LG ACAH020HETB Installation And Owner's Manual
  1. Manuals
  2. Brands
  3. LG Manuals
  4. Inverter
  5. ACAH020HETB
  6. Installation and owner's manual

LG ACAH020HETB Installation And Owner's Manual

Air-cooled cooling only inverter scroll chiller
Hide thumbs
Table of Contents

Advertisement

Quick Links

LG AIR-COOLED
COOLING ONLY
INVERTER SCROLL CHILLER
INSTALLATION AND
OWNERS MANUAL
Cooling Only
20 Tons, 460V Model

Advertisement

Table of Contents
loading

Related Manuals for LG ACAH020HETB

Summary of Contents for LG ACAH020HETB

  • Page 1 LG AIR-COOLED COOLING ONLY INVERTER SCROLL CHILLER INSTALLATION AND OWNERS MANUAL Cooling Only 20 Tons, 460V Model...
  • Page 2 4. For more technical materials such as submittals, catalogs, engineering, owner’s, best practices, and service manuals, visit www.lghvac.com. For continual product development, LG Electronics U.S.A., Inc. reserves the right to change specifications without notice. © LG Electronics U.S.A., Inc.

  • Page 3: Table Of Contents

    Error Code Tables ........................................78-80 Checklist for Chiller Installation ..................................... 81-82 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 4: Safety Precautions

    Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 5 Install the drain hose to ensure adequate drainage. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 6 Failure to carefully read and follow all instructions in this manual can result in equipment malfunction and property damage. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 7 Non-secured covers can result in malfunction due to dust or water. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 8: Unit Nomenclature

    T = Direct Exchange Type (DX) Type (Shell and Tube) Generation Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 9: Introduction

    Human Machine Interface (HMI) controllers, built within the ACAH chiller itself, applies LG’s unique control logic to monitor all parameters controlling the operation. These parameters can be controlled to improve operational efficiency, and can continuously supply chilled water by adjusting to the environment.
  • Page 10 S y t i c i t Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 11 Schneider Electric USA, Inc. ® Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 12: Electrical Data

    Temperature: 54°F / 44°F). FLA: Full Load Amps (A). Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 13: Dimensions

    Dimensions 30-1/8 86-17/32 86-5/8 84-13/16 19-31/32 27-9/16 15-1/8 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 14: Refrigerant Piping

    • Add antifreeze if the chiller is to operate in ambient air temperatures below 41°F (the water in the pipes could freeze). Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 15: Installation To Test Run Flowchart

    INSTALLATION TO TEST RUN FLOWCHART Figure 7: Installation to Test Run Flowchart. Start Delivery and Instruction and installation of base Installation following IOM and all applicable codes Delivery and Installation Lorem ipsum Wiring and Piping Set Control Address Test Operation Check before Initial Start Check During and After Initial Start Stop...

  • Page 16: Placement Considerations

    PLACEMENT CONSIDERATIONS Selecting the Best Location for the Chiller DANGER • • injury or death. • pipes). These conditions could cause a fire, resulting in bodily injury or death. • injury or death. • • location is insufficient, the chiller could fall, causing physical injury or death. WARNING Install a fence or barricade around the chiller to prevent animals and / or unauthorized individuals from accessing it.
  • Page 17 PLACEMENT CONSIDERATIONS Oceanside Installation Precautions • Avoid installing the chiller where it would be directly exposed to ocean winds. • Install the chiller on the side of the building opposite from direct ocean winds (so the building can block the winds). •...
  • Page 18 PLACEMENT CONSIDERATIONS Clearance Requirements Follow the ventilation (suction and discharge air flow) and service requirements as shown below and on the next page when choosing a chiller installation area. Ventilation Clearance Requirements Air-cooled chillers must be installed in an open space or must have appropriate ventilation. If the chiller must be installed near one wall or under a ceiling, there must be enough space for ventilation.
  • Page 19 PLACEMENT CONSIDERATIONS Service Clearance Requirements Ensure there is enough space around the chiller for maintenance and service. See the figures below for minimum dimensions. Figure 10: Service Clearance Requirements for One Chiller. Location where the Service Space water pipes are Min.
  • Page 20 PLACEMENT CONSIDERATIONS Seasonal Wind and Winter Installation Precautions To ensure the chiller operates properly, certain measures are required in locations where strong cold winds, heavy snowfall, and freezing temperatures could occur. Consider chiller fan operation when installing in snow-prone areas. If the chiller fan is installed below a certain level, it could trigger a high pressure error within the circuit and cause operation malfunction.

