TOTAL NETWORK SOLUTIONS
CNet is proud to introduce CFC-10CS media converter providing the simplest way to interconnect any copper 1000-TX
port to fiber 1000BASE-LX interface. CFC-10CS smoothly transfers data between RJ-45 and 1000BASE-LX Multi-
Mode SC type Fiber ports. CNet media converters are hybrid-networking devices compliant to IEEE 802.3 and 802.3u
standards.
KEY FEATURES
=
Operates at Maximum Packet Filtering and
Forwarding Rate
=
Auto-MDI/MDI-X on TP Port
=
Auto-negotiation on Fiber Port
=
Converts Twisted Pair Media Interfaces to Fiber or
Vice Versa
=
Complies with IEEE 802.3ab for 1000BASE-T and
IEEE 802.3z 1000BASE-LX Standards
SPECIFICATIONS
Product Name
Model Name
Fiber Mode
Wave Length
Fiber Cable
Fiber Cable Distance
TP Ports
Power Adapter
Environment
Certifications
Dimensions
ORDERING INFORMATION
Model
CFC-10CS (A)
Specifications are subject to change without notice
CFC-10CS–1000B
1000Base-TX to 1000Base-LX Gigabit Media Converter, SC Type/Single-Mode
CFC-10CS
Single-Mode
1310nm
9/125µm
10KM
RJ-45 phone-type
External DC5V, 2A
Operating Temperature: -20° ~ 70° C (-4° ~ 158° F)
Storage Temperature: -40° ~ 80° C (-40° ~ 176° F)
Humidity: 10% ~ 90% Non-condensing
CE, FCC
94 x 70.3 x 26.2 mm (3.7 x 2.77 x 1.03 inches)
1000Base-TX to 1000Base-LX Gigabit Media Converter, SC Type/Single-Mode
-TX
1000B
-LX G
ASE
TO
ASE
www.cnetusa.com
50/125µm
550m
Description
Trademarks & Trade Names belong to their owners
M
C
IGABIT
EDIA
ONVERTER
