Supero 1027R-72BRFTP User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
S
S
UPER
ERVER
1027R-72BRFTP
USER'S MANUAL
1.0b

Advertisement

Table of Contents
loading

Summary of Contents for Supero 1027R-72BRFTP

  • Page 1 UPER ® UPER ERVER 1027R-72BRFTP USER’S MANUAL 1.0b...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
  • Page 3 Preface About This Manual This manual is written for professional system integrators and PC technicians. It pro- vides information for the installation and use of the SuperServer 1027R-72BRFTP Installation and maintenance should be performed by experienced technicians only. Manual Organization...
  • Page 4 UPER ERVER 1027R-72BRFTP. User's Manual Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the SC119XTQ-R700WB server chas- sis. You should follow the procedures given in this chapter when installing, removing or reconfiguring SAS or peripheral drives and when replacing system power supply modules and cooling fans.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 1027R-72BRFTP. User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 Onboard SAS ....................1-2 Onboard Serial ATA ..................1-2 Rear I/O Ports ....................1-2 System Power ....................1-3 Hard Drives .....................
  • Page 7 Table of Contents UID ........................3-1 Power ......................3-1 Control Panel LEDs ..................3-2 Information LED ....................3-2 NIC2 ........................ 3-2 NIC1 ........................ 3-2 HDD ......................... 3-3 Power ......................3-3 Drive Carrier LEDs ..................3-3 Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements ............
  • Page 8 UPER ERVER 1027R-72BRFTP. User's Manual Adding PCI Cards ..................5-10 Serverboard Details ..................5-11 Connector Definitions ..................5-14 Jumper Settings .................... 5-22 5-10 Onboard Indicators ..................5-25 5-11 SAS/SATA Port Connections ................. 5-27 5-12 Installing Software ..................5-28 SuperDoctor III ....................5-29 5-13 Onboard Battery ....................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 1027R-72BRFTP. is a high-end server comprised of two main subsystems: the SC119XTQ-R700WB 1U server chassis and the X9DRW-7TPF dual processor serverboard. Please refer to our web site for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 10: Serverboard Features

    ERVER 1027R-72BRFTP User's Manual Serverboard Features At the heart of the SuperServer 1027R-72BRFTP. lies the X9DRW-7TPF, a dual processor serverboard based on the Intel® C606 chipset. Below are the main features of the serverboard. (See Figure 1-1 for a block diagram of the chipset).

  • Page 11: System Power

    Chapter 1: Introduction 1-3 Server Chassis Features The 1027R-72BRFTP is built upon the SC119XTQ-R700WB chassis. Details on the chassis and on servicing procedures can be found in Chapter 6.The following is a general outline of the main features of the chassis.
  • Page 12 UPER ERVER 1027R-72BRFTP User's Manual Figure 1-1. Intel C606 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. RJ45 Powerville-2 to WIO L1/L2 RJ45 Left WIO Right WIO x8 CPU0 CPU0 PE2 [7..0]...

  • Page 13: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 14 UPER ERVER 1027R-72BRFTP User's Manual Notes...

  • Page 15: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the 1027R-72BRFTP. was shipped in and note if it was damaged in any way. If the server itself shows damage you should file a damage claim with the carrier who delivered it.

  • Page 16: Warnings And Precautions

    UPER ERVER 1027R-72BRFTP User's Manual installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units.

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 18: Installing The System Into A Rack

    UPER ERVER 1027R-72BRFTP User's Manual Installing the System into a Rack This section provides information on installing the server into a rack unit with the rack rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.

  • Page 19: Inner Rails

    Chapter 2: Server Installation Figure 2-2: Identifying the Sections of the Rack Rails (right side rail shown) Inner Rails The SC119 chassis inner rails are composed of two sections: inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack.

  • Page 20: Outer Rails

    UPER ERVER 1027R-72BRFTP User's Manual Outer Rails Installing the Outer Rails to the Rack 1. Attach the shorter outer rail to the outside of the longer outer rail. You must align the pins with the slides. Both bracket ends must face the same direction.
  • Page 21 Chapter 2: Server Installation Installing the Server into the Rack Installing the Chassis into a Rack (Figure 2-4) 1. Confirm that the chassis includes the inner rails and rail extensions, and confirm that the outer rails are installed on the rack. 2.

