IMPORTANT!
PLEASE READ THIS MANUAL AND KEEP IT FOR FUTURE REFERENCE!
THIS MANUAL CONTAINS SECTIONS OF SAFETY INSTRUCTIONS, OPERATING INSTRUCTIONS
& TROUBLESHOOTING TIPS, ETC.
BAUMATIC
BDW45.1 DISHWASHER
45CM FULL HEIGHT DISHWASHER
INSTRUCTION MANUAL
CAREFULLY READING IT BEFORE USING THE DISHWASHER WILL HELP
YOU USE AND MAINTAIN THE DISHWASHER PROPERLY.
09/01/06

Advertisement

Table of Contents
loading

Related Manuals for Baumatic BDW45.1

Summary of Contents for Baumatic BDW45.1

  • Page 1 PLEASE READ THIS MANUAL AND KEEP IT FOR FUTURE REFERENCE! THIS MANUAL CONTAINS SECTIONS OF SAFETY INSTRUCTIONS, OPERATING INSTRUCTIONS & TROUBLESHOOTING TIPS, ETC. BAUMATIC BDW45.1 DISHWASHER 45CM FULL HEIGHT DISHWASHER INSTRUCTION MANUAL CAREFULLY READING IT BEFORE USING THE DISHWASHER WILL HELP YOU USE AND MAINTAIN THE DISHWASHER PROPERLY.

  • Page 2: Table Of Contents

    BAUMATIC BDW45.1 dishwasher user manual CONTENTS • SAFETY FIRST! SAFETY INFORMATION .……………..…………3 *Please read this before using your dishwasher! • KNOWING YOUR DISHWASHER CONTROL PANEL ………………………..……..…4 DISHWASHER FEATURES …………..………….4 BEFORE CALLING FOR SERVICE • USING YOUR DISHWASHER WATER SOFTENER …………………..………...5-6 REVIEWING THE SECTION ON DETERGENT ………………......6...

  • Page 3: Safety Information

    COMPARTMENT OF YOUR OLD APPLIANCE BEFORE DISCARDING IT. • DURING THE GUARANTEE PERIOD ONLY BAUMATIC SERVICE ENGINEERS OR AN AUTHORISED AGENT OF BAUMATIC SHOULD CARRY OUT REPAIRS ON THIS UNIT. • DO NOT USE IF THE SUPPLY CORD IS DAMAGED. •...

  • Page 4: Control Panel

    BAUMATIC BDW45.1 dishwasher user manual CONTROL PANEL NOTE: YOUR DISHWASHER’S CONTROL PANEL IS ON THE TOP LIP OF THE DOOR. IF YOUR APPLIANCE IS BEING INSTALLED UNDER A WORKTOP, YOU WILL NEED TO OPEN THE DOOR TO SEE THE CONTROL PANEL.
  • Page 5 BAUMATIC BDW45.1 dishwasher user manual Note on chemicals used by the dishwasher • Your dishwasher is equipped with an adjustable rinse aid and salt container. Using individual detergents, rinse aid and salt will give the best possible results as this will give the correct dosage of each chemical to suit your needs.

  • Page 6: Detergent

    BAUMATIC BDW45.1 dishwasher user manual SETTING THE WATER SOFTENER LEVEL YOU CAN ADJUST THE AMOUNT OF SALT USED BY THE DISHWASHER TO SOFTEN WATER TO GET THE BEST WASHING RESULTS, BASED ON THE HARDNESS OF WATER IN YOUR AREA. THERE IS A RING ON THE NECK OF THE CONTAINER.

  • Page 7: Rinse Aid

    BAUMATIC BDW45.1 dishwasher user manual FINAL RINSE TO PREVENT WATER FROM RINSE AID FORMING DROPLETS ON YOUR DISHES THAT CAN CAUSE SPOTS AND STREAKS. IT ALSO IMPROVES DRYING BY ALLOWING WATER TO FALL OFF THE DISHES. • YOUR DISHWASHER IS DESIGNED TO USE LIQUID RINSE AIDS.

  • Page 8: Loading Your Dishwasher

    BAUMATIC BDW45.1 dishwasher user manual LOADING NOTE: YOUR FOR BEST PERFORMANCE, FOLLOW THESE LOADING GUIDELINES. FEATURES AND DISHWASHER APPEARANCE RACKS & CUTLERY BASKETS MAY VARY FROM YOUR MODEL. BEFORE LOADING! • REMOVE ALL SCRAPS OF FOOD. • EMPTY DRINKS & LIQUIDS FROM CUPS.
  • Page 9 BAUMATIC BDW45.1 dishwasher user manual Note: Do not wash stainless steel and silver cutlery together. Iron objects can rust and stain other items. Aluminium tends to go black. Copper, pewter & brass stain. HOW TO USE THE UPPER RACK POSITION...
  • Page 10 BAUMATIC BDW45.1 dishwasher user manual ***NOTE***: THE UPPER RACK HAS SIDE FLAPS (PICTURED AT LEFT ABOVE BASKET). THERE ARE 4 (2 ON EACH SIDE). THESE CAN BE ADJUSTED INTO 2 POSITIONS = POSITION 1 (HIGH) AND POSITION 2 (LOW). TO MOVE THE FLAPS BETWEEN THESE...
  • Page 11 BAUMATIC BDW45.1 dishwasher user manual CUTLERY BASKET CUTLERY SHOULD BE PLACED IN THE CUTLERY BASKET WITH HANDLES ALWAYS POINTING DOWNWARD (AT THE BOTTOM). VERY LONG UTENSILS (LADLES, etc.) SHOULD BE PLACED HORIZONTALLY AT THE FRONT OF THE UPPER RACK. Forks...

