- Page 1 LG-20 Scorpion™ G USER MANUAL CHAUVET, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com...
-
Page 2: Table Of Contents
Master/Slave Mode ... 7 Manual Mode ... 7 COMPLIANCE STATEMENT ... 8 ASER AFETY AND OMPLIANCE NFORMATION APPENDIX... 9 ... 9 AINTENANCE ... 9 ETURNS ROCEDURE ... 9 LAIMS ...10 ATTERNS HART ...12 ECHNICAL PECIFICATIONS LG-20 User Manual ... 8 11/14/2007/18:10... -
Page 3: Before You Begin
Warning! Verify that the power select switch on your unit matches the line voltage applied. All fixtures must be connected to circuits with a suitable Earth Ground. LG-20 User Manual Warranty Card User Manual Figure 1 - AC Voltage Switch Not all fixtures have a voltage select switch. -
Page 4: Safety Instructions
Avoid direct eye exposure to lamp while it is on. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET. LG-20 User Manual usage and maintenance? 11/14/2007/18:10... -
Page 5: Introduction
Thank you for purchasing this laser product. You can be assured that you have made an investment into the highest quality laser products available today. This product has been designed by the development team at CHAUVET. You can be confident that our quality and after sales service is equal to our status of being the global leader in entertainment lighting and laser products. -
Page 6: General Instructions
In Automatic mode the patterns will change at a steady and pre-determined interval. Turn 2-Way Switch to the left for Stand-Alone mode. Sound Active Set 2-Way Switch to the left. Set Dipswitch 2 to the OFF position LG-20 User Manual Indicator DIPSWITCH SET FUNCTION POWER LINK IN... -
Page 7: Automatic
In manual mode Pattern Rotary Knobs 1 and 2 are available for image creation and manipulation. Set 2-Way Switch to the right to set unit to Manual mode. Use both Pattern Rotary Knobs 1 and 2 to create patterns. LG-20 User Manual 11/14/2007/18:10... -
Page 8: Compliance Statement
OMPLIANCE TATEMENT Your LG-20 has been designed to comply with FDA and IEC Standards for its classification. A special optic design regulates the output of the projector so that when properly used the output remains at levels government agencies have determined to be appropriate for the products function. -
Page 9: Appendix
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 10: Patterns Chart
Patterns Chart LG-20 User Manual 11/14/2007/18:10... - Page 11 LG-20 User Manual 11/14/2007/18:10...
-
Page 12: Technical Specifications
Weight ...4.0 lbs (1.81 kg) POWER Power adapter ...DC 12V 800mA LASER Diode ... 1 x 4.8 ~ 5 mW green laser Wavelength...532 nm Part No ... 4.9mW Green THERMAL Maximum ambient temperature... 40° (104° F) ORDERING INFORMATION Scorpion G...LG-20 LG-20 User Manual 11/14/2007/18:10...