  • Page 21: Transporting / Lifting

    WARNING • • • • • falling and causing physical injury. Precautions When Moving the Chiller With the Forklift Figure 14: Using the Forklift (For Illustrative Purposes Only; Appearanc- es Will Vary Depending on Model). • Keep the chiller as level as possible. •...

  • Page 22: Storing Chiller / Installing Anti-Vibration, Anchor Bolts

    VIBRATION AND ANCHOR BOLTS Storing the Chiller If the chiller must be stored at the construction site before installation / operation, do not allow dirt or moisture inside, and do not expose it to humidity. Place a protective cover on the chiller until ready for installation. Installation Considerations •...

  • Page 23: Water Pipe System / Piping

    Water pipe system installation is an important part of the chiller system. Any defect in the water pipe system can lead to chiller malfunction. When designing the water pipe system, consider future service and maintenance, and install the field-supplied water pipe system compo- nents as detailed below.
  • Page 24 Temperature Sensor (1: Inlet, 2: Outlet) Optional P1 or P2 Strainer (50 Mesh) * Pressure Gauge (1: Inlet, 2: Outlet) Cold Water Pump (Pump Sized to Meet Minimum to Flexible Joint Maximum Flow for LG Chiller) Service Port for Cleaning * Required...
  • Page 25 Temperature Sensor (1: Inlet, 2: Outlet) Optional P1 or P2 Strainer (50 Mesh) * Pressure Gauge (1: Inlet, 2: Outlet) Cold Water Pump (Pump Sized to Meet Minimum to Flexible Joint Maximum Flow for LG Chiller) Service Port for Cleaning * Required...

  • Page 26: Freezing Precautions

    • Maintain water flow following design specifications to reduce damage from rusting, scaling, and corrosion. • LG is not responsible for any chiller damage resulting from poor water quality management or improper water processes. Inlet Water Pipe To Be Installed Level Figure 20: Inlet Water Pipe with Drain Hole.

  • Page 27: Water Pipe Installation / Pump Control

    ACAH Heat Exchanger Pressure Drop Graph Table 5: System Maximum Pressure and Water Pressure 36.3 One (1) Unit 29.0 Operating Maximum Water Pressure Model No. Pressure (psi) Drop (psi) 21.8 Refrigerant: 597; ACAH020HETB 5.63 Water: 142 14.5 7.25 52.8 105.6 158.5 211.3 264.1 369.8 422.6...
  • Page 28 The terminal block that receives the external main power. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 29: Button Locations And Functions

    Sets the Selected Function. SW_BACK Returns to the Previous Step. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 30: Optional Settings

    Version information is subjected to change for product performance or quality improvement. (Specified in 0 level) Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 31: Chiller Address Settings

    If the main controller address does not match the HMI address, an error will occur. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 32: Hmi Screens