  • Page 22: Installing The Server Into A Telco Rack

    UPER ERVER 1027R-72BRFTP User's Manual Installing the Server into a Telco Rack To install the chassis into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far the server will extend out the front of the rack.

  • Page 23: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the hard drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

  • Page 24: Control Panel Leds

    UPER ERVER 1027R-72BRFTP User's Manual Control Panel LEDs The control panel located on the front of the SC119XTQ chassis has five LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 25: Hdd

    Chapter 3: System Interface Indicates IDE channel activity. On the 6016T-6RFT+/6016T-6F+ this light indicates HDD and/or DVD-ROM drive activity when flashing. Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Drive Carrier LEDs  Green: Each hard drive carrier has a green LED.
  • Page 26 UPER ERVER 1027R-72BRFTP User's Manual Notes...

  • Page 27: About Standardized Warning Statements

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 28 UPER ERVER 1027R-72BRFTP User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 29 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 30: Installation Instructions

    UPER ERVER 1027R-72BRFTP User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de...

  • Page 31: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 32: Power Disconnection Warning

    UPER ERVER 1027R-72BRFTP User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 33 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 34: Equipment Installation

    UPER ERVER 1027R-72BRFTP User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 35: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 36: Battery Handling

    UPER ERVER 1027R-72BRFTP User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬...
  • Page 37 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 38: Redundant Power Supplies

    UPER ERVER 1027R-72BRFTP User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 39: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 40: Comply With Local And National Electrical Codes

    UPER ERVER 1027R-72BRFTP User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬...

  • Page 41: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 42: Hot Swap Fan Warning

    UPER ERVER 1027R-72BRFTP User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 43 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 44: Power Cable And Ac Adapter

    UPER ERVER 1027R-72BRFTP User's Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
  • Page 45 Chapter 4: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
  • Page 46 UPER ERVER 1027R-72BRFTP User's Manual Notes 4-20...

  • Page 47: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X9DRW-7TPF serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.

  • Page 48: Processor And Heatsink Installation

    UPER ERVER 1027R-72BRFTP User's Manual Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: • Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components.
  • Page 49 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate finger, remove the 'WARNING'...
  • Page 50 UPER ERVER 1027R-72BRFTP User's Manual Warning: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the load plate again and double-check that the CPU is aligned properly.

  • Page 51: Removing The Heatsink

    Chapter 5: Advanced Serverboard Setup Removing the Heatsink Warning: We do not recommend removing the CPU or the heatsink. If you do need to remove the heatsink, please follow the instructions below to prevent damage to the CPU or other components. 1.

  • Page 52: Connecting Cables

    UPER ERVER 1027R-72BRFTP User's Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfigured systems to prevent them from blocking the flow of cooling air that moves through the system from front to back.

  • Page 53: I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Front Control Panel Header Pins (JF1) Ground x (key) x (key) Power LED 3.3V HDD LED UID Switch/Vcc NIC1 Link LED NIC1 Active LED NIC2 Link LED NIC2 Active LED Blue: OH/Fan Fail/Power Fail/UID LED Red: (Blue LED Cathode) Power Fail LED 3.3V...

  • Page 54: Installing Memory

    UPER ERVER 1027R-72BRFTP User's Manual Installing Memory Note: Check the Supermicro web site for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing DIMMs 1. Insert the desired number of DIMMs into the memory slots, starting with slot P1-DIMM1A.
  • Page 55 Chapter 5: Advanced Serverboard Setup Processor & Memory Module Population Configuration For memory to work properly, follow the tables below for memory installation. Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules CPU 1 DIMMA1 DIMMB1 DIMMC1 DIMMD1 DIMMA2 DIMMB2 DIMMC2 DIMMD2...

