Cisco Catalyst 2960-S and 2960 Series Switches with
LAN Base Software
The Cisco
ease of use, highly secure business operations, improved sustainability, and a borderless network
experience. The Cisco Catalyst 2960-S Series Switches include new Cisco FlexStack switch stacking
capability with 1 and 10 Gigabit connectivity, and Power over Ethernet Plus (PoE+) with the Cisco Catalyst
2960 Switches offering fast Ethernet access connectivity and PoE capabilities. The Cisco Catalyst 2960-S
and 2960 Series are fixed-configuration access switches designed for enterprise, midmarket, and branch
office networks to provide lower total cost of ownership. The Cisco Catalyst 2960-S is shown in Figure 1,
and the Cisco Catalyst 2960 Series Switches are shown in Figure 2.
What's new for the Cisco Catalyst 2960-S Series Switches with LAN Base software:
10 and 1 Gigabit Ethernet uplink flexibility with Small Form-Factor Pluggable Plus (SFP+), providing business
●
continuity and fast transition to 10 Gigabit Ethernet
24 or 48 ports of Gigabit Ethernet desktop connectivity
●
Cisco FlexStack stacking module with 40 Gbps of throughput, allowing ease of operation with single
●
configuration and simplified switch upgrade
PoE+ with up to 30W per port that allows you to support the latest PoE+ capable devices
●
Power supply options, with 740W or 370W fixed power supplies for PoE+ switches are available
●
USB storage for file backup, distribution, and simplified operations
●
A wide range of software features to provide ease of operation, highly secure business operations,
●
sustainability, and a borderless network experience
Limited lifetime hardware warranty, including next-business-day replacement with 90-day service and support
●
The Cisco Catalyst 2960 Series Switches with LAN Base software offer the following:
Dual-purpose uplinks for Gigabit Ethernet uplink flexibility, allowing use of either a copper or fiber uplink; each
●
dual-purpose uplink port has one 10/100/1000 Ethernet port and one SFP-based Gigabit Ethernet port, with
one port active at a time
24 or 48 ports of Fast Ethernet desktop connectivity
●
PoE configurations with up to 15.4W per port
●
A wide range of software features to provide ease of operation, highly secure business operations,
●
sustainability, and a borderless networking experience
Limited lifetime hardware warranty
●
© 2010 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information.
®
®
Catalyst
2960-S and 2960 Series Switches are the leading Layer 2 edge, providing improved
Data Sheet
Page 1 of 28