  • Page 12: Starting A Wash Cycle

    BAUMATIC BDW45.1 dishwasher user manual STARTING A WASH CYCLE 1) MAKE SURE THAT YOUR DISHWASHER’S ‘ON/OFF’ BUTTON PLUG HAS BEEN PUSHED ALL THE WAY INTO ‘ON/OFF’ LIGHT WILL COME ON. THE WALL SOCKET. 2) MAKE SURE THAT THE WATER SUPPLY IS 6) PRESS THE ‘P’...
  • Page 13 15 grams OVERFLOW PROTECTION YOUR BAUMATIC DISHWASHER HAS AN OVERFILL PROTECTION DEVICE WHICH AUTOMATICALLY SHUTS OFF THE INLET VALVE AND STARTS THE DRAIN PUMP IF THE WATER OVERFLOWS. IF THIS OCCURS THEN TURN OFF THE MAINS WATER SUPPLY BEFORE CALLING THE SERVICE DEPARTMENT. IF THERE IS WATER IN THE BASE PAN BECAUSE OF AN OVERFILL OR SMALL LEAK, THE WATER SHOULD BE REMOVED BEFORE RESTARTING THE DISHWASHER.
  • Page 14 BAUMATIC BDW45.1 dishwasher user manual FORGET TO ADD A DISH? A FORGOTTEN DISH CAN BE ADDED AT ANY TIME BEFORE THE DETERGENT DISPENSER OPENS. OPEN THE DOOR A LITTLE TO STOP THE WASHING. • WAIT ABOUT TEN SECONDS. AFTER THE SPRAY ARMS STOP WORKING, •...

  • Page 15: Filtering System

    BAUMATIC BDW45.1 dishwasher user manual AT THE END OF THE WASH CYCLE WHEN YOUR DISHWASHER’S WASHING CYCLE HAS FINISHED: • THE ALARM WILL SOUND FOR EIGHT SECONDS. • OPEN THE DOOR OF YOUR DISHWASHER & SWITCH YOUR DISHWASHER OFF USING THE ‘ON/OFF’ KEY.
  • Page 16 BAUMATIC BDW45.1 dishwasher user manual Filter & 3) The Fine Filter. 1 MAIN FILTER Food and soil particles trapped by this filter are pulverized by a special jet on the lower spray arm and washed down the drain. 2 COARSE FILTER Larger items, such as pieces of bone or glass that could clog the drain are trapped in the coarse filter.
  • Page 17 BAUMATIC BDW45.1 dishwasher user manual CLEANING THE FILTERS • THE FILTER ASSEMBLY MUST BE KEPT CLEAN FOR BEST PERFORMANCE. You should remove the larger bits of food trapped in the filter after each wash cycle by rinsing the semicircular filter and cup under running water.
  • Page 18 BAUMATIC BDW45.1 dishwasher user manual HOW TO KEEP YOUR DISHWASHER IN SHAPE , leave the door slightly ajar so that moisture and odours are not trapped FTER VERY inside. before cleaning or performing maintenance. Never run the risk of electric EMOVE THE shocks.
  • Page 19 BAUMATIC BDW45.1 dishwasher user manual BEFORE YOU CALL FOR SERVICE … CHECKING AGAINST THE CHARTS BELOW MAY FIX YOUR PROBLEM. PROBLEM POSSIBLE CAUSES WHAT TO DO • Replace fuse or reset circuit breaker. • Fuse blown, • Remove other appliances...
  • Page 20 BAUMATIC BDW45.1 dishwasher user manual PROBLEM POSSIBLE CAUSES WHAT TO DO • Sound from soft food shredding • Some audible sounds action and detergent cup opening. are normal This is not a problem. • Utensils are not secure baskets •...
  • Page 21 BAUMATIC BDW45.1 dishwasher user manual PROBLEM POSSIBLE CAUSES WHAT TO DO • Make sure there are no large dishes • Improper rack loading blocking the action of the detergent dispenser and the spray arms. To remove spots from glassware: •...
  • Page 22 BAUMATIC BDW45.1 dishwasher user manual PROBLEM POSSIBLE CAUSES WHAT TO DO Detergent left in • Dishes block detergent • Reload the dishes properly. dispenser cups! cups • There is some steam coming through Steam! • Normal phenomenon the vent by the door latch during drying and water draining.
  • Page 23 BAUMATIC BDW45.1 dishwasher user manual PROBLEM POSSIBLE CAUSES WHAT TO DO • Level appliance & ensure top screws attaching appliance to work surface • Appliance not level are not lifting the weight of the dishwasher. • Door fitted • See pages 27-28 for information correctly about correct fitting of door.