  • Page 56: Adding Pci Cards

    UPER ERVER 1027R-72BRFTP User's Manual Adding PCI Cards PCI Expansion Slots The X9DRW-7TPF has two proprietary PCI slots. Riser cards installed to the system allow you to add PCI expansion cards (see below). The SC119XTQ-R700WB chas- sis can support the use of two standard size expansion cards and one low-profile expansion card (with pre-installed riser cards).

  • Page 57: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-4. SUPER X9DRW-7TPF Layout SFP2 SFP1 VGA1 USB0/1 COM1 KB/MOUSE LAN2 LAN1 SXB1_1 CTRL TLAN1 TLAN2 SXB1_2 CTRL LEM2 X9DRW-7TPF/iTPF Rev. 1.01 CPU1 SCU-SGPIO1 CLOSE 1st Intel BATTERY OPEN 1st CPU2 CLOSE 1st LEDS1 JPS1 LEDS2...
  • Page 58 UPER ERVER 1027R-72BRFTP User's Manual X9DRW-7TPF Quick Reference Jumper Description Default Setting Clear CMOS See Section 5-9 JBT1 C1/JI SMB to PCI-E Slots Open (Disabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled) JPS1 SAS Enable/Disable...
  • Page 59 Chapter 5: Advanced Serverboard Setup Description LED1 Power LED LED2 UID LED LED3 BMC Heartbeat LED LED4 SAS Activity LED LED5 SAS Heartbeat LED LED6 SAS Error LED LED7 UID LED 5-13...

  • Page 60: Connector Definitions

    UPER ERVER 1027R-72BRFTP User's Manual Connector Definitions Power Connectors ATX Power 24-pin Connector Pin Definitions A 2 4 - p i n m a i n p o w e r s u p p l y Pin# Definition Pin #...
  • Page 61 Chapter 5: Advanced Serverboard Setup HDD LED HDD LED Pin Definitions (JF1) The HDD LED connection is located Pin# Definition on pins 13 and 14 of JF1. Attach a ID_UID_ cable here to indicate HDD activ- SW_3.3V/3.3V SB ity. See the table on the right for pin HDD Active definitions.
  • Page 62 UPER ERVER 1027R-72BRFTP User's Manual Power Fail LED PWR Fail LED Pin Definitions (JF1) The Power Fail LED connection is Pin# Definition located on pins 5 and 6 of JF1. Re- fer to the table on the right for pin 3.3V...
  • Page 63 Chapter 5: Advanced Serverboard Setup Serial Ports Serial COM) Ports Pin Definitions Two COM connections (COM1 & Pin # Definition Pin # Definition COM2) are located on the moth- erboard. COM1 is located on the Backplane I/O panel. COM2, located next to the JTPM1/Port 80 header, is used to provide front access sup- Ground...
  • Page 64 UPER ERVER 1027R-72BRFTP User's Manual Fan Headers Fan Header Pin Definitions This motherboard has six system/CPU Pin# Definition fan headers (Fan 1~Fan 6) on the moth- Ground erboard. All these 4-pin fans headers are +12V backward compatible with the traditional Tachometer 3-pin fans.
  • Page 65 Chapter 5: Advanced Serverboard Setup Standby Power Header Standby PWR Pin Definitions The Standby Power header is located Pin# Definition at JSTBY1 on the motherboard. See +5V Standby the table on the right for pin defini- Ground tions. (You must also have a cable to Wake-up use this feature.) T-SGPIO/S-SGPIO Headers...
  • Page 66 UPER ERVER 1027R-72BRFTP User's Manual Ethernet Ports GLAN Ports (LAN 1/2) Pin Definition Two Gigabit Ethernet ports (LAN1/2) Pin# Definition and two 10G LAN ports (TLAN1, P2V5SB SGND TLAN2) are located on the I/O back- TD0+ Act LED plane to provide internet connec-...
  • Page 67 Chapter 5: Advanced Serverboard Setup TPM Header/Port 80 TPM/Port 80 Header Pin Definitions A Trusted Platform Module/Port 80 Pin # Definition Pin # Definition header is located at JTPM1 to provide LCLK TPM support and Port 80 connection. LFRAME# <(KEY)> Use this header to enhance system LRESET# +5V (X)

