Project 2056659 2 of 25 ITEM / ARTICLE / ARTICULO # 296474 STAINLESS STEEL LP BUILT-IN GRILL MODEL / MODÈLE / MODELO # 740-0594A WARNING WARNING To reduce the risk of fire, burn hazard or other FOR OUTDOOR USE ONLY injury, read the Care and Use Manual carefully and completely before using your grill.
Figure 2244 CSA International Project 2056659 3 of 25 TABLE OF CONTENTS Safety Information….…………………………………………………..………………...……..….2 Package Contents List………………………………………………………………………..……..6 Preparation……………….…………………. ……………………….…………….………………..7 Island Construction…………………………………………………………….…..……..………….7 Assembly Instructions…………………………………………………………….…..……..………9 Installation Instructions……………………………………………………………..…….……...10 Operation Instructions…….…………………………………………………….…..…..……….…13 Gas Conversion from LP to NG…………………………………………………………………..15 Care and Maintenance……………………………………………………………………………..18 Troubleshooting…………………………………………………………………..……….……..…20 Warranty………………………………….…………………………………………..………..…….22 Replacement Parts List………………….…...……………………………………..…….……….23 SAFETY INFORMATION RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS DANGER...
Page 3
Figure 2244 CSA International Project 2056659 4 of 25 WARNING 1. The grill and its individual shut-off valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressure in excess of 1/2 psi. (3.5 kpa). 2.
Page 4
Figure 2244 CSA International Project 2056659 5 of 25 CAUTION CAUTION When using the rotisserie burner, remove the The grill head is heavy and will require two or warming rack. High heat from the burner may more people to lift and position onto grill cart. cause the warming rack to bend.
Page 5
Figure 2244 CSA International Project 2056659 6 of 25 WARNING TESTED IN ACCORDANCE WITH ANSI Z21.58 Do not try lighting this appliance without first LATEST STANDARD and CGA 1.6-2007 reading the “LIGHTING INSTRUCTIONS” STANDARED FOR OUTDOOR COOKING GAS section of this manual. APPLIANCES.
Page 6
Do not use briquettes of any kind in the grill. The 740-0594A liquid propane gas grill is designed for optimum performance without the use of briquettes. Do not place briquettes on the flame tamers as this will block the vent to the grill burners. Adding briquettes can damage ignition components, thus voiding the warranty.
Figure 2244 CSA International Project 2056659 8 of 25 PACKAGE CONTENTS LIST 1. Body Assembly ----------1pc. 2. Tank Tray----------1 pc. 3. Bracket----------1 pc. PREPARATION Before beginning assembly, installation or operation of product, make sure all parts are present. Compare parts with package contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or operate the product.
Page 8
Figure 2244 CSA International Project 2056659 Fig. 2 9 of 25 Island cutout dimensions for 5 burners built-in grills: 41 1/4 in.(104.78cm) Width 38 inches (83.82 cm) 37 1/4 in.(94.62cm) Depth 21 inches (53.34cm) Height 11 inches (27.94 cm) Tank bolt dimension for 5 burners LP Tank bolt type: 1/2 inches-12UNC (1.27 cm) 37 3/4 in.(95.89cm) Tank bolt length: 9/20 inches (11.5 cm)
Figure 2244 CSA International Project 2056659 10 of 25 ASSEMBLY INSTRUCTIONS Fig. 5 1.Battery Installation Unscrew the ignition button housing (A); insert the battery from pack G into the housing with the positive terminal (+) facing outward (B). Replace the ignition button housing after the battery has been installed as shown in fig.
This grill is configured for Liquid Propane. Do not use a Natural Gas supply. Total gas consumption (per hour) of the 740-0594A Liquid Propane gas grill with all burners set on “HI”: Main burners 60,000 BTU/Hr.