  • Page 24: Your Dishwasher

    BAUMATIC BDW45.1 dishwasher user manual ERROR CODES - WHAT THEY MEAN * YOUR DISHWASHER MAY EXPERIENCE A FAULT. SHOULD THIS HAPPEN, A CODE CONSISTING OF ‘E’ & A NUMBER FROM 1-7 CAN BE DISPLAYED. USE THIS TABLE TO UNDERSTAND WHAT IS WRONG.

  • Page 25: Characteristics

    BAUMATIC BDW45.1 dishwasher user manual DISHWASHER CHARACTERISTICS The BAUMATIC BDW45.1 dishwasher model is based firmly on convenience. Apart from having the same general workings as other household dishwashers, it has several extra features. Performance CLASS Dishwasher Your 8 place settings...
  • Page 26 BAUMATIC BDW45.1 dishwasher user manual NOTE: APPLIANCE SHOULD ONLY BE FITTED BY A TRAINED TECHNICIAN INSTALLING YOUR DISHWASHER a) PREPARATION Before you install your appliance, make sure that the place you have chosen to fit it is: • Near the existing power socket.
  • Page 27 BAUMATIC BDW45.1 dishwasher user manual kitchen décor available from your kitchen unit dealer) can be attached to the front of the dishwasher according to the following diagram. (Measurement is in millimetres): NOTE: 4.5-5 THE MAXIMUM WEIGHT OF THE DOOR IS KILOGRAMS •...
  • Page 28 BAUMATIC BDW45.1 dishwasher user manual Installing the furniture door : NAMED IN FIGURE AS ‘ NOTE AESTHETIC ’ PANEL (PICTURED ON RIGHT) Take away the cover. Affix the screw. Replace the cover. c) TENSION ADJUSTMENT OF THE DOOR SPRING Your dishwasher’s outer door is attached to springs. These are set at the factory to...
  • Page 29 BAUMATIC BDW45.1 dishwasher user manual ensure they’re at the proper tension so that the door can open and close smoothly and conveniently. Note: If you have installed a cover panel over the door, you will have to adjust the door spring tension.
  • Page 30 BAUMATIC BDW45.1 dishwasher user manual appliance. Make sure the water pressure is the same as the range indicated on the data tag. DO NOT CONNECT TO THE HOT WATER SYSTEM! If your appliance is fitted with an aqua stop system then this must be fitted vertically (pointing upwards) not downwards or sideways.
  • Page 31 BAUMATIC BDW45.1 dishwasher user manual f) NOW YOU ARE READY TO CONNECT THE POWER CORD. WARNING! ELECTRICITY CAN BE DANGEROUS. PLEASE READ THE FOLLOWING CAREFULLY: ELECTRICAL CONNECTION Electrical Requirements The dishwasher is designed for operation on an adequately wired individual 220-240V AC, 50Hz system.
  • Page 32 BAUMATIC BDW45.1 dishwasher user manual h) THEN, APPLY THE CONDENSATION STRIP. The Condensation Strip must be fitted to the underside of the worktop above your dishwasher to protect it against any moisture. Its purpose is to deflect steam rising from your appliance to protect your worktop’s underside.
  • Page 33 BAUMATIC BDW45.1 dishwasher user manual WARNING! BE CAREFUL WHILE YOU ARE LEVELLING YOUR DISHWASHER IN PLACE – IT COULD TIP OVER AND INJURE YOU! CONSULT THE FIGURE BELOW FOR HELP! THE REAR FEET CAN BE ADJUSTED FROM THE FRONT OF THE DISHWASHER BY TURNING THE SCREWS ON THE LEFT AND RIGHT HAND SIDES OF THE CABINET.
  • Page 34 BAUMATIC BDW45.1 dishwasher user manual FINAL CHECKLIST BEFORE OPERATING NOTE: BEFORE YOU START USING YOUR DISHWASHER, PLEASE MAKE SURE YOU HAVE CHECKED WHETHER THE DISHWASHER IS LEVEL AND FIXED. • WHETHER THE INLET VALVE IS OPENED. • WHETHER THERE LEAKAGE •...

  • Page 35: Conditions Of Guarantee

    In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fitted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date.
  • Page 36 BAUMATIC BDW45.1 dishwasher user manual Baumatic Ltd Make-up for your kitchen Headquarters Baumatic Ltd. Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX, United Kingdom Sales Telephone +44 118 933 6900 Sales Fax +44 118 931 0035 Service Telephone +44 118 933 6911...