  • Page 68: Jumper Settings

    UPER ERVER 1027R-72BRFTP User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used Connector to choose between optional settings. Pins Jumpers create shorts between two pins to change the function of the Jumper connector.
  • Page 69 Chapter 5: Advanced Serverboard Setup GLAN/10G_LAN Enable/Disable LAN1/2, TLAN1/2 Enable Jumper Settings Use JPL1 to enable/disable LAN Ports 1/2, Jumper Setting Definition and use JPL2 for TLAN Ports 1/2. See the Pins 1-2 Enabled (default) table on the right for jumper settings. The Pins 2-3 Disabled default setting is Enabled.
  • Page 70 UPER ERVER 1027R-72BRFTP User's Manual BIOS Write-Protect Close Pins 1/2 of Jumper JWP1 to BIOS Write Protect support BIOS Write-Protect to prevent Jumper Settings BIOS Setup utility settings from being Jumper Setting Definition illegally altered. The default setting Enabled is to close 2-3 for normal operation.

  • Page 71: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup Manufacture Mode Jumper JPME1 allows the user to flash the system firmware from a host server ME Mode Select Jumper Settings to modify system settings. Close this Jumper Setting Definition jumper to bypass SPI flash security, Pins 1-2 Manufacture Mode and force ME into Recovery mode...
  • Page 72 UPER ERVER 1027R-72BRFTP User's Manual LAN 1/LAN 2 IPMI Dedicated LAN LEDs IPMI LAN In addition to the Gigabit Ethernet ports, an Link LED Activity LED IPMI Dedicated LAN is also located above the Backplane USB ports 0/1 on the moth- IPMI LAN IPMI LAN Link LED (Left) &...

  • Page 73: 5-11 Sas/Sata Port Connections

    Chapter 5: Advanced Serverboard Setup 5-11 SAS/SATA Port Connections Serial ATA Ports SATA2.0/SATA3.0 Pin Definitions There are two SATA 3.0 Ports (I-SATA0/1) Pin# Definition and eight SATA 2.0 Ports (I-SATA 2-5, Ground S-SATA 0-3) on the motherboard. These TX_P ports provide serial-link signal connec- TX_N tions, which are faster than the connec- Ground...

  • Page 74: 5-12 Installing Software

    UPER ERVER 1027R-72BRFTP User's Manual 5-12 Installing Software After the hardware has been installed, you should first install the operating system and then the drivers. The necessary drivers are all included on the Supermicro CDs that came packaged with your serverboard.
  • Page 75 BIOS. Any subsequent changes to these thresholds must be made within SuperDoctor, as the SuperDoctor settings override the BIOS settings. To set the BIOS temperature threshold settings again, you would first need to uninstall SuperDoctor. Supero Doctor III Interface Display Screen (Health Information) 5-29...

  • Page 76: Superdoctor Iii

    UPER ERVER 1027R-72BRFTP User's Manual Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User's Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we recommend using SuperDoctor II. 5-30...

  • Page 77: 5-13 Onboard Battery

    Chapter 5: Advanced Serverboard Setup 5-13 Onboard Battery Care must be taken to assure that the chassis cover is in place when the 1027R- 72BRFTP is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed. Figure 5-5.
  • Page 78 UPER ERVER 1027R-72BRFTP User's Manual Notes 5-32...

  • Page 79: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC119XTQ chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step.

  • Page 80: Control Panel

    "Chapter 5: Advanced Serverboard Setup." System Fans The 1027R-72BRFTP. contains six counter-rotating fans. Each fan unit is actually made up of two fans joined back-to-back, which rotate in opposite directions. This counter-rotating action generates exceptional airflow and works to dampen vibra-...

  • Page 81: System Fan Failure

    Chapter 6: Advanced Chassis Setup System Fan Failure Fan speed is controlled by system temperature via a BIOS setting (Fan Speed Control Modes). If a fan fails, the remaining fan will ramp up to full speed and the overheat/fan fail LED on the control panel will turn on. Replace any failed fan at your earliest convenience with the same type and model (the system can continue to run with a failed fan).

