Quick guide
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.hotpoint.eu/register
CONTROL PANEL
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is properly
connected, either to the dryer's water tank or to your domestic
drainage system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
DESCRIPTION OF CONTROL PANEL
1. "Start" button
Press to begin drying.
2. "Drying Time" selection knob
This is used to set the drying time: turn the knob in a
direction until the indicator is set to the desired drying time. The
0 position switches off the dryer.
3. "Emptying Water Tank" indicator light
To indicate when the water tank needs emptying.
Lighting up when the container is full, the door is closed and the
"Start" button has been pressed.
After emptying, reposition it correctly and the light will take
around 30 seconds to switch off after restarting the drying cycle
with the "Start" button.
IMPORTANT: If the container becomes full during the cycle, the
dryer will automatically stop and clothes will not be dried. To
avoid this empty the tank after or before starting a cycle.
4. "High Heat" button
To be used to increase the heat on drying cycles.
You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:
• Visiting our website -
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product's identifi cation plate.
Before using the appliance read the Safety Instructions carefully.
clockwise
docs.hotpoint.eu
2
4
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying cycle.
- remember to clean your condenser unit regularly (monthly).
- remember to clean your filter after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the drying time table.
Empty pockets. Make sure garments do not get caught between the
door and/or the door filter.
3. Close the door.
4. Turn the "Drying Time" selection knob until the indicator is
pointing towards the most suitable drying time for the type of
fabric in that load.
Note: do not attempt to turn the knob anticlockwise.
5. If necessary, set the temperature using the "High Heat" button.
6. Press the "Start" button to begin drying.
7. A final COOL TUMBLE phase (i.e. the fabrics are cooled) activates
during the last few minutes of the drying cycle; always allow this
phase to finish.
8. The cycle ends when the selection knob reaches the "0" zero
position and the drum stops.
9. Open the door, remove the laundry.
10. Disconnect the dryer from the power supply.
11. Clean the filter and replace it.
12. Empty the water tank and put it back in its slot.
OPENING THE DOOR DURING THE CYCLE
Laundry can be checked while the drying cycle runs and any
garments already dry can be removed, while drying continues for
the remaining items. After closing the door, press the "Start" button
to resume machine operation.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
EN
