CONCORD Eye-Q Go LCD Quick Start Manual page 4

LOADING THE BATTERY
The Concord Eye-Q Go LCD uses one 3V (CR123) lithium
battery.
Loading the Battery:
1. Locate the battery door on the bottom of the camera.
2. Slide the battery door outwards, as indicated by the arrow
and lift the battery door to open. (fig.1.1)
3. Insert the 3V (CR123) lithium battery with the positive
terminal (+) toward the inside of the battery compartment.
(fig.1.2)
4. Close the battery door, press down on it and slide it
towards the center of the camera until it snaps into place.
TURNING THE CAMERA ON AND OFF
1. Press the On/Off button
will beep when it is turned on.
2. To turn the camera off, press the On/Off button
for a few seconds. (fig.1.3)
INSERTING THE MULTIMEDIACARD OR THE SECURE DIGITAL MEMORY CARD
1. Locate the battery cover on the bottom of the camera.
2. Slide the battery door away from the camera body and lift
the battery door to open.
3. Insert the MMC or SD memory card as indicated by the
arrow. (fig.1.5)
4. Close the battery door. Press down on it and slide it
towards the center of the camera until it snaps into place.
for a few seconds. The camera
2
fig.1.1
fig.1.2
fig.1.3
fig.1.4
fig.1.5