  • Page 82: Air Shroud

    UPER ERVER 1027R-72BRFTP User's Manual Figure 6-2. System Fans Air Shroud Air shrouds concentrate airflow to maximize fan efficiency. The SC119 chassis air shroud does not require screws to set up. Air Shroud Installation 1. Disconnect the chassis from any power souce.
  • Page 83 Chapter 6: Advanced Chassis Setup Figure 6-3. Air Baffle Installation Air Baffle Figure 6-4. Air Shroud Installation Notch Screw...
  • Page 84 Proceed to the "DVD-ROM Drive Installation" section later in this chapter for instructions. Note: Only a "slim" DVD-ROM drive will fit into the 1027R-72BRFTP Warning! Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers.

  • Page 85: Hard Drive Installation

    Chapter 6: Advanced Chassis Setup Hard Drive Installation The SC119 chassis accepts eight hot-swappable 2.5" hard drives. The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis. System power may remain on when removing carriers with drives installed. These carriers also help promote proper airflow for the drive bays.
  • Page 86 UPER ERVER 1027R-72BRFTP User's Manual Installing a Hard Drive into a Drive Carrier 1. Remove the dummy drive, which comes pre-installed in the drive carrier, by removing the screws securing the dummy drive to the carrier. Note that these screws cannot be reused on the actual 2.5" hard drive.

  • Page 87: Hard Drive Backplane

    Chapter 6: Advanced Chassis Setup Hard Drive Backplane The hard drives plug into a backplane that provides power and drive ID. A RAID controller can be used with the backplane to provide data security. The operating system you use must have RAID support to enable the hot-swap capability of the drives.

  • Page 88: Power Supply

    Battery Backup Power (BBP™) Feature The SuperServer 1027R-72BRFTP features two redundant Battery Backup Power modules. In the event that power to the SuperServer 1027R-72BRFTP is interrupted, the BBP feature will provide power to the unit. Each BBP can provide 200 watts (400 watts total) for five minutes, 100 watts (200 watts total) for 15 minutes or six seconds of 350 watt (600 watts total) surge.
  • Page 89 Chapter 6: Advanced Chassis Setup Removing the Power Supply 1. First unplug the AC power cord from the failed power supply module. 2. Depress the locking tab on the power supply module. 3. Use the handle to pull it straight out with the rounded handle. Installing a New Power Supply 1.
  • Page 90 UPER ERVER 1027R-72BRFTP User's Manual Notes 6-12...

  • Page 91: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup utility for the X9DRW-7TPF/iTPF. It also provides the instructions on how to navigate the AMI BIOS Setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. Starting BIOS Setup Utility To enter the AMI BIOS Setup utility screens, press the <Del>...

  • Page 92: How To Change The Configuration Data

    UPER ERVER 1027R-72BRFTP User's Manual How To Change the Configuration Data The configuration data that determines the system parameters may be changed by entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing <Delete> at the appropriate time during system boot.
  • Page 93 Chapter 7: BIOS System Date/System Time Use this option to change the system time and date. Highlight System Time or System Date using the arrow keys. Enter new values through the keyboard and press <Enter>. Press the <Tab> key to move between fields. The date must be entered in Day MM/DD/YY format.

