TOTAL NETWORK SOLUTIONS
CNet is proud to introduce CFC-20CM media converter providing the simplest way to interconnect any copper 10/100
TP port to fiber 100BASE-FX interface. CFC-20CM smoothly transfers data between RJ-45 and 100BASE-FX Multi-
Mode SC type Fiber ports. CNet media converters are hybrid-networking devices compliant to IEEE 802.3 and 802.3u
standards.
KEY FEATURES
=
TP Port supports Auto-negotiation and Auto-MDI-X
=
Operates at Maximum Packet Filtering and
Forwarding Rate
=
TP Port:10/100Mbps Full-/Half-duplex
=
Fiber Port:100Mbps Full-/Half-duplex
=
Interoperable with 10BASE-TX, and 100BASE-FX
Hubs or Switches
SPECIFICATIONS
Product Name
Model Name
Fiber Mode
Wave Length
Fiber Cable
Fiber Cable Distance
Fiber Connector
TP Ports
LED Indicators
Power Adapter
Environment
Certifications
Dimensions
ORDERING INFORMATION
Model
CFC-20CM (A)
Specifications are subject to change without notice
CFC-20CM–10/100M
10/100Mbps TP to 100Base-FX Media Converter, SC Type/ Multi-Mode/ 2KM
CFC-20CM
Multi-Mode
1310nm
62.5/125µm
2KM
SC Type
RJ-45 phone-type
FX: LINK/ACT
FX: FDX/COL
TP: LINK.ACT
TP: 100
External DC5V, 2A
Operating Temperature: -20° ~ 70° C (-4° ~ 158° F)
Storage Temperature: -40° ~ 80° C (-40° ~ 176° F)
Humidity: 10% ~ 90% Non-condensing
CE, FCC
94 x 70.3 x 26.2 mm (3.7 x 2.77 x 1.03 inches)
10/100Mbps TP to 100Base-FX Media Converter, SC Type/ Multi-Mode/ 2KM
TP
100B
-FX M
BPS
TO
ASE
www.cnetusa.com
Description
Trademarks & Trade Names belong to their owners