Page 11
Figure 2244 CSA International Project 2056659 12 of 25 CONNECTING THE LIQUID PROPANE CYLINDER Your grill is equipped with gas supply orifices for use with only Liquid Propane gas. It is also equipped with a high capacity hose/regulator assembly for connection to a standard 20-lb Liquid Propane cylinder (18-1/4 inches high, 12-1/4 inches diameter).
Page 12
Figure 2244 CSA International Project 2056659 13 of 25 WARNING WARNING Storage of an outdoor cooking gas appliance Cylinder must be stored outdoors out of the indoor is permissible only if the cylinder is reach of children and must not be stored in a disconnected and removed from the outdoor building, garage or any other enclosed area.
Figure 2244 CSA International Project 2056659 14 of 25 OPERATING INSTRUCTIONS General Use of the Grill Each main burner is rated at 12,000 BTU/Hr. The main grill burners encompass the entire cooking area and are side ported to minimize blockage from falling grease and debris. Above the burners are flame tamers. The igniter knobs are located on the center portion of the valve panel.
Page 14
Figure 2244 Fig. 10 CSA International Project 2056659 15 of 25 and stable with no yellow tips, excessive noise or lifting. Yellow flames indicate insufficient air. Noisy flames or flames Rear Burners that lift away from the burner indicate too much air (See the “Flame Characteristics”...
This grill is certified for use with either Liquid Propane (LP Gas) or Natural Gas and comes complete with the necessary parts to convert the grill for use with Natural Gas hose and regulator sold separately. The Nexgrill patented Conversion Valves allows the use of Natural Gas without replacing the burners or entire valve system.
Page 16
CSA International Project 2056659 17 of 25 Natural Gas Conversion for Item#296474/Model# 740-0594A Warning: Make sure all grill components are completely cool and gas supply is turned off and removed from grill prior to performing the conversion. NG Hose and Regulator Conversion...
Page 17
Figure 2244 CSA International Project 2056659 18 of 25 6mm Nut Driver Steps: 1. Remove the main tube burners by removing the screw securing the burners near the back wall of the firebox and the screws near the front of the firebox that secure the igniter brackets to the burners. Gently lift the question mark burners up and out.
Figure 2244 CSA International Project 2056659 19 of 25 Steps: 1. Remove the three screws securing the wind baffle and six screws securing rear baffle from inside the grill. Remove the Rear Baffle and wind baffle from the back of the grill. 2.
Page 19
Figure 2244 CSA International Project 2056659 20 of 25 Grill Burners Extreme care should be taken when removing a burner. It must be correctly centered on the orifice before any attempt is made to relight the grill. Frequency of cleaning will depend on how often you use the grill. Failure to properly place the burner over the orifice could cause a fire to occur behind and beneath the valve panel, thereby damaging the grill and making it unsafe to operate.
Figure 2244 CSA International Project 2056659 21 of 25 TROUBLESHOOTING Please refer to the following Troubleshooting Guide if you have any problems lighting or operating your grill. Many solutions given here can make your grilling experience safer and more enjoyable. Problem Possible Solutions 1.
Page 21
Figure 2244 CSA International Project 2056659 22 of 25 Problem Possible Solutions The propane regulator assembly incorporates an excess flow device designed to supply the grill with sufficient gas flow under normal conditions, yet control excess gas flow. Rapid changes in pressure can trigger the excess flow device, Providing a low flame and low temperature.
LIMITED WARRANTY (Model # 740-0594A) Nexgrill warrants to the original consumer-purchaser only that this product (Model #740-0543) shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase. The manufacturer reserves the right to require photographic evidence of damage, or that defective parts be returned, postage and or freight pre-paid by the consumer, for review and examination.
Figure 2244 CSA International Project 2056659 24 of 25 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-877-323-5263, 8 a.m. – 6 p.m., PST, Monday – Friday and 8 a.m. – 12 p.m. PST, Saturday. REF# DESCRIPTION REF# DESCRIPTION...
Page 24
Figure 2244 CSA International Project 2056659 25 of 25 Printed in China...