  • Page 94: Advanced Setup Configurations

    UPER ERVER 1027R-72BRFTP User's Manual Advanced Setup Configurations Select the Advanced tab to access the following submenu items. Boot Feature Quiet Boot This feature allows the user to select bootup screen display between POST mes- sages and the OEM logo. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages.
  • Page 95 Chapter 7: BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 96 UPER ERVER 1027R-72BRFTP User's Manual • CPU Signature • Microcode Patch • CPU Stepping • Maximum / Minimum CPU Speed • Processor Cores • Intel HT (Hyper-Threading) Technology • Intel VT-x Technology • Intel SMX Technology • L1 Data Cache / L1 Code Cache •...
  • Page 97 Chapter 7: BIOS Active Processor Cores Set to Enabled to use a processor's second core and above. (Please refer to Intel's website for more information.) The options are All, 1, 2, 4, and 6. Limit CPUID Maximum This feature allows the user to set the maximum CPU ID value. Enable this function to boot the legacy operating systems that cannot support processors with extended CPUID functions.
  • Page 98 UPER ERVER 1027R-72BRFTP User's Manual Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent parti- tions, creating multiple "virtual" systems in one physical computer. The options are Enabled and Disabled.
  • Page 99 Chapter 7: BIOS CPU C6 Report (Available when Power Technology is set to Custom) Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to the operating system. During the CPU C6 State, the power to all cache is turned off.
  • Page 100 UPER ERVER 1027R-72BRFTP User's Manual Short Duration Power Limit During Turbo Mode, the system may exceed the processors default power setting and exceed the Short Duration Power limit. By increasing this value, the proces- sor can provide better performance for short duration. This item displays the time period during which short duration power is maintained.
  • Page 101 Chapter 7: BIOS IOU1-PCIe Port This feature allows the user to set the bus speed between the IOU1 and the PCI-Exp port. The options are x4x4 and x8. IOU2-PCIe Port This feature allows the user to set the bus speed between the IOU2 and the PCI-Exp port.
  • Page 102 UPER ERVER 1027R-72BRFTP User's Manual QPI Configuration Current QPI Link This item displays the current status of the QPI Link. Current QPI Frequency This item displays the frequency of the QPI Link. Isoc Select Enabled to enable Isochronous support to meet QoS (Quality of Service) requirements.
  • Page 103 Chapter 7: BIOS  DIMM Information CPU Socket 1 DIMM Information, CPU Socket 2 DIMM Information The status of the memory modules is displayed as detected by the BIOS. Memory Mode When Independent is selected, all DIMMs are available to the operating system. When Mirroring is selected, the motherboard maintains two identical copies of all data in memory for data backup.
  • Page 104 UPER ERVER 1027R-72BRFTP User's Manual Demand Scrub Demand Scrubbing is a process that allows the CPU to correct correctable memory errors found on a memory module. When the CPU or I/O issues a demand-read command, and the read data from memory turns out to be a correctable error, the error is corrected and sent to the requestor (the original source).
  • Page 105 Chapter 7: BIOS Legacy USB Support (Available when USB Functions is not Disabled) Select Enabled to support legacy USB devices. Select Auto to disable legacy sup- port if USB devices are not present. Select Disabled to have USB devices available for EFI (Extensive Firmware Interface) applications only.
  • Page 106 UPER ERVER 1027R-72BRFTP User's Manual AHCI Mode The following items are displayed when the AHCI Mode is selected. Aggressive Link Power Management When Enabled, the SATA AHCI controller manages the power usage of the SATA link. The controller will put the link in a low power mode during extended periods of I/O inactivity, and will return the link to an active state when I/O activity resumes.
  • Page 107 Chapter 7: BIOS PCIe/PCI/PnP Configuration Launch Storage OpROM Policy Use this feature to select the Option ROM to boot the system when there are multiple Option ROMs available in the system. The options are UEFI only and Legacy only. PCI Latency Timer Use this feature to set the latency Timer of each PCI device installed on a PCI bus.
  • Page 108 UPER ERVER 1027R-72BRFTP User's Manual BCM57810S 10G OPROM Select Enabled to boot the computer using the BCM57810S Ethernet device. The options are Enabled and Disabled. Onboard LAN Option ROM Select Select iSCSI to use the iSCSI Option ROM to boot the computer using a network device.
  • Page 109 Chapter 7: BIOS Serial Port 1 Configuration Serial Port Select Enabled to enable serial port 1. The options are Enabled and Disabled. Device Settings This item displays the settings of Serial Port 1. Change Settings This option specifies the base I/O port address and the Interrupt Request address of Serial Port 1.
  • Page 110 UPER ERVER 1027R-72BRFTP User's Manual Serial Port 2 Attribute Use this feature to select the attribute for this serial port. The options are SOL (Serial Over LAN), and COM. Serial Port Console Redirection COM1, COM2 These two submenus allow the user to configure the following Console Redirection settings for a COM Port specified by the user.
  • Page 111 Chapter 7: BIOS in transmission. Select Mark to add a mark as a parity bit to be sent along with the data bits. Select Space to add a Space as a parity bit to be sent with your data bits. The options are None, Even, Odd, Mark and Space. Stop Bits A stop bit indicates the end of a serial data packet.
  • Page 112 UPER ERVER 1027R-72BRFTP User's Manual Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) The submenu allows the user to configure Console Redirection settings to support Out-of-Band Serial Port management. Console Redirection (for EMS) Select Enabled to use a COM Port selected by the user for Console Redirection.
  • Page 113 Chapter 7: BIOS ACPI Settings Use this feature to configure Advanced Configuration and Power Interface (ACPI) power management settings for your system. ACPI Sleep State Use this feature to select the ACPI State when the system is in sleep mode. Select S1 (CPU_Stop_Clock) to erase all CPU caches and stop executing instructions.
  • Page 114 UPER ERVER 1027R-72BRFTP User's Manual Pending Operation Use this item to schedule an operation for the security device. The options are None, Enable Take Ownership, Disable Take Ownership, and TPM Clear. Note: During restart, the computer will reboot in order to execute the pend- ing operation and change the state of the security device.
  • Page 115 Chapter 7: BIOS Intel TXT (LT-SX) Dependencies Be sure to enable the features displayed below for Trusted Execution Technology to work properly in the system. VT-d Support: Intel Virtualization Technology with Direct I/O support VT Support: Intel Virtualization Technology support TPM Support: Trusted Platform support TPM State: Trusted Platform state ME Subsystem...
  • Page 116 UPER ERVER 1027R-72BRFTP User's Manual Ethernet Controller i350 Gigabit Network Connection Intel ® These items display the following information on the Intel i350 Gigabit network connections. NIC Configuration Link Speed Use this feature to change the link speed and duplex for the current port. The op- tions are AutoNeg, 10Mbps Half, 10Mbps Full, 100Mbps Half, and 100Mbps full.