    Return to the previous menu. Access the Home Screen. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 33 (When the chiller is in operation, the pump output maintains an “ON” state, otherwise, an alarm will occur.) Capacity Displays the capacity of the device. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 34 The setting unit for the Maximum Operating Frequency is 10 Hz. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 35 Press Cancel to maintain the previous setting. Figure 36: Setting Temperature Screen Numeric Keyboard. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 36 / down arrows in the pop up window. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 37 Displays the current high pressure value. Displays the current low pressure value. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 38 Displays cycle HEX temperature value. Displays cycle liquid line temperature value. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 39 Checks the start time of the schedule and the set operation mode. Check the set schedule in a list. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 40 Figure 51: Time Screen. Figure 52: Days of Week Screen. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 41 Figure 56: ON / OFF Screen. Figure 57: ON / OFF Screen. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 42 It maintains the current setting, and the pop up window disappears. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 43 After the Delete button is activated, and when the Delete button is pressed, the selected list will be removed. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 44 Figure 66: Error Screen Where the Errors Have Been Deleted. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 45 Thermo On Offset Correction Service function; restricted. (Value) Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 46 If two (2) or more units are selected, an input address is necessary for each unit. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 47 Figure 77: Password Input Fail Screen. Figure 76: Change Password Screen. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 48 • Range of outdoor (air) temperature settings: 36°F to 108°F (20 to 60°C). Figure 79: Condensing and Outdoor Temperature Screens. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 49 Figure 82: Canceling Screen Saver. Figure 83: Set Screen Saver. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 50 Choose the screen brightness from 25%, 50%, 75%, and 100%. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 51 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 52 If the Cancel is button pressed, the previous setting is maintained. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 53 The Clear function is for trained service technicians only; end user use is restricted. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 54 CD-ROM. A minimum fee will be charged to cover the cost of materials and shipping. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 55 Figure 99: Cycle Information Screen. Figure 100: Error Screen. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 56: Electrical

    Temperature: 54°F / 44°F). FLA: Full Load Amps (A). Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 57 • Install the power wiring only after the ring terminal is connected. Improper connections can damage electrical components. • components. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 58 Do not include splices or wire nuts in the communication cable. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 59 All control power used as a part of potential operation and approved internal bus wiring is provided inside the unit. 4. Additional Wiring / Cable Connections. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 60 Main Power Supply Circuit Breaker Main Power Supply Main Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 61 PCBs and HMI PCB connected. If it is not performed, it will result in operation error. • • Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 62 HMI to avoid communication problems from electrical interference. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 63 Setting about the Controller Address Settings in the Chiller Installation and Operation Manual.) Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 64: Modbus Protocol

    See the Modbus protocols in the following pages. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 65: Modbus Protocol Registers

    1 : 4 Way Valve 2 On of Cycle 2 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 66 1 : Inverter Compressor 2 On of Cycle 3 10329~10416 Reserve Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 67 Intake Temperature of Inverter Compressor 2 of Cycle 1 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 68 Accumulated Operation Time of Inverter Compressor 2 of Cycle 2 (Lower Level) 30249~30300 Reserve Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 69 Max. Operating Frequency Setting: (0 : 120, 1 : 130, 2 : 110, 3 : 100, 4 : 90, 5 : 80, 6 : 70) 40009~40022 Reserve Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 70: Test Run

    After start and stop, check the functions by operating the chiller, and adjusting if necessary. Adjust the water outlet temperature setting to adjust the load. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 71 • If the chiller RPM is changed, the cooling capacity may be reduced. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 72 If comprised of three (3) cycles, chiller will maintain overall operation, even when two (2) cycles are in error. The chiller will stop only when all three (3) cycles are in error. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 73 3. After cleaning is complete, operate the chiller to see if it functions properly. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 74 Minimize the air contacting the anti-freeze, and periodically measure the concentration of anti-freeze. Maintain the anti-freeze concentration by adding as necessary. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 75 • Perform an air purge procedure to remove all air inside the water pipe. • Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 76: Troubleshooting General Errors

    Check for abnormal noise in motor (noise in multiple RPM) Motor bearing is burned. and replace motor. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 77 This is a normal condition, but verify if the pressure falls within high. load increase. the operating range. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 78: Error Code Tables

    Automatically return to normal CHxx032 compressor discharge cycle condition temperature. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 79 CHxx077 Fan over-voltage error Fan over-voltage cycle condition Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 80 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.

  • Page 81: Checklist For Chiller Installation, Page 1 Of 2

    Model Name: Model Name: Compressor B Serial: Serial: Serial: Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 82 Is the strainer installed on the piping to the evaporator? Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
  • Page 83 To access additional technical documentation, visit www.lghvac.com. LG Electronics, U.S.A., Inc. Air Conditioning Technologies 4300 North Point Parkway Alpharetta, Georgia 30022 New Issue: IOM_Chiller_CoolingOnly_460V_06_21 www.lghvac.com...
