...
- Page 7 5 minutes and repeat the lighting procedure. • Always close LP tank valve and remove coupling 7. Ignite other burners by turning knob to nut before moving LP tank from specified Lighting instructions continued on next page. operation position. 463370108 • 7...
- Page 8 • Cooking surfaces: If a bristle brush is used to clean any of the grill cooking surfaces, ensure no loose bristles remain on cooking surfaces prior to grilling. It is not recommended to clean cooking surfaces while grill is hot. 8 • 463370108...
- Page 9 • Store grill indoors ONLY if LP tank is turned off and Firebox disconnected, removed from grill and stored outdoors. Electrode burner • When removing grill from storage, follow “Cleaning the Burner bracket Assembly” instructions before starting grill. 463370108 • 9...
- Page 10 • When reheating takeout foods or fully cooked meats like hot dogs, grill to 165° F, or until steaming hot. 2 Burner Cooking Great indirect cooking on low. Produces slow, even heating. Ideal for slow roasting and baking. 10 • 463370108...
- Page 11 The methods below are suggestions for cleaning stainless steel surfaces. Choose a cleaning method appropriate for your needs. It is recommended that you use a Char-Broil® grill cover to help prolong the life and prevent discoloration of your grill.
-
Page 12: Parts List
Bradley Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collection by Char-Broil ™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™, The Minute Grill™, The Edge™, The Tuscan Collection™, and The Urban Grill™... -
Page 13: Parts Diagram
PARTS DIAGRAM – Model No. 463370108 463370108 • 13... -
Page 14: Assembly
ASSEMBLY – Model No. 463370108 • Place legs as shown (A). Left leg assembly has large holes on ends of legs. Hook tank exclusion wire into right and left leg assemblies (B). Tank Exclusion Wire Right Leg no holes on ends of leg... - Page 15 Place bottom shelf with cut out hole for LP tank next to legs with axle holes. Attach to right and left leg assemblies with 1/4-20x1-1/2" screws and 1/4-20 flange nuts. Qty: 4 1/4-20 Flange Nut Qty: 4 1/4-20x1-1/2" Machine Screw Bottom Shelf LP tank hole Axle Hole 463370108 • 15...
- Page 16 • Insert axle rod into wheel, legs and other wheel. Attach with a wheel bushing and hitch pin. Leg Extenders • Push leg extenders into right legs. 1” Hitch Pin Axle Rod Qty. 1 Wheel Axle Washer Wheel Bushing Qty. 1 Qty. 2 Wheel Bushings "Cone" side of wheel against leg Axle Washer 16 • 463370108...
- Page 17 • Carefully lower the grill head onto the cart. Make sure the regulator hose is hanging outside the cart. Attach with 1/4-20x1/2" screws, 7mm lock washers and 7mm flat washers. Grill Head Qty: 4 Qty: 4 Qty: 4 7mm Flat Washer 7mm Lock Washer 1/4-20x1/2" Machine Screw 463370108 • 17...
- Page 18 • Attach shelf with flange nuts on each side. (C). Qty: 4 Qty: 4 Qty: 4 1/4-20 Fiber Washer 1/4-20x1/2" Flange Nut Machine Screw Right Side Shelf • Attach fascia to firebox with #8x3/8" self-tap screw. Qty: 2 #8x3/8" Fascia, Right Side Shelf Self-Tap Screw 18 • 463370108...
- Page 19 • Attach fascia to firebox with (1) #8x3/8" self-tap screw (D). Qty: 4 Qty: 4 Fiber Washer 1/4-20x1/2" Machine Screw Qty: 4 Qty: 2 1/4-20 #8x3/8" Sideburner Shelf Flange Nut Self-Tap Screw Back of cart Left Fascia 463370108 • 19...
- Page 20 • Press sideburner control knob onto valve stem (E). • Place grate onto sideburner shelf (F). Qty: 1 Wing Nut Sideburner Bezel Sideburner Sideburner Valve Correctly assembled burner-to-valve engagement Burner Clip Sideburner Ignitor Wire Sideburner Grate Sideburner Control Knob 20 • 463370108...
- Page 21 Swing Away is installed upside-down. • Unscrew ignitor cap and place AA battery into ignitor slot with positive end (+) facing outward. Screw ignitor cap onto ignitor. Swing Away Pivot Wire Leg Wire – Cooking Grate AA Battery 463370108 • 21...
- Page 22 See Use and Care section to correctly Leak Test and CAUTION perform the Burner Flame Check. • Failure to install tank correctly may allow gas hose to be damaged in operation, resulting in the risk of fire. LP Tank Tank Thumbscrew 22 • 463370108...
-
Page 23: Troubleshooting
• Wires are loose or disconnected. • Reconnect wires or replace electrode/wire assembly. • Wires are shorting (sparking) between • Replace ignitor wire/electrode assembly. ignitor and electrode. • Dead battery. • Replace with a new AA-size alkaline battery. 463370108 • 23... - Page 24 • The worn nozzles don’t have enough “bite” to engage the valve. Try with worn threads. a second LP dealer. One burner does not light from other • Grease buildup or food particles in • Clean carry-over tube(s) with wire brush. burner(s). end(s) of carryover tube(s). 24 • 463370108...
- Page 25 • Electrodes are wet. • Has moisture accumulated • Use paper towel to remove moisture. on electrode and/or in burner ports? • Electrodes cracked or • Inspect electrodes for • Replace cracked or broken electrodes. broken “sparks at cracks. crack”. 463370108 • 25...
-
Page 26: Warranty
Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-800-241-7548 and then clearly marked on the outside of the package and the package is shipped freight/postage pre-paid to the address above. 26 • 463370108... -
Page 27: Registration Card
Merci d’avoir bien voulu remplir ce questionnaire. Vos réponses nous aideront et aideront d’autres compagnies à vous communiquer des offres spéciales susceptibles de vous intéresser. Si vous préférez ne pas recevoir d’informations concernant ces offres spéciales, veuillez cocher ici 463370108 • 27... - Page 28 Always ensure control knobs are in OFF position and regulator is attached to tank BEFORE opening tank valve to avoid low flames. Perform leak test regularly. Thank You for Your Purchase! Char-Broil, LLC • Columbus, GA 31902 • Printed in China...