  • Page 117: Event Logs

    Chapter 7: BIOS Event Logs Select the Event Logs tab to access the following submenu items. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 118 UPER ERVER 1027R-72BRFTP User's Manual Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes, Next reset, and Yes, Every reset.

  • Page 119: Ipmi

    Chapter 7: BIOS IPMI Select the IPMI (Intelligent Platform Management Interface) tab to access the fol- lowing submenu items. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system. System Event Log ...
  • Page 120 UPER ERVER 1027R-72BRFTP User's Manual When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.

  • Page 121: Boot

    Chapter 7: BIOS Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). Boot This submenu allows the user to configure the following boot settings for the system.

  • Page 122: Security

    UPER ERVER 1027R-72BRFTP User's Manual Security This menu allows the user to configure the following security settings for the system. Password Check Use this feature to determine when a password entry is required. Select Setup to require the password only when entering setup. Select Always to require the pass- word when entering setup and on each boot.

  • Page 123: Save & Exit

    Chapter 7: BIOS Save & Exit This submenu allows the user to configure the Save and Exit settings for the system. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit, and press <Enter>.
  • Page 124 UPER ERVER 1027R-72BRFTP User's Manual Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previ- ous values, select Yes to load the values previous saved, or select No to keep the changes you've made so far.

  • Page 125: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 126 UPER ERVER 1027R-72BRFTP User's Manual Notes...

  • Page 127: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Single or dual Intel® E5-2600 Series (Socket R) processors in LGA 2011 sockets Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C602 chipset BIOS 128 Mb AMI®...
  • Page 128 UPER ERVER 1027R-72BRFTP User's Manual Serverboard X9DRW-7TPF (Proprietary form factor) Dimensions: 16.5 x 12.8 in (419 x 325 mm) Chassis SC119XTQ-R700WB (1U rackmount) Dimensions: (WxHxD) 17.2 x 1.7 x 26.9 in. (437 x 43 x 683 mm) Weight Gross Weight: 46 lbs. (20.9 kg.)
  • Page 129 Appendix B: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
